Summary of Contents for MG MOTOR MG 3 ICE
- Page 1 MG 3 ICE Quick Guide...
- Page 2 Before starting the journey, it is recommended to read the Owner's Manual in the vehicle's infotainment system, MG iSMART App or on the MG Motor website to understand all the information required for the use of the vehicle. Always remember that if you have any queries concerning the operation or specification of your car, your MG Authorised Repairer will be glad to advise you.
- Page 3 If you require MG Assistance please provide the following information when you call: • Your name • A contact telephone number (if available) • Registration, make, model and colour • Address • Nature of breakdown • Exact location...
-
Page 4: Interior Layout
Interior Layout 1. Power Window Switch 2. Interior Lock Switch 3. Wiper Stalk Switch 4. Horn Button 5. Driver Airbag 6. Instrument Pack 7. Direction Indicator/Main Beam Stalk Switch 8. Intelligent Display 9. Passenger Airbag 10. Glove Box 11. Gear Lever * 12. - Page 5 Instrument Pack 1 Active Safety 2 Warning Lights and Indicators 3 Speedometer 4 Message Centre 5 Tachometer 6 Driving mode 7 Fuel Gauge and Driving Range 8 Engine Coolant Temperature 9 Gear Display...
-
Page 6: Engine Compartment
Engine Compartment Petrol model 1. Washer Fluid Reservoir 2. Engine Coolant Expansion Tank 3. Oil Dipstick 4. Brake Fluid Reservoir 5. Oil Filler Cap... -
Page 7: Locking And Unlocking
Locking and Unlocking 1. Lock Button 2. Tailgate Button 3. Unlock Button 4. Remote Key 5. Mechanical Key Keyless Locking * After stopping the engine, press the button on the front door handle once (no need to press the lock button on the smart key) to lock all doors before leaving the car, then the vehicle will enter anti-theft alarm state. - Page 8 Power System Start/Stop Starting Procedure 1. Switch off all unnecessary electrical equipment (including the air conditioning); 2. For vehicles with automatic transmission, make sure the shift lever is in P or N position and press the brake pedal; 3. For manual transmission vehicle, ensure neutral is selected when the clutch pedal is fully pressed;...
- Page 9 Accessing Owners Literature Select ‘User Manual’ in the Main Interface Page, scan the QR code to select your region and download the iSMART APP. Register and view the user manual. The full Owners Manual is also available in the Owners Section of www.mg.co.uk...
-
Page 10: Emergency Starting
Emergency Starting NEVER attempt to power the vehicle by pushing or towing. Make sure that both batteries are of the same rated voltage (12 volts), and that the booster cables are approved for use with 12 volt car batteries. Ensure sparks and naked flames are kept well away from the front compartment. Ensure that each booster cable connection is securely made. - Page 11 Emergency Starting NOTE: Where it is possible to open the tailgate of the disabled vehicle (B), please always give priority to the positive battery terminal as the positive connecting point. If the tailgate cannot be opened, please open the front compartment fuse-box. The terminal shown in figure(1) can be used as the positive connecting point.
-
Page 12: Towing For Recovery
Towing for Recovery Vehicle Recovery Towing for Recovery Towing Hook When pushing or towing the vehicle from a dangerous situation or onto the transporter, the speed must remain below 3mph and be completed within 3 minutes. When pushing or towing the vehicle for temporary situation, the locking tab of the driver seat belt should be inserted into the buckle and maintained in the inserted state, then turn the shift knob to N and release the EPB, otherwise the vehicle maybe damaged. - Page 13 Towing for Recovery Towing points are intended for use by qualified recovery specialists to assist in the recovery of your car when a breakdown or accident occurs. They are not designed for towing other vehicles. The vehicle can be towed using a tow rope but a towing bar is recommended. NEVER use a twisted tow rope, may cause the towing eye to unscrew.
- Page 14 Towing for Recovery Towing for Recovery When towing, DO NOT suddenly accelerate or brake suddenly, this can cause accidents. Suspended Towing Suspended towing is the best method for recovering a vehicle that needs to be towed. The drive wheels MUST be suspended above the ground. Ensure the EPB is released when the rear wheels are in contact with the road surface.
- Page 15 Emergency Tyre Inflation Tyre Repair * Tool Identification Type A* Type B* 1. Electric air pump 1. Towing hook 2. Repair Fluid 2. Repair fluid 3. Wheel bolt cap removal 3. Wheel bolt cap removal tool tool 4. Warning triangle 4.
- Page 16 Emergency Tyre Inflation 3.Switch on the power switch of the electric compressor (i.e., press ‘-‘), to start pumping sealant into the tyre. The tyre sealant bottle will become empty after approximately 30 seconds. The tyre should reach the specified pressure within 5 or 10 minutes.
- Page 17 Emergency Tyre Inflation Please follow different guidelines based on the tyre pressure measured: • If the tyre pressure has dropped to less than 0.8 bar (11.6 psi), do not continue driving, seek assistance instead. • If the tyre pressure is between 0.8 bar (11.6 psi) and specified pressure, use the electric air pump to inflate the tyre until it reaches the specified pressure.
- Page 18 ： Note MG Motor strive to make the manual as comprehensive and detailed as possible. MG Motor reserves the right to modify the content information without further notice. Considering that the information may still change after printing and delivery, please contact MG Motor for latest information.
