SYMEO LPR-1D24 Manual

Local positioning radar
Hide thumbs Also See for LPR-1D24:
Table of Contents

Advertisement

Quick Links

Download this manual
SYMEO L
P
R
OCAL
OSITIONING
ADAR
®
Product: LPR
-1D24
Product Documentation
Table of Content

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPR-1D24 and is the answer not in the manual?

Questions and answers

Related Manuals for SYMEO LPR-1D24

Summary of Contents for SYMEO LPR-1D24

  • Page 1 SYMEO L OCAL OSITIONING ADAR ® Product: LPR -1D24 Product Documentation Table of Content...
  • Page 2 Mounting of Fall Protection ..................16 Fresnel Zone ......................17 REQUIREMENTS FOR POWER SUPPLY ..............18 SPECIFICATION OF CONNECTORS ............... 19 Overview of Connections ..................19 LED-Display ....................... 20 Power Supply ......................21 Content Copyright © SYMEO GmbH 2022 Page 2 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 3 7.5.12 Device - Settings - Relay Zones ................. 56 7.5.13 Device - Settings - Remote Access ................56 7.5.14 Device - Settings - Timezone ..................57 7.5.15 Device - Settings - VPN Remote Access ..............57 Content Copyright © SYMEO GmbH 2022 Page 3 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 4 9.2.4 Type 0x16 - Distance Data ..................90 9.2.5 Type 0x25 - Load Data ....................91 Remarks ........................92 ® 9.3.1 LPR -1D24 Address ....................92 9.3.2 Distance Error Codes ....................92 Content Copyright © SYMEO GmbH 2022 Page 4 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 5: Table Of Contents

    Figure 47: Device - Settings - Network Routes ..............52 Figure 48: Device - Settings - Network Routes - Add route ........... 52 Figure 49: Device - Settings - Network Routes - Review changes ......... 52 Content Copyright © SYMEO GmbH 2022 Page 5 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 6 Figure 92: L-Functionality ....................... 84 Figure 93: Forwarding Settings ....................84 Figure 94: Forwarding Settings – Submit/Review changes ............ 85 Figure 95: Structure of the data packet .................. 86 Content Copyright © SYMEO GmbH 2022 Page 6 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 7 Table 10: Data Type 0x16 - Distance Data Output for Group Master ........90 Table 11: Data Type 0x25 - Load Data .................. 91 ® Table 12: LPR -1D24 address ....................92 Table 13: Error codes ......................92 Content Copyright © SYMEO GmbH 2022 Page 7 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 8 Updated Release Version Profinet application note to: DOC.EDO.000258.0002.EN; Profinet updated; 1.06 28.03.2018 WebUI updated to version 7.0.0; New function “Filter” in Settings added; New function “Payload Slave to Master” added under Settings - > Measurement; Content Copyright © SYMEO GmbH 2022 Page 8 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 9 Delivery options and technical changes reserved. Application specific documentation can be obtained from the Partner Login under www.symeo.com or from Symeo support. Content Copyright © SYMEO GmbH 2022 Page 9 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 10: Safety Instructions

    Place the cables in such a way so that they do not build the possible cause of risk and are not damaged. Do not drop the device and do not expose it to strong vibrations. Content Copyright © SYMEO GmbH 2022 Page 10 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 11: Power Supply

    Be careful that the device can be damaged with reverse polarity despite of strict implementation of polarity reversal protection. In that case, the unit must be sent to the SYMEO service for further testing. Setup and Operation During mounting, make sure that no objects or liquids reach inside the device (risk of short-circuit).

  • Page 12: Additional Instructions

    (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Content Copyright © SYMEO GmbH 2022 Page 12 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 13: Device Overview

    Interference with any WiFi equipment operating in parallel can be excluded at all times. ® -1D24 sensors are maintenance-free. A unique ID per each unit allows operating multiple pairs in immediate vicinity. Device Overview Copyright © SYMEO GmbH 2022 Page 13 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 14: Technical Data

    Figure 2: Beam width of LPR -1D24 To achieve maximum performance and range, the two radars must be of the same orientation, preferably with plug connections facing downwards. Device Overview Copyright © SYMEO GmbH 2022 Page 14 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 15: Mounting And Alignment

    -1D24 to a suitable pipe with the bracket. To adjust the radar, do not tighten the mounting bracket finally. Specified alignments have to be adhered to if indicated by Symeo.  A minimum distance of 3 meters between the measuring radars must be maintained to guarantee the specified accuracy.

  • Page 16: Figure 4: Mounting Of Fall Protection

    (see Figure 4). The fall protection should be installed before the assembly of the unit to secure it against falling. Figure 4: Mounting of fall protection Mounting and Alignment Copyright © SYMEO GmbH 2022 Page 16 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 17: Figure 5: Calculation And Figure Of Fresnel Zone

    50 m 0.40 m 100 m 0.56 m 250 m 0.89 m 500 m 1.25 m 1000 m 1.80 m Figure 5: Calculation and figure of Fresnel zone Mounting and Alignment Copyright © SYMEO GmbH 2022 Page 17 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 18: Requirements For Power Supply

    • Short-term maximum current flow (when switched on): At 24 V DC: 2000 mA for 50 ms At 12 V DC: 2500 mA for 50 ms Requirements for Power Supply Copyright © SYMEO GmbH 2022 Page 18 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 19: Overview Of Connections

    B3: Can-Bus OUT/ Profibus OUT/ Termination (optional) B4: Pressure equalization membrane B5: Serial interface RS422/RS485 / Relays (optional) B6: Power supply B7: Mini-USB B8: USB – A (Logging) B9 - B11: Status LEDs Specification of Connectors Copyright © SYMEO GmbH 2022 Page 19 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 20: Table 1: Led Display

    -1D24 – Product Documentation ® On the following pages, you will find the connector type, the pin assignment, the product code and the Symeo order number. For more information, please see the corresponding Phoenix datasheets. Mounting instructions in the datasheets must be followed.

  • Page 21: Figure 8: M12 Connector For Power Requirement

    Power Supply 10 V DC – 36 V DC M12 Connector Pin 1 Pin 2 (bridged to Pin 1) Pin 3 Pin 4 (bridged to Pin 3) Table 2: Pin assignment power supply Specification of Connectors Copyright © SYMEO GmbH 2022 Page 21 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 22: Figure 9: Scheme Of Normally Open Relay Contacts

    Recommended connector: o SACC-M12FS-8CON-PG9-M - 1513347 Cable diameter: 6 – 8 mm (PG9) Tightening torque: 0.4 Nm Symeo order number: MTE101847 Figure 10: M12 Connector for relay Specification of Connectors Copyright © SYMEO GmbH 2022 Page 22 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 23: Table 3: Pin Assignment Relay

    Maximum switching voltage: 25 V AC 30 V DC Maximum switching current: 8 A @ 25 V AC 5 A @ 30 V DC Table 4: Contact specification Specification of Connectors Copyright © SYMEO GmbH 2022 Page 23 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 24: Profibus (Optional)

    Cable diameter: 4 - 8 mm Tightening torque: 0.4 Nm Symeo order number: MTE101763 • Connector: Profibus Termination o SAC-5P-M12MS PB TR - 1507803 Tightening torque: 0.4 Nm Symeo order number: MTE101764 Specification of Connectors Copyright © SYMEO GmbH 2022 Page 24 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 25: Figure 11: M12 Connector Profibus In

    SYMEO Local Positioning Radar -1D24 – Product Documentation ® Figure 11: M12 Connector Profibus IN Figure 12: M12 Connector Profibus OUT Figure 13: M12 Connector Profibus Termination Specification of Connectors Copyright © SYMEO GmbH 2022 Page 25 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 26: Table 5: Pin Assignment For Profibus Connectors In And Out

    Plugs Recommended connector: • Connector Ethernet M12 o SACC-M12MSD-4CON-PG 7-SH - 1521258 Cable diameter: 4 – 6 mm (PG7) Tightening torque: 0.4 Nm Symeo order number: MTE101768 Specification of Connectors Copyright © SYMEO GmbH 2022 Page 26 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 27: Figure 14: Ethernet M12

    The connector cable M12 – RJ45 required for connecting via the Ethernet the LPR ® -1D24 (with M12 connector) to a PC (with RJ 45 connector) for initial commissioning and configuration is available from Symeo: Symeo order number: MTE102007 USB – A Devices ®...

  • Page 28: Figure 15: Lpr -1D24 Housing Dimensions

    -1D24 – Product Documentation ® ® -1D24 Housing Dimensions ® Figure 15: LPR -1D24 Housing Dimensions The minimum pipe diameter is 40 mm, the maximum pipe diameter is 75 mm. LPR®-1D24 Housing Dimensions Copyright © SYMEO GmbH 2022 Page 28 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 29 ® required for configuration of the LPR -1D24 with M12 and RJ45 connectors. This connector cable can be ordered by Symeo (see chapter 5.6.3). Please read the Notes on the Firmware Update in “Partner Login” area (Symeo_Docs -> Firmware -> „Readme_Firmware_Update_LPR-1D24“) under https://www.symeo.com/en/partner-login/index.html.

  • Page 30: Figure 16: Network Settings

    Enter in the cmd.exe window: ping 192.168.1.99 or the IP-address of LPR -1D24. ® Figure 17: Ping of LPR -1D24 ® The LPR -1D24 should answer with a Reply. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 30 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 31: Figure 18: Open Web User Interface

    User Interface will appear. A language selection can be made using the flags in the top right corner of the homepage. Figure 18: Open Web User Interface Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 31 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 32: Figure 19: Webui Login

    Figure 19). Figure 19: WebUI Login  Enter the user name "symeo" and the password "54all2u" and press "Login". Now your status is displayed as „Logged in". 7.2.2 Initial Operation When the WebUI is opened for the first time or after a software reset, the note „Environment uninitialized”...

  • Page 33: Figure 20: Initial Setup Of Environment Of Lpr ® -1D24

     Select your country to determine the operating environment and confirm it with the „Save” button (see Figure 20). The setting has to be the same on all Symeo devices used in a specific country. Now activate the settings by clicking the „Activate changes" button ...

  • Page 34: Mandatory Settings

    Further information about these mandatory settings please refer to the chapter 7.5.6.  If you have entered all these settings, click the „Submit changes” button. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 34 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 35: Figure 24: Change Of Mandatory Values

    You can review your changes by clicking the „Review…” button in the top left corner of  the homepage (see Figure 25) or the „Review changes” button at the bottom of the screen (see Figure 24). Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 35 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 36: Figure 25: Save Or Discard All Changes

    Some settings additionally require a reboot of the radar. Figure 26: Changes have been saved You can always come back to the start page if you press on the Symeo symbol the top left hand corner of this page.

  • Page 37: Figure 27: The Home Page Of Lpr ® -1D24

    Figure 27: The Home Page of LPR -1D24 On top of every page, the device status is shown (see Figure 28): Figure 28: WebUI - Device Status Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 37 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 38: Figure 29: Webui Information Overview

     enter the time in the current timezone configured for the unit or as UTC time Figure 30: Set system time Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 38 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 39: Figure 31: Webui - Product Properties

    Not all product features can be combined with each other. For example, the simultaneous use of the Profibus module and the relays is not possible. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 39 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 40: Figure 33: Device Menu

    Measurement  Modem  Network Routes  Profibus  Profinet  Relay Mapping  Relay Zones  Remote Access  Timezone  VPN Remote Access Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 40 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 41: Figure 34: Device - Settings Menu

    „LAN" (all other settings only when required). Some settings are only displayed on the screen if the necessary hardware is available (e.g. Profibus, Profinet or Relay). Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 41 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 42: Figure 35: Device - Settings - Customer Protocol

     Output forwarded relay commands ® Outputs relay switch messages, forwarded by another LPR -1D24. Figure 35: Device - Settings - Customer protocol Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 42 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 43: Figure 36: Device - Settings - Filter

    The customer can enter USER- and RELAY- data records. These are forwarded with ® the injection rate, but not faster than the LPR -1D24 measurement rate (about 30  Enable custom forward interval – Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 43 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 44: Figure 37: Device - Settings - Forwarding

    „Submit changes" button to enter the Destination IP address or the Output interval. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 44 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 45: Figure 38: Device - Settings - Forwarding - Parameter Setting

    DNS (IP of name server - domain name system  Syslog (IP of server for syslog messages)  NTP Server (IP or hostname of time server - network time protocol) Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 45 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 46: Figure 39: Device - Settings - Lan Settings

    Log to volatile memory only Figure 40: Device - Settings - Logging The logging function is only to be activated temporarily in case of trouble shooting. The Symeo Support Team must be informed under support@symeo.com prior to the activation. Web User Interface for LPR®-1D24 Copyright ©...
  • Page 47 Concerns only the payload from slave to master; for master to slave transmissions 200 bytes payload is always possible. These settings must be the same on Master and Slave. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 47 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 48: Figure 41: Device - Settings - Measurement

    FSK communication channel and Measurement channel must be configured. The values for the FSK communication channel must be in the range given for the specific country, here between 16…35 (see Figure 41). Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 48 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 49: Figure 42: Example Configuration Of One Measurement Pair Master And Slave Unit

    -1D24 – Product Documentation ® ® Example Configuration of One Pair of LPR -1D24: Figure 42: Example configuration of one measurement pair Master and Slave unit Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 49 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 50: Figure 43: Device - Settings - Measurement - Submit/Review Changes

     Click „Submit changes” button to save your changes or the “Review changes” button to check your changes. The „Review changes” window will be shown. Here you can check all parameters that you have changed. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 50 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 51: Figure 44: Device - Settings - Measurement - Save All Changes

    In this menu (see Figure 46), the following settings are available:  PPP Point to Point protocol connection  APN address  APN username  APN password Figure 46: Device - Settings - Modem Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 51 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 52: Figure 47: Device - Settings - Network Routes

    Here you can check the made changes and add the new route (see Figure 49). Figure 49: Device - Settings - Network Routes - Review changes Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 52 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 53 In this menu, you can view the settings of the Profinet interface.  Click the „Refresh" button to reload the view or press „Clear Profinet settings" to delete the current settings (see Figure 52). Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 53 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 54 You can also download the GSDML file directly from the device under „Device -> Downloads” (see Figure 53). Figure 53 Device - Settings - Downloads, Profinet GSDML file Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 54 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 55 -1D24 -> Relay is switched by a relay switching command via the air interface (see chapter 9.2.3). Figure 54: Device - Settings - Relay mapping Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 55 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 56 7.5.13 Device - Settings - Remote Access This function allows to configure a VPN-access if required: Figure 56: Device - Settings - Remote Access Settings Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 56 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 57 The certificate must be an All-In-One certificate. All keys and certificates must be contained in the same file. Figure 58 Device - Settings - VPN Remote Access Settings Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 57 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 58: Device - Firmware Update

    In this menu (see Figure 61), the following settings are available:  Update the firmware Use the „Browse“ button to find the firmware file provided by Symeo and press „Upload firmware“. Please use the latest firmware version .tar.gz file. You can download it online on the partner/customer website of Symeo GmbH under: https://www.symeo.com/en/partner-login/index.html...
  • Page 59 (Firmware -> „Readme_Firmware_Update_LPR-1D24“) under https://www.symeo.com/en/partner-login/index.html. Device - Factory Reset In this menu (see Figure 63), you can restore factory settings: Figure 63: Device - Factory Reset Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 59 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 60 Hardware Status  Storage device  Relay status  Range measurement statistics  Record measurement data  Packet monitor  Packet inspector  Station scan Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 60 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 61 SYMEO Local Positioning Radar -1D24 – Product Documentation ® Figure 65: Diagnostics Menu Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 61 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 62 Diagnostics - Operating System Status In this menu (see Figure 66), the operating system status can be displayed. In case of problems, this information may be requested by Symeo support. Figure 66: Diagnostics - Operating System Status Web User Interface for LPR®-1D24 Copyright ©...
  • Page 63 Diagnostics - Hardware Status In this menu (see Figure 67), system values and system voltages are displayed. In case of problems, this information may be requested by Symeo support. Figure 67: Diagnostics - Hardware Status This display is automatically refreshed every 5 seconds.
  • Page 64 Control relays” button, you can bridge the normal relay control and test the By pressing the „ opening and closing of the relays one by one or altogether (see Figure 70 and Figure 71). Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 64 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 65 Diagnostics - Control relays - override Figure 71 Diagnostics - Control relays - Relay states This should never be done in live-operation, but at best during commissioning or maintenance operation. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 65 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 66  Live range measurement  Signal strength statistics  Measurement rate statistics  Number valid measurements statistics Figure 72: Diagnostics - Range Measurement Statistics Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 66 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 67 Figure 73: Diagnostics - Distance over time graph By pointing the mouse in the graph and using the scroll wheel, you can downsize or enlarge the timeline. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 67 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 68 This helps identifying distances with increased signal distortions (e.g. due to multipath signal propagation), as the variance of the signal strength there usually increases. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 68 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 69 This helps identifying distances with increased errors in range measurement (e.g., due to multipath signal propagation), as the measurement rate decreases as errors are encountered. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 69 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 70 Log to USB stick if available, use SD card as fallback  Log to volatile memory only  Click the drop-down menu window „Change logging mode” (see Figure 77) to choose the logging mode. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 70 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 71 Log to USB stick if available (recommended): Log to SD card if available: Figure 78: Diagnostics - Record measurement data - Change logging mode - Example Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 71 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 72 Under “Measurements” you can view record measurement data (see Figure 79):  Measurements from all logging devices  Measurements from volatile memory  Measurements from SD card Figure 79: Diagnostics - Record measurement data Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 72 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 73 Figure 80: Diagnostics - Packet monitor If problems occur, this information can be requested by Symeo support. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 73 of 92...
  • Page 74 By expanding of „Hexadecimal view” and/or „Detailed view”, you can view this data in the appropriate format. Under the „Outgoing packets/Incoming packets” button, the outgoing and incoming data packets will be shown. Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 74 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 75 SYMEO Local Positioning Radar -1D24 – Product Documentation ® Figure 81 Diagnostics - Packet inspector Web User Interface for LPR®-1D24 Copyright © SYMEO GmbH 2022 Page 75 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 76 -1D24 – Product Documentation ® 7.11.9 Diagnostics - Station Scan In this menu (see Figure 82), the following Symeo units found in your current local area network (LAN) would be displayed. Figure 82 Diagnostics - Station scan Web User Interface for LPR®-1D24 Copyright ©...
  • Page 77 Figure 83: Distance measurement between two LPR ® -1D24 The necessary settings for this must be made under „Device -> Settings -> Measurement”: Figure 84: Menu Device - Settings - Measurement Application Copyright © SYMEO GmbH 2022 Page 77 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 78 SYMEO Local Positioning Radar -1D24 – Product Documentation ® ® Example Configuration of One Pair of LPR -1D24: Figure 85: Example Configuration of one measuring pair - Master and Slave unit Application Copyright © SYMEO GmbH 2022 Page 78 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 79 The customer specific offset may only be used for exchanging of the ® -1D24 Master units with a production date before December 2016. For further information, please refer to the Application Note “DOC.EDO.000241.0001.EN_Replacement_procedure_for_LPR- 1D24_Master-Units_delivered_before_12.2016.pdf”. Application Copyright © SYMEO GmbH 2022 Page 79 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 80 „Device -> Settings -> Relay zones" are necessary. Figure 87: Setting of Zone (usually identical on Master and Slave by crane toward crane measurement) Application Copyright © SYMEO GmbH 2022 Page 80 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 81 Relay Switching Command (described in section 9.2.3). In this case, the customer has to determine which relay switching data has to be sent and when it has to be sent. Application Copyright © SYMEO GmbH 2022 Page 81 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 82 Only when the set timeout is exceeded without receiving a Relay Switching Command, the relays open. The time limit can be set under „Device -> Settings -> Relay mapping“ (see Figure 54). Application Copyright © SYMEO GmbH 2022 Page 82 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 83 In addition to the settings described in Application 1, you only have to activate the forwarding „Radio channel forwarder -> Enable” by selecting „Enabled" option. of these user data via See „Device -> Settings -> Forwarding“, Figure 91. Figure 91: Forwarding Settings Application Copyright © SYMEO GmbH 2022 Page 83 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 84 In addition to the settings described in Application 1, you have to activate the forwarding of the distance data via „Radio channel forwarder -> Enabled". See „Device -> Settings -> Forwarding“, Figure 93. Figure 93: Forwarding Settings Application Copyright © SYMEO GmbH 2022 Page 84 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...
  • Page 85 If the data should be available on all units, you must also set the forwarding settings on Master 2 with the destination IP address of Master 1. Please make sure that the both devices connected via Ethernet must have different IP addresses. Application Copyright © SYMEO GmbH 2022 Page 85 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 86: General Description

    (TYPE and DATA), but not for the START and END field. The customer protocol accepts also CRC = 0 for incoming packets. Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 86 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 87: Data Types

    (i.e. to 47 bytes for the default settings). It is not important, what data is used to fill up the data packets, however, the use of zero bytes could facilitate a possible troubleshooting. Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 87 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 88: Table 7: Data Type 0X01 - User Data

    A Send Request is only sent if the „TX requests” field is activated in the WebUI under „Device -> Settings -> Customer protocol”. Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 88 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 89: Table 9: Data Type 0X03 - Relays Switching Command

    No acknowledgment of the relay switch command will be sent because this data frame can ® be forwarded to other LPR -1D24 and thus no reception on the destination unit is guaranteed. Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 89 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 90: Table 10: Data Type 0X16 - Distance Data Output For Group Master

    Reserved unsigned integer 0x#### unsigned integer 0x7F Table 10: Data Type 0x16 - Distance Data Output for Group Master Total length: 47 byte Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 90 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 91: Table 11: Data Type 0X25 - Load Data

    Bit 4 – 7: reserved The current value of the height sensor in cm, where 0 means the hoist/load is at the top position. Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 91 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

  • Page 92: Table 12: Lpr ® -1D24 Address

    Synchronization error 0x16 Synchronization error 0x19 Synchronization error 0x20 Synchronization error 0xfe Outlier detected (only diversity) 0xff No data received Table 13: Error codes Description of Binary Protocol XP (1D Messages) Copyright © SYMEO GmbH 2022 Page 92 of 92 DOC.EDO.000072.0014.EN_LPR-1D24_Product_Documentation.docx...

Table of Contents
