4 Burner Gas Grill
OWNER'S MANUAL
ASSEMBLY AND OPERATING IN STRUC TIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE
Model GAS5420AS
WARNING
NOTICE TO INSTALLER:
HAZARDOUS EXPLOSION MAY RESULT IF THESE
LEAVE THESE INSTRUCTIONS WITH
WARNINGS AND INSTRUCTIONS ARE IGNORED. READ
THE GRILL OWNER FOR FUTURE
AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH
REFERENCE .
OR PROPERTY DAMAGE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Even Embers GAS5420AS
Summary of Contents for Even Embers GAS5420AS
- Page 1 4 Burner Gas Grill OWNER’S MANUAL ASSEMBLY AND OPERATING IN STRUC TIONS SAVE THIS MANUAL FOR FUTURE REFERENCE Model GAS5420AS WARNING NOTICE TO INSTALLER: HAZARDOUS EXPLOSION MAY RESULT IF THESE LEAVE THESE INSTRUCTIONS WITH WARNINGS AND INSTRUCTIONS ARE IGNORED. READ...
-
Page 2: Important Safety
IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL. -
Page 3: Table Of Contents
TABLE OF CONTENTS: General Warnings ..........3-4 LP Gas Cylinder (Tank) Specifi cations and Installation . -
Page 4: General Warnings
GENERAL WARNINGS: WARNING • Leak test all connections before fi rst use, even if grill was purchased fully assembled and after each tank refi ll. Check the propane tank rubber seal for damage. • Always check the grill and propane tank prior to each use as indicated in the “Checking for Leaks” & “Pre-Start Check List”... -
Page 5: Lp Gas Cylinder (Tank) Specifications And Installation
• Grill is hot when in use. To avoid burns: • DO NOT attempt to move the grill. • Block the wheels so the unit does not accidentally move. • Wear protective gloves or oven mitts. • DO NOT touch any hot grill surfaces. •... - Page 6 LP GAS CYLINDER (TANK) SPECIFICATIONS: LP gas cylinder (not supplied with this grill) The LP (Liquid Propane) gas cylinder specifi cally designed to be used with this grill must be 12” (30.5 cm) diameter x 18” (45.7 cm) tall and have a 20 lb. (9.1 kg) capacity incorporating a Type 1 cylinder valve and an over-fi lling protection device (OPD).
-
Page 7: Hose & Regulator Specifications And Installation
DO NOT attempt to connect grill, as purchased for LP (propane) gas, to any other fuel supply source such as a natural gas line. For dual fuel grills that can be converted to natural gas, a Even Embers conversion kit must be purchased and installed for use with natural gas. •... -
Page 8: Leak Testing
HOSE AND REGULATOR: Your grill is equipped with a Type 1 connection device with the following features: 1. The system will not allow gas fl ow from the cylinder until a positive connection to the valve has been made. Note: The cylinder valve and all grill burner knobs must be turned OFF before any connection is made or removed. -
Page 9: Checking For Leaks
DANGER To prevent fi re or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS in a well ventilated area that is protected from the wind. • Never perform a leak test with a match or open fl ame. -
Page 10: Pre-Start Check List
PRE-START CHECK LIST: DANGER Property damage, bodily harm, severe burns, and death could result from failure to follow these safety steps. These steps should be performed after the grill has been assembled and prior to each use. DO NOT operate this grill until you have read and understand ALL of the warnings and instructions in this manual. -
Page 11: Match Lighting The Main Burner
5. To light other burners, follow steps 3-4. 6. If burner does not ignite using the igniter, see “Match Lighting the Main Burners” section. To turn off, turn each control knob clockwise until it locks in the “OFF” position. This does not turn off the gas fl ow from the cylinder. -
Page 12: Operating The Grill
OPERATING THE GRILL: WARNING • Read and follow all warnings and instructions contained in the preceding sections of this manual. • Flavoring chips must be contained in a metal smoking box to contain ash and prevent fi res. • DO NOT cover cooking grates or other components with aluminum foil, as this blocks ventilation and damage to grill or personal injury may occur. -
Page 13: Rotisserie Cooking
ROTISSERIE COOKING: • Your grill was pre-drilled from the factory to include mounting holes for a rotisserie (sold separately). • Read and follow all instructions provided with the rotisserie. Save instructions for future reference. WARNING • When using an AC current rotisserie, it must be electrically grounded in accordance with local codes, or in the absence of local codes: •... -
Page 14: Proper Care And Maintenance
PROPER CARE & MAINTENANCE: WARNING: If a bristle brush is used to clean any of the cooking surfaces, ensure no loose bristles remain on the cooking surfaces prior to grilling as loose bristles may attach to food. CLEANING INTERIOR OF GRILL: •... - Page 15 BURNER ASSEMBLY/MAINTENANCE: • Although your burners are constructed of stainless steel, they may corrode as a result of the extreme heat and acids from cooking foods. Regularly inspect the burners for cracks, abnormal holes, and other signs of corrosion damage. If found, replace the burner.
-
Page 16: Transporting And Storage
TRANSPORTING AND STORAGE: WARNING • Never move a grill when hot or in use. • Make sure that cylinder valve is closed and burner knobs are in the off position. • DO NOT store a spare LP gas cylinder (fi lled or empty) under or near the grill. •... -
Page 17: Trouble Shooting
TROUBLE SHOOTING: Problem Possible Cause Prevention/Cure Burner will not light LP gas tank valve is closed Make sure regulator is securely attached to the LP gas tank, turn LP gas tank valve to “OPEN” LP gas tank is low or empty Check if LP gas tank is empty. -
Page 18: Grill Cooking Tips
Problem Possible Cause Prevention/Cure Flame blows out High or gusting winds Do not use grill in high winds Low on LP gas Replace or refi ll LP gas tank Burner holes may be obstructed Refer to “Burner Assembly/Maintenance” instructions Flow limiting device tripped Refer to “Regulator Resetting Procedure”... -
Page 19: Assembly Instructions
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT. The following tools are required to assemble this Even Embers 4 Burner Gas Grill: • Phillips Screwdriver PARTS LIST:... - Page 20 NOTE: Some screws are pre-assembled to the grill. You may need to loosen some screws partially while others may need to be removed to assemble parts.
- Page 21 Attach front left leg rear left leg to left cart panel over keyholes using six M6 x 15 mm bolts. Attach front right leg and rear right leg right cart panel over keyholes using six M6 x 15 mm bolts. Attach back cart panel using four M6 x 15 mm bolts over keyholes.
- Page 22 Attach upper door frame to left and right cart panels using four M6 x 15 mm bolts. Attach cart base to left and right side cart panels using eight M6 x 15 mm bolts. Then attach cart base to back panel using two M6 x 15 mm bolts.
- Page 23 Lock casters attach to cart. Unlocked Locked Attach left door and right door by inserting lower hinge in hole in cart base and pressing upper hinge and aligning with hole in upper door frame.
- Page 24 Attach door handles and door handle bezels to left and right doors using four M6 x 15 mm bolts and M6 x 20 mm washers. Place grill body on cart and secure with four M6 x 15 mm bolts.
- Page 25 Install one M6 x 15 mm bolt halfway. Loosen bolts in control panel 3-4 mm. Then attach sear burner assembly over bolts. Do not tighten bolts at this time. Secure sear burner assembly using three M6 x 15 mm bolts and M6 x 16 mm washers.
- Page 26 Tighten two bolts from Step 9. Install two M4 x 12 mm bolts through front panel. Remove two screws from back of sear burner. Install sear burner valve between control panel and burner venturi. You may need to move sear burner around slightly to install sear burner valve.
- Page 27 Attach control knob bezel and sear burner valve to control panel using two M4 x 12 mm bolts. Press control knob onto valve stem. Slide sear burner grease tray into rear of sear burner assembly .
- Page 28 Install sear burner grate Attach side table front panel to side table using three M4 x 12 mm bolts. Attach three accessory hooks to side table...
- Page 29 Install one M6 x 15 mm bolt halfway. Loosen bolt in control panel 3-4 mm. Then attach side table over bolts. Do not tighten bolts at this time. Secure side table using three M6 x 15 mm bolts and M6 x 16 mm washers. Note: Make sure front panels are aligned before tightening bolts.
- Page 30 Tighten two bolts from Step 17. Install two M4 x 12 mm bolts through front panel. Attach igniter to side table front panel using retaining nut. Attach electrodes from burners to connectors on back of igniter Insert AA Battery into igniter and secure with cap.
- Page 31 Install heat tents , cooking grates and warming rack Attach temperature gauge using pre-attached wingnut and washer.
- Page 32 Remove two bolts from grease tray handle . Move handle to the outside and attach handle using two bolts. Attach grease cup rails to bottom of grease tray using four M4 x 12 mm bolts, M4 x 12 mm washers and M4 nuts. Insert grease tray into back of grill.
- Page 33 Even Embers GAS5420AS Assembled...
-
Page 34: Warranty
WARRANTY Fair Game Group warrants to the original pur chas er that the Even Embers 4 Burner Gas Grill is free from defects due to workmanship or materials for: Ten-year: on stainless steel tube burners Three-year: on all other stainless steel parts One-year: on valves, frame, housing, cart, igniter, cooking grates and other related parts Fair Game Group’s obligations under this warranty are limited to the following guidelines:...
