Crib N Changer
THIS PRODUCT IS NOT INTENDED FOR
INSTITUTIONAL OR COMMERCIAL USE.
When contacting Delta Consumer Care please reference the above information. Before contacting Delta
Consumer Care please ensure that the information above matches the information found on the label on
the Crib End bottom rail, please reference the information found on the product when contacting Delta
Consumer Care.
To register your product for important safety alerts and updates to your product please visit
www.DeltaChildren.com and click on Product Registration.
APRIL 28, 2014, 25081, R0
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Consumer Care:
www.DeltaChildren.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Style #:
Date:
Conforms to
ASTM F1169 Full Size
Crib & F1821 & F2388
Safety Standards
Tele.212-645-9033
___________
Lot:
___________
___________
©2014 DELTA ENTERPRISE CORP.
A
REV

Advertisement

loading
Need help?

Need help?

Do you have a question about the Crib N Changer and is the answer not in the manual?

Questions and answers

Related Manuals for Delta Children Crib N Changer

Summary of Contents for Delta Children Crib N Changer

  • Page 1 KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. Crib N Changer Consumer Care: www.DeltaChildren.com Delta Children’s Products 114 West 26th Street New York, NY 10001 Tele.212-645-9033...
  • Page 2 Securely tighten loose bolts and other fasteners. Do not use crib if any parts are missing, damaged or broken. Contact Delta Children's Products for replacement parts and instructional literature if needed. Do not substitute parts.
  • Page 3 Tighten all loose screws and bolts before each use. The maximum recommended weight of the child is 30lbs for the changing table. Use only the pad provided by Delta Children’s Products. Always secure the pad to the changing surface by inserting the strap through the hole in the middle of the pad.
  • Page 4 - Do not scratch or chip the finish. - Inspect the product periodically, contact Delta Children's Products for replacement parts or questions. - Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a damp, cold basement.
  • Page 5 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. C. Changer Top Rail x 2 Part # 25063 D. Changer Upper Shelf Rail x 2 Part # 25064 B. Changer End x 1 A. Common Side x 1 Part # 25062 Part # 25061 E.
  • Page 6 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. P. Changer Pad x 1 R. Changer Bottom Part # 25083 Shelf Panel x 1 Part # 25074 S. Changer Middle Panel x 1 Part # 25075 W. Crib Back Rail x 1 Part # 25057 U.
  • Page 7 PARTS: HARDWARE KIT PART #25082-988 FOR COLOR 207 . SEE FRONT COVER. Phillips Screwdriver (not supplied) CC. Mattress Support x 1 Flat Head Screwdriver Part # 24343 (not supplied) Pouch attached to mattress support - keep instructions in this pouch after assembly. Warnings related to the safe use of this crib are LL.
  • Page 8 Section 1: Changing Table Assembly Step 1 Parts and tools required to complete step. C. Changer Top Rail x 2 H. Changer Middle Top Rail x 1 E. Changer Lower J. Changer Middle Shelf Rail x 2 Bottom Rail x 1 A.
  • Page 10 Section 1: Changing Table Assembly Step 2 Parts and tools required to complete step. D. Changer Upper Shelf Rail x 2 F. Changer Front Lower Rail x 1 From Step 1 Lay Common Side (Part A) on It’s side and loosely insert (2) Changer Upper Shelf Rails (Part D) and (1) Changer Front Lower Rail (Part F) as shown.
  • Page 11 Section 1: Changing Table Assembly Step 3 Parts and tools required to complete step. L. Changer Middle Front Shelf Panel x 1 S. Changer Middle Panel x 1 M. Changer Middle Back Shelf Panel x 1 From Step 2 R. Changer Bottom N.
  • Page 12 Section 1: Changing Table Assembly Step 4 Parts and tools required to complete step. DD. M6 x 70 mm Bolt x 4 FF. M6 x 50 mm Bolt x 3 From Step 3 B. Changer End x 1 GG. M6 x 35 mm Bolt x 1 JJ.
  • Page 14 Section 2: Crib Assembly Step 1 Parts and tools required to complete step. U. Crib Front Rail x 1 M4 Allen Wrench Supplied V. Stabilizer Bar x 1 JJ. M6 x 17 mm Barrel Nut x 4 T. Left Crib Side x 1 From Section 1 Step 4 DD.
  • Page 15 Section 2: Crib Assembly Step 2 Parts and tools required to complete step. M4 Allen Wrench Supplied HH. M6 x 18 mm Bolt x 4 From Section 2 CC. Mattress Support x 1 Step 1 Attach the Mattress Support (Part CC) in all corners using (1) M6x18 mm Bolt (Part HH) in each corner. Tighten with the M4 Allen Wrench.
  • Page 16 Section 2: Crib Assembly Step 3 Parts and tools required to complete step. M4 Allen Wrench Supplied W. Crib Back Rail x 1 JJ. M6 x 17 mm Barrel Nut x 4 From Section 2 Step 2 DD. M6 x 70 mm Bolt x 4 Attach (1) Crib Back Rail (Part W) to the assembly from section 2 step 2 using (4) M6 x 70 mm Bolts (Part DD) and (4) M6 x 17mm Barrel Nuts (Part JJ).

  • Page 17: Section 3: Drawer Assembly

    Section 3: Drawer Assembly Step 1 Parts and tools required to complete step. LL. 25 mm Screw x 8 Y. Drawer Left Side x 2 Z. Drawer Right Side x 2 Phillips Screwdriver X. Drawer Front x 2 (not supplied) Attach (1) Drawer Left Side (Part Y) and (1) Drawer Right Side (Part Z) to (1) Drawer Front (Part X) with (4) 25mm Screws (Part LL).
  • Page 18 Section 3: Drawer Assembly Step 2 Parts and tools required to complete step. BB. Drawer Bottom Panel x 2 From Section 3 Step 1 (x 2) Slide (1) Drawer Bottom Panel (Part BB) in the grooves on the Drawer Left Side and Drawer Right Side, into the groove on the Drawer Front.
  • Page 19 Section 3: Drawer Assembly Step 3 Parts and tools required to complete step. MM. 40 mm Screw x 8 NN. Plastic Barrel Nut x 8 Phillips Screwdriver From Section 3 (not supplied) AA. Drawer Back x 2 Step 2 (x 2) Attach (1) Drawer Back (Part AA) to the assembly from section 3 step 2 with (4) 40 mm Screws (Part MM) and (4) Plastic Barrel Nut (Part NN).
  • Page 20 Section 3: Drawer Assembly Step 4 Parts and tools required to complete step. PP. Handle x 2 Phillips Screwdriver From Section 3 RR. Handle Bolt x 2 (not supplied) Step 3 (x 2) Attach (1) Handle (Part PP) to the assembly from section 3 step 3 with (1) Handle Bolt (Part RR). Tighten with the Phillips Screwdriver.
  • Page 21 Section 3: Drawer Assembly Step 5 Parts and tools required to complete step. From Section 3 Step 4 From Section 2 Step 3 Insert the Drawers as shown.
  • Page 22 Section 4: Step 1 Changing Pad attachment and use Parts and tools required to complete step. M4 Allen Wrench P. Changer Pad x 1 Supplied 1. Check that the bolt securing the strap is tight using M4 Allen Wrench. 2. Insert the Strap through the hole in the Changing Pad (Part P). 3.
  • Page 23 KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. Booklet Crib N Changer Consumer Care: www.DeltaChildren.com Delta Children’s Products 114 West 26th Street New York, NY 10001 Tele.212-645-9033...
  • Page 24 Section 5: Toddler Bed Conversion Step 1 Parts and tools required to complete step. M4 Allen Wrench Supplied Remove the Crib Front Rail and Stabilizer Bar installed in Step 1 of Section 2 crib assembly.
  • Page 25 Section 5: Toddler Bed Conversion Step 2 Parts and tools required to complete step. KK. Φ4x30 mm Metal Pin x 2 M4 Allen Wrench Supplied V. Stabilizer Bar x 1 JJ. M6 x 17 mm Barrel Nut x 2 From Section 5 Step 1 DD.
  • Page 26 Section 5: Toddler Bed Conversion Step 3 WARNING: SEE PAGE 3 FOR TODDLER BED WARNINGS The mattress support must be in the lowest position. Store all hardware safely. Read all warnings on page 3. As shown, use as a day bed or love seat sofa. Do Not use without stabilizer bar installed.
  • Page 27 Section 6: Full Size Bed Conversion Step 1 Parts and tools required to complete step. M4 Allen Wrench Supplied Disassemble the Changer unit by reversing all steps in section 1: Changer Assembly. Remove the post from the Common Side (Part A) by removing the bolts. Store all parts carefully for future use, see page 3 for information.
  • Page 28 Section 6: Full Size Bed Conversion Step 2 Parts and tools required to complete step. M4 Allen Wrench Supplied Disassemble the Crib End by removing the preassembled bolts with the M4 Allen Wrench. Attach the post removed from the changer in the previous step and the post from Left Crib S ide to the Crib Back Rail using (4) M6x70mm Bolts (Part DD) and (4) M6x17mm Barrel Nuts (Part JJ).
  • Page 29 Section 6: Full Size Bed Conversion Step 3 Parts and tools required to complete step. M4 Allen Wrench Supplied From Section 6 Step 2 HH. M6 x 18 mm Bolt x 4 Attach Bed Frame to the Headboard (From Section 6 Step 2) using (4) M6x18mm Bolts (Part HH). Follow all instructions supplied with the Bed Frame.

  • Page 30: Warranty

    Consumer Care: www.DeltaChildren.com Delta Children’s Products 114 West 26th Street New York, NY 10001 Tele.212-645-9033 Warranty: This Delta Crib is warranted to be free from defects for a period of 1 year from the date of purchase under normal use. This warranty extends only to the original retail purchaser and is valid only when supplied with proof of purchase, or if received as a gift, when the registration is on file with Delta.
