- Page 1 DEC WANcontroller 618 Cabling Instructions and Specifications Part Number: EK–A0545–CI.001 Digital Equipment Corporation. 1992. All Rights Reserved.
-
Page 2: Cabling Instructions
Cabling Instructions To install the DEC WANcontroller 618, perform the following steps: See this card Check kit contents Assemble the distribution panel See this card Install the Network Interface Card (NIC) See Note Install the distribution panel and connecting cable... -
Page 3: Kit Contents
Kit Contents Option DNSCA–xx DNSAA–AA DNSXH–xx Option DNSAA–AA DEC WANcontroller 618 Network Interface Card (NIC) 50-way loopback connector (male), DNSXT–CA Documentation set: DEC WANcontroller 618 Cabling Instructions and Specifications DEC WANcontroller 618 Problem Solving DEC WANcontroller 618 Configuration Card DEC WANcontroller 618 PTT Information LKG–5734–91I... - Page 4 Assembling the Distribution Panel 1. The distribution panel kit contains the following items: 1 distribution panel 2 side panels 1 cable rail 4 plastic insulating tabs 11 screws 2. Assemble the distribution panel: LKG–5855–91I...
- Page 5 Installing the Distribution Panel and Connecting Cable Always disable the NIC before you attach or remove the connecting cable 1. Disable the NIC: move the NIC switch down. 2. Mount the dis- Rack mount tribution panel support within reach of the connecting cable (cable length = 2 m).
- Page 6 Attaching the Communication Cables You do not need to disable the NIC when attaching these cables. Notes V.35 The distribution panel provides ground strap holes on either side of each port. V.24. EIA–232D Use an EIA–232C adapter connector (Part 12–27591–01) if you are using EIA–232C de- vices.
-
Page 7: Cabling Information
Cabling Information Extension Cables Electrical Interface Part number V.24/V.28, EIA–232D BC22F–xx V.36/V.11, EIA–422 BC55D–xx V.35 BC19L–xx For BT Kilostream extension (see below) BC22Z–xx where xx represents cable lengths as follows: 7.6 m (25 ft) 15.2 m (50 ft) 22.9 m (75 ft) 30.5 m (100 ft) -
Page 9: Specifications
Specifications Communication Specifications Line speeds 0.3–64.0 Kbits/s Number of lines Line interfaces V.36/V.11, EIA-422 V.24/V.28, EIA-232D V.35 BT Kilostream (see Cabling Information ) NRZI signalling Optional Modem control Full control on each line, except BT Kilostream Physical Specifications Weight 0.6 kg (1.325 lb) LKG–5736–91I...
