Summary of Contents for Digital Equipment Pro-Face GLC2000 Series

  • Page 1 GLC2400/2500/2600 Series User Manual Digital Electronics Corporation...
  • Page 2 Preface Thank you for purchasing the Pro-face Graphic Logic Controller GLC2400T/ GLC2500T/GLC2600T (hereby referred to as “GLC” or “GLC unit”). This controller features a number of improvements over the previous GLC series including enhanced functions and advanced operability. Flex Network communi- cation, Ethernet, CF Card, and Sound output are available for the GLC2000 Series without having to purchase and install an optional expansion unit.

  • Page 3: Table Of Contents

    Preface Table of Contents Preface ........................1 Table of Contents ....................... 2 Essential Safety Precautions ..................6 General Safety Precautions ..................12 About GLC2000 Series Models ................14 Package Contents ....................14 UL/c-UL Application Notes ..................15 CE Marking Notes ....................16 Revision Version ......................

  • Page 4: Preface

    Preface Interface Specifications ............... 2-6 2.3.1 Serial Interfaces ..............2-6 2.3.2 Printer Interface ..............2-8 2.3.3 External Reset Input I/F, Flex Network Communication I/F, and Sound Output I/F ............2-8 Part Names and Functions ..............2-9 Dimensions ..................2-12 2.5.1 GLC2400T External Dimensions ........
  • Page 5 Preface Chapter 5 OFFLINE Mode Entering OFFLINE Mode ..............5-1 5.1.1 After Plugging in the Power Cord ........5-2 5.1.2 From the Menu Bar .............. 5-2 OFFLINE Mode Main Menu ............. 5-3 INITIALIZATION ................5-4 SELF-DIAGNOSIS ................5-6 Chapter 6 Initializing the GLC Initialization Screen ................
  • Page 6 Preface SET UP TIME ..................6-37 SET UP SCREEN ................6-38 Chapter 7 RUN Mode and Errors RUN Mode ................... 7-1 7.1.1 After Connecting the Power Cord ........7-1 7.1.2 Via OFFLINE Mode ............. 7-2 SELF-DIAGNOSIS ................7-3 7.2.1 SELF-DIAGNOSIS ITEM LIST .......... 7-3 7.2.2 SELF-DIAGNOSIS - Details ..........

  • Page 7: Essential Safety Precautions

    Preface Essential Safety Precautions This manual includes procedures that must be followed to operate the GLC cor- rectly and safely. Be sure to read this manual and any related materials thoroughly to understand the correct operation and functions of the GLC unit. Safety Symbols Please pay attention to the following safety symbols and their meanings: Indicates situations that will definitely...
  • Page 8 Preface DANGERS (2) When the GLC generates a “Watchdog Timer Error,” GLC operation will halt. Also, when Errors occur in Input/ Output control areas that the GLC cannot detect, unex- pected movement may occur in those areas. Therefore, and to prevent unsafe machine movement, a “Failsafe Circuit”...
  • Page 9 Preface DANGERS • Design your system so that equipment will not malfunction due to a communication fault between the GLC and its host controller. This is to prevent any possibility of bodily injury or material damage. Do NOT use the GLC as a warning device for critical warn- •...
  • Page 10 Preface WARNINGS Installation Warnings: • High voltage runs through the GLC. To prevent an electrical shock, do NOT disassemble the GLC for any reason other than to replace the backlight. • Do NOT modify the GLC unit. Doing so may cause a fire or an electrical shock.
  • Page 11 Preface WARNINGS • The GLC uses a lithium battery to back up its internal clock and to control memory data. If the battery is incorrectly re- placed (reversed positive [+] and negative [-] ends), the bat- tery may explode. Therefore, Pro-face recommends that you contact your local GLC distributor for instructions before replacing or changing the battery.
  • Page 12 Preface CAUTIONS Be sure that metal filings or wiring remnants do not fall • inside the GLC, since they can cause a fire, accident, or malfunction. GLC Operation and Maintenance Cautions: • Be sure to read the GLC unit’s manual and online help in- formation carefully before performing program changes, entering forced output, or using the RUN, STOP, or PAUSE commands while the GLC is operating.

  • Page 13: General Safety Precautions

    Preface General Safety Precautions • Do NOT strike the touch panel with a hard or pointed object, or press on the touch panel with too much force, since it may damage the touch panel or the display. • Do NOT install the GLC where the ambient temperature can exceed the allowed range.
  • Page 14 Preface About the GLC Unit’s Display Panel • The data that is currently displayed on the GLC unit’s screen, the screen’s brightness, and the GLC unit’s voltage each affect the screen’s inten- sity of Contouring — wavelike pattern that is created when some parts of the screen are brighter than others.

  • Page 15: About Glc2000 Series Models

    Preface About GLC2000 Series Models The GLC2000 Series in this manual refers to the following GLC model numbers: GLC Type with Series Model Screen Model Number Comments Name Name Creation Software GLC2400T GLC2400-TC41-24V GLC2400 GLC2500-TC41-200V GLC2000 UL/c-UL Approved GLC2500T GLC2500 Series CE Marked GLC2500-TC41-24V...

  • Page 16: Ul/C-Ul Application Notes

    Preface UL/c-UL Application Notes The GLC2500-TC41-200V, GLC2600-TC41-200V are UL/c-UL recognized components. (UL File No.E171486 or E231702) The GLC2400-TC41-24V, GLC2600-TC41-24V are UL/c-UL listed products. (UL File No.E182139) Standards Model registered format GLC2400-TC41-24V 2980025 GLC2500-TC41-200V 3280036-02 GLC2500-TC41-24V 3280036-03 GLC2600-TC41-200V 3280036-01 GLC2600-TC41-24V 3280021-01 These products conform to the following standards: A) UL 508 Industrial Control Equipment B) UL 60950...

  • Page 17: Ce Marking Notes

    Preface UL1604/CSA-C22.2, No.213 Conditions of Acceptability and Handling Cautions: 1. Power, input and output (I/O) wiring must be in accordance with Class I, Division 2 wiring methods - Article 501- 4(b) of the National Electrical Code, NFPA 70 within the United States, and in accordance with Section 18-152 of the Canadian Electrical Code for units installed within Canada.

  • Page 18: Revision Version

    Preface Revision Version The revision code can be easily found using the GLC unit’s rear face identification label or revision sticker. In the area titled “REV”, the code is indicated by aster- isks (*) or marked with a marker pen. How to Read the Code In the example below, asterisks (*) are placed at positions “D”, “1”, and “2”, which indicates the revision version as “D-2”.

  • Page 19: Documentation Conventions

    Preface Documentation Conventions The list below describes the documentation conventions used in this manual. Symbol Meaning Indicates important information or procedures that must be followed for correct and risk-free software/device operation. Software used to create, transfer, and monitor a GLC logic program. Pro-Control Editor Indicates the GLC2400T, GLC2500T and GLC2600T units Indicates the combined software package of GP-PRO/PBIII for...

  • Page 20: Chapter 1 Introduction

    1. Prior to Operating the GLC 2. System Design 3. Accessories Chapter 4. GLC2000 Series Overview 1 Introduction Prior to Operating the GLC Use the following steps to create projects for the GLC unit. 1. Preparation – Before using the GLC, make sure that you have all the required hardware and have read all specification, wiring, and installation information.

  • Page 21: System Design

    Chapter 1 – Introduction System Design The following diagram represents the main selection of devices connectable to the GLC. GLC RUN Mode Peripherals RUN Mode Edit Mode To an Ethernet Network Flex Network GLC Unit Communication Cable Flex Network FN-CABLE2010-31-MS I/O Unit, FN-CABLE2050-31-MS FN-CABLE2200-31-MS...
  • Page 22 Chapter 1 – Introduction (10) RS-232C Cable GP410-IS00-O* Host RS-422 Cable GP230-IS11-O* Controller GP230-IS12-O* (11) (for Multi-link cable) RS-422 Connector Terminal Adapter (PLCs, etc.) GP070-CN10-O* Mitsubishi PLC A, (12) 2 Port Adaptor II Q, C, FX Series' Cable 2 Port Adaptor II GP070-MDCB11 GP070-MD11 (12)
  • Page 23 Chapter 1 – Introduction GLC Edit Mode Peripherals GLC Unit To an Ethernet Network Logic Program Development Software Data Transfer Cable GPW-CB02 GP-PRO/PBIII Personal for Windows USB Data Transfer Computer* software Cable GPW-CB03 CF Card CF Card Adapter CA3-CFCALL/64MB-01 GP077-CFAD10 CA3-CFCALL/128MB-01 CA3-CFCALL/256MB-01 CA3-CFCALL/512MB-01...
  • Page 24 Chapter 1 – Introduction Recommended Units The following tables list I/O devices that have been confirmed to be compatible with the GLC. If you connect a device that is not listed below, be sure to confirm that the unit functions correctly using the actual unit. Recommended units are subject to additions/changes without notice.
  • Page 25 Chapter 1 – Introduction Bar Code Readers (Connected to Expansion Serial Interface) Manufacturer Model No. Type Power Supply BR-730RS Battery powered BR-530RS Aimex Corporation Requires separately-sold Touch Scanner BB-60 for power. BW-665RS Read Width: 65mm OPT-1125- Touch Scanner RS232C(D02) Requires separately-sold Read Width: 60mm OPT Electronics DC5300T for power.

  • Page 26: Accessories

    Chapter 1 – Introduction Accessories All optional equipment listed here is produced by Digital Electronics Corporation. Available Software Product Name Model No. Description GP-PRO/PB III Used to create screen and logic program data on your PC for the GPPRO-CNT01W-P03 C-Package 03 GLC unit.
  • Page 27 Chapter 1 – Introduction I/O Units Product Name Model No. Description Flex Network 16-Point Input Sink 16-point sink/source shared I/O Unit. DC24V input signal can be FN-X16TS41 Source Type I/O Unit connected. Flex Network 32-Point Input Sink 32-point sink-source shared I/O Unit. DC24V input signal can be FN-X32TS41 Source Type I/O Unit connected.
  • Page 28 Chapter 1 – Introduction Expansion Unit Certain GP70/77R Series expansion units can be used with the GLC unit. Please contact your local GLC distributor for details. Product Name Model No. Description VM Unit GP2000-VM41 Video Capture Unit CF Card Items Product Name Model No.
  • Page 29 Chapter 1 – Introduction Maintenance Items These are all original GLC standard equipment items. They are also available separately as optional maintenance items. Product Name Model No. Corresponding GLC Rev. Description Backlight PS400-BU00-M S GLC2400T Series GP577RT-BL00-M S GLC2500T Series Rev.3 is GLC2600-TC41-24V marked.*1...

  • Page 30: Glc2000 Series Overview

    Chapter 1 – Introduction GLC2000 Series Overview The GLC2400T/GLC2500T/GLC2600T are equipped with a variety of new and useful features, such as an Ethernet, CF Card and Sound interfacesas standard equipment. The new GLC features are as follows: Ethernet Feature Your GLC2000 Series unit includes an Ethernet 10BASE-T connector as standard equipment.

  • Page 31: Ethernet Connectivity

    Chapter 1 – Introduction 1.4.1 Ethernet Connectivity The GLC2000 Series units can be connected to a LAN or an Ethernet compatible PLC. The GLC2000 Series units also support the 2-way function. This feature allows you to setup a GLC and to also perform screen data transfer. You can even set up a completely new GLC via an Ethernet network.

  • Page 32: Cf Card

    Chapter 1 – Introduction 1.4.2 CF Card The new GLC2000 series unit allows you to use a CF Card. You can set up the GLC or send screen data by saving backup data (all data necessary for GLC operation) in the CF Card using the GLC unit’s CF Memory Loader Tool feature.

  • Page 33: Sound Output

    Chapter 1 – Introduction Send Data from a GLC to a CF Card, then to another GLC The CF Card allows you to use backup data saved in a GLC for setting up another GLC. First, upload (transfer) your GLC unit’s backup data to your CF Card. Next, remove the CF Card, insert it in a different GLC and download (transfer) the CF Card’s data to that GLC.

  • Page 34: Flex Network Communication I/F

    Chapter 1 – Introduction 1.4.5 Flex Network Communication I/F The following information explains how to connect the GLC to a Flex Network Communication I/F and I/O Unit. When connecting the I/O unit, 2 lines are available - CH1 and CH2. Each channel outputs the same data and either can be used for data transmission.

  • Page 35: Printer / Serial Device / Tool Connector Interface

    Chapter 1 – Introduction 1.4.6 Printer / Serial Device / Tool Connector Interface Printer I/F This interface is used to connect a printer to the GLC2400/GLC2600. Be sure to use the PSM-PRCB00 printer cable made by Digital Electronics Corporation. See 2.3.2 – “Printer I/F” Serial I/F This interface is used to connect RS-232C and RS-422 interface cables to a host (PLC).
  • Page 36 Chapter 1 – Introduction Internal 2-Port Feature Usage Notes • To use the internal 2-Port feature, you will need to adjust your GLC’s settings. For information about these settings, refer to GP-PRO/PBIII for Windows Device/PLC Connection Manual (included with the screen creation software) •...

  • Page 37: Backlight Burnout Detection Feature

    Chapter 1 – Introduction 1.4.8 Backlight Burnout Detection Feature When the GLC unit’s backlight burns out, it will be automatically detected. The GLC unit’s Status LED will alert you that the backlight is burned out so that you can disable GLC Touch Panel Operation and prevent a possible GLC operation error.

  • Page 38: Chapter 2 Specifications

    1. General Specifications 2. Functional Specifications 3. Interface Specifications Chapter 4. Part Names and Functions 5. Dimensions 2 Specifications General Specifications 2.1.1 Electrical GLC2500-TC41-200V/GLC2600-TC41-200V GLC2500-TC41-200V GLC2600-TC41-200V AC100 to 240V Rated Voltage AC85 to 265V Rated Voltage Range 20ms or less Allowable Voltage Drop 50VA or less (ACIN100V) Power Consumption...

  • Page 39: Environmental

    Chapter 2 – Specifications 2.1.2 Environmental C to +50 Ambient Operating Temp. C to +60 Storage Temperature 10%RH to 90%RH Operating Humidity (non-condensing, wet bulb temperature: 39 C or less) 10%RH to 90%RH Storage Humidity (non-condensing, wet bulb temperature: 39 C or less) 0.1mg/m or less (non-conductive levels)

  • Page 40: Functional Specifications

    Chapter 2 – Specifications Functional Specifications 2.2.1 Display GLC2400T GLC2500T GLC2600T T FT type color LCD Type 640 x 480pixels 800 x 600pixels Resolution W149.8mm x W211.2mm x W246.0mm x H112.3mm H158.4mm H184.5mm Effective Display Area [5.90 x 4.42in.] [8.31 x 6.24in.] [9.69 x 7.27in.] 256/No blink 64 colors/3-speed blink...

  • Page 41: Memory

    Chapter 2 – Specifications 2.2.2 Memory 4MB FLASH EPROM (Approx. 1280 screens at 3.2KB/screen) Application 256KB SRAM (uses lithium battery) Data Backup 2.2.3 Control Memory SRAM Max. 64KB. However, size varies depending on main unit revision code and Variable Area software settings.

  • Page 42: Interfaces

    Chapter 2 – Specifications 2.2.5 Interfaces Asynchronous Transmission: RS-232C/RS-422 Data Length: 7 or 8 bits Serial Interface Stop Bit: 1 or 2 bits Parity: None, Odd or Even Data Transmission Speed: 2,400 to 115,200bps Asynchronous Transmission: RS-232C Data Length: 7 or 8 bits Expansion Serial Interface Stop Bit: 1 or 2 bits Parity: None, Odd or Even...

  • Page 43: Interface Specifications

    Chapter 2 – Specifications Interface Specifications 2.3.1 Serial Interfaces This interface can be either RS-232C or RS-422. Connects GLC to Host (PLC). This interface uses a socket-type connector. Signal Pin Assignments Pin # Condition Name Frame ground Send data (RS-232C) Receive data (RS-232C) Request send (RS-232C) Clear send (RS-232C)
  • Page 44 Chapter 2 – Specifications Use the following instructions to create your own cable: With an RS-422 cable: • The following pins must be shorted as follows: #18 (CSB) <—> #19 (ERB) #21 (CSA) <—> #22 (ERA) • Connecting the RS-422 cable’s #9 (TRMX) and #10 (RDA) pins inserts a termination resistance of 100Ω...

  • Page 45: Printer Interface

    Chapter 2 – Specifications 2.3.2 Printer Interface When connecting a printer, use Digital’s printer cable (PSM-PRCB00). Signal Pin Assignments Pin # Condition Name Ground RESERVE Reserved PDB5 Data Signal Data Signal PDB4 PDB3 Data Signal Ground SLCT Select Status (Input) PDB0 Data Signal Strobe Signal (Output)

  • Page 46: Part Names And Functions

    Chapter 2 – Specifications External Reset Input Circuit Input Section AUXCOM DC 24V 5.4K AUXRESET DC24V ± 10% Input Voltage Input Current 4mA(TYP)/DC24V Minimum Input Pulse Width Operating Voltage Power ON Minimum DC21.2V Power OFF Maximum DC3V Isolation Method Photocoupler isolation Part Names and Functions A: Display Panel The GLC monitor screen displays user-...
  • Page 47 Chapter 2 – Specifications D: Expansion CF Card Interface Connects the CF Card front maintenance unit (available only with GLC2500T/ GLC2600T). E: Expansion Unit Interface 1 Connects a data communication unit to the GLC. F: Expansion Unit Interface 2 Connects a unit to expand display fea- tures (available only with GLC2500T/ Rear GLC2600T).
  • Page 48 Chapter 2 – Specifications O: Printer Interface Connect the printer cable here. Recom- mended cable: Digital Electronic Corpo- ration PSM-PRCB00 Cable. P: Flex Network Interface Bottom Flex Network I/F status LED will turn ON (GLC2500T/GLC2600T) or flash, according to the unit’s status. Status LED Contents RUN (Green)

  • Page 49: Dimensions

    Chapter 2 – Specifications Dimensions 2.5.1 GLC2400T External Dimensions Unit: mm [in.] 204 [8.03] 60 [2.36] 215 [8.46] [0.31] Side Front The following drawing shows the GLC2400T Series unit with installation fasteners. Unit: mm [in.] 135 [5.31] 67.5[2.66] 60 [2.36] 215 [8.46] 8[0.31] Front...

  • Page 50: Glc2500T/Glc2600T External Dimensions

    Chapter 2 – Specifications 2.5.2 GLC2500T/GLC2600T External Dimensions Unit: mm [in.] 301 [11.85] 317 [12.48] 58 [2.28] [0.31] Front Side The External Dimensions for the GLC2500T and GLC2600T Series units are commonly shown here. However, each has a different Effective Display Area size. For the details, 2.2.1 Display The following drawing shows the GLC2500T/GLC2600T Series unit with installation...

  • Page 51: Installation Fasteners

    Chapter 2 – Specifications 2.5.3 Installation Fasteners Unit: mm [in.] 31 [1.22] 16 [0.63] 19.5 [0.77] 2.5.4 Panel Cut Dimensions GLC2400T Unit: mm [in.] +0.04 204.5 0 [8.05 4-R3 or less GLC2500T/GLC2600T Unit: mm [in.] +0.04 301.5 0 [11.87 4-R3 or less 2–14 GLC2400/2500/2600 Series User Manual...

  • Page 52: Chapter 3 Installation And Wiring

    1. Installation 5. CF Card Insertion and Removal 2. Wiring Cautions 3. Tool Connector 6. Connecting to the Screw Chapter Lock Terminal 4. Ethernet Cable Connector 3 Installation and Wiring Installation 3.1.1 Installation Procedures Follow the steps in this section to install the GLC. Attaching the Installation Gasket Pro-face strongly recommends that you use the installation gasket to absorb vibration as well as repel water.
  • Page 53 Chapter 3 – Installation and Wiring Creating a Panel Cut Create an opening with the correct dimensions to install the GLC. For the correct installation dimensions, see Section 2.5.4 – “GLC Panel Cut Dimensions.” The installation gasket, installation fasteners, and attachment screws are all re- quired when installing the GLC.
  • Page 54 Chapter 3 – Installation and Wiring • Make sure that the ambient operation temperature and the ambient hu- midity are within their respective, designated ranges. (When installing the GLC in a cabinet or enclosure, the term “ambient operation tem- perature” indicates the cabinet or enclosure’s internal temperature.) Cabinet Enclosure •...
  • Page 55 Chapter 3 – Installation and Wiring Installing the GLC 1. Insert the GLC into the panel cutout, as follows: 2. Insert the installation fasteners into the GLC unit’s insertion slots — two slots each, at the top and bottom of the unit (4 slots total). Installation Slots GLC2400T Installation Slots...
  • Page 56 Chapter 3 – Installation and Wiring 4. Be sure to pull the fastener back until it is flush with the rear of the attachment hole. 5. Use a Phillips screwdriver to tighten each fastener screw and secure the GLC in place.

  • Page 57: Wiring Cautions

    Chapter 3 – Installation and Wiring Wiring Cautions 3.2.1 Connecting the Power Cord WARNINGS • To avoid an electric shock, be sure the power cord is un- plugged from the power outlet when connecting the power terminals to the GLC unit. •...
  • Page 58 Chapter 3 – Installation and Wiring Connecting the Power Supply Lines GLC2500-TC41-200V, GLC2600-TC41-200V Power Terminal Block AC Input Live Line AC Input Neutral Line G rounding T erm inal c onnec ted to the G LC c hassis. GLC2400-TC41-24V GLC2500-TC41-24V, GLC2600-TC41-24V + - FG + - FG...

  • Page 59: Conneting The Power Supply

    Chapter 3 – Installation and Wiring 1. Make sure that the GLC unit’s power cord is not plugged in to the power supply. 2. Remove the Terminal Strip’s clear plastic cover. 3. Remove the screws from the three (3) middle terminals, position the Ring Terminals (as shown above), and reattach the screws.
  • Page 60 Chapter 3 – Installation and Wiring Main • The power supply cable must not be power power bundled or positioned close to main GLC unit circuit lines (high voltage, high current), or input/output signal lines. Input/Out- Input/Output put device power •...

  • Page 61: Grounding

    Chapter 3 – Installation and Wiring 3.2.3 Grounding CAUTION Do NOT use common grounding, since it can lead to an accident or machine breakdown. Connect the terminal found on the back of the to an exclusive ground (diagram A). (A) Exclusive Grounding (BEST) •...

  • Page 62: I/O Signal Line Cautions

    Chapter 3 – Installation and Wiring 3.2.4 I/O Signal Line Cautions To help prevent noise and interference problems, separate all communication lines from power lines by placing them in a separate duct. Duct for Communication Lines Duct for Power Lines If different wires must be placed in the same duct, separate them with an earthed/ grounded divider.
  • Page 63 Chapter 3 – Installation and Wiring Failsafe Electrical Circuits When designing failsafe circuits, be aware of possible malfunctions resulting from differences in the startup times of the control device connected to GLC output unit (especially the DC power supply), the GLC unit’s system, and the program. When using a remote I/O, create a logic program to check the terminal status.
  • Page 64 Chapter 3 – Installation and Wiring Interlock Circuit 1 Create an interlock circuit outside the GLC (below), to control a motor’s forward/ reverse rotation circuit using a GLC or PLC connection. Auxiliary B contact of electromagnetic switch for motor reverse rotation Electromagnetic switch for motor Motor rotation signal...

  • Page 65: Tool Connector

    Chapter 3 – Installation and Wiring Tool Connector A Data Transfer Cable, Memory Loader, or a Bar-Code Reader can be attached to the GLC unit’s Tool Connector. WARNING To prevent an electrical shock, unplug the GLC unit’s power cord from the main power supply prior to attach- ing or detaching any connectors to or from the GLC.

  • Page 66: Cf Card Installation And Removal

    Chapter 3 – Installation and Wiring CF Card Installation and Removal CAUTIONS When using the GLC Unit and a CF Card, follow these pre- cautions: • Prior to inserting or removing a CF Card, turn the GLC unit’s CF Card ACCESS switch OFF, and confirm that the ACCESS lamp is not lit, to prevent damage to or loss of the CF Card’s internal data.
  • Page 67 Chapter 3 – Installation and Wiring Inserting the CF Card Use the following steps to insert the CF Card in the GLC. (The illustration shows a GLC2500/GLC2600 unit. The procedure, however, is the same as it is for that of a GLC2400 unit.) 1.

  • Page 68: Cf Card Handling

    Chapter 3 – Installation and Wiring 3.5.1 CF Card Handling The CF Card has a data overwrite limit of approximately 100,000 times. Therefore, be sure to back up all CF Card data regularly to another storage media. (100,000 times assumes the overwriting of 500KB of data in DOS format) Two methods are available for backing up data.

  • Page 69: Connecting To The Screw Lock Terminal

    Chapter 3 – Installation and Wiring Connecting to the Screw Lock Terminal Use the following procedure to connect the External Reset, Flex Network, or Sound Output to the Screw Lock Terminal. 3.6.1 Cable Preparation Remove the wire’s external covering and insert the center strand into the connec- tor opening Unit: mm [in.] Blue(TR+)
  • Page 70 Chapter 3 – Installation and Wiring 3. Make sure that each line (cable) is inserted completely. 4. Retighten the two (2) set screws. 5. Reattach the screw lock terminal block to the GLC. Pins used for External Reset: Pin number Signal Name AUXCOM AUXRESET...

  • Page 71: Sound Volume Adjustment

    Chapter 3 – Installation and Wiring 3.6.3 Sound Volume Adjustment Use the following steps to adjust the sound volume. 1. Call up the GLC menu bar. 6.4.3 – SETUP TOUCH PANEL 2. Touch the left-most key to call up the next menu. 3.

  • Page 72: Data Transfer

    1. Serial Data Transfer 2. Ethernet Data Transfer 3. CF Memory Loader Tool Chapter 4 Data Transfer This chapter explains how to transfer data created with the screen creation soft- ware using one of the following three (3) methods. • Transfer data between the GLC and your PC via the data transfer cable. •...
  • Page 73 When using USB transfer cable (GPW-CB03) Please install the USB connector of the USB transfer cable in the USB port of the personal computer. Data Transfer Cable To PC’s To GLC unit’s USB port tool connector USB transfer cable (GPW-CB03) is an optional. When USB transfer cable is used, it is necessary to install the driver by setting up the cable bundle CD.
  • Page 74 Chapter 4 – Transfer Screen Data Completing Data Transfer using GLC setup When transferring screen data from the GLC screen creation software, the screen automatically switches to If the screen does not SCREEN DATA TRANSFER. switch to select mode. SCREEN DATA TRANSFER, SCREEN DATA TRANSFER During data transfer, the R and...

  • Page 75: Ethernet Data Transfer

    Chapter 4 – Transfer Screen Data Ethernet Data Transfer The GLC2000 Series unit is equipped with the Ethernet I/F which allows you to set up the GLC via an Ethernet network, as well as transfer GLC screen data. When using the Ethernet communication protocol, you must specify the port number for the protocol as +10 or higher than the value speci- fied in this section.

  • Page 76: Checking The Ip Address

    Chapter 4 – Transfer Screen Data When transferring data using the GLC setup is completed When you transfer screen creation software data from your PC to the GLC while the GLC is in RUN mode, the screen will change automatically to “Ethernet Mode.”...

  • Page 77: Cf Memory Loader Tool

    Chapter 4 – Transfer Screen Data 3. Next, click on the 2/3 cell to display the following menu. 4. The IP Address assigned to the GLC will appear in the menu bar. IP Address will not be reflected unless GLC was reset or power cord was re-connected.

  • Page 78: Data Upload And Download

    Chapter 4 – Transfer Screen Data 2. GLC Dip Switches: Forced Start via GLC Dip Switches You can also use the Dip Switches on the rear of the GLC, next to the CF Card Slot. If you turn ON Dip Switch No.1 (raise it) and then connect the GLC unit’s power cord, the“CF Memory Loader Tool will automatically start.
  • Page 79 Chapter 4 – Transfer Screen Data UPLOAD (From GLC to CF Card) This feature is for saving all GLC internal data (i.e. system program, communica- tion protocol, expansion program, screen data and Backup SRAM data) in the CF Card as backup data. To start data upload, enter the password you designated in the screen creation software’s “Transfer”...

  • Page 80: Chapter 5 Offline Mode

    1. Entering OFFLINE Mode 2. OFFLINE Mode Main Menu 3. INITIALIZATION Chapter 4. SELF-DIAGNOSIS 5 OFFLINE Mode Mode provides access to the GLC unit’s Initialize menu, Self-Diagnosis OFFLINE menu, and other GLC features. You will need to change the GLC to OFFLINE mode before you can use any of these features.

  • Page 81: After Plugging In The Power Cord

    Chapter 5 – OFFLINE Mode 5.1.1 After Plugging in the Power Cord Touch the top-left corner of the GLC screen within 10 seconds after plugging in the GLC unit’s power cord, and the GLC will change to mode. OFFLINE Up to 10 seconds can elapse before the OFFLINE mode appears. During this time, the GLC unit’s logic program can enter RUN mode.

  • Page 82: Offline Mode Main Menu

    Chapter 5 – OFFLINE Mode Enter the Password, then touch to enter mode. OFFLINE For more information about Passwords, see Section 6.3.1 – “ SYS- ” TEM SETUP. For information about Entering Password Numbers, see Section 5.3 – “ ” INITIALIZATION.

  • Page 83: Initialization

    Chapter 5 – OFFLINE Mode INITIALIZATION Selecting Menu and Setting Items Touch a menu item to select that menu; touch a setting item to select its input field. Entering Numbers After selecting an input field, touch the numeric touch keys located at the bottom of the screen to enter the value of the selected item.
  • Page 84 Chapter 5 – OFFLINE Mode After Entering All Setting Data Touch the top-left [SET] key to write the setup data to the Internal FEPROM. After entering the Setup data, do NOT touch the screen until the previous menu reappears. Writing the Setup conditions to the Internal FEPROM is a process that requires a short period of time to complete.

  • Page 85: Self-Diagnosis

    Chapter 5 – OFFLINE Mode SELF-DIAGNOSIS Selecting a Sub-Menu Touch the desired menu item and the corresponding sub-menu appears. Using the [CONFIRM], [START], and [CANCEL] Keys After selecting the Self Diagnosis item, the [CONFIRM], [START], and [CAN- CEL] keys may appear at different times at the top of the screen. [CONFIRM] Key Touch the [ ] key to inform the GLC that you have completed all steps...
  • Page 86 Chapter 5 – OFFLINE Mode Returning to the SELF-DIAGNOSIS Menu After performing the Self-Diagnosis check, OK is displayed. Touch once any- where on the display screen to return to the SELF-DIAGNOSIS MENU If an Error Message displays, press the bottom-left corners of the panel [1], and then touch the bottom-right corner of the panel [2] to return to the SELF-DIAGNO- SIS MENU...
  • Page 87 Chapter 5 – OFFLINE Mode Memo 5–8 GLC2400/2500/2600 Series User Manual...

  • Page 88: Chapter 6 Initializing The Glc

    1. Initialization Screen PLC SETUP 2. Initialization Items INITIALIZE INTERNAL MEMORY SYSTEM ENVIRONMENT SETUP SET UP TIME Chapter SET UP I/O SET UP SCREEN 6 Initializing the GLC Initialization Screen To change your GLC unit’s general operation settings, use the GLC unit’s OFFLINE mode to access the items in the option.

  • Page 89: Initialization Items

    Chapter 6 – Initializing the GLC Initialization Items This chapter explains the contents of the Initialize setup items listed below. For information about screen operations and numeric input, see Chap- ter 5 – “OFFLINE Mode.” 1 SYSTEM ENVIRONMENT SETUP SYSTEM SETUP SYSTEM AREA SETUP GLOBAL WINDOW SETUP CHARACTER STRING DATA SETUP...

  • Page 90: System Environment Setup

    Chapter 6 – Initializing the GLC System Environment Setup Adjustments to the GLC operation environment are made within the setup screens contained in the menu. Screens include the SYSTEM ENVIRONMENT SETUP SYSTEM SETUP, SYSTEM DATA AREA, GLOBAL WINDOW SETUP, CHAR- screens.

  • Page 91: System Area Setup

    Chapter 6 – Initializing the GLC PASSWORD SETUP The password setting item is used when the GLC switches to the Initialize Memory or Initialize ( mode) screens. The password — a number between 0 and 9999 OFFLINE — is a security feature within the mode, to protect the GLC settings.
  • Page 92 Chapter 6 – Initializing the GLC When the Current Screen Number, Error Status, Clock Data (Current), Change Screen Number, and Display ON/Off setting items have been selected, a word address is assigned to each item, in order, as shown. In the above screen, the device address used for the SET UP OPERATION SUR- setting’s is “+0.”...

  • Page 93: Global Windows Setup

    Chapter 6 – Initializing the GLC 6.3.3 GLOBAL WINDOWS SETUP A GLC2400/2600 Series unit can display one Global Window and two Local Windows at any one time. The Global Window is common to all the display screens. The Local Window displays exclusively on a designated base screen. This section describes the is described here.

  • Page 94: Character String Data Setup

    Chapter 6 – Initializing the GLC 6.3.4 CHARACTER STRING DATA SETUP Character String Data ordering varies from manufacturer to manufacturer. Set up the Character String Data order to match that of the corresponding PLC. Set up the CHARACTER STRING DATA MODE to match that of the corre- sponding PLC.
  • Page 95 Chapter 6 – Initializing the GLC I. Data Device Storage Order Example characters: A B C D E F G H • Storage from Start Data • Storage from End Data D100 D100 D101 D101 D102 D102 D103 D103 II. Byte Storage Order (LH/HL), using Single Words Example characters: A B C D •...
  • Page 96 Chapter 6 – Initializing the GLC Relationship between K-tag Write Character value and the PLC device. 16-bit Devices The GLC stores the character string in one internal Device, in groups of two, starting with the first pair of characters. When nine characters make up a string, they are arranged as follows: 1 2 3 4 5 6 7 8 9 Null When the characters do not divide evenly by two, NULL is added to the last character to make up the final pair and com-...

  • Page 97: Set Up I/O

    Chapter 6 – Initializing the GLC SET UP I/O This section describes the communication setup with the Host (PLC) and the configuration for any peripheral equipment. The menu includes the SET UP I/O SET UP SIO SET UP PRINTER, SET UP TOUCH PANEL COMMUNICATION SETUP SOUND SETTINGS, EXPANSION SERIAL SETUP...
  • Page 98 Chapter 6 – Initializing the GLC CONTROL setting prevents the overflow of data transmitted and received. CONTROL Select either the XON/XOFF or the ER (DTR) control. COMMUNICATION FORMAT Select one of the following options for the Communication Format setting: • RS-232C •...

  • Page 99: Set Up Printer

    Chapter 6 – Initializing the GLC 6.4.2 SET UP PRINTER This screen sets up the designated printer that will be connected to the GLC. PRINTER TYPE Printers that can be used with the GLC are those that are compatible with NECPC- , and Laser Jet PCL 4 commands, EPSON...
  • Page 100 Chapter 6 – Initializing the GLC HARDCOPY ORIENTATION (only with GLC2600T) This setting designates the direction — horizontal or vertical — of the GLC2600 unit’s screen copy printout. EPSON PM/Stylus (6-color ink) and EPSON Stylus (4-color ink) models do not support "Vertical”...
  • Page 101 Chapter 6 – Initializing the GLC When specifying "PRINTER TYPE", except for EPSON PM/Stylus (6-color), EPSON Stylus (4-color) printers, touching the key causes the following screen to appear. Touch the key, and the [SET UP PRINTER] screen will reappear. 6–14 GLC2400/2500/2600 Series User Manual...

  • Page 102: Set Up Touch Panel

    Chapter 6 – Initializing the GLC 6.4.3 SET UP TOUCH PANEL Set up the touch panel’s Touch Operation and Force Reset modes, and adjust the Display Device settings in this screen. Depending on the GLC type, these settings may vary. TOUCH OPERATION MODE Designates One Point, Two Points, or No Slide.
  • Page 103 Chapter 6 – Initializing the GLC CONTRAST ADJUSTMENT This setting is not available with the GLC2000 Series. BRIGHTNESS ADJUSTMENT When is set to ON, you can adjust the brightness by BRIGHTNESS ADJUSTMENT touching the GLC unit’s screen. To enter mode, BRIGHTNESS ADJUSTMENT press the screen’s bottom-right corner (screen A, position 1, below), and then touch the bottom-left corner (position 2).

  • Page 104: Communication Setup

    Chapter 6 – Initializing the GLC 6.4.4 COMMUNICATION SETUP This section explains how to use the Retry command to deal with errors, including those that occur during GLC and PLC communication. RECEIVE TIMEOUT (1 to 127) Use a numeric value to set a period of time in which the GLC receives data from the PLC.

  • Page 105: Expansion Serial Setup

    Chapter 6 – Initializing the GLC 6.4.6 EXPANSION SERIAL SETUP This section describes the communication setup for a device connected to the Expansion Serial Interface. This setup screen will not display unless the communi- cation protocol for the Expansion Serial Interface (specified with SET UP EXPAN- of the screen creation software package) is transferred to the GLC.
  • Page 106 Chapter 6 – Initializing the GLC RI / VCC Use this setting to specify the Expansion Serial Interface 9-pin to be at RI or VCC. VCC is available only when the setting is at the operation mode. VCC will be switched to RI when the operation mode is switched to the offline mode.

  • Page 107: Expansion Serial Environment Setup

    Chapter 6 – Initializing the GLC 6.4.7 EXPANSION SERIAL ENVIRONMENT SETUP The following setting varies depending on the communication protocol for the Expansion Serial Interface being transferred. This section explains the case where ) is transferred. SERIAL CODE READER Use this setting when a serial code reader is connected to the Expansion Serial Interface to read serial code data.

  • Page 108: Setup Capture Operation

    Chapter 6 – Initializing the GLC 6.4.8 SETUP CAPTURE OPERATION SETUP CAPTURE OPERATION This screen contains the settings required to control the screen capture operation. This feature captures GLC screen information as a JPEG file and saves it to the GLC unit’s CF Card.

  • Page 109: Set Up Display Device

    Chapter 6 – Initializing the GLC 6.4.9 SET UP DISPLAY DEVICE This setting is not suported by the GLC2400T/26000T unit. Return to the previous screen by tuching the CANCEL button. 6.4.10 FUNCTION SETUP This setting is not suported by the GLC2400T/26000T unit. Return to the previous screen by touching the CANCEL button.

  • Page 110: Communication Port Setup

    Chapter 6 – Initializing the GLC 6.4.11 COMMUNICATION PORT SETUP This screen allows you to set up the connection environment of the GLC's com- munication port. SERIAL I/F CHANGE Selecting "YES (COM1 <->COM2)" designates that the communication used for the Extended SIO Script Protocol starts at the Serial I/F (COM1).

  • Page 111: Plc Setup

    Chapter 6 – Initializing the GLC PLC SETUP Set up the GLC unit’s System Area and the Unit Number in this screen. Because 1:1 and n:1 GLC connections use different settings, confirm your connection requirements before using any settings. The following assumes that the Direct Access format is used. •...

  • Page 112: Station Setup (N:1)

    Chapter 6 – Initializing the GLC 6.5.2 STATION SETUP (n:1) , required with an n:1 (multi-link) setup, checks whether data STATION SETUP communication is being performed correctly between the GLC and the PLC. NETWORK INFORMATION ADDRESS With an n:1 (multi-link) connection, the Network Information setting uses two (2) words —...
  • Page 113 Chapter 6 – Initializing the GLC For example, when four GLCs — bits 0, 2, 3, and 5 — are connected, 002D (h) is written. Bit 16 Bit 1 002D (h) • Be certain to setup this data before running. •...

  • Page 114: Customize Setup (N:1)

    Chapter 6 – Initializing the GLC 6.5.3 CUSTOMIZE SETUP (n:1) The Customize function modifies the n:1 (multi-link) connection’s communica- tion method to make it more efficient. To perform GLC<-->PLC communication efficiently, the user should first determine whether they wish to have Operation or Display priority set for the GLC.
  • Page 115 Chapter 6 – Initializing the GLC Speed Difference between Display Priority and Operation Priority When using the Mitsubishi Electric Corporation A3A PLC, with consecutive addresses (80 words, not including the System Area), the difference in reading speed is as shown in the following graphs. GP TOUCH MONOPOLIZE Touch panel monopolization can be turned .

  • Page 116: Ethernet Setup

    Chapter 6 – Initializing the GLC 6.5.4 ETHERNET SETUP This menu is for Ethernet settings. This information is used as setting data during GLC setup or screen transfer, or, if the Pro-Server software is used, for the 2-Way Driver. • Enter the ETHERNET SETUP settings after receiving information from your network’s system administrator.

  • Page 117: Syslog Setup

    Chapter 6 – Initializing the GLC 6.5.5 SYSLOG SETUP These settings are used for outputting 2-Way driver’s operation logs. Therefore, if you are not using the Pro-Server software, these settings are not necessary. HOST IP ADDRESS Sets up the IP address of the host computer that will output the 2-Way driver’s operation logs.

  • Page 118: Others Setup

    Chapter 6 – Initializing the GLC 6.5.6 OTHERS SETUP Designates the GLC operation performed when a 2-Way driver error occurs. BUZZER ON ERROR Enables/disables the buzzer sound output produced when an error related to the 2-Way driver operation occurs. DISPLAY WARNING Enables/disables the warning message display used when an error related to the 2-Way driver operation occurs.

  • Page 119: Controller Settings

    Chapter 6 – Initializing the GLC 6.5.8 Controller Settings The setting items included in the Controller Menu are the CONTROLLER SET- TING 1, CONTROLLER SETTING 2 CONTROLLER SELF-DIAGNOSIS COPY TO , and Flex Network Driver . This section describes the FEPROM CONTROLLER listed in the...
  • Page 120 Chapter 6 – Initializing the GLC Information set by the Pro-Control Editor or GLC Controller Settings are stored in the GLC unit’s nonvolatile memory. Although each entry in the Controller Set- tings has a default setting, they should be set according to your application. CONTROLLER SETTING 1 TARGET SCAN TIME Use Target Scan Time to set the time periods for the Controller Operation and the...
  • Page 121 Chapter 6 – Initializing the GLC CONTROLLER SETTING 2 Enable I/O Sets whether to enable I/O or not. CHANGE SCREEN CHECK After #Screen is used to perform the screen change, the #Screen setting value is reset to "0". Using the ON (initial) setting will clear the #Screen value to "0". Refer to the Pro-Control Operation Manual (included in the GP-PRO/PB III C-Package).

  • Page 122: Initialize Memory

    Chapter 6 – Initializing the GLC INITIALIZE MEMORY This section explains how to initialize the GLC unit’s internal memory (screen data), or how to initialize a CF card inserted in the GLC. Select one of the menu items, [INITIALIZE MEMORY], [INITIALIZE CF CARD] and [CSV DATA INDEX].

  • Page 123: Initialze Cf Card

    Chapter 6 – Initializing the GLC 6.6.2 INITIALZE CF CARD CF Card initialization deletes all CF Card data installed in the GLC. Initialization cannot be canceled once the START switch is touched. Initializes the CF Card. Enter either the default password “1101” or the password you designated in the menu.

  • Page 124: Set Up Time

    Chapter 6 – Initializing the GLC If the touch [ESC] key during the operation to create the index file, the operation will stop, then the following screen will appear. CONTINUE The operation restarts. When the message “CREATED INDEX FILE, PLEASE PRESS END KEY”...

  • Page 125: Set Up Screen

    Chapter 6 – Initializing the GLC SET UP SCREEN Use this screen to enter the number of the screen that is initially displayed after startup, the character size when the GLC is in RUN mode, and other general screen items. INITIAL SCREEN NO.
  • Page 126 Chapter 6 – Initializing the GLC FONT SETTING Selects the font type displayed on the GLC unit’s screen during operation. KANJI FONT QUALITY Designates the font display quality for enlarged characters. Differences in FONT SETTINGS: When is set to [ FONT SETTING JAPAN Single-byte characters will remain 8x16-dot characters when they are enlarged.
  • Page 127 Chapter 6 – Initializing the GLC Memo 6–40 GLC2400/2500/2600 Series User Manual...

  • Page 128: Chapter 7 Run Mode And Errors

    1. GLC RUN Mode 4. Error Messages 2. SELF-DIAGNOSIS 5. Error Message Details 3. Troubleshooting Chapter 7 RUN Mode and Errors RUN Mode The GLC unit enters the RUN mode in two instances: either immediately after plugging in the unit’s power cord, or from the GLC unit’s mode.

  • Page 129: Via Offline Mode

    Chapter 7 – RUN Mode and Errors 7.1.2 Via OFFLINE Mode Touch the option to start your downloaded project. MAIN MENU’s RUN menu’s screen designates the screen that initially appears INITIALIZE SET UP in RUN mode. After this first screen appears, communication with the PLC begins.

  • Page 130: Self-Diagnosis

    Chapter 7 – RUN Mode and Errors SELF-DIAGNOSIS The GLC unit is equipped with a number of Self-Diagnosis features used to check its System and Interfaces for any problems. 7.2.1 SELF-DIAGNOSIS ITEM LIST 1. CHARACTER PATTERN Checks the characters inside the A.

  • Page 131: Self-Diagnosis - Details

    Chapter 7 – RUN Mode and Errors 7.2.2 SELF-DIAGNOSIS - Details This section explains the contents of SELF-DIAGNOSIS For information on how to operate the menu interface, see Chapter 5 – “ Mode.” OFFLINE For information on how to set up the Special Tools, see Chapter 3 – “Installation and Wiring.”...
  • Page 132 Chapter 7 – RUN Mode and Errors 5. INTERNAL FEPROM CHECKSUM (System and Protocol) The Internal System and Protocol check searches for any problems FEPROM that may occur during operation. When running the check, the screen changes as follows: When the FEPROM is normal, OK displays. If a problem exists, the screen stops in the middle of operation.
  • Page 133 Chapter 7 – RUN Mode and Errors A. PRINTER I/F Checks the printer I/F when the printer does not function properly. You need to connect the printer prior to performing this check. Connecting the printer buffer may cause an error. Therefore, connect the GLC and the printer directly.
  • Page 134 Chapter 7 – RUN Mode and Errors E. SOUND I/F Checks if Sound Output operates. Connect the speaker to the GLC prior to using this check menu. The first three notes of the musical scale (do, re, mi) will sound. F.

  • Page 135: Controller Self-Diagnosis

    Chapter 7 – RUN Mode and Errors 7.2.3 CONTROLLER SELF-DIAGNOSIS The Pro-Control Editor or GLC controller setting data is written to non-resident memory. Each of the setting items below is assigned a default value, but, if neces- sary, make sure that your own settings are entered. CONTROLLER DATA Shows the current controller version data.

  • Page 136: Troubleshooting

    Chapter 7 – RUN Mode and Errors Troubleshooting This section describes how to find and resolve problems that may occur with the GLC. If a problem exists with the PLC, refer to the corresponding PLC manual. 7.3.1 Possible Types of Trouble The following items are problems that may occur while using this unit.

  • Page 137: No Display

    Chapter 7 – RUN Mode and Errors 7.3.2 No Display Follow the flowchart below when the screen does not display when powering up, or the screen turns OFF by itself during RUN mode, to find an appropriate solu- tion. No Screen Display Transfer screen data from the screen editing software.
  • Page 138 Chapter 7 – RUN Mode and Errors Does turning the power ON Is the one more time start the Status LED’s orange light display? The SIO turned ON? cable may not be connected The back light has burned properly. out. Contact your nearest Is the SIO cable, GLC distributor for the AUX cable con-...
  • Page 139 Chapter 7 – RUN Mode and Errors Erase the data that has been written. When using Direct Access, the address is +9; when using Memory Link, the address is 12. Display Off data For details on the been written to the SYSTEM , refer to the DATA AREA...

  • Page 140: No Glc/Host Communication

    Chapter 7 – RUN Mode and Errors 7.3.3 No GLC/Host Communication When the GLC will not communicate with the host PLC, follow the flowchart below to find both the cause of the problem and a suitable response. Or, if an error message displays on the screen, check the error code to find the appropriate solution.
  • Page 141 Chapter 7 – RUN Mode and Errors Is the SELF-DIAGNOSIS/ the corresponding SIO INITIAL- SIO CHECK IZE settings OK? There is a problem with the GLC unit. Contact your local GLC distributor. Enter correct settings and values. Chapter 6 – Are all Tags set up “Initializing the GLC”...

  • Page 142: Touch Panel Does Not Respond

    Chapter 7 – RUN Mode and Errors 7.3.4 Touch Panel Does Not Respond When the touch panel does not respond, or its response time is very slow after it is pressed, use the flowchart below to find the origin of the problem, and the appro- priate solution.

  • Page 143: Cannot Execute Logic Program

    Chapter 7 – RUN Mode and Errors 7.3.5 Cannot Execute Logic Program Problem Reason Solution Battery Problem Change the battery. Controller Memory's Data Save Area data is not saved after power is Memory Problem Change the memory unit. turned OFF This is a program data transfer Use Pro-Control to restart the control feature.

  • Page 144: Buzzer Sounds When Glc Power Is Turned On

    Chapter 7 – RUN Mode and Errors 7.3.6 Buzzer Sounds when GLC power is turned ON If you start the GLC unit and the internal buzzer sounds, use the following chart to find the reason and the appropriate solution. Buzzer Sound Timing Reason Solution...

  • Page 145: Clock Settings Cannot Be Entered

    Chapter 7 – RUN Mode and Errors 7.3.7 Clock Settings Cannot be Entered This problem occurs when the lithium backup battery’s voltage, used for the internal clock, runs out. To enter the clock settings, please read the CLOCK SET UP ERROR directions. See 7.5.4 –...

  • Page 146: Error Messages

    Chapter 7 – RUN Mode and Errors Error Messages This section explains the messages that appear when an error has occurred in the GLC unit during RUN mode. The problem causing the error message and its related countermeasure are explained in the table below. After a problem has been solved, unplug the GLC unit’s power cord and then reattach it.
  • Page 147 Chapter 7 – RUN Mode and Errors The SIO address used for this GLC Check all GLC unit's SIO address NETWORK ADDRESS is different from other GLC units. settings, and correct any that are ERROR (02 : F8) (Only for the multi-link connection) incorrect.

  • Page 148: Error Message Details

    Chapter 7 – RUN Mode and Errors Error Message Details 7.5.1 System Errors Indicates a fault in the basic operations of the GLC. Following the error message, an error code, as shown below, will appear. Report the error number and details on how the error developed to your local GLC dis- tributor.
  • Page 149 Chapter 7 – RUN Mode and Errors When the GLC changes to OFFLINE mode during RUN mode When the GLC changes to OFFLINE mode without the user first pressing the screen, there is a possibility that the screen data has been damaged. In this case, after the SYSTEM ERROR displays, the screen automatically reverts to OFFLINE mode after about 10 seconds.

  • Page 150: Illegal Address Screen Data

    Chapter 7 – RUN Mode and Errors 7.5.2 Illegal Address Screen Data Caused by an overlap of addresses. After the error message, error codes, as listed below will appear. If the error cannot be fixed, report the error code and details on how the error developed to your local GLC distributor.

  • Page 151: Plc Com. Error

    Chapter 7 – RUN Mode and Errors 7.5.3 PLC COM. Error Appears when the address setup for tags exceeds the address range used in the host (PLC.) Check the Error Number that appears and use the following table to solve the problem. PLC COM.

  • Page 152: Clock Set Up Error

    Chapter 7 – RUN Mode and Errors • With the Toshiba PROSEC T Series, the Error Code is 4 characters long. On the GLC, Error Numbers are changed to and displayed in Hexadecimal. • With the Allen-Bradley PLC-5 and SLC-500 Series, the EXT/STS error codes have been re-mapped to start at D0 HEX, so they will not conflict with other error codes.

  • Page 153: D-Script And Global D-Script Errors

    Chapter 7 – RUN Mode and Errors 7.5.7 D-Script and Global D-Script Errors The following error messages are displayed when D-Scripts and Global D-Scripts are not configured properly. The GLC2400/2500/2600 Series unit displays the error message on the bottom at the GLC screen. Error Message D-Script D-Script Error (***)

  • Page 154: Extended Sio Script Error

    Chapter 7 – RUN Mode and Errors 7.5.8 Extended SIO Script Error The following error message is displayed when an Extended SIO Script is not configured properly. The GLC2400/2500/2600 Series unit displays the error message on the bottom at the GLC screen. Error Message Extended SIO Script Extended SIO Script Error (***) The following table lists the numbers assigned to (***) in the above error mes-...

  • Page 155: Serial I/F Change Error

    Chapter 7 – RUN Mode and Errors 7.5.9 Serial I/F Change Error The following error message is displayed when the GLC currently in use does not support the "Serial I/F Switch" feature, however in the screen editor, "Yes" has been specified for the switch. GLC2400/2500/2600 Series units display the error message at the bottom of the screen.

  • Page 156: Chapter 8 Maintenance

    1. Regular Cleaning 2. Periodic Check Points 3. Changing the Backlight Chapter 8 Maintenance Regular Cleaning 8.1.1 Cleaning the Display When the surface or the frame of the display gets dirty, soak a soft cloth in water with a neutral detergent, wring the cloth tightly, and wipe the display. •...

  • Page 157: Periodic Check Points

    Chapter 8 – Maintenance • If the water-resistant gasket is not properly inserted into the groove, the gasket’s moisture resistance may not be equivalent to IP65f. • Be sure the gasket's seam is not inserted into any of the unit's corners, only in the straight sections of the groove.

  • Page 158: Replacing The Backlight

    Chapter 8 – Maintenance Replacing the Backlight When the unit’s backlight burns out, the unit’s status will turn orange. If the menu’s feature is OFFLINE USE TOUCHPANEL AFTER BACKLIGHT BURNS OUT set to , the unit’s touch panel will be disabled. 6.4.3 –...
  • Page 159 Chapter 8 – Maintenance • Use the following table to check that you have ordered the correct backlight. GLC Model Rev. Backlight Model GLC2400-TC41-24V PS400-BU00-MS GLC2500-TC41-24V GP577RT-BL00-MS GLC2500-TC41-200V GLC2600-TC41-24V Rev.3 is marked. CA3-BLU12-01 GLC2600-TC41-200V Rev.4 is marked. GLC2600-TC41-24V Rev.3 is not marked. PS600-BU00 GLC2600-TC41-200V Rev.4 is not marked.

  • Page 160: Replacing Ca3-Blu12-01

    Chapter 8 – Maintenance 8.3.1 Replacing CA3-BLU12-01 I/F Covers 1) Turn the GLC’s power OFF (i.e. dis- connect the GLC's power cord). Re- move the three (3) I/F covers, and use a Phillips screwdriver to remove the case’s seven (7) rear attachment Rear screws.
  • Page 161 Chapter 8 – Maintenance 5) Disconnect the backlight's one (1) power connectors. Connector 6) Loosen the backlight unit attachment screw. Next, slide the backlight in the di- rection shown and lift it forward and re- move it from the GLC. 7) Insert the new backlight in the GLC.

  • Page 162: Index

    Index Symbol Clock Set Up Error .......... 7-25 Clock Settings Cannot be Entered ....7-18 2 Port Adaptor II ..........1-3 Colors ..............2-3 2-D Code Reader ..........1-2 COMMUNICATION FORMAT ....6-11, 6-19 COMMUNICATION PORT SETUP ....6-23 COMMUNICATION RATE ..... 6-10, 6-18 About GLC2000 Series Models ......
  • Page 163 Index Error Messages ..........7-19 Illegal Address Screen Data ......7-23 Error Screens ..........7-18 In-Rush Current ..........2-1 Essential Safety Precautions ........ 6 INITIALIZATION ..........5-4 Ethernet .......... 1-12, 2-5, 2-11 Initialization ............6-1 ETHERNET SETUP ........6-29 Initialization Items ..........6-2 Ethernet Cable Connector .......
  • Page 164 Index ONLINE ERROR DISPLAY ......6-38 Operating Humidity ..........2-2 Scan Time ............6-33 Operation Altitude ..........2-2 SCANNING MODE .......... 6-24 OTHERS SETUP ..........6-31 SCREEN DATA TRANSFER ......5-3 OUTPUT LEVEL ..........6-30 Screen Editor ............18 Screen Tag Limit Exceeded ......7-25 Screw Lock Terminal Block ......
  • Page 165 Index Table of Contents ..........2 TARGET SCAN TIME ........6-33 Text ..............2-3 TOOL CONNECTOR ......... 7-5 Tool Connector ......2-5, 2-10, 3-14 TOUCH BUZZER SOUND ........ 6-3 TOUCH OPERATION MODE ......6-15 TOUCH PANEL ..........7-5 Touch Panel Does Not Respond ...... 7-15 Troubleshooting ..........

This manual is also suitable for:

Pro-face glc2400 seriesPro-face glc2500 seriesPro-face glc2600 seriesPro-face glc2400tPro-face glc2500tPro-face glc2600t

Table of Contents
