Seagate BlackArmor NAS 220 Specification

Horiz x Vert x Depth - 6.30"x 8.15" x 10.59" (160mm x 207mm x 269mm)
Product Dimensions
Weight: 13.60lbs (6.16kg)
Retail Packaging Specs Box dimensions: Horiz x Vert x Depth – 14.37" x 9.29" x 9.5" (277mm x 156mm x 279mm)
Box weight: 16.6lbs (7.62Kg)
Master carton dimensions: Horiz x Vert x Depth – 19.33" x 15.00" x 10.20" (322mm x 288mm x 301mm)
Master carton weight: 36.05lbs (8.39Kg)
Master carton quantity: 2
Master cartons per pallet: 36
Pallet dimensions: Horiz x Vert x Depth – 47.25" x 39.37" x 47.10" (1,016mm x 1,219.20mm x 1,030mm)
Pallet weight: 718.85 lbs (326.06 kg)
Pallet layers: 3
Connectivity
Technical Specifications
Network Protocols
Network Authentication
File Sharing Protocols
File System Management
Volume Management
Disk Management
Backup Management
Event Management
Media Streaming
Download Server
Remote Access
PC On Network
Software Requirements
• Pentium III, 500MHz equivalent processor or higher
®
• Microsoft Windows ® XP or Vista
• Internet Explorer ® 6.0 or later, or Firefox
(for management interface and web access)
• 256MB RAM
System Requirements
• Local area network (LAN)
• Internet connection (for system updates and web access)
• BlackArmor NAS 220 storage server
Inside the Box
• 2M – RJ45 cable
• AC power cord
• Quick Start Guide
Region Product Capacity
AMER BlackArmor NAS 220 2TB
AMER BlackArmor NAS 220 4TB
AMER BlackArmor NAS 220 6TB
© 2010 Seagate Technology LLC. All rights reserved. Seagate, Seagate Technology, the Wave logo, Barracuda, Global Access and BlackArmor are trademarks or registered trademarks of Seagate Technology LLC or one of
its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. When referring to hard drive capacity, one terabyte, or TB, equals
one thousand billion bytes. Your computer's operating system may use a different standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions and
will not be available for data storage. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and Security (for more information,
visit www.bis.doc.gov) and controlled for import and use outside of the U.S. Actual data rates may vary depending on operating environment and other factors. Seagate reserves the right to change, without notice, product
offerings or specifications. Seagate Technology LLC, 920 Disc Drive, Scotts Valley CA 95066 U.S.A. www.seagate.com DS1691.3-1010 AMER
• 2 internal SATA II ports • 1 RJ45 Ethernet port (Gigabit)
• 2 USB 2.0 host ports
CIFS, NFS, HTTP, HTTPS, FTP, Bonjour
®
Microsoft Windows Server Active Directory 2000/2003/2008 integration for population of users and groups.
®
CIFS, NFS, HTTPS, FTP over SSL/TLS, FTP, Bonjour, Microsoft Rally
RAID 0, 1, JBOD
• Share management • Share/folder-level access control list (ACL) support
• Volume level encryption • Quotas setting
• Multi-volume management • Drive standby mode
• SMART status monitor
• Local backup • Client system backup, Bare MetalRestore
(USB device to NAS, NAS to USB device) (full-system recovery) over network
• Network NAS to NAS replication • Time Machine ® software compatible
Event email notification
• iTunes ® server
• DLNA ® compliant digital media server
Downloader (HTTP and FTP)
Seagate Global Access service
™
Mac On Network
• Mac OS X 10.4.11 or later
®
® • Apple ® Safari ® 3.1 or later
™ 2.X or later
• Wired or wireless router with an available 10/100/1000
Ethernet port
• USB printer or USB disk drive (optional)
• DVD-ROM with
– BlackArmor Discovery Software for Windows
®
– BlackArmor Discovery Software for Mac
®
– BlackArmor ® Backup Software for Windows (5 licenses*)
– Online registration link
– Warranty information card
*Additional licenses available for purchase at www.seagate.com
Model Number UPC Code
ST320005LSA10G-RK 763649016510
ST340005LSA10G-RK 763649016534
STAV6000100 763649028001
Visit Seagate.com for more information about these and other Seagate retail products.
Perfect for when you need to:
• Store and access files from a
central, secure location.
• Access and manage files
remotely.
• Stream media with DLNA or
iTunes ® .
• Automatically perform full-
system backups on network
connected PC and Mac
computers.*
• Secure files with hardware-
based encryption.
• Share a USB printer with
network connected PCs and
Macs.
Connectivity
• One Ethernet port for local
network connection, web-
based management and remote
access.
• Two USB 2.0 ports for external
OS
®
drives, printers and uninterrupted
OS
®
power supplies (UPS).
• Two internal SATA II ports.
Multi-pack UPC
10763649016517
10763649016531
10763649028008
Interface 10/100/1000 Ethernet, USB 2.0
Capacities 2TB, 4TB, 6TB
The BlackArmor ® NAS 220 server is a small-business-specific network attached storage solution designed to
provide centralized storage and data backup, helping to deliver business continuity for up to 20 PCs. Automatically
backup business-critical data with RAID 1 mirroring, full-system backup, SafetyDrill+
software and powerful hardware-based encryption.
Highlights
• Designed to provide centralized storage and data backup for up to 20 PCs.
• Enables automatic data mirroring with RAID 1 configuration.
®
• Help protect network connected PCs with incremental and full-system, automatic backup.*
• Time Machine ® software compatible, for Mac ® computer backup
• Functions as an FTP server for remote file access.
• Stream media to DLNA ® compliant devices and computers running iTunes
• Includes two reliable, user-replaceable Seagate
• Connect external drives, share a printer or utilize an uninterrupted power supply with the two USB 2.0 ports.
• Secure files with powerful hardware-based encryption.
• Microsoft Active Directory 2003/2008 support for populating users and groups.
®
• Multi-volume management.
• Event email notification.
• 3-year limited warranty.
* Includes data backup software licenses for 5 PCs. Additional licenses available for purchase at www.seagate.com.
bare metal recovery
™
® software.
® hard drives.
