OWNER'S MANUAL
LG Digital Signage
(MONITOR SIGNAGE)
Please read the user manual before using this product to ensure
safe and convenient use.
55TR3DQ-B
55TR3DQ-I
65TR3DQ-B
65TR3DQ-I
75TR3DQ-B
75TR3DQ-I
86TR3DQ-B
86TR3DQ-I
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 55TR3DQ-B and is the answer not in the manual?

Questions and answers

Summary of Contents for LG 55TR3DQ-B

  • Page 1 OWNER’S MANUAL LG Digital Signage (MONITOR SIGNAGE) Please read the user manual before using this product to ensure safe and convenient use. 55TR3DQ-B 55TR3DQ-I 65TR3DQ-B 65TR3DQ-I 75TR3DQ-B 75TR3DQ-I 86TR3DQ-B 86TR3DQ-I www.lg.com Copyright © 2024 LG Electronics Inc. All Rights Reserved.
  • Page 2: Table Of Contents

    Table of Contents Getting to Know the Product 3 Using the Wi-Fi Module . . . . . . . . . . . . 17 Installation Procedure Checking Components .
  • Page 3: Getting To Know The Product

    An electronic blackboard is a display product that can be used by touching the screen. A touch pen, remote control and others are provided with the product. If any of the listed components are missing, contact customer support. LG Electronics also sells optional components that can help you use the product more effectively as separate purchases.
  • Page 4 Checking Components Remote control and batteries Electronic blackboard User manual and warranty (AAA, 2 pieces) HDMI cable Power cable TOUCH cable USB Type-C cable Touch pens and pen tips (2 each) Wi-Fi Module Note • : Availability may vary depending on your geographic location. •...
  • Page 5: Checking Optional Components

    Optional components may change without prior notice to improve product performance. New components may be added. Note • All optional components are separate purchases. Contact LG Electronics if you wish to purchase them. • Component images shown in the user manual are for the user’s understanding and may differ from actual components.
  • Page 6: Installing The Product

    (mm) (mm) Screw Model Name Quantity Specifications VESA Dimensions (A x B) Maximum Length (inches) (inches) 400 x 200 55TR3DQ-B 55TR3DQ-I 15.7 x 7.8 600 x 400 65TR3DQ-B 65TR3DQ-I 23.6 x 15.7 800 x 400 75TR3DQ-B 75TR3DQ-I 31.4 x 15.7...
  • Page 7: Installing The Product

    Installing on Wall Caution • Disconnect the power cord first before moving or installing the product. There is risk of electric shock. • Do not install the product on a ceiling or sloped wall. There is a risk of falling and injury. •...
  • Page 8: Connecting To Power

    Connecting to Power Connecting to Power Connect the power cable provided as a component to the power terminal at the bottom of the product. Press the power switch on the front of the product or next to the power terminal to turn the power on. Note •...
  • Page 9: Exploring The Product

    Exploring the Product * The illustrations may differ depending on the model. Names of Each Part Front No . Name Explanation Screen that displays the contents of the electronic blackboard and can be Touch screen operated by touching it with your hand or with a touch pen. Microphone When switched on, the microphone can be used for voice collection.
  • Page 10: Back

    Names of Each Part Back No . Name Explanation Used for moving the electronic blackboard. (May vary for different Handle for Transportation models.) Used for mounting the electronic blackboard on a stand or installing it Screw Holes on a wall with a wall mount. Bass speaker Outputs low-pitched sound.
  • Page 11: Side

    Names of Each Part Side No . Name Explanation Used for moving the electronic blackboard. (May vary for different Handle for Transportation models.) Built-in PC (OPS) Slot Inserts the built-in PC (OPS). Terminals that allow you to connect each of the external devices of the following specifications.
  • Page 12: Checking The Input/Output Terminals

    Checking the Input/Output Terminals Checking the Input/Output Terminals Check the location and function of the input/output terminals for connecting external devices to the electronic blackboard. Front Cable Terminal No . Name Explanation Power Sources Turns the power on or off. Used to connect external devices with a USB Type-C cable.
  • Page 13: Side Cable Terminal

    Checking the Input/Output Terminals Side Cable Terminal No . Name Explanation Used for touch control of the PC screen input through the terminal. Used to connect the terminal and PC with a TOUCH cable. Used for data transfer or connecting USB devices such as a mouse or (USB 3 .0) keyboard with a USB cable.
  • Page 14: Bottom Cable Terminal

    Checking the Input/Output Terminals Bottom Cable Terminal No . Name Explanation Used to output audio to an external device using an SPDIF cable. 比例 25.400 Used to input audio from an external device. Used to output audio to an external device. Used for data transfer or connecting USB devices such as a mouse or (USB 2 .0) keyboard with a USB cable.
  • Page 15: Using The Touch Pen

    Using the Touch Pen Using the Touch Pen The touch pen can be used for various purposes, such as touching the screen to launch menus or to take notes, annotate, and draw on data. Getting to Know the Touch Pen Functions Two pens can be used simultaneously to write or draw together.
  • Page 16: Storing The Pen

    If the touch pen tip is worn or damaged, it must be replaced with a new tip. Remove the old tip by pulling on the end with tools such as tweezers. Slide the new tip into the pen body. Note • To purchase additional touch pens or spare tips, contact LG Electronics.
  • Page 17: Using The Wi-Fi Module

    Using the Wi-Fi Module Using the Wi-Fi Module Installation Procedure Caution • Ensure the power cord of the product is disconnected before installation. Unscrew and remove the Wi-Fi module cover located on the bottom of the product. Following the direction of the arrow, insert the Wi-Fi module fully into the slot. Feature Once installation is complete, power on the product to automatically activate the Wi-Fi module.
  • Page 18: Precautions For Use

    Precautions for Use Dust The warranty will not cover any damage caused by using the product in an excessively dusty environment. Afterimage • After-image appears when the product is turned off. - Pixels may be damaged rapidly if a still image is displayed on the screen for a long period of time. Use the screen-saver function.
  • Page 19: Recommended Usage Condition

    Afterimage Recommended Usage Condition Change the background color and text color at equal intervals. - Afterimages occur less when the colors to be changed are complementary to one another. ITO or MoTi Pixel Layer Switch the screen at equal time intervals. - Take caution, and ensure that text or images from before the screen change are not left in the same location after the screen change.
  • Page 20: Product Specifications

    Product Specifications Without prior notice, all product information and specifications contained in this manual are subject to change to improve the performance of the product. symbol means alternating current, and the symbol means direct current. Input/Output Ports Embedded Not Applied Battery Recommended VGA: 1920 x 1080 @ 60 Hz...
  • Page 21: Touch Screen

    Speaker Touch screen Windows 10 / Windows 8 / Windows 7 / Android / Linux / macOS 50 Points (Linux / macOS are supported with the 1 Point touch function.) Chrome OS 16 Points Spacing between touches: at least 25 mm (0.9 inches) Speaker * Applicable only to speaker-supporting models.
  • Page 22: Specifications By Model

    Specifications by Model Specifications by Model 55TR3DQ-B 55TR3DQ-I Power Power Voltage 100-240 V~ 50/60 Hz 3.0 A 1269.1 mm x 783.4 mm x 99.7 mm / 26.65 kg Dimensions (Width x Height x Depth) / Weight (49.9 inches x 30.8 inches x 3.9 inches/ 58.7 lbs)
  • Page 23: Resolution

    Resolution Resolution Note • Vertical Frequency: The monitor screen functions by the screen image changing dozens of times every second like a fluorescent lamp. The vertical frequency or refresh rate is the number of image displays per second. The unit is Hz. •...
  • Page 24 Resolution Horizontal Vertical Frequency Frequency Resolution HDMI DP 1 .2 Type-C (kHz) (Hz) 1080p / 50 Hz 56.250 50.00 1080p / 60 Hz 67.500 60.00 720 (1440) x 480i / 60 Hz 15.734 59.94 720 (1440) x 576i / 50 Hz 15.625 50.00 1080i / 50 Hz...
  • Page 25: Wireless Module Specifications

    Wireless module Specifications Wireless module Specifications Wireless module (SI07E) Specifications Wireless LAN (IEEE 802 .11a/b/g/n/ac/ax) Frequency range (MHz) Output power (Max .) (dBm) 2412 to 2472 19.94 5180 to 5320 21.36 5500 to 5700 19.93 5745 to 5825 13.93 5955 to 6415 15.00 Bluetooth Frequency range (MHz)
  • Page 26: Licence

    Licence Supported licenses may differ by model. Visit www.lg.com for more information on licenses. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
  • Page 27 Supplier’s Declaration of Conformity Trade Name Responsible LG Electronics USA, Inc. Party Address 111 Sylvan Avenue, North This product qualifies for ENERGY Building, Englewood Cliffs, NJ STAR®. 07632 Changing the factory default E-mail lg.environmental@lge.com configuration and settings or enabling certain optional features...
