OWNER'S MANUAL
LG Digital Signage
(MONITOR SIGNAGE)
Please read this manual carefully before operating your set and retain it for future
reference.
55TR3DK-B
55TR3DK-I
65TR3DK-B
65TR3DK-I
75TR3DK-B
75TR3DK-I
86TR3DK-B
86TR3DK-I
98TR3DK-B
98TR3DK-I
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
www.lg.com
www.lg.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the CreateBoard 65TR3DK-I and is the answer not in the manual?

Questions and answers

Related Manuals for LG CreateBoard 65TR3DK-I

Summary of Contents for LG CreateBoard 65TR3DK-I

  • Page 1 Please read this manual carefully before operating your set and retain it for future reference. 55TR3DK-B 55TR3DK-I 65TR3DK-B 65TR3DK-I 75TR3DK-B 75TR3DK-I 86TR3DK-B 86TR3DK-I 98TR3DK-B 98TR3DK-I www.lg.com www.lg.com Copyright © 2023 LG Electronics Inc. All Rights Reserved. Copyright © 2023 LG Electronics Inc. All Rights Reserved.
  • Page 2 Table of Contents Getting to Know the Product 3 Using the Wi-Fi Module . . . . . . . . . . . . . . .17 Installation Procedure Checking Components .
  • Page 3 An electronic blackboard is a display product that can be used by touching the screen. A touch pen, remote control and others are provided with the product. If any of the listed components are missing, contact customer support. LG Electronics also sells optional components that can help you use the product more effectively as separate purchases.
  • Page 4 Checking Components Remote control and batteries Electronic blackboard Owner’s manual and warranty (AAA, 2 pieces) HDMI cable Power cable TOUCH cable USB Type-C cable Touch pens and pen tips (2 each) Wi-Fi Module Note • : Depending on country • The components provided in the box may vary depending on the region and model.
  • Page 5 Optional components may change without prior notice to improve product performance. New components may be added. Note • All optional components are separate purchases. Contact LG Electronics if you wish to purchase them. • Component images shown in the owner’s manual are for the user’s understanding and may differ from actual components.
  • Page 6 Installing the Product Installing on Wall The electronic blackboard can be used in a wall-mounted format by securing it to a wall. To install it on a wall, first attach a wall mount support (optional) to the back of the product body. The wall mount support is a separate purchase and can be purchased from a nearby dealer.
  • Page 7 Installing on Wall Caution • Disconnect the power cord first before moving or installing the product. There is risk of electric shock. • Do not install the product on a ceiling or sloped wall. There is a risk of falling and injury. •...
  • Page 8 Connecting to Power Connecting to Power Connect the power cable provided as a component to the power terminal at the bottom of the product. Press the power switch on the front of the product or next to the power terminal to turn the power on. Note •...
  • Page 9 Exploring the Product Names of Each Part Front No . Name Explanation Screen that displays the contents of the electronic blackboard and can be Touch screen operated by touching it with your hand or with a touch pen. Speaker Outputs the sound. Touch Pen Holder Holds a touch pen by attaching it magnetically.
  • Page 10 Names of Each Part Back No . Name Explanation Handle for Used for moving the electronic blackboard. Transportation Used for mounting the electronic blackboard on a stand or installing it on a Screw Holes wall with a wall mount. Power Cable Terminal Connects the power cord.
  • Page 11 Names of Each Part Side No . Name Explanation Handle for Used for moving the electronic blackboard. Transportation Built-in PC (OPS) Slot Inserts the built-in PC (OPS). Terminals that allow you to connect each of the external devices of the following specifications.
  • Page 12 Checking the Input/Output Terminals Checking the Input/Output Terminals Check the location and function of the input/output terminals for connecting external devices to the electronic blackboard. Front Cable Terminal No . Name Explanation Power Sources Turns the power on or off. USB Type-C Used to connect external devices with a USB Type-C cable.
  • Page 13 Checking the Input/Output Terminals Side Cable Terminal No . Name Explanation Used to connect an cable. Used for wired internet connection. Used for data transfer or connecting USB devices such as a mouse or keyboard with a USB cable. Used for touch control of the PC screen input through the terminal.
  • Page 14 Checking the Input/Output Terminals Bottom Cable Terminal 01 02 No . Name Explanation SPDIF Used to output audio to an external device with a SPDIF cable. Used to input audio from an external device. Used to output audio to an external device. Used to connect external devices with a cable.
  • Page 15 Using the Touch Pen Using the Touch Pen The touch pen can be used for various purposes, such as touching the screen to launch menus or to take notes, annotate, and draw on data. Getting to Know the Touch Pen Functions Two pens can be used simultaneously to write or draw together.
  • Page 16 If the touch pen tip is worn or damaged, it must be replaced with a new tip. Remove the old tip by pulling on the end with tools such as tweezers. Slide the new tip into the pen body. Note • To purchase additional touch pens or spare tips, contact LG Electronics.
  • Page 17 Using the Wi-Fi Module Using the Wi-Fi Module Installation Procedure Caution • Ensure the power cord of the product is disconnected before installation. Unscrew and remove the Wi-Fi module cover located on the bottom of the product. Following the direction of the arrow, insert the Wi-Fi module fully into the slot. Feature Once installation is complete, power on the product to automatically activate the Wi-Fi module.
  • Page 18 Precautions for Use Dust The warranty will not cover any damage caused by using the product in an excessively dusty environment. Afterimage • After-image appears when the product is turned off. - Pixels may be damaged rapidly if a still image is displayed on the screen for a long period of time. Use the screen-saver function.
  • Page 19 Afterimage Recommended Usage Condition Change the background colour and text colour at equal intervals. - Afterimages occur less when the colours to be changed are complementary to one another. ITO or MoTi Pixel Layer Switch the screen at equal time intervals. - Take caution, and ensure that text or images from before the screen change are not left in the same location after the screen change.
  • Page 20 Product Specifications Without prior notice, all product information and specifications contained in this manual are subject to change to improve the performance of the product. symbol means alternating current, and the symbol means direct current. Input/Output Ports Embedded Battery Not Applied Recommended VGA: 1920 x 1080 @ 60 Hz Resolution...
  • Page 21 Specifications by Model Specifications by Model 55TR3DK-B 55TR3DK-I Power Power Voltage 100-240 V~ 50/60 Hz 3.5 A Dimensions (Width x Height x 1271 mm x 774 mm x 87 mm / 26.1 kg Depth) / Weight 65TR3DK-B 65TR3DK-I Power Power Voltage 100-240 V~ 50/60 Hz 4.0 A Dimensions (Width x Height x 1488 mm x 897 mm x 88 mm / 34.95 kg...
  • Page 22 Resolution Resolution Note • Vertical Frequency: The monitor screen functions by the screen image changing dozens of times every second like a fluorescent lamp. The vertical frequency or refresh rate is the number of image displays per second. The unit is Hz. •...
  • Page 23 Resolution USB Type-C Supported Mode Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 640 x 480 / 60 Hz 31.469 59.94 800 x 600 / 56 Hz 35.156 56.25 800 x 600 / 60 Hz 37.879 60.317 1024 x 768 / 60 Hz 48.363 60.004 1280 x 768 / 60 Hz (RB)
  • Page 24 Resolution Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 720 x 576P / 50 Hz 4:3 31.25 720 x 576P / 50 Hz 16:9 31.25 1280 x 720P / 50 Hz 16:9 37.5 1440 x 576P / 50 Hz 16:9 31.25 1920 x 1080P / 50 Hz 16:9 56.25 1920 x 1080P / 23 Hz 16:9...
  • Page 25 Resolution HDMI / OPS Supported Mode Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 640 x 480 / 60 Hz 31.469 59.94 800 x 600 / 60 Hz 37.879 60.317 1024 x 768 / 60 Hz 48.363 60.004 1280 x 768 / 60 Hz (RB) 47.396 59.995 1280 x 768 / 60 Hz...
  • Page 26 Resolution Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 1080i / 60 Hz 33.75 1080i / 59 Hz 33.716 59.94 1080i / 50 Hz 28.125 1080p / 60 Hz 67.5 1080p / 50 Hz 56.25 1080p / 30 Hz 33.75 1080p / 29 Hz 33.716 29.97 1080p / 25 Hz...
  • Page 27 Wireless module Specifications Wireless module Specifications Wireless module (SI07B) Specifications Wireless LAN (IEEE 802 .11a/b/g/n/ac/ax) Frequency range (MHz) Output power (Max .) (dBm) 2412 to 2472 19.14 5150 to 5250 18.90 5250 to 5350 15.11 5470 to 5725 17.37 5725 to 5850 13.58 Bluetooth Frequency range (MHz) Output power (Max .) (dBm) 2402 to 2480 7.29 •...
  • Page 28 Licence Supported licenses may differ by model. Visit www.lg.com for more information on licenses. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
  • Page 29 This product qualifies for ENERGY STAR®. Changing the factory default configuration and settings or enabling certain optional features and functionalities may increase energy consumption beyond the limits required for ENERGY STAR® certification. Refer to ENERGYSTAR.gov for more information on the ENERGY STAR®...
