Sensors
EasyAir
SNS212 MC, SNS412 MC
Design-in Guide
Single, compact, cost-effective
luminaire control
Philips EasyAir SNS212 MC, SNS412 MC
March 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyAir SNS412 MC and is the answer not in the manual?

Questions and answers

Summary of Contents for Philips EasyAir SNS412 MC

  • Page 1 Sensors EasyAir SNS212 MC, SNS412 MC Design-in Guide Single, compact, cost-effective luminaire control Philips EasyAir SNS212 MC, SNS412 MC March 2025...
  • Page 2: Table Of Contents

    Mounting in a bracket (SMB-50) Installing EasyAir SNS212 MC with ceiling mount bracket (SNS212 MC CMP) Labels EasyAir SNS212 MC with multiple Philips Xitanium SR LED drivers (1:N application) Luminaire Production Test Contact details Philips EasyAir SNS212 MC...
  • Page 3: Introduction To This Guide

    Introduction to this guide Thank you for choosing Philips EasyAir SNS212 MC, EasyAir SNS412 MC. In this guide luminaire manufacturers will find the information required to design this product into a luminaire and configure it to suit specific applications. This...
  • Page 4: Warnings And Instructions

    Warnings and instructions • EasyAir SNS212 MC, SNS412 MC must be used with SR LED drivers, e.g. Philips Xitanium SR drivers. • Do not apply mains power directly to the sensor. • Do not cover the sensor during operation or mount the sensor internal to the luminaire.
  • Page 5: Introduction Of Easyair Sns212 Mc

    Introduction of EasyAir SNS212 MC and EasyAir SNS412 MC The Philips EasyAir SNS212 MC is the ideal solution for per- luminaire control of smart luminaires. It is the future proof successor of Philips EasyAir SNS210 MC. Occupancy sensing, daylight harvesting and task tuning are combined in a single, compact package for easy OEM luminaire assembly.
  • Page 6: Product Characteristics

    Product characteristics EasyAir SNS212 MC overview EasyAir SNS212 MC contains multiple functions in one housing and uses two wires to connect with an SR driver. (See wiring diagram in the Mechanical design-in section.) Functions include: • Occupancy sensor (PIR) • Zigbee/BLE •...
  • Page 7: Detector

    Motion detector The occupancy sensor is a PIR (Passive Infrared) sensor that detects movement with an X-Y cross-area under an angle of X = 62° and Y = 84°. Two types of movements are defined as follows: • Major movement: movement of a person walking into or through an area.
  • Page 8: Sensor View Shield

    To prevent false triggers, the EasyAir SNS212 MC must be mounted more than 2 m away from air vents in all directions, see figures below: > 2 Luminaire > 2 > 2 > 2 Sensor view shield The sensor comes with an occupancy view shield that can be used to block the movement detection by the sensor in a certain area.
  • Page 9: Light Sensor

    The EasyAir SNS212 MC converts the illuminance signal into ON/OFF or dimming commands to the Philips Xitanium SR LED driver in order to maintain a constant light level on the desk. Window The sensor should be installed with a minimum distance of 0.6...
  • Page 10: Daylight Regulation And Calibration

    Daylight regulation and calibration Daylight regulation without calibration When daylight-based control is switched on and no calibration is performed, the light output adjusts approximately to 500 lux times the value set for the Eco-on level. If the Eco-on level is set to 80% for example, the light output from the luminaire adjusts to approximately 400 lux in the working area.
  • Page 11: Mechanical Design-In

    Mechanical design-in Wire strip length Wiring Information Strip length Applicable wires 8.0 ± 0.5 mm Conductor size: solid 0.2 - 0.75 mm Conductor size: fine-stranded 0.2 - 0.75 mm Conductor size: fine-stranded 0.25 - 0.34 mm Conductor Insulation (with insulated formule) Conductor size: fine-stranded 0.25 - 0.34 mm [ Conductor: Bare Copper / Strand wire ]...
  • Page 12: Wire Distance For Remote Mounting

    Wire distance for remote mounting ≥ ≥ 1 1.5 It is recommended to keep the wire distance from sensor to Xitanium SR LED driver less than 2 m and meet the wire gauge requirement to guarantee the performance. Luminaire-to-luminaire distance If multiple luminaires with EasyAir SNS212 MC are used in the same area, the distance between the different sensors should be kept at least 1.5 m.
  • Page 13: To A Luminaire

    Without the shield some light can tunnel through the white housing and impact daylight sensing. Mounting EasyAir SNS412 MC inside of a luminaire Easy Air SNS412 MC can also be placed inside of a sealed luminaire with plastic housing, because plastic materials...
  • Page 14: Mounting In A Bracket (Smb-50) Installing

    Mounting in a bracket (SMB-50) 65 Max. The EasyAir SNS212 MC, SNS412 MC can be mounted in a bracket (SMB 50). Refer the figures for details on mounting and design-in into luminaire. All dimensions are in mm. 26 Max. 64 Max. 60 ±...
  • Page 15 Installing EasyAir SNS212 MC, SNS412 MC with ceiling mount bracket (CMP/W) The ceiling mount CMP bracket is available as a bracket without any pre-mounted sensor or cable. The luminaire manufacturer needs to mount the sensor in the CMP bracket and attach cable to it. The cable and screws are available with the accessory. Caution: The cable length from the EasyAir sensor to SR driver should be kept <2m.
  • Page 16: Labels

    Labels SNS212 MC, SNS412 MC sensors are supplied with three labels which each contain the assigned ZigBee MAC Address. For a typical application, the top two labels can be removed and discarded. For a network application using a gateway, the labels can be used to identify a luminaire and where it is installed in the building. •...
  • Page 17 NEUTRAL SGND LINE NFC ANTENNA In case EasyAir SNS212 MC, SNS412 MC is connected to multiple Philips Xitanium SR LED drivers, the number of drivers Connectors is limited to 10. Not more than 4 drivers should have DALI LED+ LED+ power supply enabled.
  • Page 18: Luminaire Production Test

    1st second followed by dimming up to 100% in the next second. This behaviour is only visible in non-commissioned devices i.e. once grouped using Philips MasterConnect app, this behaviour will cease to exist. March 2025 Design-in Guide - EasyAir SNS212 MC, SNS412 MC...
  • Page 19: Faq

    Is EasyAir SNS212 MC “failsafe”? Unlike traditional occupancy sensors, EasyAir SNS212 MC does not have a mechanical relay. This is a benefit of Philips SR LED drivers, as on/off is done relay-free within the driver. Devices with mechanical relays should be designed so that relay failure results in “lights on.
  • Page 20: Contact Details

    Contact details Philips EasyAir SNS212 MC Product information: https://www.lighting.philips.com/prof/led-electronics/ masterconnect-system/masterconnect-sensors/ LP_CF_9218075_EU/family Or contact your local Philips sales representative. March 2025 Design-in Guide - EasyAir SNS212 MC, SNS412 MC...
  • Page 21: Disclaimer

    Disclaimer ©2025 Signify Holding B.V. All rights reserved. Note that the information provided in this document is subject to change. This document is not an official testing certificate and cannot be used or construed as a document authorizing or otherwise supporting an official release of a luminaire.
  • Page 22 The information presented in this document is not intended as any commercial offer and does not form part of any quotation or contract. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. All other trademarks are owned by Signify Holding or their respective owners.
