- Page 1 Swash Eco Thinline T66 Electronic Luxury Bidet Toilet Seat Model: T66-EW Owner’s Manual...
-
Page 2: Table Of Contents
T66 OWNER’S MANUAL Contents This manual contains important safety information. Before operating the bidet, please read this manual thoroughly, and retain it for future reference. SAFETY INFORMATION TECHNICAL INFORMATION Important Safeguards Troubleshooting Product Specifications Regulatory and Safety Notices PRODUCT INFORMATION Warranty Contact Information Product Features... -
Page 3: Safety Information
Do not forcefully bend the power cord or it immediately from the electrical outlet place heavy objects on it to prevent it from and contact Brondell. Failure to do so may being damaged or deformed. result in electric shock or fire. - Page 4 Brondell Service Center. power plug out of the electrical outlet, turn Do not use the product if it is not working off the main water valve, and call the Brondell properly. Please unplug the product immediately, close the main water supply valve.
- Page 5 Contact the Brondell Service Center for Connect the product to a properly grounded examination and repair. outlet only. Refer to the Grounding Instructions in Keep the cord away from heated surfaces and the next pages of the manual.
- Page 6 SAFETY INFORMATION Important Safeguards READ ALL INSTRUCTIONS BEFORE USING BE CAREFUL TO KEEP THIS SAFETY INFORMATION. PLEASE READ THIS INFORMATION TO PREVENT PROPERTY LOSS AND ENSURE SAFETY. ATTENTION For those with certain medical or mobility issues in the bathroom, we recommend our Swash 1400 or Swash 1000 bidet seats, as their mounting systems are engineered for the most secure transitions from wheelchairs or walkers.
-
Page 7: Product Information
PRODUCT INFORMATION Product Features Heated toilet seat Eco-friendly design 10% recycled ABS plastic used in lid, Provides 4 temperature settings for remote and dock comfort (off/low/medium/high). Self-cleaning, stainless steel nozzle Multicolored LED nightlight with Nozzle retracts to stay clean between uses. on/off switch Self-cleaning feature gives nozzle a sanitary Select a preferred nightlight color to help... -
Page 8: Product Dimensions
PRODUCT INFORMATION Product Dimensions Elongated Top View Required Distance Between Mounting Holes 20.7 in 11.8 in 5.3–7.7 in 7.9 in 15 in... -
Page 9: Product Parts
PRODUCT INFORMATION Product Parts 1. Lid 7. Deodorizer inlet 2. Auxiliary control panel 8. Mounting plate 3. Nozzle assembly 9. Water inlet with mesh filter 4. Seat sensor area 10. Nightlight 5. Quick-release button 11. Power cord 6. Deodorizer cover & outlet... -
Page 10: Product Installation
PRODUCT INSTALLATION Installation Parts 1. Metal mounting bolt (2) 7. Adjustable brackets (2) 2. Rubber anchor (2) 8. Mounting plate 3. T-Valve connector with rubber washer 9. Remote control 4. Deodorizer cover 10. Remote control wall mount 5. Carbon deodorizer cartridge 11. -
Page 11: Before Installation
PRODUCT INSTALLATION Before Installation CAUTION Do not plug the product in while the unit is upside down. This may cause damage to the internal components. Residual moisture is normal Every product is tested with pure water during production to ensure the highest quality and performance. -
Page 12: Swash Installation
PRODUCT INSTALLATION Swash Installation Please read these instructions carefully before 3. Connect the top of the T-Valve to the installing the Swash. Failure to do so could incoming water connection on the result in flooding, leaking, or damage to the bottom of your toilet tank product. - Page 13 PRODUCT INSTALLATION Swash Installation (Cont’d) 5. Installing mounting plate Steps 5b–5d a. Wet the rubber anchors with water, squeeze the sides of the anchors, and firmly press them all the way down into the mounting holes on top of the toilet. TIP: Wetting the rubber anchors will allow for easier installation.
- Page 14 PRODUCT INSTALLATION Swash Installation (Cont’d) 7. Connect the bidet hose to the seat 9. Connect the open end of the bidet hose to the T-Valve Connect the bidet hose to the water inlet and hand-tighten to secure; take care not to twist the bidet hose, excessively bend Step 9 it, or strip the plastic screw threads when...
-
Page 15: External Bidet Filter Installation
PRODUCT INSTALLATION External Bidet Filter Installation (optional, not included) 4. Connect the bidet hose to the male NOTE: Customers with hard water, end of the Swash filter well water, and softened water can extend the life of their bidet seat by Step 4 purchasing and installing an external inline water filter to be used with the... -
Page 16: Product Operation
PRODUCT OPERATION Remote Control 1. Battery installation and remote pairing a. Insert 3 AAA batteries (included) into the remote within 5 minutes of plugging the seat into a GFCI outlet. b. After inserting batteries, a blue light on the remote will turn on. c. - Page 17 PRODUCT OPERATION Remote Control (Cont’d) 1. Stop Button 10. Deodorizer Button Stops all wash and dry functions Deodorizer is defaulted to automatically currently operating. turn on when seated (indicator light is ON). Press button to turn the auto 2. Rear Wash / Move Button deodorizer off (indicator light is OFF).
-
Page 18: Auxiliary Control Panel
PRODUCT OPERATION Auxiliary Control Panel Basic functions such as rear wash and front wash can be used without the remote by utilizing the auxiliary touch control panel located on the side of the bidet seat. 1. Front Wash Swipe finger toward the front to initiate a front wash utilizing the last settings used. -
Page 19: Using The Swash: Getting Started
PRODUCT OPERATION Using the Swash: Getting Started Warm air dryer NOTE: The seat has a built-in skin Press the Dry button to activate the warm air conductivity sensor. The wash dryer. The dryer will run for 2 minutes and functions will not work unless the turn off automatically. -
Page 20: Special Mode Operations
PRODUCT OPERATION Special Mode Operations Deodorizer Factory Default Reset 1. The deodorizer is defaulted to 1. Factory reset can only be performed automatically turn on when seated. When when the seat is not occupied. the auto deodorizer is on, the deodorize 2. - Page 21 PRODUCT OPERATION Special Mode Operation: Memory Functions Using User 1 and User 2 Memory Function User Memory Settings The Swash User 1 and User 2 memory 1. Sit on the seat and select User 1 or functions allow you to program your User 2.
-
Page 22: Expert Mode Operations Level 1
PRODUCT OPERATION Expert Mode Operations Level 1 Expert Mode Operations Level 1 allows the user to turn Eco Mode, Silent Mode, or Seat Sensor Override ON and OFF. Using the remote, follow steps 1–3 to enter, program, and exit Expert Mode Level 1. 1. - Page 23 PRODUCT OPERATION Expert Mode Operations Level 1 (Cont’d) 2. Programming 3. Exit Expert Expert Modes (cont’d) Mode Level 1 Seat Sensor Override Press/hold STOP & Nozzle Cleaning for Seat Sensor Override bypasses the body 2 seconds. sensor located in the seat and allows the wash and dry functions to operate without engaging skin to seat contact.
-
Page 24: Expert Mode Operations Level 2
PRODUCT OPERATION Expert Mode Operations Level 2 Expert Mode Operations Level 2 allows for Expert Mode status with the seat sensor customizing and changing the cycle times overridden and turned off, and with the seat for Rear Wash, Front Wash, Strong Wash, unoccupied. - Page 25 PRODUCT OPERATION Expert Mode Operations Level 2 (Cont’d) 2. Changing Cycle Times (cont’d) 3. Exit Expert Mode Level 2 Warm Air Dryer Gentle Wash Gentle Wash 1. Turn ON seat Dry Cycle sensor - place hand (default 2 min) (default 1.5 min) on right area of (default 2 min) seat.
-
Page 26: Maintenance
If necessary, replacement 10 times before retracting. seat parts can be purchased through f. Pressing the Stop button at any time will Brondell customer support. cancel the nozzle cleaning process. g. Pressing the Nozzle Cleaning button during a self-clean will interrupt the process;... -
Page 27: Mesh Filter And Carbon Deodorizer Cartridge
MAINTENANCE Mesh Filter and Carbon Deodorizer Cartridge Cleaning the mesh filter Replacing the carbon deodorizer cartridge Cleaning intervals will differ depending on use We recommend replacing the carbon deodorizer cartridge every 6 months. and water quality. It is recommended to check the filter at least once per year. -
Page 28: Product Storage
MAINTENANCE Product Storage Short term non-use If the product will not be used for more than a few weeks, you can simply unplug it. You may also consider shutting the water supply off at the wall for extra precaution. Long term non-use If the product will not be used for an extended time (longer than 4 months), you should unplug the unit, shut the water... -
Page 29: Technical Information
TECHNICAL INFORMATION Troubleshooting If the bidet appears to be operating Check before continuing: abnormally, please review the Make sure the bidet seat is connected troubleshooting tips. to power and that the outlet is working properly. Make sure you check & test the reset button on the GFCI outlet (Standard 120V GFCI outlet). - Page 30 TECHNICAL INFORMATION Troubleshooting (Cont’d) Problem Possible Cause(s) Solution(s) Low water flow or 1. Clogged filter 1. Remove, clean, and reinstall mesh spray pressure 2. Water supply valve not filter (see maintenance section on opened fully page 27) 3. Nozzle is dirty 2.
- Page 31 TECHNICAL INFORMATION Troubleshooting (Cont’d) Problem Possible Cause(s) Solution(s) Water temp lights Water supply not Make sure that the bidet hose is blinking connected properly correctly connected and tight, and that water supply shut off valve is open Seat is not heated 1.
-
Page 32: Product Specifications
TECHNICAL INFORMATION Product Specifications SWASH ECO THINLINE T66 ELECTRONIC LUXURY BIDET TOILET SEAT Model T66-EW Power Voltage 120 V / 60 H Max Power Consumption 1470 W Supply Water Pressure 7.11 psi–106.7 psi / 0.05 MPa–0.74 MPa Dimensions Elongated: 20.7” x 15“ x 3.9” / 52.6 cm x 38.1 cm x 9.9 cm Weight Elongated: 8.7 lb / 3.9 kg... -
Page 33: Regulatory And Safety Notices
TECHNICAL INFORMATION Regulatory and Safety Notices USA: Federal Communications Commission Canada: Industry Canada (IC) Statement (FCC) Statement This device meets the IC requirements for RF This device complies with Part 15 of the FCC exposure in public or uncontrolled environments. Rules. -
Page 34: Warranty
BRONDELL reserves the right to make such inspections as may be necessary to determine the cause of the defect. BRONDELL will not charge for labor or parts in connection with warranty repairs for the first year from date of purchase on all products except those that may be subject to commercial use limitations.
