ORDER NO. MD0605170C3
Speaker System
SB-WVK650EE
Colour
(S)... Silver Type
SPECIFICATIONS
Specification
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-WVK650EE and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic SB-WVK650EE

Summary of Contents for Panasonic SB-WVK650EE

  • Page 1 ORDER NO. MD0605170C3 Speaker System SB-WVK650EE Colour (S)... Silver Type SPECIFICATIONS Specification...

  • Page 2: Assembling And Disassembling

    2. Total harmonic distortion is measured by the digital spectrum analyzer. Music Center : SA-VK650EE-S System : SC-VK650EE-S Front Speaker : SB-VK650EE-S Subwoofer : SB-WVK650EE-S 2006 Matsushita Electric Industrial Co. Ltd.. All rights reserved. Unauthorized copying and distribution is a violation of law. 1. Assembling and Disassembling “ATTENTION SERVICER”...
  • Page 3 4. Refer to the Parts No. on the page of “Parts Location and Replacement Parts List” (Section 5), if necessary. Below is the list of disassembly sections - Disassembly of Front panel assembly - Disassembly of Woofer guard - Disassembly of Woofer 1.1.
  • Page 4 make a gap allowance between the front panel assembly and wooden cabinet assembly as arrow shown. Step 2: Insert a flathead screwdriver into the groove as shown. Ensure that the screwdriver is above the steel rule.
  • Page 5 Step 3: At the boss area, push up as arrow shown to open the bosses. Caution: Do not exert strong force as it may damage front panel assembly. 1.3. Disassembly of Woofer guard...
  • Page 6 Step 1: Remove 4 screws. 1.4. Disassembly of Woofer Step 1: Remove 4 screws.
  • Page 7 Step 2: Detach the (+) red and (-) black wires. - Disassembly of Wooden cabinet assembly Follow (step 1) to (step 3) in item 1.2. Follow (step 1) in item 1.3. Follow (step 1) to (step 2) in item 1.4. 1.5.

  • Page 8: Connection Of The Speaker Cables

    Step 1: Scrape off using the scriber and clean up the remaining glue at the 8 bosses and 8 holes of the front panel assembly and wooden cabinet assembly and replace with new glue. Step 2: Fix the front panel assembly firmly back to the wooden cabinet assembly. 2.
  • Page 9 cords do not have vinyl tips, connect them directly to the terminals. Make sure the bare ends of the wires are not unravelled. 2. Insert the wire to the rear panel of the unit and close the lever. Notes : - To prevent damage to circuitry, never short-circuit positive (+) and negative (-) speaker wires.
  • Page 10 Positioning for best effect 1. You cannot take the front net off the speakers. 2. Set the speakers up on an even surface to prevent them from falling. Take proper precautions to prevent the speakers from falling if you cannot set them up on an even surface. 3.

  • Page 11: Exploded View

    4. Exploded view 4.1. Cabinet Parts Location 4.2. Packaging...

  • Page 12: Replacement Parts List

    5. Replacement Parts List Notes : - Important safety notice : When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list. - [M] markings in the Remarks columns indicates parts supplied by PAVCSG.
  • Page 13 Ref. No. Part No. Part Name & Description Remarks CABINET AND CHASSIS RYKX0332-S WOODEN CABINET ASSY RMQX0202-K EVA PACKING (PORT) RMQX0205-K EVA PACKING (PORT) RYBX0142-S FRONT PANEL ASSY RMQX0171-W HIMELON (TOP/BTM) RMQX0172-W HIMELON (SIDE) RKA0072-KJ LEG CUSHION RGNX0386-K SPEC SHEET XTB4+16AFJK SCREW(STAND) RGPX0263-S...
