EB A-038105-04 User Manual

Gen 3 batteries
Hide thumbs

Advertisement

Table of Contents

U S E R MA N UA L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A-038105-04 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EB A-038105-04

Summary of Contents for EB A-038105-04

  • Page 1 U S E R MA N UA L...
  • Page 2 ® FOR MORE PRODUCT INFO AND INSTALLATION INSTRUCTIONS S CAN C O D E O R VI S IT www.ecobattery.com/quickstart User Manual - Gen 3 Batteries...
  • Page 3 ® THANK YOU FOR YOUR PURCHASE! R E G I STE R YO U R BAT TE RY Your battery must be registered within 90 days of purchase to activate your full duration limited warranty. Batteries not registered within 90 days of purchase will carry a 1 year limited warranty only! www.ecobattery.com/register User Manual - Gen 3 Batteries...

  • Page 4: Lithium Batteries

    LITHIUM BATTERIES Models Covered: 51.2V 105Ah 51.2V 60Ah 38.4V 105Ah A-051105-03 A-051060-05 A-038105-04 51.2V 160Ah 51.2V 105Ah 70.4V 105Ah A-051160-06 A-051105-01 A-070105-06 User Manual - Gen 3 Batteries...
  • Page 5 READ BEFORE INSTALL HEAVY HIGH VOLTAGE DO NOT PRESSURE CHARGE BATTERY TEAM LIFT REQUIRED HANDLE WITH CARE WASH OR SUBMERGE BEFORE USE WAR N I N G S U S E & CAR E • High Voltage. DO NOT install or service this •...

  • Page 6: Bat Te Ry C O M P O N E Nts

    BAT TE RY C O M P O N E NTS POWER BUTTON POSITIVE TERMINAL NEGATIVE TERMINAL 7 PIN COM PORT 5 PIN COM PORT (Remote Wake-up Button) (CAN Connection) STATE OF CAN CONNECTORS CHARGE METER WAKE-UP BUTTON User Manual - Gen 3 Batteries...
  • Page 7 Q U I C KSTART G U I D E Bolt Converter Charger Controller Motor Controller Solenoid Battery Ring terminals should be stacked largest to smallest, with the largest cable (highest draw) nearest to the battery. b+ b- 110v - 220v POSITIVE AC Outlet Battery Charger...
  • Page 8 P OWE R I N G O N YO U R BAT TE RY POWER BUTTON POWER BUTTON Gen3 batteries utilize a momentary (non-latching) on/o button. To power the battery ON, press/hold the button until the green LED illuminates (~1 sec), then release. The LED indicator on the button will illuminate anytime the battery is powered on. To power the battery OFF, press/hold the power button, then release it when the LED indicator begins to ash (~3 sec).
  • Page 9 C HAR G I N G CHARGER Use only genuine Eco Battery lithium chargers, or a lithium charger speci cally approved by Eco Battery. This will ensure optimal charging and extend the battery’s service life. DO NOT USE UNAPPROVED BATTERY CHARGERS OR TENDERS. DO NOT CONNECT DC OUTPUT CABLES TO BATTERY WITH REVERSE POLARITY.
  • Page 10 CAN C O M M U N I CATI O N S CAN CONNECTORS The two connectors located on your meter cable are CAN communication ports used for diagnostics or CONNECTORS communicating with a charger or motor controller. Some battery chargers are CAN enabled and will have a male CAN plug to connect to either one of the two CAN ports. If your charger is CAN enabled, the charger will NOT charge unless CAN is connected.
  • Page 11 STATE O F C HAR G E M ETE R (S O C%) BATTERY VOLTAGE: The voltage will vary based on the current load or charge placed on the battery. STATE OF CHARGE: The state of charge is displayed in percent. 0% = empty | 100% = full 100 - 50% = Green 49 - 20% = White.

  • Page 12: Power Save Mode

    P OWE R SAVE M O D E Your battery is programmed to enter Power Save Mode after extended periods of inactivity. Power Save Mode will ensure that your battery will not be fully depleted in the event that your cart sits for an extended period of time. All golf carts have some degree of power consumption while sitting idle (even with the key o ), and Power Save Mode will ensure that your battery will not be completely depleted upon your return.

  • Page 13: C O L D Weath E R

    C O L D WEATH E R Your battery is equipped with a temperature sensor that will shut it down in temperatures below -4 °F. This feature protects the battery from cell damage caused by excessively low operating temperatures. While your battery will discharge down to -4°F, it will not accept any type of charge below 32°F. This includes plug in charging as well as regenerative charging from your cart’s motor controller.
  • Page 14 H EATE D BAT TE RY (S E L E CT S K U S O N LY) Auto Heating Your particular Eco Battery lithium battery model may be equipped with an internal heater. This heater is fully automatic and requires no input or programming by the user. The purpose of this heater is to enhance cold weather performance and operation, and to allow complete battery charging in ambient temperatures down to -30°F.
  • Page 15 B M S E R R O R C O D E S CODE ERROR DESCRIPTION LEVEL Level 1 = MOS Error External Short Circuit Serious Fault. Cell Di erential Will not self-resolve. Cell Over Voltage Contact Eco Battery Cell Under Voltage Pack Over Voltage Level 2 = Pack Under Voltage...

  • Page 16: Need More Help

    ® N E E D M O R E H E L P? 877-326-2288 support@ecobattery.com For additional product info, user manuals, user guides, and warranty information visit https://ecobattery.com/pages/quickstart DOWNLOAD OUR APP! User Manual - Gen 3 Batteries...
  • Page 17 ®...

This manual is also suitable for:

A-051105-03A-051060-05A-051160-06A-051105-01A-070105-06
