Toshiba IK-WB01A Advanced User's Manual

Hide thumbs Also See for IK-WB01A:

User manual (142 pages)

Advanced user's manual (119 pages)

Quick start manual (4 pages)

Table Of Contents

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

Quick Links

Download this manual

NETWORK CAMERA

: IK-WB01A

Model

IK-WB11A

Advanced User's Guide

For information on the latest products and peripheral devices, refer to

the following Web page.

■ http://www.netcam.toshiba.com

The above URL is subject to change without prior notice. If the URL

changes, refer to theToshiba website

(http://www.toshiba.com/taisisd).

All manuals and user guides at all-guides.com

Table of Contents

Need help?

Do you have a question about the IK-WB01A and is the answer not in the manual?

Questions and answers

Summary of Contents for Toshiba IK-WB01A

Page 1 All manuals and user guides at all-guides.com NETWORK CAMERA : IK-WB01A Model IK-WB11A Advanced User's Guide For information on the latest products and peripheral devices, refer to the following Web page. ■ http://www.netcam.toshiba.com The above URL is subject to change without prior notice. If the URL changes, refer to theToshiba website (http://www.toshiba.com/taisisd).
Page 2 All manuals and user guides at all-guides.com Product Name : NETWORK CAMERA Tested To Comply Model Number(s) : IK-WB01A, IK-WB11A With FCC Standards FOR HOME OR OFFICE USE FCC Notice "Declaration of Conformity Information" This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Warning : Changes or modifications made to this equipment, not expressly approved by Toshiba or parties authorized by Toshiba could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :...
Page 3: Introduction
All manuals and user guides at all-guides.com Introduction Thank you for purchasing the IK-WB01A/IK-WB11A Network Camera. Before you start using the camera, read this User's Guide carefully to ensure correct usage. Once you have finished reading this User's Guide, keep it in a convenient place for future reference. The design, specifications, software, and User's Guide contents are subject to change without prior notice. IK-WB01A is designed for indoor-use only. You may use IK-WB11A either inside or outside. Terms and Trademarks ● The term "OS" is used in this manual to indicate operating systems compatible with this product. − Windows 98SE: Microsoft ® Windows ® 98 operating system; Second Edition − Windows 2000: Microsoft ® Windows ®...
Page 4: Accessories
All manuals and user guides at all-guides.com Introduction (Cont.) Accessories Confirm that all of the following accessories have been supplied with the network camera. ● Accessories common to IK-WB01A and IK-WB11A AC adaptor (x1) Basic User's Guide (x1) Power cord (x1) Quick Start Guide (x1) ● Accessories for IK-WB01A Screw set Wall attachment for ・Self-tapping screw (x1) indoor use (x1) (Black) ・Wood screws (x4) (Silver) Wire clamp (x1) LAN cable (Straight- through cable)(x1) Clamp filter(x2) ※ Put the Clamp filter to both ends of your LAN cable. ● Accessories for IK-WB11A Rear cover (waterproof cover Sun visor (x1) Wall bracket (x1) and attachment holder for indoor and outdoor installation) with a...
Page 5: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Introduction ● Introduction ....................... 3 Terms and Trademarks ................... 3 ・ Accessories ......................4 ・ ● Table of Contents ....................5 ● IMPORTANT SAFETY INSTRUCTIONS ............7 ● Precautions for Use ....................8 About the SD Memory Card (IK-WB11A only) ..........8 ●...
Page 6 ・ ● Updating the Firmware ..................89 Initial Procedure ....................89 ● Others ● Alarm Terminals ....................94 ● Glossary (Index) ....................96 ● Errors and Messages ..................101 ● Before Calling Service Personnel................106 ● Specifications ..................... 116 ● Appearance Diagram (IK-WB01A) ............... 117 ● Appearance Diagram (IK-WB11A) ............... 118...
Page 7: Important Safety Instructions
All manuals and user guides at all-guides.com IMPORTANT SAFETY INSTRUCTIONS When using this camera, always follow basic safety precautions to reduce the risk of fire, electric shock, or personal injury. Read and understand all the instructions. Keep the User's Guide for future reference. Heed all warnings. Follow all the instructions. Wipe off any dust on the camera lens with a lens-cleaning cloth. Do not place the camera near any heat sources such as radiators, heat registers, stoves, or other devices (including amplifiers) that produce heat. Protect the power cord from being stepped on or pinched particularly at plugs. convenience outlet, and the point where they exit from the unit. Use only specified attachments/accessories such as stands, tripods, and brackets. Do not touch the camera or the AC adaptor during lightning storms. 10. Unplug the power cord when you do not use the camera for a long period of time. 11. Refer all the services to qualified service personnel. Repairing is required when the camera has been damaged in any way, such as :if power cord or plug is damaged; the camera does not operate normally, the camera has fallen to the ground.
Page 8: Precautions For Use
● The camera supports the following SD memory cards. Do not use memory cards with other specifications. SD memory card: 8, 16, 32, 64, 128, 256, and 512 MB SD memory cards (3.3 V) supported. Physical interface: Part 1. Physical Layer Specification; Version 1.01 ● Images may not be recorded or read correctly if an unsupported SD memory card is used with the camera. ● Carefully read the User's guide, precautions on use, and any other information supplied with a purchased memory card. ● An SD memory card can be used for the loop recording of images. The life- span (number of rewrites possible) of an SD memory card is greatly affected by the capacity of the SD memory card. The use of a 128, 256, or 512 MB large-capacity SD memory card is recommended for loop recording. ● To achieve maximum performance of the camera, the use of a Toshiba SD memory card is recommended. If a card of another company is used, the recording intervals may lengthen and the erasure time during overwriting may increase. As a result, the number of delivered frames of live video may decrease. ● Do not use a memory card containing the data recorded by another device with the camera as this may result in the camera not functioning correctly. ● Do not modify, overwrite the data, or change the folder name of an SD memory card. It may result in the camera not to function correctly. ● Data recorded with the camera do not comply with the image file format Exif and the DCF standard. If the SD memory card is to be removed to play images, use a personal computer to play the images. Other devices may not be capable of displaying the images. Caution for wireless mode ● During wireless mode operation, try to leave minimum of 20cm (8 inches) spacing between people and the equipment.
Page 9: About The Ac Adaptor
All manuals and user guides at all-guides.com About the AC adaptor Be sure to use only the supplied AC adaptor. Using a different AC adaptor may cause the camera to malfunction, heat up, or catch fire. Before using the AC adaptor, carefully read and observe the IMPORTANT SAFETY INSTRUCTIONS (→ page 7) and the notes below. Do not allow the connectors on the AC adaptor to come into contact with any ● other metal object as this may result in short circuit. To connect the AC adaptor, firmly insert the plug on the end of the cable into ● the AC adaptor jack. Do not insert the plug into other jacks as this may cause a malfunction. When removing the connection cable, disconnect the cable by holding its plug. ● Do not disconnect the cable by pulling on the cable. Do not drop the AC adaptor or subject it to strong impact. ● Do not use the AC adaptor in hot and humid places. ● Do not use the supplied AC adaptor with devices other than this camera. ● Temperature increasing on the surface of the adaptor is normal. Before moving ● the adaptor to another location, unplug it from the wall outlet, and wait until its temperature decreases. Buzzing noises may come from inside. This does not indicate malfunction. ● Using the AC adaptor near a radio, TV, or cellphone may cause interference. ● Use the adaptor at sufficient distances from these devices. Specifications AC adaptor (AC-WB10) Power supply : 100 to 240 V AC, 0.5 A, 50/60 Hz Rated output...
Page 10 All manuals and user guides at all-guides.com...
Page 11: Viewing・Listening And Operation
All manuals and user guides at all-guides.com Viewing・Listening and Operation ● Camera Administrator and User ● Viewing and Listening (Administrator) ● Operation of Live Camera Images by Administrator ● Using Playback Function ● Presetting of Camera Con- ditions by Administrator ● Playing Recorded Alarm Images by Administrator ● Playing Recorded Normal Images by Administrator (IK-WB11A) ● Viewing and Listening (Users)
Page 12: Camera Administrator And User
All manuals and user guides at all-guides.com Camera Administrator and User This User's Guide explains use of the camera from the standpoints of the administrator and the user. This distinction is difficult to make, because normally the owner of a network camera is an administrator and a user. Therefore, the following will explain the use of the camera from both standpoints. The network camera serves four main functions. (1) Viewing camera images (2) Listening to sound from the camera (3) Operating the camera (4) Configuring the camera Whether each function is made available for the administrator and the user is determined for both standpoints from consideration of "what will be done" with the network camera. "Administrator" indicates the standpoint where all the functions of the camera can be used and "user" indicates the standpoint where functions such as the configuring of camera parameters are restricted. The camera differentiates between the administrator and the user via authentication at login. The following shows the different functions that are available for the administrator and the user. Function Administrator User Live images ○ ...
Page 13: Viewing And Listening (Administrator)
All manuals and user guides at all-guides.com Viewing and Listening (Administrator) The viewing of images, listening sound and operating cameras are not restricted to the administrator. The administrator can use all the functions. However, it is necessary for the administrator to log in through the "Administrator Login" screen, because an administrator who logs in from the "User Login" screen is subject to the same restrictions as users. How to view images, listen sound and operate cameras are explained after the following administrator login procedure. ※ Install "JAVA 2" to display images and output sound correctly on an administrator's personal computer.(→ Basic User's Guide page 12) Administrator Login You must enter the administrator's login ID and password first so that you can be verified as an administrator on the network camera. With the Internet browser displayed on the administrator's personal computer, enter the following URL and press ENTER http://192.168.0.30/admin.htm (When IP address is in default setting) If you enter this URL, the "Administrator Login" screen appears. Correctly enter the administrator login ID and the password, and then click the ...
Page 14: Viewing Images By Administrator
All manuals and user guides at all-guides.com Viewing and Listening (Administrator) (Cont.) Important At the time of purchase, the login ID is "root." and the password is "ikwb." For ● security reasons, change the login ID and password settings immediately (→ Basic User's Guide page 39). For the security reasons, if you leave the Admin Menu screen for more than ● 5 minutes without taking any actions, it automatically logs you out. If you were logged out, try login procedure to log in again. Viewing Images by Administrator ■ Viewing Images in Single-View Mode by Administrator If the Administrator Login was performed correctly, a window containing the Admin Menu appears. Click the LIVE button NOTE LIVE The boosted single-view mode screen by clicking the button is displayed ● in the same size as that of the sent image size from the camera. However, 1280x960size of IK-WB11A is compressed into 800x600 when displayed. You may change the size of single-view mode screen bigger or smaller as ● much as you want. You may not see the full camera name or time display when you change the ● picture size to smaller one, but these will be fully displayed when you make the size bigger.
Page 15 All manuals and user guides at all-guides.com To close the camera image, click the button in the upper-right corner of the window For an explanation on each component of the Single-View Mode window, refer to the table below. Number and Item Description ① Camera name The name of the camera displaying live images. ② Alarm notification This is displayed if the network camera detects motion (→ page 54) or an alarm goes off (→page 51). The Alarm Alarm disappears if it is clicked. ③ Time and date The current time and date of the accessed network camera. ④ Switch views Clicking the button switches the single-view Multi view mode to multi view. For details on multi view, refer to Multi view "Viewing Images in Multi-View Mode by Administrator" (→page 17). ⑤ Switch sound on/off If you click the button, the button changes to and outputs the sound. Clicking the button changes the icon back to and stops the sound. ⑥ Display controller Clicking the button displays the controller in a separate window. ...
Page 16: Logging Out From Camera (Log Off)
All manuals and user guides at all-guides.com Viewing and Listening (Administrator) (Cont.) ■ Logging out from Camera (Log Off) Click button in the upper-right corner to close the camera image window Click button in the left side of the Admin Menu The message, "Settings Completed." will be displayed. Click button Close NOTE Do not close the Admin Menu when the single-view or multi-view screen is ● displayed. If you click the button when image screen is still displaying, the camera perceives it as the proof that you are still logged in. Remember, if this happens, you cannot log in again for 5 minutes.
Page 17: Viewing Images In Multi-View Mode By Administrator
All manuals and user guides at all-guides.com ■ Viewing Images in Multi-View Mode by Administrator At Step 2 on the previous page, click the Multi view button in the upper-right corner of the window ・ The Multi-View mode window appears. This window is automatically split into frames in accordance with the Multi-screen mode setting (→ page 79) for the number of cameras to display. For details on the number of cameras and multi-view mode, refer to "Multi-Screen Mode Window Configuration" (→ page 18). ・ button will not be displayed when you set "Multi-Screen Mode" Multi view setting to "OFF." (→ page 79) Operating the multi-view mode For an explanation on each component of the window, refer to "Multi- Screen Mode Window Components."(→ page 18) To close the camera images, click the button in the upper-right corner of the window...
Page 18 All manuals and user guides at all-guides.com Viewing and Listening (Administrator) (Cont.) ● Multi-Screen Mode Window Configuration Number of Cameras Selected (Including Administrator' s Camera) Configuration 1 to 4 2×2 5 to 9 3×3 10 to 16、17 or more※ 4×4 ※ More than 16 cameras cannot be displayed simultaneously in the window. Select the cameras you want to display. (→ page 79) ● Multi-Screen Mode Window Components Number and Item Description ① Camera name Each individually given camera name is displayed in the corresponding camera screen. ② Alarm notification This icon is displayed for each network camera that detects motion (→page 54) or generates external alarm (→page 51). In the example window, the icon in the Alarm upper-left screen indicates that an alarm has gone off for the back door, and the icon in the lower-right screen indicates that an alarm has gone off for the garage. Usually (when no motion is detected or no alarm goes off), this icon does not appear. For details on the operations that you can perform when this icon appears, refer to "Playing Recorded Alarm Images by Administrator" (→page 29). ③ Time and date ...
Page 19: Operation Of Live Camera Images By Administrator
All manuals and user guides at all-guides.com Operation of Live Camera Images by Administrator In administrator single-view or multi-view mode, click the button ・The basic administrator controller is displayed in a separate window. Use the controller to operate images For an explanation on each component of the administrator controller, refer to "Basic Administrator Controller Components" (→ page 20). To close the controller, click the button in Close the upper-right corner of the window...
Page 20 All manuals and user guides at all-guides.com Operation of Live Camera Images by Administrator (Cont.) ● Basic Administrator Controller Components Item Description Close Close Clicking the button closes the controller. Close Auto Patrol The Auto Patrol feature moves the lens automatically to all the configured preset positions in order. Clicking Auto Patrol the button starts Auto Patrol. If you do not Auto Patrol want to display images captured while the lens is moving, enable the Freeze Activity function (→page 66). This allows you to view images at the preset positions only. Clicking one of buttons stops the action. Scan The Scan feature automatically moves (swivels) the lens horizontally back and forth once. Clicking the Scan Scan button starts Scan. Clicking one of buttons stops the action. 1 Shot This function converts an image to a picture data on 1 Shot the computer, and displays it on a new window. You ...
Page 21 All manuals and user guides at all-guides.com Item description Back Light This feature performs back light compensation. Clicking the button performs back light compensation. Back Light Back Light Clicking the button again cancels compensation. Zoom in This feature enables you to enlarge camera images by up to 5 times. Each click of the button gradually Zoom in Zoom in enlarges images in the window. This feature enlarges images on the computer which have been received once, and not the direct image from the camera. Therefore, quality may deteriorate if you use this feature. ※Dragging the mouse pointer to enlarge the size of the window continuously enlarges the images. Zoom out This feature enables you to the reduce camera images enlarged with Zoom in. Each click of the button gradually Zoom out Zoom out reduces the images in the window. Once the images have been reduced to their actual size, you cannot zoom out anymore. ...
Page 22: Using Playback Function
All manuals and user guides at all-guides.com Using Playback Function If you use this function when you are viewing live images, you can play and see the images of which right before you use the function. This function is valid only when the LIVE icon is displayed on the lower part of the single or multi- view mode screen. The length of the time of recorded images differs depending on the picture size and the quality. (It plays for approximately 1 minute when the size is 640x480 and the quality is MIDDLE.) In administrator single-view or multi-view mode, click the button ・ The basic administrator controller is displayed in a separate window. Use the controller to operate For an explanation on each component of the controller, refer to "Basic Administrator Controller Components" (→ page 23). Close To close the controller, click the button in the upper-right corner of the window...
Page 23 All manuals and user guides at all-guides.com ● Basic Administrator Controller Components Item Description Other camera Refer to page 20. operation buttons This is the Rewind feature. Clicking the button Rewind rewinds the recorded images in the window. This is the Frame Backward feature. Clicking the Frame Backward button rewinds back the recorded images in the window by one frame. This is the Pause feature. Clicking the button Pause pauses the recorded images in the window. This is the Frame Forward feature. Clicking the Frame Forward button forwards the recorded images in the window by one frame. ...
Page 24: Presetting Of Camera Conditions By Administrator
All manuals and user guides at all-guides.com Presetting of Camera Conditions by Administrator The presets function enables you to register up to ten different angles and names for the camera. Clicking the button on the basic administrator Preset controller opens the preset controller. ※ You cannot register zoom information.
Page 25: Selecting A Preset
All manuals and user guides at all-guides.com Selecting a Preset Selecting a pre-registered preset from the Preset list of the preset controller switches to the preset lens angle. In the list, click the radio button on the left of the preset you want to select Click the Go button ・ The lens moves to the pre-registered position of the preset. If a position was not registered for the preset you selected, the lens does not move. Moving the lens using this feature requires the position of the preset to be registered beforehand. See "Configuring a Preset" in next page.
Page 26: Configuring A Preset
All manuals and user guides at all-guides.com Presetting of Camera Conditions by Administrator (Cont.) Configuring a Preset Register the lens position in the Preset list. Click the button to move the camera lens to the position you want to set In the list, click the radio button on the left of the preset you want to configure Click the button ・Register the current lens position in the selected preset. NOTE Any existing settings of a preset will be overwritten when you register new ● settings to the preset.
Page 27: Deleting Preset Settings
All manuals and user guides at all-guides.com Deleting Preset Settings You can delete the lens position setting of a preset in the Preset list. In the list, click the radio button of the preset setting you want to delete Clear Clear Click the button ・The settings registered for the selected preset are deleted. NOTE Clicking Clear button also deletes the registered preset name. Clear ●...
Page 28: Naming/Renaming Individual Presets
All manuals and user guides at all-guides.com Presetting of Camera Conditions by Administrator (Cont.) Naming/Renaming Individual Presets You can name each preset in the Preset list. This makes it easier to distinguish individual preset settings. In the list, click the radio button on the left of the preset you want to name Name Name Click the button ・A window for naming the preset and the button appears. Save Save Save Save Enter a new name and click the button ・The name appears instead of the preset number.
Page 29: Playing Recorded Alarm Images By Administrator
All manuals and user guides at all-guides.com Playing Recorded Alarm Images by Administrator The administrator can play images which are recorded when alarm goes off. The images play at fixed intervals regardless of the setting at the time of recording. Image settings such as "Camera Picture Size" correspond to the settings at the time the alarm went off. How to play a recorded image In administrator single-view or multi-view mode, click the button ・ The basic administrator controller is displayed in a separate window. Click the button Alarm ・The administrator controller for the Alarm list is displayed. NOTE When the administrator controller for the Alarm list is displayed, you can ● also use all of the features explained in "Basic Administrator Controller Components" (→ page 20). Items in the Alarm list appear from left to right in the order of list number, ● alarm type, generation time/date, and play button. If you click the button at the bottom of the screen, the list of previous ten ● alarms appears. If you click the button, the list of next ten alarms appears. If you click the Alarm tab, the administrator controller returns to its original ● size.
Page 30 All manuals and user guides at all-guides.com Playing Recorded Alarm Images by Administrator (Cont.) In the list, click the button on the right of the recording you want to play ・The recording selected in the Alarm list plays. NOTE You can use the control buttons when playing a recorded image to, for ● example, rewind or fast-forward. To return from the recorded image to the live image screen, click the ● button. While the Alarm list is displayed, click the tab to switch to the Preset Preset ● list and the tab to switch to the Record list. Record When playing recorded alarm images, the camera will not record new alarm ● notification. When new alarm has been generated while the alarm controller is displayed, ● the notification will not be added to the list right away. In that case, close the controller once and re-display it. ● Alarm List Controller Components Item Description Other camera Refer to page 20. operation buttons ...
Page 31: Playing Recorded Normal Images By Administrator (Ik-Wb11A)
All manuals and user guides at all-guides.com Playing Recorded Normal Images by Administrator (IK-WB11A) The administrator can play recorded normal images saved to an SD memory card. The images play at fixed intervals regardless to the setting at the time of recording. Image settings such as "Camera Picture Size" correspond to the settings at the time of recording. How to play the recording In administrator single-view or multi-view mode, click the button ・ The basic administrator controller is displayed in a separate window. Click the button Record ・The administrator controller for the Record list is displayed. NOTE When the administrator controller for the Record list is displayed, you can ● also use all the functions explained in "Basic Administrator Controller Components" (→ page 20). Items in the Record list appear from left to right in the order of list number, ● generation time/date, and play button. If you click the button at the bottom of the screen, the list of previous ten ● recordings appears. If you click the button, the list of next ten recordings appears. If you click the tab, the administrator controller returns to its original Record ●...
Page 32 All manuals and user guides at all-guides.com Playing Recorded Normal Images by Administrator (IK-WB11A) (Cont.) In the list, click the button on the right of the recording you want to play ・The recording selected in the Record list plays. NOTE You can use the control buttons when playing a recorded image to, for ● example, rewind or fast-forward. To return from the recorded image to the live image screen, click the ● button. While the Record list is displayed, click the tab to switch to the Preset ● Preset list and the Alarm tab to switch to the Alarm list. Operation of recorded normal images is the same as the operation of recorded ● alarm images (→ page 29). Normal images are recorded by the hour. ● The camera cannot record normal images when playing recorded normal ● images. ● Record List Controller Components Item Description Other camera Refer to page 20. ...
Page 33: Viewing And Listening (Users)
All manuals and user guides at all-guides.com Viewing and Listening (Users) The viewing and listening are not restricted for users. However, the administrator may restrict the use of features. Basically, users can operate the lens from a remote location, but cannot configure camera presets or view recorded images. For details, refer to "Camera Administrator and User" (→ page 12). How to view images, listen sound and operate cameras are explained after the following user login procedure explanation. ※ Install "Java 2" to display images and output sound correctly on a user's personal computer, (→ Basic User's Guide page 12). User Login If the administrator sets "User Restrictions" to "ON," users cannot access a camera unless they enter the user information (user ID and password) which the administrator configured. Viewing Images in Single-View Mode by Users With the Internet browser displayed on the user's personal computer, enter the following URL and press ENTER http://192.168.0.30/ (When IP address is in default setting) ・If you enter this URL, the User Login screen appears. NOTE The login screen differs depending on whether or not the administrator is ● restricting the user. When there is no user restriction, login ID and password entering fields will not be displayed. The boosted single-view mode screen by clicking the LIVE button is displayed ● in the same size as that of the sent image size from the camera. However, 1280x960size of IK-WB11A is compressed into 800x600 when displayed. You may change the size of single-view mode screen bigger or smaller as much as you want.
Page 34 All manuals and user guides at all-guides.com Viewing and Listening (Users) (Cont.) Correctly enter the user login ID and the password, and then click the login button ・The camera images appear in single-view mode. NOTE The configuration and way of performing operations for this window are the ● same as that of the administrator single view window except icon display. LIVE For details on the configuration and way of performing operations, refer to "Viewing Images in Single-View Mode by Administrator" (→ page 14).
Page 35: Viewing Images In Multi-View Mode By User
All manuals and user guides at all-guides.com Viewing Images in Multi-View Mode by User At Step 2 on the previous procedure, click the button in the upper-right corner of the Multi view window ・ The Multi-Screen Mode window appears. This window is automatically split into frames in accordance with the Multi-Screen Mode settings (→ page 79) for the number of cameras to display. For details on the number of cameras and multi view, refer to "Multi-Screen Mode Window Configuration" (→ page 18). ・ Only the administrator can select which cameras will appear in multi- view mode screen. When the user switches to multi view, the multi view configuration corresponds to the cameras selected by the administrator. ・The configuration and way of performing operations for this window are the same as that of the administrator multi-view window. For details on the configuration and way of performing operations, refer to "Viewing Images in Multi-View Mode by Administrator" (→ page 17).
Page 36: Operating Live Camera Images By User
All manuals and user guides at all-guides.com Viewing and Listening (Users) (Cont.) Operating Live Camera Images by User In user single-view or multi-view mode, click the button ・The basic user controller is displayed in a separate window. Use the controller to operate ・ For an explanation on each component of the user controller, refer to "Basic User Controller Components" (→ page 37). To close the controller, click the button in Close the upper-right corner of the window...
Page 37 All manuals and user guides at all-guides.com ● Basic User Controller Components Item Description Close Close Clicking the button closes the controller. Close 1 shot This function converts an image to a picture data on the computer, and displays it on a new window. You 1 Shot can save the image as JPEG file here. Controller This feature adjusts the direction of the lens by panning (left/right) and tilting (up/down). 1. Each time you click the button, the lens moves up. You can move the lens in a range of eight different vertical positions. When the camera lens reaches its upper limit, clicking on the button has no effect. 2. Each time you click the button, the lens moves left. You can move the lens in a range of eight different horizontal positions. When the camera lens reaches its left most limit, clicking on the button has no effect. 3. Each time you click the button, the lens moves down. You can move the lens in a range of eight different vertical positions. When the camera lens ...
Page 38 All manuals and user guides at all-guides.com...
Page 39: Set Up
All manuals and user guides at all-guides.com Set up ● Configuring the Camera ● Setting Items ● Connecting the Camera to a Server ● Returning to the Default Settings ● Updating the Firmware...
Page 40: Configuring The Camera
All manuals and user guides at all-guides.com Configuring the Camera Only the administrator can configure the network camera. For details on the settings the administrator can configure, refer to "Setting Items" (→ page 69). Enter the correct administrator information (administrator ID and password) to log in to the initial window for configuring settings. For details on administrator login, refer to "Administrator Login" (→ page 13). The IP address 192.1.168.0.30 is used for the network camera in explanations hereafter. Configuring General Settings The following explains the procedure for configuring settings. The procedure for performing operations here and other settings are exactly the same. For details on configuring some of the main settings, refer to "Main Setting Items" (→ page 43). For details on all other settings, refer to "Setting Items" (→ page 69). Perform administrator login (→ page 13) ・A window containing the Admin Menu appears. In the left side of the window, click the toggle (＋) of "Camera Settings", "Network Settings", "Security S e t t i n g s " , " M u l t i - S c r e e n M o d e S e t t i n g s " , "Administrator Functions", or "Log Management"...
Page 41 All manuals and user guides at all-guides.com ・If you click the toggle (＋) of "Network Settings" or other menus while the menus are as above, the "Camera Settings" sub menus disappear and the sub menus of "Network Settings" or other menus appear. Click a sub menu ・The settings appear in the right side of the window.
Page 42 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) Configure each setting ・For details on configuring settings, refer to "Main Setting Items" (→ page 43) or "Setting Items" (→ page 69). After you have configured all the settings, click the button save ・The settings are registered in the network camera and a message appears to inform you that camera configuration is complete. ・If you want to configure other settings, click another toggle (＋) or menu and select the submenu of the settings you want to configure. Then, repeat Steps 4 and 5 above. Important If the settings were configured incorrectly, they are not registered in the ● network camera and an input error message appears. Read the error message and reconfigure the settings accordingly. save To register the settings in the network camera, be sure to click the ● button. The settings are not registered in the network camera when: ・You close the setting window before saving the changes. ・ You click another menu in the left side of the window and different settings appear. NOTE save Clicking the button instead of clicking button at Step 5 reset ● restores the previous configuration.
Page 43: Main Setting Items
All manuals and user guides at all-guides.com Main Setting Items The following explains how to configure some of the main settings. ■ Configuring the IP Address To connect to a network, it is necessary for the administrator to configure the network camera IP address. There are two options for configuring the IP address. ・ Obtaining an IP address automatically from the DHCP server ・ Entering an IP address manually ● Obtaining an IP address automatically from the DHCP server The "DHCP" setting is configured to "ON" by default. This allows you to connect to a network that uses a DHCP server without any settings. If the DHCP server cannot be found, the camera automatically uses the IP address 192.168.0.30. ● Entering an IP address manually ・Enter an IP address manually if you do not want to use the DHCP server or the network does not use a DHCP server. ・If you use the DHCP server, the IP address changes from time to time. Therefore, the IP address you set last time may not be valid next time, and you may not able to access to the camera. To be able to access the camera every time you use, you need to set fixed IP address (setting IP address manually) to the network camera. If you do not know the pre-assigned IP address, consult the relevant support center or refer to the relevant manuals of the network system devices (router, hub, modem, etc.).
Page 44 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) Perform administrator login (→ page 13) to open the Admin menu In the left side of the window, click the toggle (＋) of "Network Settings" ・The sub menus appear. From the list of sub menus, click "General" ・The settings appear in the right side of the window. Enter the camera name NOTE The camera name is displayed along with images in single-view mode or ● multi-view mode. If there are multiple cameras, enter a name that will make it easy to identify what the camera is monitoring. Set "DHCP" to "OFF" ・ The default setting is "ON." When you will set your own IP address without using DHCP server, set "DHCP" to "OFF."...
Page 45 All manuals and user guides at all-guides.com Enter the IP address, subnet mask, and default gateway Important If you do not know the subnet mask, consult the provider or relevant network ● system administration support center. You do not need to enter the default gateway if the network camera will not ● be accessed from another network. If you do need to enter a default gateway, consult your network system administration support center. Click the button save ・The settings are registered. NOTE save Clicking the reset button instead of clicking button at Step 7 ● restores the previous configuration. The network camera has a feature (useful for multi view) to automatically ● detects and remember other cameras on the same network. If there are other cameras on the same network, it is recommended to set "Auto Identification of Other Cameras" to "ON" (→...
Page 46: Configuring Settings For Wireless Lan
All manuals and user guides at all-guides.com Configuring the Camera (Cont.) ■ Configuring Settings for Wireless LAN To establish a wireless connection, it is necessary for the administrator to configure the appropriate wireless LAN settings. The administrator also needs to configure the IP address. For details on configuring the IP ad- dress, refer to "Configuring the IP Address" (→ page 43). Perform administrator login (→ page 13) to open the Admin menu In the left side of the window, click the toggle (＋) of "Network Settings" ・The sub menus appear. From the list of sub menus, click "Wireless LAN" ・The settings appear in the right side of the window. Configure the communication mode ① Click ▼ for the "COM Mode" setting in the right side of the window. ② Select an item from the pull-down menu. ・If you are going to connect the network camera to the network via a wireless broadband router or access point (AP), select "infrastructure." If you are going to connect the network camera directly to a personal computer, select "adhoc."...
Page 47 All manuals and user guides at all-guides.com Configure the communication channel ① Click ▼ for the "COM Channel" setting in the right side of the window. ② Select an item from the pull-down menu. ・Channels 1 to 11 are available for use. If you are configuring the network camera to work in an existing wireless LAN environment, select the same channel. NOTE If you cannot establish a satisfied wireless connection, try other channels ● and select the channel that enables the optimal connection. To have communication in adhoc method with the computer which cannot ● change the communication channel, start up the network camera in wireless LAN mode before turning on your computer. The network camera can communicate only on the configured channel of ● the camera. Enter the ESS-ID ・If you are connecting the network camera to an existing wireless LAN, set the same ESS-ID as the existing wireless LAN environment. If you are configuring a new wireless LAN, make sure that you do not set the same ID as another existing wireless LAN. Important There are restrictions on the values you can enter. You can only enter up to ● 32 alphanumeric characters. NOTE ESS-ID is sometimes simply expressed as SS-ID, SSID, or network group ● name. In this manual we use "ESS-ID". This setting is an ID for identifying the wireless group when multiple wireless LAN groups exist in the network environment.
Page 48 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) Configure the WEP key ① Click ▼ for the "WEP Key" setting in the right side of the window. ② Select an item from the pull-down menu. ・ This setting determines the method used to encrypt data transferred during wireless communication. Typically, 64-bit and 128-bit WEP keys are used. (128-bit WEP sets tighter security) ・You can select either of the two WEP keys or select not to use an encryption key. If you are connecting the network camera to an existing wireless LAN that uses a WEP key, set the same WEP key to the network camera. NOTE WEP setting is not mandatory. Do not perform the WEP setting if you are ● not using WEP with your current wireless LAN. When you use encryption with the WEP key for the network camera, select ● the items for "Encryption" and "WEP Key" correctly. There are rules for entering the WEP keys used for wireless data encryption. Enter a 10-byte (hexadecimal digits) or 5-byte (ASCII text) character string for the 64-bit WEP key, and a 26-byte (hexadecimal digits) or 13-byte (ASCII text) character string for the 128-bit WEP Key. Configure the WEP Key by referring tables below. Sometimes "64-bit WEP" is described as "40-bit WEP", in here, we use the ● term "64-bit WEP." This means that other wireless devices using 40-bit WEP are using the same level of security as and are compatible with devices that use 64-bit WEP. When you do not perform encryption of the data by WEP, your wireless ● communication could be intercepted easily by third party. By using WEP for your data encryption, it becomes very difficult to decode the data. Because of this, it is recommended to do WEP setting if you are using wireless communication.
Page 49: Configuring Multi-Screen Mode Settings
All manuals and user guides at all-guides.com ■Configuring Multi-Screen Mode Settings ● Selecting Multiple Cameras The images of network cameras selected by this setting appear in multi- view mode. 1） In the left side of the window, click the toggle (＋) of "Multi-Screen Mode Settings", and then click the sub menu "Selecting Cameras" ・The settings appear in the right side of the window. 2）Set "Multi-Screen Mode" to "ON" 3）From "Selection of Cameras for Multi-Screen Display," select cameras (check boxes) 4）Click the save button ・The settings are registered in the network cameras. NOTE save Clicking the button instead of clicking button at Step 4) reset ● restores the previous configuration. When "Multi-Screen Mode" is set to "OFF," button will not be displayed ● Multi view and cannot switch to the multi-view mode screen.
Page 50 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) ● Adding Multiple Cameras The network camera has a feature to automatically detect other cameras on the same network. If you want to display images from network cameras, which are on other networks, in multi-view mode, register them on the "Multi- Screen Mode Settings" "Adding and Removing Cameras" screen. 1） In the left side of the window, click the toggle (＋) of "Multi-Screen Mode Settings" ・The sub menus appear. 2）From the list of sub menus, click "Adding and Removing Cameras" ・The settings appear in the right side of the window. 3）Enter the camera name 4）Enter an IP address 5）Click the button save ・The settings are registered in the network cameras. NOTE save Clicking the button instead of clicking button at Step 5) reset ● restores the previous configuration. You can use any of the following procedures to confirm whether the network ● camera of an entered IP address has been registered. ・In the left side of the window, click "Multi-Screen Mode Settings". ・From the list of sub menus of "Multi-Screen Mode Settings", click "Selection of Cameras".
Page 51: Configuring External Alarm Settings
All manuals and user guides at all-guides.com ■ Configuring External Alarm Settings If you connect a sensor or other device to the alarm input terminal (→page 94), an alarm will notify you when the sensor detects anything out of the ordinary. For example, if you connect a sensor attached to a door, an alarm can notify you when the door is opened or closed. 1）Perform administrator login (→ page 13) ・A window containing the Admin Menu appears. 2） In the left side of the window, click the toggle (＋) of "Camera Settings" ・The sub menus appear.
Page 52 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) 3） From the list of sub menus, click "Alarm Settings" ・The settings appear in the right side of the window. 4）Set "Function" of the "External Alarm" setting to "ON"...
Page 53 All manuals and user guides at all-guides.com 5）Configure each of the other settings ・Input Type (alarm notification conditions) This is the setting for external alarm input method. Set the conditions depending on kinds of sensor you are using. Normal Opened (NO) ：Non-Voltage point method. It opens the point (circuit) when nothing is happening (normal), and closes when alarm has generated. Normal Closed (NC) ：Non-Voltage point method. It closes the point (circuit) when nothing is happening (normal), and opens when alarm has generated. ※ The default setting is "Normal Opened (NO)." ・Associate to P/T Operation (camera operation when an external alarm went off) ：The lens will not move even if an alarm has generated. Preset ： The lens moves to the preset position specified for "Preset No." Auto Patrol：The lens moves to each of the preset positions in order. （Available Settings when "Preset" is Selected Above）・Preset No. (number of the preset which shows the camera images when an external alarm has gone off) 1 to 10 ※For example, you can select the preset number of a lens position for showing the area around a sensor or other device attached to a door. ・Resume Function (returns the lens to the position where it was when the alarm went off) ON ： When a fixed period of time elapses after the lens moved in response to an alarm, the lens returns to the position where it was when the alarm went off.
Page 54: Configuring Motion Sensor Settings (Ik-Wb11A)
All manuals and user guides at all-guides.com Configuring the Camera (Cont.) 6）To finish configuring the alarm settings, click the button below the settings save ・The changes are saved. To restore the previous configuration, click the button below the settings reset ・The changes are discarded. To configure other alarm settings, proceed to the next section NOTE For details on connecting alarm input components, refer to the respective ● manuals of the components. ■ Configuring Motion Sensor Settings (IK-WB11A) If you set "Function" of the "Motion Sensor" to "ON," an alarm will notify you a change detected. 1）Set "Function" of the "Motion Sensor" setting to "ON"...
Page 55 All manuals and user guides at all-guides.com 2）Configure each of the other settings ・Sensitivity (detection sensitivity level) Configures sensitivity for changing brightness. HIGH ：Generates an alarm upon detection even to the slightest change in brightness. MIDDLE ：Sensitivity is at a level between HIGH and LOW. ：Generates an alarm upon detection of significant changes in brightness only. ※ The default setting is "MIDDLE." ※ If an alarm is detected frequently when there are no abnormalities, reduce the level of sensitivity. ・Size (detection size) Configures the abilty to detect movement. Large ：Generates an alarm upon detection even to the slightest movement. The camera can detect easily any movement. Medium ：Detection size is at a size between "Large" and "Small". Small ：Generates an alarm upon detection of significant movement only. ※ If an alarm generates frequently even in normal occasion, change the setting to "Small." ・Detection range (range within which you can configure the motion sensor to work) ①When you click "Click here to launch the settings window", the range setting screen (8X8 squares) appears.
Page 56 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) ② Paint out any square you want to set the sensor by clicking it ・To undo this action, click the square again. Setting the sensor outside the current displayed range of the screen (1) In the left side of the window for configuring the range, click the button. (2) Paint out any square you want to set the sensor by clicking it all ON ・Click the button to paint out all squares. ・Click the button to unset all squares. all OFF ③ Click the button save ・The settings are saved and the window for configuring the range closes. ・Clicking the button closes the window for configuring the close range without saving the changes. NOTE Squares set for Privacy Mask (→ page 64) are already painted out in (dark) ● black. Clicking the reset button discards all unsaved changes.
Page 57 All manuals and user guides at all-guides.com Available Settings when "Preset" is Selected ・Preset No. (number of the preset which images the camera shows when an external alarm has gone off) 1 to 10 ・Resume Function (returns the lens to the position where it was when the alarm went off) ON : When a fixed period of time elapses after the lens moved in response to an alarm, the lens returns to the position where it was when the alarm went off. OFF : After the lens moved in response to an alarm, the lens stays still at the position of the selected preset. ・Resume Time (period of time until the Resume function starts) 10, 30, 60 seconds NOTE The "Preset No.," "Resume Function," and "Resume Time" settings are only ● valid when "Preset" is selected for "Associate to P/T Operation." Detection range of the motion sensor is the range the camera is monitoring. If ● there were some movements in where out of the camera monitoring range, the movements cannot be detected. 3）To finish configuring the alarm settings, click the save button below the settings ・The changes are saved. To restore the previous configuration, click the button below the settings reset ・The changes are discarded. To configure other alarm settings, proceed to the next section...
Page 58: Configuring Alarm Output Settings
All manuals and user guides at all-guides.com Configuring the Camera (Cont.) ■ Configuring Alarm Output Settings The alarm output terminal (→page 94) facilitates the use of a siren, buzzer, emergency light, or other device when an alarm goes off. 1）Set the alarm notification time for "Output Hold Time" of the "Alarm Output" setting ・This setting is only valid if a light or other component is connected to the alarm output terminal. ・Select a time from 1, 5, 10, 15, 30, and 60 seconds. NOTE A new alarm cannot be received while an alarm recording (sound) is playing. ● 2）To finish configuring the alarm, click the save button below the settings ・The changes are saved. To restore the previous configuration, click the button below the settings reset ・The changes are discarded. NOTE For details on connecting alarm output components, refer to the respective ● manuals of the components.
Page 59: Configuring Mail Settings
All manuals and user guides at all-guides.com ■ Configuring Mail Settings Network cameras have a feature for sending mail. If you configure this feature, mail is sent when: ・ An external alarm goes off. ・ Motion is detected. (IK-WB11A) ・ The internal battery runs out of power. ・ The IP address is changed. ● Configuring conditions for sending mail 1） In the left side of the window, click the toggle (＋) of "Network Settings" ・The sub menus appear. 2）From the list of sub menus, click "Mail" ・The settings appear in the right side of the window. 3） Enter the IP address or server name (host name) of the SMTP ・Enter the SMTP server information specified by the provider.
Page 60 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) NOTE Some providers verify users by receiving mail. If you cannot send mail even if ● these items are correctly configured, enter the ID and password for verifying the IP address or server name (host name) of the POP3 server. POP3 is a protocol for receiving (retrieving) mail from the mailbox. However, ● these settings will not result in received mail, for example, being deleted because the network camera does not retrieve mail. 4）Enter the administrator mail address ・Correctly enter the mail address specified by the provider. The following explains how to configure settings related to when mail should be sent. ●Configuring the conditions of sending mail when an external alarm goes off or motion is detected. 1）Configure the "Conditions for Sending Mail When An External Alarm Goes Off" setting ・Set the sending of mail when an external alarm goes off to "ON" or "OFF." NOTE The default setting is "OFF." ●...
Page 61 All manuals and user guides at all-guides.com 2） Enter the Message Body and configure the "Attach Alarm Picture To Mail" setting ・The text entered here becomes the body of messages. To the actual body of a message, the time/date when the alarm went off and the camera name are added to the text entered here. ・ If "ON" is set for "Attach Alarm Picture To Mail," the image saved by the network camera, when an external alarm was detected, is attached to a message at the size specified for "Attached Picture Size." NOTE The attached image data is in a format that ordinary mail client software can ● read. 3） Configure the "Conditions for Sending Mail When Motion Is Detected" setting ・Set the sending of mail when motion is detected to "ON" or "OFF." NOTE The default setting is "OFF." ● 4） Enter the Message Body and configure the "Attach Motion Picture To Mail" setting ・The text entered here becomes the body of messages. To the actual body of a message, the time/date when a motion was detected and the camera name are added to the text entered here. ・If "ON" is set for "Attach Motion Picture To Mail," the image saved by the network camera, when motion was detected, is attached to a message at the size specified for "Attached Picture Size." NOTE The attached image data is in a format that ordinary mail client software can ● read.
Page 62 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) The following explains how to configure settings related to sending mail when the camera detects that the internal battery has run out of power. ● Configuring the conditions for sending mail when the inter- nal battery runs out of power The internal battery may be out of power when the network camera is first unpacked after purchase or has been left unused with the power turned off for a while. Note that the network camera will no longer indicate the current time because the time and date are reset to their initial values when the internal battery runs out of power. ※If the time is not set correctly, the recording/playing functions may not work right. Be sure to set correct time. 1）Configure the "Conditions for Send Mail When Internal Battery Runs Out Of Power" setting ・ Set the "Send Mail When Internal Battery Runs Out of Power" to "ON" or "OFF." NOTE The default setting is "ON." ● 2）Enter the message body ・The text entered here becomes the body of messages. The following explains how to configure settings related to sending mail when the IP address is changed.
Page 63 All manuals and user guides at all-guides.com ● Configuring the conditions for sending mail when the IP ad- dress is changed If the network camera is set to obtain an IP address automatically from the DHCP server, the IP address is changed when the power of the net- work camera is turned off or on, or periodically for security reasons. You can configure the network camera to send mail to inform you that the IP address has been changed. Configure the "Condition for Sending Mail When IP Address Is Changed" setting ・Set the "Send Mail When IP address Is Changed" to "ON" or "OFF." The default setting is "ON." NOTE Mail is not sent if the mail settings (SMTP server information and administrator ● mail address) (→ page 59) have not been configured. The following fixed information are also added to the body of messages. ● ・The new IP address ・The subnet mask ・The default gateway ・The time and date ・The camera name...
Page 64: Configuring Privacy Mask Settings
All manuals and user guides at all-guides.com Configuring the Camera (Cont.) ● Configuring Mail Address Settings for Sending Mail Enter mail addresses and select the conditions for sending mail. 1） Configure the "Address For Sending Mail" settings and "Address For Sending Mail (Copy)" settings ・ Enter mail addresses and click the boxes beside each address to select the conditions for which mail is sent. 2）Press the button save ・The settings are registered in the network cameras. NOTE save After setting sending mail setting and clicking button, you may try ● "test." It is recommended to try the test to check your mail settings. ■ Configuring Privacy Mask Settings You can configure the masking of camera images. Places with masking set are painted out in black. This is a convenient feature for not showing certain places in images. For example, it allows you to hide the number plates of cars when the camera is installed in a garage or other location. 1）Perform administrator login (→ page 13) ・A window containing the Admin Menu appears. 2）In the left side of the window, click the toggle (＋) of "Camera Settings" ・The sub menus appear.
Page 65 All manuals and user guides at all-guides.com 3）From the list of sub menus, click "Privacy Mask" ・The settings appear in the right side of the window. 4）Set "Function" to "ON" 5） Use the "Setup Range" setting to specify the mask range ・ For details on how to specify a range for the mask, see the explanation for the "Detection Range" setting in "Configuring Motion Sensor Settings" (→ page 54). 6）Click the button below the settings save ・The changes are saved.
Page 66: Freeze Activity Settings
All manuals and user guides at all-guides.com Configuring the Camera (Cont.) ■ Freeze Activity Settings When in "Auto Patrol" mode, the "Freeze Activity Function" allows you to view a still image while the lens is moving. When you set this function to ON , the screen shows the regular motion images when the lens is at the preset positions, and shows a still image (an image right before the lens moves) when the lens is moving. 1）Perform administrator login (→ page 13) ・A window containing the Admin Menu appears.
Page 67 All manuals and user guides at all-guides.com 2） In the left side of the window, click the toggle (＋) of "Camera Settings" ・The sub menus appear. 3）From the list of sub menus, click "PAN/TILT Settings" ・The settings appear in the right side of the window.
Page 68 All manuals and user guides at all-guides.com Configuring the Camera (Cont.) 4）Set the "Freeze Activity Function" to "ON" 5）Set the "Auto Patrol Stopping Time" setting ・Select a time from 1, 2, 5, and 10 minutes. ・The period of time that the lens stops at the preset position is set. 6）Click the button below the settings save ・The changes are saved.
Page 69: Setting Items
All manuals and user guides at all-guides.com Setting Items ■ Camera Settings １．General Settings Item IK-WB01A IK-WB11A Camera Picture Size 160 x 120 1280 x 960 320 x 240 800 x 600 640 x 480 640 x 480 320 x 240 ZOOM 320 x 240 160 x 120 ZOOM 160 x 120 Picture Quality HIGH/MIDDLE/LOW HIGH/MIDDLE/LOW Frame Rate HIGH/MIDDLE/LOW HIGH/MIDDLE/LOW Installation Environment Desktop/Wall, Ceiling Desktop/Wall, Ceiling AE Compensation -20 to 20 ...
Page 70 : Lower frame rate. Actual frame rate changes depending on image size and setting environment (use of network cable, performance of a PC, etc…). The maximum frame rate for HIGH setting are: 30 fps (320 × 240, 160 × 120) 7.5 fps (1280 × 960, 800 × 600, 640 × 480) The numbers in parentheses are the sizes of camera images. ※ The frame rate may get lowered when the slow shutter function and SD memory card are in use. IK-WB01A Configures the frame rate of the camera. The bigher the frame rate, the renewal speed of the single-view or multi-view mode screen becomes faster. The lower the frame rate, sensitivity of the camera heightens. HIGH ：15 fps MIDDLE ：10 fps ： 5 fps ： frame ／...
Page 71 All manuals and user guides at all-guides.com ● Installation Environment: Turning the image (180° ) depending on the installation environment. Desktop/Wall : Will not rotate the image when installing the camera on a desk or a wall. Ceiling : Rotates the image 180°when hanging the camera from a ceiling. ※The images will not rotate when capture an image with 1 shot function. (IK-WB01A) ● AE Compensation： The camera adjusts the brightness of the image automatically. Adjust to the best splendor for each conditions of an object. You can adjust the brightness between the range of -20 to 20. The bigger the number, picture becomes lighter, and the smaller the number, it becomes darker. ● Auto B/W： Configures Auto B/W function. Auto B/W is the function that when monitored object becomes darker, it turns the image into black and white picture and helps the sensitivity of the camera to have better image. When the image turns to black and white, the image may have some noise. ON ：Auto B/W takes action. OFF ：Auto B/W does not take action. ● Shutter Speed (IK-WB11A): Configures the speed of electronic shutter. When setting the Shutter Speed to "AES(Automatic Electronic Shutter)," the camera automatically sets the shutter speed depending on the brightness of an object. Possible settings：AES, 1/120, 1/60, 1/30, 1/20, 1/15, 1/8, 1/4, 1/2, 1, 2, 4 NOTE When the shutter speed is set "AES," it automatically switches ND ●...
Page 72 ON ：The slow shutter takes action. OFF ：The slow shutter does not take action. ● Auto Sensitivity Boost (IK-WB11A): Configures Auto Sensitivity Boost function. Auto sensitivity boost function boosts up the sensitivity of the camera when an object gets darker. The screen may have more noises and resolution may get lowered when the image gets darker. ON ：The auto sensitivity boost takes action. OFF ：The auto sensitivity boost does not take action. ● Sound Sensitivity: Configures the sensitivity of microphone (sound). Change the settings depending on installation environment. IK-WB11A HIGH ：Heightens the sensitivity of sound input. MIDDLE ：Standard sound input sensitivity. ：Lowers the sensitivity of sound input. IK-WB01A HIGH ：Heightens the sensitivity of a microphone (sound). ：Lowers the sensitivity of a microphone (sound). ２．PAN/TILT Settings Item IK-WB01A IK-WB11A P/T Operation Restrictions None/Administrator Only None/Administrator Oniy Auto Patrol Stopping Time 1, 2, 5, 10 minutes 1, 2, 5, 10 minutes Scan Speed SLOW/FAST SLOW/FAST Power Boost CENTER, HOME, CENTER, HOME, ...
Page 73 All manuals and user guides at all-guides.com ３．Alarm Settings １）External Alarm Item IK-WB01A IK-WB11A Function ON/OFF ON/OFF Input Type Normal Closed (NC)/ Normal Closed (NC)/ Normal Opened (NO) Normal Opened (NO) Associate to P/T OFF, Preset,Auto Patrol OFF, Preset,Auto Patrol Operation Preset No. 1 to 10 1 to 10 Resume Function ON/OFF ON/OFF Resume Time 10, 30, 60 seconds 10, 30, 60 seconds ２）Motion Sensor Item IK-WB01A IK-WB11A ...
Page 74 All manuals and user guides at all-guides.com Setting Items (Cont.) ５．Recording Settings １）Alarm Recording Item IK-WB01A IK-WB11A External Alarm ON/OFF ON/OFF Motion Sensor ― ON/OFF Pre-Recording 0, 3, 5, 10 frames 0, 3, 5, 10 frames Post-Recording 0, 3, 5, 10, 20 frames 0, 3, 5, 10, 20 frames ※ Recording Cycle 1, 2, 5, 10 seconds 1, 2, 5, 10 seconds ※ The camera records only one image of the moment alarm has generated when "Pre-Recording" and "Post-Recording" are set to "0 frame". ２）Normal Recording (Only Possible when SD Memory Card Inserted) Item IK-WB01A IK-WB11A Function ― ON/OFF ※...
Page 75: Network Settings
All manuals and user guides at all-guides.com ■ Network Settings １．Network Connection Settings １）General Settings Item IK-WB01A IK-WB11A Camera Name Enter up to 32 single-byte Enter up to 32 single-byte characters characters Auto Identification of ON/OFF ON/OFF Other Cameras DHCP ON/OFF ON/OFF IP Address Enter the static IP Enter the static IP address address Subnet Mask Enter the subnet mask Enter the subnet mask Default Gateway Enter the default gateway Enter the default gateway...
Page 76 All manuals and user guides at all-guides.com Setting Items (Cont.) ３．Mail Settings １）Server Settings Item IK-WB01A IK-WB11A SMTP Server Name Enter the server name Enter the server name SMTP IP Address Enter the IP address Enter the IP address POP3 Server Name Enter the server name Enter the server name POP3 IP Address Enter the IP address Enter the IP address ２）Verification Settings Item IK-WB01A IK-WB11A User ID Enter the user ID Enter the user ID Password Enter the password Enter the password Password (Confirm) Reenter the password Reenter the password ３） Administrator Mail Settings Item ...
Page 77 All manuals and user guides at all-guides.com ７）Conditions for Sending Mail when Internal Battery Runs Out Of Power Item IK-WB01A IK-WB11A Send Mail When Internal ON/OFF ON/OFF Battery Runs out Out Of Power Enter up to 256 single- Enter up to 256 single- Message Body byte characters byte characters ８）Conditions for Sending Mail When IP Address Is Changed Item IK-WB01A IK-WB11A Send Mail When IP ON/OFF ON/OFF Address is Changed Message Body The IP address is The IP address is changed. changed. New IP address: *** New IP address: *** ...
Page 78: Security Settings
All manuals and user guides at all-guides.com Setting Items (Cont.) ４．Routing Table Settings Item IK-WB01A IK-WB11A Static Routing Table Configure the following Configure the following Settings settings for up to ten settings for up to ten entries: destination entries: destination address, subnet mask, address, subnet mask, gateway address, and gateway address, and metric metric ５．ARP Table Settings １）Static ARP Table Settings Item IK-WB01A IK-WB11A Static ARP Table Configure the following Configure the following Settings settings for up to ten settings for up to ten entries: IP address, MAC entries: IP address, MAC address address ２）Browse ARP Table...
Page 79: Multi-Screen Mode Settings
All manuals and user guides at all-guides.com ２．Filtering Settings Item IK-WB01A IK-WB11A ON/OFF ON/OFF Filtering by MAC Address MAC Address Enter up to ten MAC Enter up to ten MAC addresses addresses ３．User Restriction Settings Item IK-WB01A IK-WB11A User Restrictions ON/OFF ON/OFF Login ID Enter the login ID Enter the login ID Password Enter the password Enter the password Password (Confirm) Reenter the password...
Page 80: Administrator Functions
All manuals and user guides at all-guides.com Setting Items (Cont.) ■ Administrator Functions １．Changing the Password Item IK-WB01A IK-WB11A Current Login ID Enter the current login ID Enter the current login ID Current Password Enter the current password Enter the current password New Login ID Enter the new login ID Enter the new login ID New Password Enter the new password Enter the new password New Password Reenter the password Reenter the password (Confirm) ２．Setting the Time １）Time Zone Item IK-WB01A IK-WB11A Time Zone GMT-12:00〜GMT+12:00 GMT-12:00〜GMT+12:00 ２）Changing the Time Manually Item ...
Page 81: Log Management
All manuals and user guides at all-guides.com ３．Firmware Update Item IK-WB01A IK-WB11A File Name Download the firmware. Download the firmware. Then, select the file by Then, select the file by entering the file path or entering the file path or browsing browsing ■ Log Management １．Forwarding Settings Item IK-WB01A IK-WB11A Forward Log to ON/OFF ON/OFF Another Server Name of Destination Enter the server name Enter the server name Server IP Address of Enter the IP address Enter the IP address...
Page 82: Connecting The Camera To A Server
All manuals and user guides at all-guides.com Connecting the Camera to a Server Using a high-capacity server for storing video image data delivered from network cameras enables you to save all video image data within a specific period, for retrieving and playing when necessary. Although no special external interface is provided for retrieving video image data from network cameras, you can easily retrieve video image data using the normal HTTP protocol. Some programming in perl or another language is required for data retrieval; however, you need only to create components that are essential to data sampling. You do not need to write programs for the screen frame design and other viewer aspects that are not essential. Furthermore, the network camera stores various information generated internally as logs. These logs support the syslog protocol, so they can be transferred from the network camera to a server (running an OS such as Unix or Linux that supports the syslog protocol) if you configure the log transfer setting of the network camera. Constant monitoring of these logs facilitates expert detection of any trouble occurring within the network camera. Although this requires continuous monitoring of syslog (or messages) on the server, the recent increase in the popularity of network management systems (NMS) equipped with many features for monitoring, for example, networks, system performance, and resources means that this is not a problem.
Page 83: Returning To The Default Settings
All manuals and user guides at all-guides.com Returning to the Default Settings Follow the procedure below to return to the default settings. ・Return to the defaults settings by using a thin, pointed object to press the reset button, shown in the figure on page 14, 15 in Basic User's Guide, for at least 5 seconds. ・The settings return to the defaults. ・The following shows the default settings. NOTE Pressing the reset button for less than a second switches ON/OFF of the ● video output. This function, the video output, is only for checking images on the screen when installing the camera. At this moment, the camera stops image recordings and sending images and sound to the network.
Page 84: Default Settings
All manuals and user guides at all-guides.com Returning to the Default Settings (Cont.) Default Settings ■ Camera Settings Item IK-WB01A IK-WB11A General Settings Camera Picture Size 640X480 640X480 Picture Quality MIDDLE MIDDLE Frame Rate HIGH HIGH Installation Environment Desktop/Wall Desktop/Wall AE Compensation 0 0 Auto B/W OFF OFF Shutter Speed ー AES ...
Page 85: Network Settings
All manuals and user guides at all-guides.com Item IK-WB01A IK-WB11A Alarm Output Output Hold Time 5 seconds 5 seconds Privacy Mask Settings Function ー OFF Setup Range ー All OFF Recording Function Settings Alarm Recording External Alarm OFF OFF Motion Sensor ー OFF Pre-Recording 10 frames 10 frames ...
Page 86 All manuals and user guides at all-guides.com Returning to the Default Settings (Cont.) Item IK-WB01A IK-WB11A Mail Settings Server Settings SMTP Server Name ーー SMTP IP Address ーー POP3 Server Name ーー POP3 IP Address ーー Verification User ID ーー Settings Password ーー ...
Page 87: Security Settings
All manuals and user guides at all-guides.com Item IK-WB01A IK-WB11A Routing Table Settings ーー Destination Address ーー Subnet Mask ーー Gateway Address ーー Metric ARP Table Settings IP Address ーーーー MAC Address Browse ARP table Browse ARP table Static ARP Table Settings ー ...
Page 88: Administrator Functions
All manuals and user guides at all-guides.com Returning to the Default Settings (Cont.) ■ Administrator Functions Item IK-WB01A IK-WB11A Changing the Password Current Login ID ーー Current Password ーー New Login ID ーー New Password ーー New Password (Confirm) ーー Setting the Time Time Zone GMT-12:00〜GMT+12:00 GMT-12:00〜GMT+12:00 Changing the ...
Page 89: Updating The Firmware
All manuals and user guides at all-guides.com Updating the Firmware Follow the procedure below to update the firmware. Initial Procedure ● Create a folder in which to save the latest firmware. ● Access the following Toshiba Web page via the Internet. URL: http://www.netcam.toshiba.com Download the latest firmware according to the explanation on the Web page. Perform administrator login ・ For details on how to login, refer to page 13. In the Admin menu, click the toggle (+) of Administrator Functions ・The sub menus appear.
Page 90 All manuals and user guides at all-guides.com Updating the Firmware (Cont.) Click "Firmware Update" ・The following screen appears. NOTE The default versions of each product are as followed. ● IK-WB01A Model…100-100-100-001 IK-WB11A Model…100-100-100-011 Click ・The following screen appears. Select the latest firmware file that was saved in the folder created in the section "Initial Procedure." ・The name of the selected file appears in the screen shown in Step 3.
Page 91 All manuals and user guides at all-guides.com Click in the screen shown in Step 3 ・The firmware update begins. ・After a while, the firmware update finishes and the camera restarts automatically. Important Updating the firmware is the responsibility of the customer. ● The camera stops moving during the firmware update. ● Do not turn off the power of the camera during the firmware updating. ● It causes failure in updating firmware.
Page 92 All manuals and user guides at all-guides.com...
Page 93: Others
All manuals and user guides at all-guides.com Others Alarm Terminals ● Glossary (Index) ● Errors and Messages ● Before Calling Service ● Personnel... Specifications ● Appearance Diagram ● (IK-WB01A) Appearance Diagram ● (IK-WB11A)
Page 94: Alarm Terminals
All manuals and user guides at all-guides.com Alarm Terminals You can connect a variety of sensors to the camera by using alarm terminals. See following table for functions of each terminal. Description Name Function ・Inputs External Alarm signal. ALARM IN Alarm Input You can choose the type of input signal: Normal Opened (NO) or Normal Closed (NC). Connect a sensor or other devices to the camera. ・Outputs open corrector. ALARM OUT Alarm Output Max.DC 24V, 50mA. ...
Page 95 All manuals and user guides at all-guides.com ■ Specifications of Alarm Signals Name Internal Circuit Signal Condition Non-Voltage point signal, CMOS 3.3V-GND signal inputs Normal Opened DC3.3V 100ms or more 3.3V 47kΩ Alarm Input 220Ω Normal Closed To 100ms or more Inside CMOS input 3.3V the Camera 220Ω Inside the Alarm Output To Max. DC24V, 50mA Camera CMOS Output ■...
Page 96: Glossary (Index)
All manuals and user guides at all-guides.com Glossary (Index) ※ BUG: Basic User's Guide Auto sensitivity boost ...... 72 Number Auto Slow Shutter ......72 1 shot ............. 20 This function captures an image as JPEG file. You can operate this Before calling service personnel 106 function from the controller, and the Browser ..........13 image is displayed in the browser for Software to view WEB screens. 1 Shot. ® There are browser of Microsoft Internet Explorer and Netscape ...
Page 97 All manuals and user guides at all-guides.com Encryption（WEP） ......48 DC IN（Power input terminal）..BUG15 Adopted encryption method by DDNS ............78 I E E E 8 0 2 . 1 1 b a s s t a n d a r d (Dynamic Domain Name System) technique. ...
Page 98 All manuals and user guides at all-guides.com Glossary (Index)(Cont.) JPEG ..........20, 37 (Joint Photographic Experts Group) IEEE802.11b ........47 Standard gauge for compression of IEEE(Institute of Electrical and colored still image by ITU-TS Electronics Engineers) (International Telecommunication International standard gauge of Union: ex-CCITT) and ISO wireless LAN by IEEE. It enables (International Organization for wireless communication without Standardization). It can compress having complicated wiring by using a still image between 1/10 to 1/ direct spectrum difusion method 100 of size. with communication speed of 11Mbps/2.4GHz range(max.) Image magnification ....15, 18 Infrastructure method ....... 46 LAN......... BUG24, 25 Infrastructure method is one of the (Local Area Network) components of wireless LAN...
Page 99 All manuals and user guides at all-guides.com Normal Opened/Closed ....53 Returning to the default settings ..83 NTP server ..........80 Reset button ........83 (Network Time Protocol) Resolution ..........69 Server which provides accurate date Resume function ........ 53 and time from network. RNCP ........... 116 (Retrieve Neighborly Cameras Protocol) OS ............... 3 Protocol for mutual communication. Because of this protocol, the Overwriting function ......74 cameras can identify each other.
Page 100 Timer recording ........74 Zoom in/Zoom out ......21 Updating firmware ......81 URL ............13 (Uniform Resource Locator) Method for assigning the Internet resource. "http://www.toshiba. com/" is the example of when accessing a website on the Internet. Video output ....... BUG15 Wall bracket ..........4 WEP ............48 (Wired Equivalent Privacy） Encryption. Standard encryption method in IEEE802.11b.Even if someone intruded to your computer...
Page 101: Errors And Messages
All manuals and user guides at all-guides.com Errors and Messages Followings are the explanations and trouble shootings for each error messages. The code numbers are needed when asking for a help to the Customer Service. By knowing the code number, the Customer Service can give you a proper advice and help. ・ Network Related ・ Web Related ・ Others ・ Other Messages (Informational Messages) Network Related Messages TCP/IP OS Cause How to Manage CODE Message 2001011 File System was There is an error(s) in the Formatted automatically. automatically File System. formatted by error detection. ...
Page 102 All manuals and user guides at all-guides.com Errors and Messages(Cont.) DHCP Client Cause How to Manage CODE Message 2011001 No response ・Network Camera is not ・Make sure that the from DHCP connected to the LAN Network Camera and server. properly. the LAN cable are ・The DHCP server is not correctly connected to turned ON, or there is no the network. DHCP server on the ・Make sure that the network even though DHCP server is turned ...
Page 103 All manuals and user guides at all-guides.com DDNS Related CODE Message Cause How to Manage 2111001 Failed to resolve ・ＤＤＮＳserver Enter the correct DDNS server information is wrong. information on "DDNS" name. settings. 2111002 Failed to connect ・ＤＤＮＳserver Enter the correct to DDNS server. information setting（→ information on "DDNS" page 78）is wrong. settings. ...
Page 104 All manuals and user guides at all-guides.com Errors and Messages(Cont.) WEB Related Messages Cause How to Manage CODE Message 3001603 F/W update ・Tried to update wrong ・Make sure that the failed. firmware. firmware is certainly for ・Firmware file is your IK-WB01A or IK- damaged. WB11A. ・Make sure that the version and the size of your firmware and the one on the TOSHIBA website are the same. If they don't match, download the matched firmware. Others Cause How to Manage CODE Message 4000001 Battery is empty. ・The internal battery of ...
Page 105 All manuals and user guides at all-guides.com Other Messages（Informational Messages） CODE Message 2000000 Rebooting 2000001 Reset to factory settings. 2000010 File System start. 2000020 SD memory card was mounted. 2000021 SD memory card was unmounted. 2000101 LAN communication was started. 2000102 Wireless communication was started. 2010001 IP address was assigned. 2010003 IP address was refreshed. 2010004 IP address was changed by DHCP server response. 2050001 Time was synchronized with NTP server. 3000001 Logged in as Administrator. 3000101 Camera basic settings were changed. 3000102 Camera PAN/TILT settings were changed. 3000103 Camera alarm settings were changed. 3000104 ...
Page 106: Before Calling Service Personnel
All manuals and user guides at all-guides.com Before Calling Service Personnel... LAN Connection How to Manage Symptom Cause Wired Wireless There is no IP ●The power of the ●Turn on the power. ○ ○ address of camera is not turned your network on. camera on The Camera ●LAN cable is not ●Connect the LAN cable of the ○ Finder s connected. ...
Page 107 All manuals and user guides at all-guides.com LAN Connection How to Manage Symptom Cause Wired Wireless There is no IP ●Setting of adhoc or ●Check the wireless connection ○ address of infrastructure mode. your network method is different ●When connecting your PC and the camera on from actual wireless network camera directly in wireless The Camera environment. connection mode, set the network Finder s ...
Page 108 All manuals and user guides at all-guides.com Before Calling Service Personnel... (Cont.) LAN Connection Symptom Cause How to Manage Wired Wireless Cannot login See "There is no IP address of your network camera on to the camera The Camera Finder's Network Camera List. (Part 2)," or "The even though message, 'The page cannot be displayed,' shows up, and entering the IP cannot login to the camera even if you start Camera Finder." address of the camera directly to the browser, and "The page cannot be displayed" shows up. ○ ○ ●Entering wrong login ●Enter right login ID and password. Error message shows up ID and password. ※The default login ID is "root," and ...
Page 109 All manuals and user guides at all-guides.com LAN Connection How to Manage Symptom Cause Wired Wireless Cannot ●Default gateway is ●Register your broadband router to ○ ○ access to the not configured. the network camera as default camera from gateway. (→ page 75) the Internet. ●Port forwarding is ●Configure port forwarding function ○ ○ not configured to the (static IP masquerade, NAPT) to ...
Page 110 All manuals and user guides at all-guides.com Before Calling Service Personnel... (Cont.) LAN Connection How to Manage Symptom Cause Wired Wireless Cannot ●Lost the power of a ●Make sure that the power of a ○ perform wireless router or wireless router or access point administrator access point (AP) (AP) is ON. settings. (Part during the performance. ...
Page 111 All manuals and user guides at all-guides.com LAN Connection Symptom Cause How to Manage Wired Wireless Cannot ●ESS-ID in "Wireless ●Make sure that the settings and ○ perform LAN Settings" under conditions of wireless LAN mode administrator "Network Settings" of all devices, including the settings. (Part has been changed. network camera, are all the same. ※Some wireless devices recognize ESS-ID automatically; however, you ...
Page 112 All manuals and user guides at all-guides.com Before Calling Service Personnel... (Cont.) LAN Connection How to Manage Symptom Cause Wired Wireless Cannot ●You have entered ●Try login procedure again after ○ ○ perform and saved different setting the IP address which you administrator IP address from your have set to "Access Restriction settings. (Part PC to "Access Settings" of the camera to your 4) Restriction Settings" PC. under "Security ...
Page 113 situations. The network ●Installed the camera ●Make sure that the camera is ○ ○ camera in wrong way. installed in right way. "TOSHIBA" images are logo on the bottom of the network reversed in camera has to be facing front. upside-down. ●Ceiling installation. ●When you suspend the camera ...
Page 114 ●The camera cannot focus at close ○ ○ object is to far. range (less than 80cm). Use the camera at the minimum distance of 80cm or more for IK-WB11A and 35cm or more for IK-WB01A from an object. No sound is ●Java 2 Runtime ●Install Java 2 Runtime ○ ○ ...
Page 115 All manuals and user guides at all-guides.com LAN Connection Symptom Cause How to Manage Wired Wireless Cannot send ●Settings of SMTP, ●Check your SMTP and POP3 ○ ○ mail. POP3 server may server which are provided from not be right. your provider. (→ page 76) ●DNS server setting ●Set your DNS server from your ○ ○ may not be right. provider to "Primary" and ...
Page 116: Specifications
All manuals and user guides at all-guides.com Specifications Model name IK-WB01A IK-WB11A Image sensor 1/5-inch CCD 1/2-inch CCD Effective Picture Element 350k pixel 1.45 megapixel Focal length f=2.6mm f = 6.0 mm ｡｡｡｡｡｡ Angle of view Horizontal: 58 , vertical: 45 , diagonal: 70 Horizontal: 56 , vertical: 44 , diagonal: 67 ...
Page 117: Appearance Diagram (Ik-Wb01A)
All manuals and user guides at all-guides.com Appearance Diagram (IK-WB01A)
Page 118: Appearance Diagram (Ik-Wb11A)
All manuals and user guides at all-guides.com Appearance Diagram (IK-WB11A)
Page 119 All manuals and user guides at all-guides.com TOSHIBA AMERICA INFORMATION SYSTEMS. INC Imaging System Division 9740 Irvine Boulevard, Irvine California 92618-1697 PhoneNumber: (800)288-1354 V1.0...

This manual is also suitable for:

Ik-wb11a
