SSt-EMF75
Use Instructions for CE Compliance
Covers the SSt-EMF75 Power Supply
Rev. 01/20/2015
T e k n i c , I n c . 1 1 5 0 - E P i t t s f o r d V i c t o r R o a d , P i t t s f o r d , N Y 1 4 5 3 4
P h o n e : 5 8 5 / 7 8 4 - 7 4 5 4 ; F A X : 5 8 5 / 7 8 4 - 7 4 6 0

Advertisement

loading
Need help?

Need help?

Do you have a question about the SSt-EMF75 and is the answer not in the manual?

Questions and answers

Related Manuals for Teknic SSt-EMF75

Summary of Contents for Teknic SSt-EMF75

  • Page 1 SSt-EMF75 Use Instructions for CE Compliance Covers the SSt-EMF75 Power Supply Rev. 01/20/2015 T e k n i c , I n c . 1 1 5 0 - E P i t t s f o r d V i c t o r R o a d , P i t t s f o r d , N Y 1 4 5 3 4...
  • Page 2 3. WARNING, SEE USER MANUAL FOR DETAILS ! Safety Precautions & Scope The user should be aware that, if the SSt-EMF75 is used in a manner not specified herein, the protection provided by the equipment may be impaired. Please read all of the following instructions before operating the SSt-EMF75 power supply.

  • Page 3: Grounding & Bonding

    Environment Type (per UL508C and EN61010, Pollution degree 2). Mounting The SSt-EMF75 should be mounted behind covers or machine skins that can only be opened with a tool. The covers or machine skins should be marked as having hazardous voltages within. Alternatively, the supply can be mounted behind doors that have a safety interlock which removes power to the supply when opened.
  • Page 4 Note that the SSt-EMF75 power supply has a capacitance bank of 47,000 uf and can hold a significant charge. After disconnecting AC-input, we recommend that you measure the DC voltage across the output terminals to ensure that the capacitors has been sufficiently discharged prior to handling.
  • Page 5 SSt drives are daisy chained connected, (from one power connector on an SSt-EMF75 and out the other power connector on the same SSt drive on to the next SSt drive, etc.). You should use a wire gauge that is appropriate for the estimated amount of peak and continuous current draw for the machine application.
  • Page 6 Reliability covers three main areas: the reliability of the supply itself, the reliability of other components within the machine and the overall machine reliability. The SSt-EMF75 is a bulk, linear, unregulated power supply and consists of a transformer, bridge rectifier, regeneration circuit and an output capacitor. This simple...
  • Page 7 In the rare cases where this may be insufficient, the EMF75 comes standard with a regeneration protection circuit. Please call your Teknic application engineer for assistance with these calculations. Cost:...

  • Page 8: Declaration Of Conformity

    Standard EN 61010, LVD 73/72/EEC Dave Sewhuk VP Engineering, Teknic, Inc. T e k n i c I n c . P h o n e : 5 8 5 / 7 8 4 - 7 4 5 4 ; F A X : 5 8 5 / 7 8 4 - 7 4 6 0...
