SERVICE MANUAL
STEREO CASSETTE PLAYER
• This Service Manual is the "Supplement" and replaces "Simple Manual"
(S/M Code No. 09-001-410-8T2).
• This Service Manual contains information about the difference between
HS-PX407(Y) and HS-PX397(Y1). If requiring other information, see Service
Manual of HS-PX397(Y1,YH) / HS-EM130(Y1), (S/M Code No. 09-995-410-8R1).
HS-PX407
BASIC TAPE MECHANISM : 6ZM-2 P9NF
S/M Code No. 09-003-410-8S1
Y
