SERVICE MANUAL
STEREO
CASSETTE PLAYER
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-004-405-2T4).
HS-PXM2000
M2000
BASIC TAPE MECHANISM : 7ZM-1 P1NF
S/M Code No. 09-006-405-2R4
YH,AH,
AE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-PXM2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa HS-PXM2000

Summary of Contents for Aiwa HS-PXM2000

  • Page 1 All manuals and user guides at all-guides.com YH,AH, HS-PXM2000 M2000 SERVICE MANUAL STEREO BASIC TAPE MECHANISM : 7ZM-1 P1NF CASSETTE PLAYER • This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-004-405-2T4). S/M Code No. 09-006-405-2R4...

  • Page 2: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Maximum output: 4 mW + 4 mW (EIAJ 16 ohms)<AE> 4 mW + 4 mW (EIAJ 32 ohms)<AH,YH> Load impedance: 16 – 32 ohms Power sources: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using an R6 (AA) dry cell battery, AC house current using the optional AC adaptor Maximum dimensions:...

  • Page 3: Electrical Main Parts List

    All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C143 87-A10-952-080 C-CAP,TN 22-4 M A MCM C151 87-016-462-080 C-CAP,S 1-16 ZF<AE> 87-A21-179-010 C-IC,TA2123AF C152 87-016-462-080 C-CAP,S 1-16 ZF<AE> 87-A21-061-010 C-IC,ML63512-120 C153...

  • Page 4: Chip Resistor Part Code

    All manuals and user guides at all-guides.com REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION S207 87-A90-698-080 C-SWICH PUSH 1-1-1 PS-170-AT S209 8Z-HK4-607-010 SW,LID 7ZM-1 SFR301 87-A91-011-080 C-SFR,6.8K RH03APA VR101 87-024-686-080 C-VR,20KAX2 DIA14 X201 87-A70-151-110 VIB,XTAL 32.768KHZ VT JACK C.B J101 85-HK3-605-010...
  • Page 5 All manuals and user guides at all-guides.com WIRING - 5 -...

  • Page 6: Schematic Diagram

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM - 6 -...

  • Page 7: Ic Block Diagram

    All manuals and user guides at all-guides.com IC BLOCK DIAGRAM - 7 -...
  • Page 8 All manuals and user guides at all-guides.com IC DESCRIPTION IC, ML63512-120 Pin No. Pin Name Description AF IN ‘H’: Exist music, ‘L’: Not exist music. SCLK Serial clock input terminal. MUTE ‘H’: MUTE OFF, ‘L’: MUTE ON. SDATA Serial data output terminal. F/R CONT ‘H’: FWD direction, ‘L’: REV direction.
  • Page 9 All manuals and user guides at all-guides.com Pin No. Pin Name Description POWER ON "H" : Power ON, "L" : Power OFF. DD DRIVE Output terminal for control DC-DC converter. EJECT SW Input terminal for detect EJECT operation. "L" : Wait. "H"...
  • Page 10 All manuals and user guides at all-guides.com ADJUSTMENT MAIN C.B VOLUME VR101 J101 PHONES (R-CH) (L-CH) IC201 IC301 SFR301 : At the other side of the pattern. 1. Tape Speed Adjustment 2. Dolby level check Settings : • Test tape : TTA–100 Settings : •...

  • Page 11: Mechanical Exploded View

    All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1 / 1 CONT C.B SW C.B 7ZM-1 P1NF MAIN C.B - 11 -...

  • Page 12: Mechanical Parts List

    All manuals and user guides at all-guides.com MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-HK4-045-010 LID,CASS 2000 ASSY<AH,YH> 24 8Z-HK4-216-010 BASE,LOCK 1 8Z-HK4-052-010 LID,CASS 2000E ASSY<AE> 25 8Z-HK4-221-010 SPR-P,CASS 2 8Z-HK4-228-010 SPR-P,LID...

  • Page 13: Tape Mechanism Exploded View

    All manuals and user guides at all-guides.com TAPE MECHANISM EXPLODED VIEW 1 / 1 HEAD FLEX. C.B BRG, 7ZSIA - 13 -...

  • Page 14: Tape Mechanism Parts List

    All manuals and user guides at all-guides.com TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 87-ZM1-230-010 HLDR,HEAD 31 87-ZM1-265-010 HLDR,CAM 2 87-ZM1-254-110 ARM ASSY,PINCH R 32 87-ZM1-261-010 LEVER,SW 3 87-ZM1-287-010 SPR-T,PINCH BACK R 33 87-ZM1-250-210...

  • Page 15: Accessories / Package List

    All manuals and user guides at all-guides.com ACCESSORIES / PACKAGE LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 8Z-HK4-922-010 IB,H(ECC) S 2000<AH> 8Z-HK4-923-010 IB,YHS(EC) S <YH> 8Z-HK4-925-010 IB,E(5L) S 2000<AE> 8Z-HK4-926-010 IB,E(5L) S 2000<AE> 87-B30-083-110 CHARGER,RB-107 E<AE>...
