- Page 1 HS-PX390 AH, D HS-PX597 AE, AK SERVICE MANUAL STEREO CASSETTE PLAYER BASIC TAPE MECHANISM : 6ZM-2 P11NF MODEL CODE : 8 Z H K 5 - 0 1 3 4 < S > 8 Z H K 5 - 0 1 6 4 < L > S/M Code No.
-
Page 3: Specifications
SPECIFICATIONS<EXCEPT 390D> SPECIFICATIONS<390D> Maximum output: 4 mW + 4 mW (EIAJ 32 ohms)<390AH> 4 mW + 4 mW (EIAJ 16 ohms)<597> Load impedance: 16–32 ohms<597 only> Power source: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using an R6 (AA) dry cell battery, AC house current using optional AC adaptor Maximum dimensions 80.1 (W) x 110.2 (H) x 24.1 (D) mm (3 in.) -
Page 4: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C203 87-012-274-080 -- CHIP CAP,U 1000P-50B<597> CHIP RESISTOR PART CODE C204 87-A11-187-080 -- C-CAP,TN 10-4 AM004R<597> 87-A21-179-040 1H C-IC,TA2123AF C205 87-A11-188-080 -- C-CAP,TN 22-4 AM004R<597> 87-A20-818-040 -- C-IC,NJM2185AV<597>... -
Page 5: Transistor Illustration
TRANSISTOR ILLUSTRATION IC BLOCK DIAGRAM- 1 IC TA2123AF 2SA1363GR 2SC3326B RN4605 2SC4116GR RN2305 RN1310 2SA1162Y... - Page 6 WIRING (MAIN)
-
Page 7: Schematic Diagram (Main)
SCHEMATIC DIAGRAM (MAIN) - Page 8 IC BLOCK DIAGRAM- 2 IC DESCRIPTION IC NJM2185AV IC, ML63512-122 Pin No. Pin Name Description AF IN H: exist music, L: no music. SCLK Input serial clock ( Not used) . MUTE H: mute OFF, L: mute ON. SDATA Output serial data (Not used). F/R CONT H: REV mode, L: FWD mode.
- Page 9 Pin No. Pin Name Description...
- Page 10 IC DESCRIPTION IC, ML63512-122...
- Page 12 ADJUSTMENT MAIN C.B VOLUME VR101 SFR 301 IC301 (R-CH) (L-CH) IC701 PHONES J101...
-
Page 13: Practical Service Figure
PRACTICAL SERVICE FIGURE <TAPE PLAYER SECTION> <TAPE SECTION>... -
Page 14: Exploded View
MECHANICAL EXPLODED VIEW 1/1<390> JACK SPACER,PWB 6ZM-2 P11NF HS-PX390 (FileName:EXPLODED.EPS) 99/7/22... -
Page 15: Parts List
MECHANICAL PARTS LIST 1/1<390> REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-HK5-026-010 1H LID ASSY,CASS BLU<390L> 27 8Z-HK5-221-010 0E SPR-T,CLICK 1 8Z-HK5-018-010 1H LID ASSY,CASS D<390S> 28 8Z-HK5-222-010 0E JOINT,HOLD 2 8Z-HK5-216-010 0E SPR-P,POP-UP 29 8Z-HK5-004-010 1A PANEL,CABI 3 8Z-HK5-214-010 1C HLDR ASSY,CASS MOT 30 8Z-HK5-007-010 1B KEY,CONT... - Page 16 MECHANICAL EXPLODED VIEW 1/1<597> JACK SPACER,PWB 6ZM-2 P11NF HS-PX597 (FileName:EXPLODED.EPS) 99/7/22...
-
Page 17: Mechanical Parts List
MECHANICAL PARTS LIST 1/1<597> REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-HK5-236-010 S-SCREW,1.4-2.3 23 8Z-HK5-008-010 LENS,LED 1 8Z-HK5-015-010 LID ASSY,CASS<597AK,597AE> 24 8Z-HK5-010-010 KNOB,SL OPEN 1 8Z-HK5-018-010 LID ASSY,CASS D<597AH> 25 8Z-HK5-013-010 KNOB,SL DSL 2 8Z-HK5-216-010 SPR-P,POP-UP 26 8Z-HK5-210-010 HLDR,KNOB OPEN... - Page 18 TAPE MECHANISM EXPLIDED VIEW 1/1 HEAD FLEX C.B SH,1.2-2.9-0.25SL SH,1.2-2.9-0.25SL HLDR,FP PLATE,THRUST...
-
Page 19: Tape Mechanism Parts List
TAPE MECHANISM PARTS LIST 1/1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 86-ZM2-255-010 0E SPR-T,PIN BACK L 36 86-ZM2-222-410 0E LEVER,PIN UP R 2 86-ZM2-252-610 0E GUIDE,TAPE 37 86-ZM2-218-310 0E LEVER,HEAD UP 38 86-ZM2-205-410 1A FLY-WHL,L 3 86-ZM2-220-210 0E SPR-T,HEAD 4 86-ZM2-219-510 0E LEVER,HEAD 39 86-ZM2-330-010 1A FLY-WHL,R2... - Page 20 2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 931261 9820572 Printed in Singapore...
