LGE Internal use only

REV.03

Service

Manual

Model : V7

720 Series

2014.

08. 14

copied, reproduced, modified, distributed, displayed, stored in

a retrieval system, or transmitted in any form by any Means

(electronic, photocopying, recording or otherwise), without the

Retention period until : 2016-10

Prior written authorization of LG Electronics.

Table of Contents

Need help?

Do you have a question about the V720 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LG V720 Series

Page 1 720 Series 2014. 08. 14 Copyrightⓒ2012 LG Electronics, Digital Mate Co., Ltd . All rights reserved. No part of this manual may be used, copied, reproduced, modified, distributed, displayed, stored in a retrieval system, or transmitted in any form by any Means...
Page 2: Table Of Contents
Ch 4. Symptom-to-part index · Power system checkout · LCD-related symptoms · Indeterminate problems Ch 5. Removing and replacing a part (FRU) Ch 6. Part list · Part list · Exploded view Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 3: Ch1. Service Information
The drive startup sequence in the computer you are servicing may have been changed. Be extremely careful during write operations such as copying, saving, or formatting. If you select an incorrect drive, data or programs can be overwritten. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 4: Safety Notices
Warning Before removing any part (FRU), turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 5: Safety Information
· After service, reinstall all safety shields, guards, labels, and ground wires. Replace any safety device that is worn or defective. · Reinstall all covers correctly before returning the machine to the customer. Caution Metal objects are good electrical conductors. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 6: Electrical Safety
An electrical shock can occur only when there is a complete circuit. By observing the above rule, you may prevent a current from through your body. · When using testers, set the controls correctly and use the approved probe leads and accessories for that tester Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 7 (This practice ensure correct grounding of the units.) · If an electrical accident occurs 1. Use caution ; do not become a victim of yourself. 2. Switch off power. 3. Send another person to get medical aid. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 8: Safety Inspection Guide
Insulation must not be frayed or worn. 4. Remove the cover. 5. Check for any obvious non-LG alterations. Use good judgment as to the safety of any non-LG alterations. 6. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.
Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge
Use the round ground-prong of the AC plug on AC-operated computers. Grounding requirements Electrical grounding of the computers is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 10: Laser Compliance Statement
1-5. Backup (Standby) RTC battery safety information When replacing or disposing of the backup (standby) RTC battery, note the following : Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 11: Read This First
1-6. Read this first Before you go to the checkout guide, be sure to read this section. Important Notes Only trained personnel certified by LG should service the computer. · Read the entire FRU removal and replacement page before replacing any FRU.
Page 12 Missing parts might be a symptom of unauthorized service or modification. · If the spindle of a hard-disk drive becomes noisy, it may have been subjected to excessive force, or · dropped. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 13: Ch2. Name Of Each Part
6. Optical Disk Operation Indicator Lamp/Eject CD 17. USB port (USB 2.0 port) Button 18. Fan Louvers 7. Optical disk drive 19. Security Key Hole (Kensington Lock Hole) 8. Multi-card slot Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 14: Front View
10. Settings menu button. Open the main menu or save the selection and exit the menu. 11. TV / External Input Buttons. Change the input source to TV, PC or HDMI. 12. Monitor / TV Power Button Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 15: Ch3. System Information
• If you connect to Bluetooth device and wireless LAN at the same time, the system may become slow. • In order the use Bluetooth 4.0, the device you want to connect to should support Bluetooth 4.0. Wireless LAN • Intel® 2230BNHMW • Intel® 135BNHMW • Ralink® RT3290 LE Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 16 ※ Manufacturers and installers cannot provide services related to human safety as this wireless device may cause radio interference. Web Camera • 1.3M HD Web Camera • Gigabit Ethernet Product Weight • Ca.7.3 kg • The weight may differ according to the model. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 18: Fn Key Combinations
Hot keys are available only in the PC Mode. Use the hot keys for more convenient PC environment. To enable OSD Guide message to appear, install the OSD3 from [LG Update Center]. Then run [LG Control Center] > [System Settings] > [On Screen Display] tile.
Page 19: Status Indicators
• Off: The monitor or TV is turned on. ※ Standby lamp is switched on every time the remote control is used. You can configure using the function by going to Settings menu > General > Display Lamp. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 20: Bios Flash
To boot from a USB device, use [F2] key to move the USB device to the top of the list in Boot menu after entering BIOS Setup, or press [F10] key to display Boot menu while the LG logo is being displayed, and the select a device you want to use.
Page 21 (For details, refer to [Check Secure Boot].) 9. It selects the :” Load Optimized Defaults” on the “Exit” menu or [F9] Key and it summons a BIOS settings at initial value. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 22: Check Secure Boot
4. Upon the system rebooting, enter BIOS Setup again and check if Secure Boot has the values in the following figure. (Check UEFI Secure Boot, Protected Signatures, CertNames and Secure Boot Option.) Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 23: Bios Setup
5. Downgrading from Windows 8 to Windows 7 (SecureBoot Disable) 1. In Windows 8, select “Restart”. 2. Once the system restarts and “LG” Logo appears, press [F2] key. The booting speed is faster than the existing models. You'd better press it as soon as the system restarts.
Page 24: Using The Keys
Display Setup Confirmation window. Press Enter to save and exit. · : Exit In a sub-menu, press Esc to move to the previous window. In Main menu, click Esc to move to Exit menu. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 25 · Slot 1~2 · Processor Spd This shows the size of the memory installed in This shows the speed of CPU. the memory slot. · BIOS Version This shows the Version of BIOS. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 26: Advanced Menu
Set if it is used a prevention function or not Data Execution Prevention of Windows XP SP2. (DEP: Technology examining memory additionally to prevent execution of malignant code in the system) Intel provide XD (eXecute Disable bit) that architecture is compatibility with DEP as a standard. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 27 For TV mode, by lowering the CPU clock. It is a feature to reduces noise of FAN . · SATA Device It select the operating mode of SATA controller. The default is “AHCI”. If you install to XP It be change to "IDE". Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 28: Security Menu
Enables password on boot. · HDD Password is This shows the system’s HDD password has been set, or not. · SSD Password is This shows the system’s SSD password has been set, or not. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 29 Ch3. System information Boot menu · Boot Priority Order Select the desired device drive by using the arrow buttons and change its booting sequence by using the [F5] or [F6] key. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 30 Select Load Setup Defaults to change the setup information to the factory default settings. If you select Load Setup Defaults or press F9, Setup Confirmation asks you to confirm your selection. Press Yes to load setup defaults. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 31 Ch3. System information ■ Using LG Recovery Center If the system has an error, you can use Windows LG Recovery Center to recover or restore the system to its initial purchase state. ※ LG Recovery Center uses the Windows 8 recovery function.
Page 32 If it is impossible to recover by using [F11], you can recover the system through a recovery drive. ※ To recover by using a recovery drive, you must have the recovery drive made through LG Recovery Center [Create Recovery Drive].
Page 33 · Emergency Recovery data is included in automatically written Backup Archives. · Emergency Recovery Token (e.g. SPEmRecToken.xml): Created by Security Platform Administrator. Protected with a dedicated password. Is required for a restoration of Emergency Recovery data. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 34 Broken hard disk or lost data Security Platform Credentials and Settings, Personal Secure Drive New Trusted Platform Module Emergency Recovery New Security Platform to be initialized Emergency Recovery, Security Platform Credentials and Settings, Personal Secure Drive Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 35 Please note that automatic backups are only executed if your PC is not shut down at the scheduled time. Please note that the user account chosen for the scheduled backup must be member of the group "Administrators" or "Backup Operators". Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 36 This button is disabled, if the Infineon Security Platform is disabled or not yet set up. Click here to create a backup authentication device. This feature is only available, if Enhanced Authentication is enabled. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 37: Ch4. Symptom-To-Part Index
1. Replace the system board. 2. If the problem persists, check the AC adapter whether it is correct product or not. Note Noise from the AC adapter does not always indicate a defect. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 38: Lcd-Related Symptoms
3. LCD Assembly. LCD screen unreadable. 4. System board. Wrong color displayed. Horizontal or vertical lines displayed LCD Assembly. on LCD Power-on indicator on, and a blank\LCD LCD Assembly. during POST. System board. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 39: Indeterminate Problems
(do not replace a non-defective FRU) a. LCD Assembly (Check external monitor whether the same problem recurs or not). b. Keyboard. c. Keydeck (TouchPad and Scroll Button Assembly). d. System board. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 40: Chapter 5. Removing And Replacing A Part (Fru)
Verify metal flakes can cause electrical short circuits. Note -As for the screw, every Torque 3 0.2Kgfcm(0.196Nm) -For further information on Removing and Replacing a Part(FRU), refer to Explore view. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 41 Ch5. Removing and replacing a part ■ 1010 Stand Back Cover 1. Push in the plastic ZIG in the furrow of the arrow and separate the cover lifting from the bottom to the upper side. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 43 ※ Remove the following parts in order before replacing this part a. Stand Back Cover(1010) 1. Removes 1 screw. FRU No. Specification Screw, M3.0 X L8 Black FAB30018405 2. Slide while pressing the Hook and removes the Hinge Bottom Cover. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 45 ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020) 1. Remove 2 cables. 2. After pressing Hook on both sides by ZIG, removes 1 cable. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 46 APCPCWM_4828539:WP_GLOBAL_PFWP_GLOBAL_PF Ch5. Removing and replacing a part 3. Remove 4 screws. FRU No. Specification Screw, M4.0 x L7.0 x D8.3 x H2.5, FAB31626901 Silver 3. Remove the Stand. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 47 Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030) 1. After removing 8 screws, remove the Memory Cover. FRU No. Specification 1SZZBA4068C Screw, M2.5 X L5.0 Black 2. Holding a hole, removes Stand Bottom Cover. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 49 Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030), d. Stand Bottom Cover(1040) 1. After removing 7 cables, remove 6 screws. FRU No. Specification Screw, M2.5 X L5.0 Black 1SZZBA4068C 2. Remove the WLAN Antenna. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 51 ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c.Stand(1030), d. Stand Bottom Cover(1040) , e. Mainboard(1050) 1. Remove Hooks. Hook 2. Remove the Memory. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 52 Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c.Stand(1030), d. Stand Bottom Cover(1040) , e. Mainboard(1050) 1. Removes 1 screw. FRU No. Specification Screw, M2.5 X L5.0 Black 1SZZBA4068C 2. Remove the WLAN. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 53 Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c.Stand(1030), d. Stand Bottom Cover(1040) , e. Mainboard(1050) 1. Remove the antenna cable and 6 fixed screws. Cable 2. Remove the CPU/GPU Fan Assembly. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 54 ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c.Stand(1030), d. Stand Bottom Cover(1040) , e. Mainboard(1050) 1. It uses screwdriver and it removes the CPU. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 55 ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c.Stand(1030), d. Stand Bottom Cover(1040) , e. Mainboard(1050) 1. Remove the 30PIN, 16PIN Cable. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 56 Mainboard(1050), f. Memory(1060), g. WLAN(1070), h. CPU/GPU Fan Assembly(1080), i. CPU(1090), j. 30PIN / 16 PIN Cable(1100) 1. Remove 2 screws FRU No. Specification 1SZZBA4068C Screw, M2.5 X L5.0 Black 2. Remove the DC – Jack Cable. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 57 Mainboard(1050), f. Memory(1060), g. WLAN(1070), h. CPU/GPU Fan Assembly(1080), i. CPU(1090), j. 30PIN / 16 PIN Cable(1100) 1. Remove 4 screws and cable. Cable FRU No. Specification Screw, M2.5 X L5.0 Black 1SZZBA4068C 2. Remove the ODD from Stand Plate. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 58 APCPCWM_4828539:WP_GLOBAL_PFWP_GLOBAL_PF Ch5. Removing and replacing a part 3. After removing ODD cable, remove 2 screws. FRU No. Specification Screw, M2.0 X L3.0 Silver(D4.0, H1.0t) 1SZZBA4019J 4. Remove the ODD Bracket. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 59 1. Remove 2 screw and the cable. Cable FRU No. Specification Screw, M2.5 X L5.0 Black 1SZZBA4068C 2. After removing 4 screws, remove the HDD Bracket. FRU No. Specification 1SZZBA4011K Screw, M3.0 X L3.0 White Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 60 ■ 1140 Hinge Top Cover ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030) 1. Remove the Hinge Top Cover by screwdriver. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 62 Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030), d. Hinge Top Cover(1140) 1. Remove 2 screws. FRU No. Specification Screw, M3.0 X L6 Yellow FAB30013616 2. It uses JIG and it removes the Display Back Cover. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 64 ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030), d. Hinge Top Cover(1140), e. Display Back Cover(1150) 1. Remove 2 cables. Cable Cable 2. Removes the LCD Cable. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 65 ※ Remove the following parts in order before replacing this part a. Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030), d. Hinge Top Cover(1140), e. Display Back Cover(1150) 1. Remove 3 cables. 2. Remove the Speaker cable. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 67 Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170) 1. Remove 2 cables and 6 screws. Cable Cable FRU No. Specification FAB30013616 Screw, M3.0 X L6 Yellow Screw, M2.5 X L4 Silver FAB30738602 2. Removes the Rear Frame. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 68 Hinge Bottom Cover(1010), b. Hinge Bottom Cover(1020), c. Stand(1030), d. Hinge Top Cover(1140), e. Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170), h. Rear Frame(1180) 1. Remove 4 screws. FRU No. Specification Screw, M3.0 X L6 Yellow FAB30013616 2. Removes the MTV Board. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 69 Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170), h. Rear Frame(1180), i. MTV Board (1190) 1. Remove 4 screws.. FRU No. Specification Screw, M4.0 X L10.0 Black FAB30012104 2. Remove the Hinge. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 70 Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170), h. Rear Frame(1180) 1. Remove 6 screws. FRU No. Specification Screw, M3.0 X L6 Yellow FAB30013616 FAB30007504 Screw, M3.0 X L8 Black(tapping) 2. Removes the Bottom Plate. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 71 Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170), h. Rear Frame(1180), i. Bottom Plate (1210) 1. Remove 1cable and 7 screws. Cable FRU No. Specification Screw, M2.5 X L4 Silver FAB30738602 2. Removes the BLU Cable Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 73 Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170), h. Rear Frame(1180), i. Bottom Plate (1210), j. LCD Assembly(1220) 1. Remove 2 screws. FRU No. Specification Screw, M2.0 X L6.0 Black(Tapping) FAB30018105 1. Remove the Webcam. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 74 Display Back Cover(1150), f. LCD Cable(1160), g. Speaker(1170), h. Rear Frame(1180), i. Bottom Plate (1210), j. LCD Assembly(1220) 1. Remove the Control Board attached to double-sided tape. 2. Remove the Control Board. Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 76: Chapter 6. Part Lists
R NHDD04 NHDD04 EAD62160301 EAD62160301 HDD Cable HDD Cable NODD01 EAZ61361602 ODD (DVD Su uper-Multi) GA31N ABA74274901 --> A NODD02 ABA74274902 ODD Bracket A Assembly BA74274902 (ODD 걸림 이슈 p/n 변경) Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 77 NKBD02 ACQ86132501 ACQ86132501 Keyskin Victor Keyskin Victor ry LITE ON ry LITE ON NSCR01 1SZZBA4011K Screw, M3.0 X X L3.0 White SCREW NSCR02 1SZZBA4019J Screw, M2.0 X X L3.0 Silver(D4.0, H1.0t) Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 78 EAD62043001 TV Antenna co onnection cable 11/8 (12') add N3D01 EBX61568102 3D Glasses N ormal type (full-HD) 1/15 (13') add N3D02 EBX61548101 3D Glasses C lip type (FHD/HD) 1/15 (13') add Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 79 NSTAND10 NSTAND11 NHEAD06 NHEAD08 NHEAD07 NHEAD10 NHEAD04 NHEAD10 NHEAD09 NMLB01 NHEAD02 NHEAD05 NWEBC01 NWEBC02 NHEAD03 NHEAD11 NHEAD01 NHEAD12 LGE Internal Use Only Copyrightⓒ2012 LG Electronics Co., Ltd.
Page 80 Camera Module NCM-141F-L NWEBC02 EAD62160501 Webcam cable Webcam NWEBC03 MAZ63523401 Case, Webcam PCB Bracket 1/18 (13') add NWEBC04 MDS64151802 Gasket, only sponge for webcam leakage(30 x 8 x 5t) 1/23 (13') add Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 81 STAND NSTAND07 EAD62248501 Cable, DC jack NSTAND08 EAA62793001 Cable antenna (Wireless_Main) EAA62793101 --> NSTAND09 EAA62964901 Cable antenna (Wireless_Aux) EAA62964901 p/n change NSTAND10 MCK67252401 Cover, Hinge Top NSTAND11 MCK67252501 Cover, Hinge Bottom Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 83 EAN62428704 i5-3210M NCPU01 EAN62428705 i3-3110M NCPU01 EAN62116604 B970 Pentium 2.3GHz 8/6 (12') add NCPU01 EAN62671901 2020M L-1 SR0U1 2.40GHz 1/15 (13') add NCPU01 EAN62428707 i5-3230M L-1 2.6GHz 3MB 1/15 (13') add Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 84 NSTAND04 NSTAND03 NSTAND07 NODD03 NODD02 NODD04 NSTAND05 NODD01 NSTAND09 NHDD04 NHDD01 NHDD03 NSTAND08 NHDD02 NSTAND06 NSTAND01 NSTAND02 LGE Internal Use Only Copyrightⓒ2012 LG Electronics Co., Ltd.
Page 85 SVC Call Label for domestic sku 6/26 (12') add NLAB07 MEZ63332202 3D label on kdeck 6/26 (12') add Window8 OS Label ALL Windows 8 Logo ( GML, NLAB08 MEZ64720301 16.077 x 22.501 mm ) Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 87 Remote control - 3D (KOREA) NACC04 EAD62043001 TV Antenna connection cable 11/8 (12') add N3D01 EBX61568102 3D Glasses Normal type (full-HD only) 1/15 (13') add N3D02 EBX61548101 3D Glasses Clip type (FHD/HD) 1/15 (13') add Copyrightⓒ2012 LG Electronics Co., Ltd. LGE Internal Use Only...
