Summary of Contents for ASROCK PHANTOM GAMING X870 RIPTIDE WiFi

  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 3: Table Of Contents

    Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram 802.11be Wi-Fi 7 Module and ASRock WiFi 2.4/5/6 GHz Antenna Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header...
  • Page 4 2.14 Post Status Checker 2.15 M.2 SSD Installation Guide (M2_1) 2.16 M.2 SSD Installation Guide (M2_2) 2.17 M.2 SSD Installation Guide (M2_3)

  • Page 5: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    • Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)* • Max. capacity of system memory: 256GB • Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: Slot • 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 7 X870 Riptide WiFi Graphics • Integrated AMD RDNA graphics (Actual support may vary by CPU) • 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz • 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz* * Only the CPU's embedded graphics can be displayed through USB4 ports.
  • Page 8 CPU: • 2 x USB4 Type-C (Rear) • 1 x USB 3.2 Gen2 Type-A (Rear (USB32_3)) • 1 x USB 3.2 Gen1 Type-A (Rear (USB32_1)) Chipset: • 1 x USB 3.2 Gen2x2 Type-C (Front) • 1 x USB 3.2 Gen2 Type-A (Rear (USB32_4)) • 6 x USB 3.2 Gen1 Type-A (2 Rear (USB32_2 and USB32_5), 4 Front) • 8 x USB 2.0 (4 Rear, 4 Front)
  • Page 9 X870 Riptide WiFi * M2_1 is the first priority for M.2 installation. * M2_1 will run at Gen5x4 with 9000 and 7000 series proces- sors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors. * If M2_3 is occupied, PCIE2 will be disabled. RAID • Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*...
  • Page 10 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    X870 Riptide WiFi 1.3 Motherboard Layout...
  • Page 12 No. Description ATX 12V Power Connector (ATX12V1) ATX 12V Power Connector (ATX12V2) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) CPU Fan Connector (CPU_FAN1) CPU Fan Connector (CPU_FAN2) AIO Pump Fan Connector (AIO_PUMP) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2) Post Status Checker (PSC) Addressable LED Header (ADDR_LED3) Addressable LED Header (ADDR_LED2)

  • Page 13: I/O Panel

    X870 Riptide WiFi 1.4 I/O Panel No. Description No. Description USB 3.2 Gen2 Ports (USB32_34)* USB4 Type-C Port (USB4_TB1) 2.5G LAN RJ-45 Port** USB 3.2 Gen1 Ports (USB32_12)**** Microphone Input Jack*** USB 2.0 Ports (USB_1234) Line Out Jack*** BIOS Flashback Button Optical SPDIF Out Port Antenna Ports USB 3.2 Gen1 Port (USB32_5)
  • Page 14 *** Function of the Audio Ports in 2, 4, 5.1 or 7.1-channel Configuration: Channel Port Function Line Out Jack Front speaker out (Rear Panel) Pink-Mic Rear speaker out (Front Panel) Microphone Input Jack 5.1ch Central/Subwoofer speaker out (Rear Panel) Lime-Headphone 7.1ch Side Speaker out (Front Panel)

  • Page 15: Block Diagram

    X870 Riptide WiFi 1.5 Block Diagram...

  • Page 16: 802.11Be Wi-Fi 7 Module And Asrock Wifi 2.4/5/6 Ghz Antenna

    1.6 802.11be Wi-Fi 7 Module and ASRock WiFi 2.4/5/6 GHz Antenna 802.11be Wi-Fi 7 + BT Module This motherboard comes with an exclusive 802.11 a/b/g/n/ac/ax/axe/be Wi-Fi 7 + BT v5.4 module that offers support for 802.11 a/b/g/n/ac/ax/axe/be Wi-Fi 7 connectivity standards and Bluetooth v5.4.

  • Page 17: Chapter 2 Installation

    X870 Riptide WiFi Chapter 2 Installation This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 18: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.
  • Page 19 X870 Riptide WiFi Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 20 Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 21: Installing The Cpu Fan And Heatsink

    X870 Riptide WiFi 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 23 X870 Riptide WiFi Installing the CPU Cooler (Type 2)
  • Page 25 X870 Riptide WiFi +12V *The illustrations shown here are for reference purposes only and may not exactly match the model you purchase.
  • Page 26 Installing the CPU Cooler (Type 3)
  • Page 27 X870 Riptide WiFi...
  • Page 29 +12V Please note that only one cable should be used at a time in this step. If you select RGB_LED1, please install ASRock utility "ASRock Polychrome SYNC". If you select USB connector, please install AMD utility "SR3 Settings Software". *The illustrations shown here are for reference purposes only and may not exactly match...

  • Page 30: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 31 X870 Riptide WiFi...

  • Page 32: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 33: Installing The Motherboard

    X870 Riptide WiFi 2.5 Installing the Motherboard...

  • Page 34: Installing Sata Drives

    2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 35 X870 Riptide WiFi SATA Power Connector SATA Data Connector...

  • Page 36: Installing A Graphics Card

    2.7 Installing a Graphics Card CLICK!
  • Page 37 X870 Riptide WiFi Expansion Slots (PCIe Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 38: Connecting Peripheral Devices

    2.8 Connecting Peripheral Devices...

  • Page 39: Connecting The Power Connectors

    X870 Riptide WiFi 2.9 Connecting the Power Connectors...

  • Page 40: Power On

    2.10 Power On...

  • Page 41: Jumpers Setup

    X870 Riptide WiFi 2.11 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRCMOS1) (see p.7, No.

  • Page 42: Onboard Headers And Connectors

    2.12 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.7, No.
  • Page 43 X870 Riptide WiFi Power LED and Speaker Header (7-pin SPK_PLED1) (see p.7, No. 19) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED- Serial ATA3 Connectors Right Angle: (SATA3_A1) (see p.7, No. 17) (Upper) (SATA3_A2) (see p.7, No.
  • Page 44 USB 2.0 Headers (9-pin USB_5_6) (see p.7, No. 21) (9-pin USB_7_8) (see p.7, No. 20) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_5_6 USB_PWR DUMMY USB_PWR USB_7_8 USB_PWR DUMMY USB_PWR USB 3.2 Gen1 Headers (19-pin USB32_6_7) (see p.7, No.
  • Page 45 X870 Riptide WiFi Front Panel Type C USB 3.2 Gen2x2 Header (20-pin USB32_TC1) (see p.7, No. 13) There is one Front Panel Type C USB 3.2 Gen2x2 Header on this motherboard. This header is used for connecting a USB 3.2 Gen2x2 module for additional USB 3.2 Gen2x2 ports.
  • Page 46 Chassis Fan Connectors (4-pin CHA_FAN1) (see p.7, No. 23) (4-pin CHA_FAN2) (see p.7, No. 24) (4-pin CHA_FAN3) (see p.7, No. 29) This header allows you to connect Case or Radiator fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CHA_FAN3 FAN_VOLTAGE CHA_FAN_SPEED...
  • Page 47 X870 Riptide WiFi CPU Fan Connector (4-pin CPU_FAN1) (see p.7, No. 4) This header allows you to connect CPU fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CPU_FAN1 +12V CPU_F AN_SPEED FAN_SPEED_CONTROL CPU Fan Connector (4-pin CPU_FAN2) (see p.7, No.
  • Page 48 AIO Pump Fan Connector (4-pin AIO_PUMP) (see p.7, No. 6) This header allows you to connect AIO (All-in-One) pump or fan. If you plan to connect a 3-pin AIO cooler fan, please connect it to Pin 1-3. AIO_PUMP FAN_VOLTAGE AIO_PUMP_SPEED FAN_SPEED_CONTROL...
  • Page 49 X870 Riptide WiFi ATX Power Connector (24-pin ATXPWR1) (see p.7, No. 11) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1 ATX 12V Power Connectors (8-pin ATX12V1) (see p.7, No.
  • Page 50 SPI TPM Header (13-pin SPI_TPM_J1) (see p.7, No. 14) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
  • Page 51 X870 Riptide WiFi Thermistor Cable Header (2-pin T_SENSOR1) (see p.7, No. 27) The Thermistor Cable Headers are used to connect thermistor cables to monitor the temperature of the critical components. Plug the thermistor cables that come with the package to these headers, and then attach the sensor ends to the components to detect their temperature.
  • Page 52 RGB LED Header (4-pin RGB_LED1) (see p.7, No. 26) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 53 X870 Riptide WiFi Addressable LED Headers (3-pin ADDR_LED1) (see p.7, No. 25) (3-pin ADDR_LED2) (see p.7, No. 10) (3-pin ADDR_LED3) (see p.7, No. 9) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation;...
  • Page 54 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 55: Smart Switches

    X870 Riptide WiFi 2.13 Smart Switches The motherboard has one smart switch: BIOS Flashback Button, allowing users to flash the BIOS. BIOS Flashback Button (BIOS_FB1) (see p.9, No. 11) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB1 USB BIOS Flashback port...
  • Page 56 ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryp- tion or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.

  • Page 57: Post Status Checker

    X870 Riptide WiFi 2.14 Post Status Checker Post Status Checker (PSC) diagnoses the computer when users power on the machine. The LEDs light up to show what component is running into an issue. They emit red, yel- low, white and yellow-green lights to indicate, respectively, the CPU, memory, VGA and storage are not detected or fail.
  • Page 58 2.15 M.2 SSD Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode. * M2_1 is the first priority for M.2 installation. * M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors.
  • Page 59 X870 Riptide WiFi Step 3 Push and hold the button on the M.2 heatsink (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 60 Step 7 Press the M.2 heatsink down into place. *Be sure not to press down the button on the M.2 heatsink. Step 8 Complete. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...
  • Page 61 X870 Riptide WiFi 2.16 M.2 SSD Installation Guide (M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2, Key M) supports type 2230/2260/2280 PCIe Gen4x4 (64 Gb/s) mode. Installing the M.2 SSD Step 1 Prepare a M.2 SSD.
  • Page 62 Step 3 Before installing a M.2 SSD, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD. Step 4 Use a screwdriver to remove the standoff.
  • Page 63 M.2 heatsink into place. Please do not overtighten the screw as this might damage the M.2 SSD and M.2 heatsink. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...
  • Page 64 2.17 M.2 SSD Installation Guide (M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_3, Key M) supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode. * If M2_3 is occupied, PCIE2 will be disabled. Installing the M.2 SSD Step 1 Prepare a M.2 SSD.
  • Page 65 X870 Riptide WiFi Step 3 Before installing a M.2 SSD, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD. Step 4 Use a screwdriver to remove the standoff.
  • Page 66 M.2 heatsink into place. Please do not overtighten the screw as this might damage the M.2 SSD and M.2 heatsink. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...

  • Page 67: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in...

  • Page 68: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 69 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 70 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 71 European Community Radio Equipment Directive Compliance Statement This device complies with directive 2014/53/EU issued by the Commision of the European Community. This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
