Summary of Contents for ASROCK PHANTOM GAMING Z890 LIGHTNING WiFi

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock Z890 Lightning WiFi o cerca il tuo prodotto tra le migliori offerte di Schede Madri...

  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...

  • Page 3: Table Of Contents

    Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram 802.11be Wi-Fi 7 Module and ASRock WiFi 2.4/5/6 GHz Antennas Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header...
  • Page 4 2.14 Smart Button 2.15 M.2 SSD Installation Guide (M2_1) 2.16 M.2 SSD Installation Guide (M2_2) 2.17 M.2 SSD Installation Guide (M2_3) 2.18 M.2 SSD Installation Guide (M2_4)

  • Page 5: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 9066+(OC)* • Max. capacity of system memory: 256GB • Supports Intel® Extreme Memory Profile (XMP) 3.0x * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: Slot • 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 7 Z890 Lightning WiFi Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. • Intel® X LPG Graphics Architecture • 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max.
  • Page 8 CPU: • 2 x Thunderbolt 4 Type-C (Rear) Chipset: • 1 x USB 3.2 Gen2x2 Type-C (Front) • 2 x USB 3.2 Gen2 Type-A (Rear) • 8 x USB 3.2 Gen1 (4 Rear, 4 Front) • 6 x USB 2.0 (2 Rear, 4 Front) * All USB ports support ESD Protection Rear Panel • 2 x Antenna Ports...
  • Page 9 Z890 Lightning WiFi RAID • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices Connector • 1 x Thermistor Cable Header • 1 x SPI TPM Header • 1 x Power LED and Speaker Header • 1 x RGB LED Header*...
  • Page 10 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    Z890 Lightning WiFi 1.3 Motherboard Layout CPU_FAN1 DRAM ATX12V1 ATX12V2 BOOT CPU_FAN2 AIO_PUMP USB 2.0 Top: T: USB_1 RJ-45 B: USB_2 CHA_FAN5 PCIE1 RoHS Intel WiFi-802.11be Module Z890 M2_WIFI1 SUPER AUDIO PCIE2 CODEC CMOS Battery PCIE3 SPI_TPM_J1 T_SENSOR1 PANEL1 CHA_FAN4 CHA_FAN3 CHA_FAN2 CHA_FAN1...
  • Page 12 No. Description ATX 12V Power Connector (ATX12V1) ATX 12V Power Connector (ATX12V2) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2) CPU Fan Connector (CPU_FAN2) CPU Fan Connector (CPU_FAN1) Post Status Checker (PSC) Addressable LED Header (ADDR_LED3) AIO Pump Fan Connector (AIO_PUMP) Addressable LED Header (ADDR_LED2)

  • Page 13: I/O Panel

    Z890 Lightning WiFi 1.4 I/O Panel No. Description No. Description Antenna Ports Microphone (Pink) USB 3.2 Gen2 Port (USB32_1) Optical SPDIF Out Port USB 3.2 Gen2 Port (USB32_2) USB 3.2 Gen1 Ports (USB32_34)** 2.5G LAN RJ-45 Port* USB 2.0 Ports (USB_12) USB 3.2 Gen1 Ports (USB32_56)** Thunderbolt 4 Type-C Port (TB_2)
  • Page 14 *There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection 100Mbps/1Gbps Blinking Data Activity...

  • Page 15: Block Diagram

    Z890 Lightning WiFi 1.5 Block Diagram...

  • Page 16: 802.11Be Wi-Fi 7 Module And Asrock Wifi 2.4/5/6 Ghz Antennas

    1.6 802.11be Wi-Fi 7 Module and ASRock WiFi 2.4/5/6 GHz An- tennas 802.11be Wi-Fi 7 + BT Module This motherboard comes with an exclusive 802.11 a/b/g/n/ac/ax/axe/be Wi-Fi 7 + BT v5.4 module that offers support for 802.11 a/b/g/n/ac/ax/axe/be Wi-Fi 7 connectivity standards and Bluetooth v5.4.
  • Page 17 Z890 Lightning WiFi WiFi Antennas Installation Guide Step 1 Prepare the WiFi 2.4/5/6 GHz Antennas that come with the package. Step 2 Connect the two WiFi 2.4/5/6 GHz Antennas to the antenna connectors. Turn the antenna clockwise until it is securely connected. Step 3 Set the WiFi 2.4/5/6 GHz Antenna as shown in the illustration.

  • Page 18: Chapter 2 Installation

    Chapter 2 Installation This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.
  • Page 19 Z890 Lightning WiFi DO NOT remove this Memory OC Shield (patent pending) from the motherboard. Removing this may affect memory overclocking performance and stability. The illustration shown here is for reference only and may not be an exact representation of your mother- board’s layout.

  • Page 20: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1851-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 21 Z890 Lightning WiFi Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 22: Installing The Cpu Fan And Heatsink

    2.2 Installing the CPU Fan and Heatsink...

  • Page 23: Installing Memory Modules (Dimm)

    Z890 Lightning WiFi 2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs.

  • Page 25: Connecting The Front Panel Header

    Z890 Lightning WiFi 2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 26: Installing The Motherboard

    2.5 Installing the Motherboard...

  • Page 27: Installing Sata Drives

    Z890 Lightning WiFi 2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 28 SATA Power Connector SATA Data Connector...

  • Page 29: Installing A Graphics Card

    Z890 Lightning WiFi 2.7 Installing a Graphics Card CLICK!
  • Page 30 Expansion Slots (PCIe Slots) There are 3 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 31: Connecting Peripheral Devices

    Z890 Lightning WiFi 2.8 Connecting Peripheral Devices...

  • Page 32: Connecting The Power Connectors

    2.9 Connecting the Power Connectors...

  • Page 33: Power On

    Z890 Lightning WiFi 2.10 Power On...

  • Page 34: Jumpers Setup

    2.11 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) (see p.7, No. 19) CLRMOS1 allows you to clear the data in CMOS.

  • Page 35: Onboard Headers And Connectors

    Z890 Lightning WiFi 2.12 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.7, No.
  • Page 36 Power LED and Speaker Header (7-pin SPK_PLED1) (see p.7, No. 18) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED-...
  • Page 37 Z890 Lightning WiFi Serial ATA3 Connectors Right Angle: (SATA3_0) (see p.7, No. 16)(Upper) (SATA3_1) (see p.7, No. 16)(Lower) (SATA3_2) (see p.7, No. 15)(Upper) (SATA3_3) (see p.7, No. 15)(Lower) These four SATA3 connectors support SATA data cables for internal storage devices with up to 6.0 Gb/s data transfer rate.
  • Page 38 USB 2.0 Headers (9-pin USB_3_4) (see p.7, No. 22) (9-pin USB_5_6) (see p.7, No. 21) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_5_6 USB_PWR DUMMY USB_PWR USB_3_4 USB_PWR DUMMY USB_PWR...
  • Page 39 Z890 Lightning WiFi USB 3.2 Gen1 Headers Right Angle: (19-pin USB32_7_8) (see p.7, No. 14) Vertical: (19-pin USB32_9_10) (see p.7, No. 12) There are two headers on this motherboard. Each USB 3.2 Gen1 header can support two ports. USB32_9_10 Vbus Vbus Vbus IntA_PB_SSRX-...
  • Page 40 Front Panel Type C USB 3.2 Gen2x2 Header (20-pin USB32_TC2) (see p.7, No. 13) There is one Front Panel Type C USB 3.2 Gen2x2 Header on this motherboard. This header is used for connecting a USB 3.2 Gen2x2 module for additional USB 3.2 Gen2x2 ports.
  • Page 41 Z890 Lightning WiFi Front Panel Audio Header (9-pin HD_AUDIO1) (see p.7, No. 30) This header is for connecting audio devices to the front audio panel. HD_AUDIO1 PRESENCE# MIC_RET OUT_RET OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly.
  • Page 42 Chassis Fan Connectors (4-pin CHA_FAN1) (see p.7, No. 23) (4-pin CHA_FAN2) (see p.7, No. 24) (4-pin CHA_FAN3) (see p.7, No. 25) (4-pin CHA_FAN4) (see p.7, No. 26) (4-pin CHA_FAN5) (see p.7, No. 31) These headers allow you to connect Case or Radiator fans. If you plan to connect a 3-pin fan, please connect it to Pin 1-3.
  • Page 43 Z890 Lightning WiFi CPU Fan Connector (4-pin CPU_FAN1) (see p.7, No. 6) This header allows you to connect CPU fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CPU_FAN1 +12V CPU_F AN_SPEED FAN_SPEED_CONTROL CPU Fan Connector (4-pin CPU_FAN2) (see p.7, No.
  • Page 44 AIO Pump Fan Connector (4-pin AIO_PUMP) (see p.7, No. 9) This header allows you to connect AIO (All-in-One) pump or fan. If you plan to connect a 3-pin AIO cooler fan, please connect it to Pin 1-3. AIO_PUMP FAN_VOLTAGE AIO_PUMP_SPEED FAN_SPEED_CONTROL ATX Power Connector (24-pin ATXPWR1) (see p.7, No.
  • Page 45 Z890 Lightning WiFi ATX 12V Power Connectors (8-pin ATX12V1) (see p.7, No. 1) (8-pin ATX12V2) (see p.7, No. 2) This motherboard provides two 8-pin ATX 12V power connectors. To use a 4-pin ATX power supply, please plug it along Pin 1 and Pin 5. *Connecting an ATX 12V 8-pin cable to ATX12V2 is optional.
  • Page 46 SPI TPM Header (13-pin SPI_TPM_J1) (see p.7, No. 20) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. SPI_TPM_J1 TPM_PIRQ RST#...
  • Page 47 Z890 Lightning WiFi Thermistor Cable Header (2-pin T_SENSOR1) (see p.7, No. 27) The Thermistor Cable Header is used to connect a thermistor cable to monitor the temperature of the critical component. Plug the thermistor cable that comes with the package to the header, and then attach the sensor end to the component to detect the temperature.
  • Page 48 RGB LED Header (4-pin RGB_LED1) (see p.7, No. 29) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 49 Z890 Lightning WiFi Addressable LED Headers (3-pin ADDR_LED1) (see p.7, No. 28) (3-pin ADDR_LED2) (see p.7, No. 10) (3-pin ADDR_LED3) (see p.7, No. 8) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation;...
  • Page 50 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 51: Post Status Checker

    Z890 Lightning WiFi 2.13 Post Status Checker Post Status Checker (PSC) diagnoses the computer when users power on the machine. The LEDs light up to show what component is running into an issue. They emit red, yellow, white and yellow-green lights to indicate, respectively, the CPU, memory, VGA and storage are not detected or fail.

  • Page 52: Smart Button

    2.14 Smart Button The motherboard has one smart switch: BIOS Flashback Button, allowing users to flash the BIOS. BIOS Flashback Button (BIOS_FB1) (see p.9, No. 14) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB1 USB BIOS Flashback port...
  • Page 53 Z890 Lightning WiFi ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryption or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.
  • Page 54 2.15 M.2 SSD Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode. Installing the M.2 SSD Step 1 Prepare a M.2 SSD.
  • Page 55 Z890 Lightning WiFi Step 3 Push the button on the M.2 heatsink in the direction shown (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 56 Step 7 Press the M.2 heatsink down into place. *Be sure not to press down the button on the M.2 heatsink. Step 8 Complete. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...
  • Page 57 Z890 Lightning WiFi 2.16 M.2 SSD Installation Guide (M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2 , Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 58 Ensure that the notch at the end of the M.2 SSD aligns with the nut. Then secure the M.2 SSD by turning the nut lock clockwise to its locked position. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...
  • Page 59 Z890 Lightning WiFi 2.17 M.2 SSD Installation Guide (M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_3 , Key M) supports type 2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes.
  • Page 60 Step 3 Push and hold the button on the M.2 heatsink (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 61 Step 7 Press the M.2 heatsink down into place. *Be sure not to press down the button on the M.2 heatsink. Step 8 Complete. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...
  • Page 62 2.18 M.2 SSD Installation Guide (M2_4) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_4 , Key M) supports 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode. Installing the M.2 SSD Step 1 Prepare a M.2 SSD.
  • Page 63 Z890 Lightning WiFi Step 3 Push and hold the button on the M.2 heatsink (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 64 Step 6 Align and gently insert the M.2 SSD into the M.2 slot. Please be aware that the M.2 SSD only fits in one orientation. Step 7 Ensure that the notch at the end of the M.2 SSD aligns with the nut. Then secure the M.2 SSD by turning the nut lock clockwise to its locked position.
  • Page 65 Step 9 Press the M.2 heatsink down into place. *Be sure not to press down the button on the M.2 heatsink. Step 10 Complete. For the latest updates of M.2 SSDsupport list, please visit our website for details: http:// www.asrock.com...

  • Page 66: Copyright Notice

    ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential...
  • Page 67 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You agree...
  • Page 68 U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S.

  • Page 69: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 70 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 71 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 72 European Community Radio Equipment Directive Compliance Statement This device complies with directive 2014/53/EU issued by the Commision of the European Community. This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
  • Page 74 BSMI 限用物質及元素清單 限用物質及其化學符號 單元 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六價鉻 (Cr ) 多溴聯苯 (PBB) 多溴聯苯醚 (PBDE) 電路板 電子元件 線材 配件 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含 量基準值。 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 備考 3.〝－〞係指該項限用物質為排除項目。...
  • Page 75 China RoHS 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2014「电子信息 产品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露产品中含有 的有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、财产造成 严重损害的期限。依上述规定，您可于本产品之印刷电路板上看见图一之标示。图一 中之数字为产品之环保使用期限。由此可知此主板之环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 以上表格依据 SJ/T 11364-2014 的规定编制。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出...
