  • Page 1 Uputstvo za upotrebu (EN) ASRock B650 PG Lightning matična ploča Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.

  • Page 3: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header Installing the Motherboard Installing SATA Drives Installing a Graphics Card Connecting Peripheral Devices Connecting the Power Connectors...
  • Page 5 2.15 M.2 SSD Module Installation Guide (M2_1) 2.16 M.2 SSD Module Installation Guide (M2_2 and M2_3)

  • Page 6: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 7: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)* • Max. capacity of system memory: 192GB • Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: Slot • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 8 PCIe Gen4x4 (64 Gb/s) mode* Chipset: • 1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x2 (32 Gb/s) mode* • 4 x SATA3 6.0 Gb/s Connectors * Supports NVMe SSD as boot disks * Supports ASRock U.2 Kit...
  • Page 9 RAID • Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices • Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe stor- age devices* * Requires additional M.2 NVMe expansion cards to support RAID 10 Connector • 1 x SPI TPM Header • 1 x Power LED and Speaker Header...
  • Page 10 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    1.3 Motherboard Layout CPU_FAN2/WP CHA_FAN1 ATX12V1 ATX12V2 CPU_FAN1 USB 3.2 Gen1 T: USB32_1 B: USB32_2 USB 3.2 Gen1 Top: T: USB32_3 RJ-45 B: USB32_4 USB 3.2 Gen1 T: USB32_5 B: USB32_6 USB 3.2 Gen1 T:USB32_7 USB 3.2 Gen2x2 B: USB32_TC1 CHA_FAN3/WP BIOS _FB1...
  • Page 12 B650 PG Lightning No. Description ATX 12V Power Connector (ATX12V1) ATX 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1) CPU/Water Pump Fan Connector (CPU_FAN2/WP) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) Post Status Checker (PSC) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2) Chassis/Water Pump Fan Connector (CHA_FAN1/WP) Addressable LED Header (ADDR_LED2) ATX Power Connector (ATXPWR1)

  • Page 13: I/O Panel

    1.4 I/O Panel No. Description No. Description 2.5G LAN RJ-45 Port* USB 3.2 Gen1 Type-A Ports Line In (Light Blue)** (USB32_56) Front Speaker (Lime)** USB 3.2 Gen1 Type-A Ports BIOS Flashback Button (USB32_34)*** Microphone (Pink)** USB 2.0 Ports (USB1234) USB 3.2 Gen1 Type-A Port USB 3.2 Gen1 Type-A Ports (USB32_7) (USB32_12)
  • Page 14 B650 PG Lightning *There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection 100Mbps/1Gbps Blinking...

  • Page 15: Block Diagram

    1.5 Block Diagram...

  • Page 16: Chapter 2 Installation

    B650 PG Lightning Chapter 2 Installation This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 17: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 18 B650 PG Lightning Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 19 Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 20: Installing The Cpu Fan And Heatsink

    B650 PG Lightning 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 22 B650 PG Lightning Installing the CPU Cooler (Type 2)
  • Page 24 B650 PG Lightning +12V *The illustrations shown here are for reference purposes only and may not exactly match the model you purchase.
  • Page 25 Installing the CPU Cooler (Type 3)
  • Page 26 B650 PG Lightning...
  • Page 28 +12V Please note that only one cable should be used at a time in this step. If you select RGB_LED1, please install ASRock utility "ASRock Polychrome SYNC". If you select USB connector, please install AMD utility "SR3 Settings Software". *The illustrations shown here are for reference purposes only and may not exactly match...

  • Page 29: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 30 B650 PG Lightning...

  • Page 31: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 32: Installing The Motherboard

    B650 PG Lightning 2.5 Installing the Motherboard...

  • Page 33: Installing Sata Drives

    2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 34 B650 PG Lightning SATA Power Connector SATA Data Connector...

  • Page 35: Installing A Graphics Card

    2.7 Installing a Graphics Card CLICK!
  • Page 36 B650 PG Lightning Expansion Slots (PCIe Slots) There are 4 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 37: Connecting Peripheral Devices

    2.8 Connecting Peripheral Devices...

  • Page 38: Connecting The Power Connectors

    B650 PG Lightning 2.9 Connecting the Power Connectors...

  • Page 39: Power On

    2.10 Power On...

  • Page 40: Jumpers Setup

    B650 PG Lightning 2.11 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRCMOS1) (see p.6, No.

  • Page 41: Onboard Headers And Connectors

    2.12 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.6, No.
  • Page 42 B650 PG Lightning Power LED and Speaker Header (7-pin SPK_PLED1) (see p.6, No. 18) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED-...
  • Page 43 Serial ATA3 Connectors Right Angle: (SATA3_1) (see p.6, No. 15) (SATA3_2) (see p.6, No. 16) Vertical: (SATA3_3) (see p.6, No. 20) (SATA3_4) (see p.6, No. 19) These four SATA3 connectors support SATA data cables for internal storage devices with up to 6.0 Gb/s data transfer rate. SATA3_3 SATA3_4...
  • Page 44 B650 PG Lightning USB 2.0 Headers (9-pin USB_5_6) (see p.6, No. 22) (9-pin USB_7_8) (see p.6, No. 21) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_7_8 USB_PWR DUMMY USB_PWR USB_5_6 USB_PWR DUMMY USB_PWR...
  • Page 45 USB 3.2 Gen1 Header (19-pin USB32_8_9) (see p.6, No. 12) There is one header on this motherboard. This USB 3.2 Gen1 header can support two ports. USB32_8_9 Vbus Vbus Vbus IntA_PB_SSRX- IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ IntA_PA_SSTX+ IntA_PB_D- IntA_PA_D- IntA_PB_D+ IntA_PA_D+ Dummy...
  • Page 46 B650 PG Lightning Front Panel Type C USB 3.2 Gen2 Header (20-pin USB32_TC2) (see p.6, No. 11) There is one Front Panel Type C USB 3.2 Gen2 Header on this motherboard. This header is used for connecting a USB 3.2 Gen2 module for additional USB 3.2 Gen2 ports.
  • Page 47 Front Panel Audio Header (9-pin HD_AUDIO1) (see p.6, No. 28) This header is for connecting audio devices to the front audio panel. HD_AUDIO1 PRESENCE# MIC_RET OUT_RET OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly.
  • Page 48 B650 PG Lightning Chassis/Water Pump Fan Connectors (4-pin CHA_FAN1/WP) (see p.6, No. 8) (4-pin CHA_FAN2/WP) (see p.6, No. 13) (4-pin CHA_FAN3/WP) (see p.6, No. 29) (4-pin CHA_FAN4/WP) (see p.6, No. 24) This motherboard provides four 4-Pin water cooling chassis fan connectors. If you plan to connect a 3-Pin chassis water cooler fan, please connect it to Pin 1-3.
  • Page 49 CPU Fan Connector (4-pin CPU_FAN1) (see p.6, No. 3) This motherboard provides a 4-Pin CPU fan (Quiet Fan) connector. If you plan to connect a 3-Pin CPU fan, please connect it to Pin 1-3. CPU_FAN1 +12V CPU_F AN_SPEED FAN_SPEED_CONTROL...
  • Page 50 B650 PG Lightning CPU/Water Pump Fan Connector (4-pin CPU_FAN2/WP) (see p.6, No. 4) This motherboard provides a 4-Pin water cooling CPU fan connector. If you plan to connect a 3-Pin CPU water cooler fan, please connect it to Pin 1-3. CPU_FAN2/WP FAN_VOLTAGE CPU_F...
  • Page 51 ATX Power Connector (24-pin ATXPWR1) (see p.6, No. 10) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1...
  • Page 52 B650 PG Lightning ATX 12V Power Connectors (8-pin ATX12V1) (see p.6, No. 1) (8-pin ATX12V2) (see p.6, No. 2) This motherboard provides two 8-pin ATX 12V power connectors. To use a 4-pin ATX power supply, please plug it along Pin 1 and Pin 5. *Connecting an ATX 12V 8-pin cable to ATX12V2 is optional.
  • Page 53 SPI TPM Header (13-pin SPI_TPM_J1) (see p.6, No. 14) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. SPI_TPM_J1 SPI_DQ3 SPI_PWR...
  • Page 54 B650 PG Lightning RGB LED Header (4-pin RGB_LED1) (see p.6, No. 27) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 55 Addressable LED Headers (3-pin ADDR_LED1) (see p.6, No. 26) (3-pin ADDR_LED2) (see p.6, No. 9) (3-pin ADDR_LED3) (see p.6, No. 25) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation;...
  • Page 56 B650 PG Lightning 1. Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your RGB LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 57: Smart Button

    2.13 Smart Button The motherboard has a smart button: BIOS Flashback Button, allowing users to flash the BIOS. BIOS Flashback Button (BIOS_FB1) (see p.8, No. 4) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB1 USB BIOS Flashback port...
  • Page 58 B650 PG Lightning ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryption or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.

  • Page 59: Post Status Checker

    2.14 Post Status Checker Post Status Checker (PSC) diagnoses the computer when users power on the machine. It emits a red light to indicate whether the CPU, memory, VGA or storage is dysfunctional. The lights go off if the four mentioned above are function- ing normally.
  • Page 60 B650 PG Lightning 2.15 M.2 SSD Module Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode.
  • Page 61 Step 3 Before installing a M.2 SSD module, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD module. Step 4 Align and gently insert the M.2 SSD module into the M.2 slot.
  • Page 62 B650 PG Lightning Step 5 Before securing the M.2 heatsink, make sure to align the notch on the SSD to the standoff on the motherboard if you use a Type 2280 SSD module; otherwise, the SSD module may be damaged. Correct Installation: The SSD's PCB is in proper place, and the M.2 heatsink can be screwed in.
  • Page 63 M.2 connector (3). *Please do not overtighten the screw as this might damage the module and M.2 heatsink. For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...
  • Page 64 B650 PG Lightning 2.16 M.2 SSD Module Installation Guide (M2_2 and M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 65 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module. NUT2 NUT1 For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...

  • Page 66: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 67 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 68 Ovaj dokument je originalno proizveden i objavljen od strane proizvođača, brenda ASRock, i preuzet je sa njihove zvanične stranice. S obzirom na ovu činjenicu, Tehnoteka ističe da ne preuzima odgovornost za tačnost, celovitost ili pouzdanost informacija, podataka, mišljenja, saveta ili izjava sadržanih u ovom dokumentu.
