Laundry Combo
User manual
WD90F53AV*
Untitled-3 1
Untitled-3 1
2025-02-05
2025-02-05
2:37:29
2:37:29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD90F53AV Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WD90F53AV Series

Summary of Contents for Samsung WD90F53AV Series

  • Page 1 Laundry Combo User manual WD90F53AV* Untitled-3 1 Untitled-3 1 2025-02-05 2025-02-05 2:37:29 2:37:29...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions CALIFORNIA PROPOSITION 65 WARNING Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Care for preventing freezing Regulatory notice FCC Notice IC Notice Open Source Announcement...
  • Page 3 Operations LCD panel Operating a cycle Cycle overview Cycle chart Settings Special features SmartThings Maintenance Product Care Drum Clean+ Emergency drain Cleaning Recovery from freezing Care for an extended period of non-use Cleaning the exterior Exhaust system Cleaning the interior Troubleshooting Checkpoints Information codes...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung Laundry Combo. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your Laundry Combo’s many benefits and features.
  • Page 5 WARNING - Risk of Fire • Laundry Combo installation must be performed by a qualified installer. • Install the Laundry Combo according to the manufacturer’s instructions and local codes. • Do not install a Laundry Combo with flexible plastic venting materials.
  • Page 6 Safety information WARNING - To reduce the risk of fire or explosion: • Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry cleaning solvents, or other flammable or explosive substances. They emit vapors that could ignite or explode.
  • Page 7 WARNING - Fire or explosion hazard • Failure to follow safety warnings exactly could result in serious injury, death or property damage. • Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance. •...

  • Page 8: Important Safety Precautions

    Safety information Important safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using this appliance. 2. DO NOT wash or dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flammable or explosive substances as they give off vapors that could ignite or explode.

  • Page 9: California Proposition 65 Warning

    15. DO NOT use heat to dry articles containing foam rubber or similarly textured rubber-like materials. 16. Keep area around the exhaust opening and adjacent surrounding areas free from the accumulation of lint, dust, and dirt. 17. The interior of the appliance should be cleaned periodically by qualified service personnel. 18.
  • Page 10 Safety information Plug the power cord firmly into a wall socket that meets local electrical specifications. Use the socket for this appliance only, and do not use an extension cord. • Sharing a wall socket with other appliances using a power strip or extending the power cord may result in electric shock or fire.

  • Page 11: Installation Cautions

    Following the repair by a non-authorized service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product which does not carefully follow these repair and maintenance instructions.
  • Page 12 Safety information In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power plug. Do not touch the appliance or power cord. • Do not use a ventilating fan. • A spark may result in an explosion or fire. Remove all door levers before disposing of the appliance.

  • Page 13: Usage Cautions

    • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power cord and contact your nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 14 Using the appliance for business purposes qualifies as an appliance misuse. In this case, the appliance will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 15 Do not touch the inside of the glass door and the drum after washing and drying as those parts may become hot and could cause burns. Do not insert your hand into the detergent drawer. • This may result in injury as your hand may be caught by the detergent input device. Remove the liquid detergent guide (applicable models only) when using powdered detergent.
  • Page 16 Safety information Make sure that the pockets of all the clothing items are empty. • Hard, sharp objects such as coins, safety pins, nails, screws, or stones can cause extensive damage to the appliance. Do not wash or dry clothing with large buckles, buttons, or other heavy metal objects. Sort the laundry by color on the basis of its colorfastness and select the recommended cycle, water temperature and additional functions.

  • Page 17: Critical Cleaning Warnings

    Critical cleaning warnings WARNING Do not clean the appliance by spraying water directly onto it. Do not use a strong acidic cleaning agent. Do not use benzene, thinner or alcohol to clean the appliance. • This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the appliance from the wall socket.

  • Page 18: Regulatory Notice

    Regulatory notice FCC Notice CAUTION Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1.
  • Page 19 Model WD90F53AV* WD90F53AV* Variant model Asterisk (*) varies from A through Z which indicates the color of the appliance. Samsung Electronics America, Inc. 85 Challenger Road Responsible Party - U.S. Contact Information Ridgefield Park, NJ 07660 Phone : 1-800-SAMSUNG (726-7864) This device complies with Part 15 of the FCC Rules.

  • Page 20: Ic Notice

    Regulatory notice IC Notice The term "IC" before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 21: Open Source Announcement

    (Please use the "Inquiry" menu.) It is also possible to obtain the complete corresponding source code in a physical medium such as a CD- ROM;...

  • Page 22: Installation

    Installation Follow these instructions carefully to ensure proper installation of the Laundry Combo and to prevent accidents when doing laundry. WARNING Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel – Do not contact the following parts while the appliance is energized: Control board, heat sink, motor, inlet valve and pump.

  • Page 23: Unpacking Your Laundry Combo

    If your Laundry Combo was damaged during shipping, or you do not have all of the items, call 1-800-SAMSUNG (1-800-726-7864). To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.

  • Page 24: What's Included

    What’s included Make sure all the parts are included in the product package. If you have a problem with the Laundry Combo or the parts, contact a local Samsung customer center or retailer. NOTE The appearance of the actual product may differ from the image shown.

  • Page 25: Parts Supplied

    • The appearance of the Laundry Combo and provided accessories may differ with the model. • To purchase an accessory or lost part, contact a local Samsung service center or retailer. Water hoses are not sold in Samsung service center or retailers.

  • Page 26: Installation Requirements

    Installation • Make sure rubber washers are inserted in each coupling of both water hoses. Installation requirements Electrical connections Before operating or testing, follow all grounding instructions in the “ Grounding” section. An individual branch (or separate) circuit serving only your Laundry Combo is recommended. Do not use an extension cord.

  • Page 27: Water Supply

    • Before using the Laundry Combo for the first time, check all connections at the water valve and taps for any leaks. Drain Samsung recommends a standpipe 18 in. (460 mm) high. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose. Flooring For best performance, the Laundry Combo must be installed on a solid floor.

  • Page 28: Clearance Requirement

    Installation Dimensions A. Overall height 43.7 in. (1110 mm) B. Width 27 in. (686 mm) C. Depth with door open 56.3 in. (1430 mm) D. Depth 34.4 in. (875 mm) Clearance requirement Alcove or closet installations Minimum clearance for stable operation Sides Rear Front...
  • Page 29 Custom cabinet and side-by-side installation 1 in. (25 mm) 1 in. (25 mm) 1 in. (25 mm) 2 in. (50 mm) CAUTION Please be aware of the following when installing and using the product. • After plugging the power plug, make sure the power cord does not get pressed or pinched by the product while you push it into the final installation position.

  • Page 30: Ducting Requirements

    Installation Ducting requirements Use only for short-run Recommended installation Weather hood type 4” (10.2 cm) 2.5” (6.4 cm) No. of 90° elbows Rigid Rigid 80 ft. (24.4 m) 74 ft. (22.6 m) 68 ft. (20.7 m) 62 ft. (18.9 m) 57 ft.

  • Page 31: Exhausting Requirements

    Exhausting requirements The Laundry Combo must not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed space of a building. Exhausting the Laundry Combo to the outside will prevent large amounts of lint and moisture from being blown into the room.

  • Page 32: Electrical Requirements

    Installation Electrical requirements The wiring diagram is located on the plate under the control panel or rear frame. WARNING • Improperly connecting the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether your Laundry Combo is properly grounded.

  • Page 33: Step-By-Step Installation

    Step-by-step installation Make sure you have a qualified technician install the Laundry Combo. Step by step installation instructions start below. • Do not remove the protective film on the door before completing the product installation. If you remove the protective film before the installation is complete, the door may get scratched or damaged during installation.
  • Page 34 Installation • Packaging materials can be dangerous to children. Dispose all packaging material (plastic bags, polystyrene, etc.) out of children’s reach. STEP 3  Adjust the leveling feet 1. Gently slide the Laundry Combo into position. Excessive force may damage the leveling feet. 2.
  • Page 35 STEP 5  Connect the electrical wiring (for electric models) Before connecting the electrical wiring, make sure you have read the “ Electrical requirements” section on page 32. 3-wire system 1. Loosen or remove the screws from the center terminal block. 2. Connect the neutral wire (white or center wire) of the power cable to the center, silver-colored terminal screw of the terminal block.
  • Page 36 Installation 4-wire system 1. Remove the external ground connector’s screw and connect the ground wire (green or unwrapped) of the power cable to the screw. CAUTION To connect the ground wire to the neutral position without through contact A (cabinet ground), contact a technician.
  • Page 37 • If there is a water leak, stop using the Laundry Combo and contact a local Samsung service center. A water leak may cause electric shock. • Do not stretch the water hoses by force. If a hose is too short, replace the hose with a longer hose.
  • Page 38 Installation 1. Attach the water hoses to the hot and cold water taps, and then hand tighten the water hose fittings until they are tight. Then, use pliers to tighten the fittings by an additional two-thirds of a turn. To avoid damaging the fittings, do not overtighten them.
  • Page 39 5. Open the water taps, and check for leaks. Using the short hose as an extension To install this product with another washer, use the separately sold Y-connector. 1. Close the water tap. If you have a washer's water hose attached to the water tap, unscrew and remove the hose.
  • Page 40 Installation STEP 7  Connect the drain hose To a Laundry Tub or Drain Pipe 1. Check the height (A) of your drain system and make sure the minimum and maximum heights shown below are met. Minimum 18 in. (46 cm) Maximum 96 in.
  • Page 41 Over the edge of a wash basin The drain hose must be placed no lower than 24 in. (60 cm) and no higher than 35 in. (90 cm) from the floor. To keep the spout of the drain hose bent, use the supplied plastic hose guide (A).

  • Page 42: Vent Blockage Test

    Installation Vent blockage test After the Laundry Combo is installed, run the Vent Blockage Test function to check if the duct system is properly installed. Vent Blockage Test automatically detects the status of the ducts and reports any blockage or problems. Proper ducting can reduce drying time and save energy. NOTE The Vent Blockage Test function must run when the Laundry Combo is cool.

  • Page 43: Before You Start

    Before you start Initial setup • When you turn on the Laundry Combo for the first time, the screen shows the initial setup process. Follow the on-screen instructions to complete it. • Once you select a language, the language selection screen will not reappear. However, you must complete a wash cycle once to stop the tutorial screen from reappearing.

  • Page 44: Laundry Guidelines

    Before you start Laundry guidelines STEP 1  Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibers, synthetics, silks, wools, and rayon. • Color: Separate whites from colors. • Size: Mixing different sized items together in the drum improves the washing performance. •...
  • Page 45 STEP 4  Determine the load capacity Do not overload the Laundry Combo. Overloading may cause the Laundry Combo to wash improperly. NOTE When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be reduced. For bedding or bedding covers, the recommended maximum spin level is Low or Medium , and the load capacity is 7 lb (3.0 kg) or less.

  • Page 46: Detergent Drawer Guidelines

    Before you start Detergent drawer guidelines NOTE Auto dispensers make laundry easier by dispensing the preset amount of washing agents without you having to pour it in every time, and it could be more economical because the exact amount will be dispensed each time of use, allowing less waste of washing agents.
  • Page 47 • Use caution when inserting the Aqua Pebble as it is supposed to be balanced on top of the laundry at the beginning of the wash. Tipping the Aqua Pebble before the start of a wash may cause detergent residue to remain on the laundry at the end of the wash, causing discoloration of the laundry or reduced washing performance.
  • Page 48 Before you start To use bleach Add only liquid chlorine bleach to the Manual bleach dispenser. Do not exceed the max line. CAUTION • Do not add the liquid bleach without the liquid detergent guide in the Manual bleach dispenser. •...
  • Page 49 To apply washing agents to the Auto dispensers NOTE If the message " Needs refill " appears on the display, refill the corresponding dispenser. • The detection time may vary depending on the type of the detergent/softener. 1. Press the Compartment cover to open it. 2.
  • Page 50 Before you start 6. Apply an appropriate amount of detergent (General detergent or Specialty detergent) or softener to the Flex auto dispenser (D). After you finish, put the cap back and turn it clockwise to close. 7. Push the Auto dispensers back into their positions. 8.
  • Page 51 Dispenser care You can check the detergent type used in each dispenser. NOTE On the Dispenser care screen, the current status of detergent and fabric softener is displayed and will alert you if any of the dispensers are running low. Follow the on-screen instructions to refill the detergent or fabric softener.

  • Page 52: Operations

    Operations WARNING To reduce the risk of fire, electric shock, or injury to persons, read the Safety information before operating this Laundry Combo. LCD panel Tap to turn the Laundry Combo on or off. 01 Power The display shows current cycle information and estimated time remaining, or 02 Display an information message when a problem occurs.

  • Page 53: Display Icon Descriptions

    Display icon descriptions Home Tap to go to the Home screen. • This icon indicates the door is locked and cannot be opened. Door Lock • The door locks automatically during a cycle and this icon turns on. • You can open the door when this icon disappears. Smart Control •...
  • Page 54 Operations This icon appears during a dry-only cycle or a washing process. Tap cycle card to change the default wash cycle settings. You can see the full option list by tapping button. • Dryness : Tap to change the dry level. You can select from 4 different levels , but the available level depends on the selected cycle.

  • Page 55: Operating A Cycle

    Operating a cycle 1. Tap to turn the power on. 2. Select the desired cycle. For more information on Cycle overview, see page 56. 3. Change the default cycle options. For the washing process, tap Temp. , Spin , Soil , Detergent , Softener , Extra Rinse , or Bubble Soak to change the default cycle settings.

  • Page 56: Cycle Overview

    Operations Cycle overview Cycle descriptions You can add or delete cycles to personalize the cycle list in the My cycles option. See page 69 for more information. NOTE • Energy savings will vary depending on the installation conditions, loads and cycles. Energy consumption could increase if the LCD screen is set to stay on all year long.
  • Page 57 Cycle Description • For lightly soiled items that you want to finish washing quickly. Small Load • For best performance, recommended load is 4 lb (2.0 kg) or lower. • The Tide POD Cold cycle provides deep cleaning as the detergent dissolves effectively even in cold water.
  • Page 58 Operations Cycle Description • Use this cycle to reduce the amount of microfibers generated during Less Microfiber washing synthetic clothes. Spin Only • To perform the spin process only. • Features an additional rinse process after fabric softener is applied Rinse+Spin to the laundry.

  • Page 59: Cycle Chart

    Cycle chart Use this chart to set the best cycle and options for your laundry. Wash Cycle chart  : factory setting,  : can be selected Functions Cycle Temp. Extra Hot Warm Cold Tap Cold Normal    ...
  • Page 60 Operations Functions Spin Wash Only Wash & Dry Cycle Rinse Drain Extra Extra Hold Extra High Medium & No High Medium High & No High Spin Spin Normal        AI Opti Wash & Dry ...
  • Page 61 Functions Soil level Cycle Bubble Soak Extra Rinse Extra Extra Heavy Normal Light Heavy Light Normal        AI Opti Wash & Dry    Super Speed       Heavy Duty ...
  • Page 62 Operations Dry Cycle chart NOTE For best drying results, avoid overloading or underloading. Cycle Recommended items Temp. Normal Cotton, mixed loads of cotton and synthetic fabrics Medium AI Opti Wash & Dry Cotton, mixed loads of cotton and synthetic fabrics Medium Super Speed Synthetic fabrics...
  • Page 63  : factory setting,  : can be selected Functions Cycle Dryness Wrinkle Dry Time Dry Prep Eco Dry Prevent More Normal Less Damp Normal : wash+dry       : dry only AI Opti Wash & Dry ...

  • Page 64: Drying Guide

    Operations Drying guide The best way to dry items is to follow the instructions on the care label. If no drying instructions are provided, see the following table for reference. Items Description Follow the care label instructions or dry using Bedding. Bedspreads &...

  • Page 65: Settings

    • When you select an additional function, a brief help message appears for the first ten times of use. Settings menu description General Options Descriptions You can log in to your Samsung account or create a new Samsung Samsung account account. English 65 Untitled-3 65...
  • Page 66 Operations Options Descriptions You can turn the Wi-Fi on or off. You can also start the Smart Control function. • Wi-Fi : Tap to turn on or off the Wi-Fi. The Laundry Combo's Wi-Fi is off as a factory default setting. However, the Laundry Combo's Wi-Fi turns on automatically when you turn on the Laundry Combo for the first time.
  • Page 67 Options Descriptions You can set the Sound mode , Sound theme , Volume , and Voice style . • Sound mode : You can set the desired Sound mode from Voice , Tone , and Mute . If you set the Sound mode to Mute , the alert sound will not be turned off for safety purposes.
  • Page 68 Operations Options Descriptions You can set the Screen reader and Visibility enhancements settings. • Screen reader : Enable this feature to receive voice guidance from your Laundry Combo. Turn on the power, tap - Accessibility - Screen reader , and tap On to enable the feature.
  • Page 69 Options Descriptions You can check the information of the Laundry Combo such as Status and About device Legal information. Washer Options Descriptions This turns on the light inside the drum so you can check the status of Drum light the items inside. You can select the dispenser mode and set the detergent type, concentration, and amount setting.
  • Page 70 Operations Options Descriptions You can use this function to clean detergent or softener residue buildup in the pump. Use this function after you empty and clean the dispenser. • You can select from Auto dispenser , Flex auto dispenser , or Auto dispenser/Flex auto dispenser .
  • Page 71 Options Descriptions You can run calibration again for accurate weight detection. • Calibration does not start if the door is not closed properly. Calibration • The drum rotates clockwise and counterclockwise for about 3 minutes. You can use this function to check for abnormal signs on your Laundry Combo.

  • Page 72: Special Features

    Operations Special features Smart Control You can connect to the SmartThings app and control your Laundry Combo remotely. Connecting your Laundry Combo 1. Download and open the SmartThings app on your smartphone or tablet (Android & iOS). 2. Tap to turn on the Laundry Combo. 3.

  • Page 73: Smartthings

    You must first log into SmartThings with your Samsung account. To create a new Samsung account, follow the instructions on the app. You don’t need a separate app to create your account. NOTE If you have a Samsung account, use the account to log in. A registered Samsung smartphone or tablet user automatically logs in. English 73...
  • Page 74 Operations To register your appliance to SmartThings 1. Make sure your smartphone or tablet is connected to a wireless network. If not, go to Settings and turn on the wireless connection and select an AP (Access Point). 2. Open SmartThings on your smartphone or tablet. 3.

  • Page 75: Maintenance

    Maintenance Keep the Laundry Combo clean to prevent deteriorated performance and to preserve its life cycle. WARNING • Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel – Do not contact the following parts while the appliance is energized: Control board, heat sink, motor, inlet valve and pump.

  • Page 76: Drum Clean

    Maintenance Drum Clean+ Certain usage and environmental conditions may result in some residue build-up or odor in the drum. To prevent this build-up or odor and keep the drum fresh and clean, perform the Drum Clean+ cycle at least once a month or every 40 cycles. Perform the recommended procedure below when using the Drum Clean+ cycle.

  • Page 77: Emergency Drain

    Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Power off and unplug the Laundry Combo from the electrical outlet. 2. Press the Compartment cover to open it. 3. Pull out the Auto dispenser (A). 4.
  • Page 78 Maintenance 7. Insert the Auto dispenser (A) back into the place. 8. Close the Compartment cover. NOTE Use a spacious container because the water in the drum may be more than expected. English Untitled-3 78 Untitled-3 78 2025-02-05 2025-02-05 2:37:43 2:37:43...

  • Page 79: Cleaning

    Cleaning Surface of the Laundry Combo Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the Laundry Combo. Mesh filter Clean the mesh filter of the water hose once or twice a year. 1. Turn off the Laundry Combo, and unplug the power cord.

  • Page 80: Drain Filter

    Maintenance Drain filter It is advisable to clean the drain filter every 2 months to prevent its clogging. 1. Turn off the Laundry Combo, and unplug the power cord. 2. Drain the remaining water inside the drum. (For more information, see the Emergency drain section on page 77.) 3.
  • Page 81 8. Insert the Auto dispenser (A) back into the place. 9. Close the Compartment cover. NOTE If the drain filter is clogged, an information code of " 5C" appears on the screen. CAUTION • Make sure the filter knob is closed properly after cleaning the filter. Otherwise, this may cause a leak. •...
  • Page 82 Maintenance Auto dispensers To prevent the detergent residue buildup in the automatic dispensers, clean the dispensers and their components once or twice a month, and whenever you refill or change the detergent or softener. CAUTION • Make sure to turn off the Laundry Combo and unplug the power cord before cleaning. •...
  • Page 83 5. Remove the dispenser tray and clean it in running water to remove leaked detergent or softener. Then, put the tray back. 6. Push the Auto dispensers back into their positions. CAUTION • Make sure the dispenser recess is completely dry before inserting Auto dispensers.
  • Page 84 Maintenance Door diaphragm 1. Open the door, and then empty the drum. 2. Combine 3/4 cups of liquid chlorine bleach and 1 gallon of warm tap water. 3. Wearing rubber gloves, use a soft, clean cloth dipped in the water and bleach solution to clean the diaphragm.

  • Page 85: Lint Filter

    Lint filter You must clean the lint filter every time after using the dry cycle. Not cleaning the lint filter could degrade the drying performance and affect the drying time. 1. Open the Lint filter cover. 2. Pull out the lint filter. Do not remove the rubber seal on the lint filter.

  • Page 86: Recovery From Freezing

    Maintenance 5. Put the inner filter into the outer filter in the correct direction. 6. Insert the assembled lint filter back into the place. CAUTION • Clean the lint filter after each load. Failure to remove lint from the filter may affect drying performance and increase drying time.

  • Page 87: Care For An Extended Period Of Non-Use

    Care for an extended period of non-use Avoid leaving the Laundry Combo unused for an extended time. However, if you intend to leave the Laundry Combo unused for a long period of time, follow the directions below: 1. Tap 2. On the cycle screen, select Rinse+Spin . 3.

  • Page 88: Troubleshooting

    Troubleshooting If a problem persists, contact a service center. The number of the service center is on the label attached to the product. Checkpoints If you encounter a problem with the Laundry Combo, first check the table below and try these suggestions. Problem Action •...
  • Page 89 Problem Action • Make sure the Laundry Combo is installed on a level, solid floor that is not slippery. If the floor is not level, use the leveling feet to adjust the height of the Laundry Combo. • Make sure the shipping bolts are removed. •...
  • Page 90 Troubleshooting Problem Action • Tap to stop the Laundry Combo. • It may take a few moments for the door lock mechanism to disengage. • The door will not open until 3 minutes after the Laundry Combo has stopped or the power has been off. •...
  • Page 91 Problem Action • Fully open both taps. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct taps. Flush water lines. • Make sure the water heater is set to supply a minimum of 49 °C hot water at the tap.
  • Page 92 Troubleshooting Problem Action • Always make sure the lint filter is clean before putting items into the Laundry Combo. When drying items that generate a large amount of lint, you may need to clean the lint filter in the middle of a cycle. The clothes have lint on •...
  • Page 93 Problem Action • After refilling the Auto dispenser and Flex auto dispenser, close the The " Needs refill " detergent drawer, and then tap and hold . Then, the Laundry Combo message does not will start to detect the detergent/softener, and the message will disappear after refilling disappear.

  • Page 94: Information Codes

    Troubleshooting Information codes If there is any problem, check the information message on the LCD screen and follow the on-screen instructions. Problem Code Action • The Laundry Combo isn't draining properly. • Clean the drain filter, then tap Start to restart the Laundry Combo.
  • Page 95 Check filter is inserted restart the Laundry Combo. Or, turn it off and on again correctly after 2-3 minutes, then try again. If any information code keeps appearing on the screen, contact a local Samsung service center. English 95 Untitled-3 95 Untitled-3 95...

  • Page 96: Specifications

    Specifications Fabric care chart The following symbols provide garment care Normal direction. The clothing care labels include Permanent press/Wrinkle resistant/ symbols for drying, bleaching, drying and ironing, Wrinkle control or dry cleaning when necessary. The use of symbols ensures consistency among garment Gentle/Delicates manufacturers of domestic and imported items.

  • Page 97: Protecting The Environment

    Warning symbols for laundering Dry-clean Do not wash Dry-clean Do not wring Do not dry-clean Do not bleach Line dry/Hang to dry Do not tumble dry Drip dry No steam (added to iron) Dry flat Do not iron Protecting the environment •...

  • Page 98: Specification Sheet

    Specif ccaiion Specification sheet Front loading washer Type WD90F53AV*** Capacity (Cu.ft) Water pressure (psi (kPa)) 20-116 (137-800) NET weight (lb (kg)) 298 (135.0) Spin revolution 1200 rpm Washing 1300 W Heating rating Drying 5200 W Washing 200 W Washing and 1400 W Power heating...

  • Page 99: Limited Warranty (U.s.a.)

    Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale and/or proof of delivery must be presented upon request to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service.
  • Page 100 Visits by an authorized servicer to explain product functions, maintenance or installation are not covered by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these issues.
  • Page 101 LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.

  • Page 102: Warranty (Canada)

    To receive in-home service, product must be unobstructed and accessible to the service agent. If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized service center. SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
  • Page 103 OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
  • Page 104 ENERGY STAR. Scan this with your smartphone QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support www.samsung.com/ca/support (English) CANADA 1-800-Samsung (726-7864) www.samsung.com/ca_fr/support (French) Untitled-3 104 Untitled-3 104...
