This quick guide provides installation instructions. For safety precautions and detailed product information, refer to the
scan the below QR code or go to the SAJ Website
NOTICE
⚫
Before installation, operation, and maintenance, read the product documentation carefully.
⚫
ONLY qualified and trained electricians who have read and fully understood all safety regulations contained in this manual can install,
maintain, and repair the equipment. The operation personnel should understand the system, its working principles, and relevant national
and regional standards.
⚫
During operations, wear protective equipment and use dedicated tools.
1. Checking the Outer Packing
1.
Check the outer packing package for any damage, such as holes and cracks.
2.
Check the equipment model.
If any serious damage is found or the model is not what you requested, do not unpack the product, and contact your dealer as soon as
possible.
2. Checking the Product Packages
Place the connectors separately after unpacking to avoid confusion for connection of cables.
Battery Control Unit
Battery control unit*1
Power cable (1.45m) *1
Waterproof cover *1
M4*10 screw *1
Note: The documents include a warranty card, a Quick Guide, and a Configuration Instructions.
V0.0
B2-5.0-(HV1, HV5)-S Quick Guide
www.saj-electric.com
Left-side cover (left)*1
Positive battery cable
(1.5m) *1
Power cable (150 mm) *1
Negative battery cable
(1.5m) *1
(Europe only)
Communication cable
RJ45 plug *2
(1.5m) *1
Documents
Locking bracket *2
to access all the product documentation.
Right-side cover *1
Grounding cable *1
Positive PV connector *1
Negative PV connector *1
(Australia only)
M10*80 screw *2
1
User Manual
. You can
Communication cable *1
Positive battery cable
(1.5m) *1
Negative battery cable
(1.5m) *1
(Australia only)
M5*12 screw *2
© 2024 Sanjing. All rights reserved.
