9144307COM
Media Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
This piece of furniture can overturn and cause serious
injuries & or death.
Anchor the furniture to a stud in the wall (if this is required).
Do not allow children to climb on furniture
Keep heavier items on lower shelves.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B349144307COM0
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9144307COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 9144307COM

Summary of Contents for Ameriwood HOME 9144307COM

  • Page 1 Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home This piece of furniture can overturn and cause serious injuries & or death. Anchor the furniture to a stud in the wall (if this is required). Do not allow children to climb on furniture Tube Keep heavier items on lower shelves.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Parts are labeled on the surface or edge of the part Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing,...
  • Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels into the holes during your assembly process. ameriwoodhome.com...

  • Page 5: Board Identification

    Board Identification Not actual size Lower Partition Upper Partition Left Panel Right Panel 39144307040 39144307030 39144307010 39144307020 Bottom 39144307060 39144307050 TV Rail Shelf 39144307080 39144307070 ameriwoodhome.com...
  • Page 6 Board Identification Not actual size BACK PANEL Back Panel Door K914430700 39144307090 This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit. ameriwoodhome.com...
  • Page 7 Board Identification Not actual size This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit. BACK PANEL ameriwoodhome.com...

  • Page 8: Part List

    Note that your unit may contain extra hardware Part List Actual Size (x15) (x10) (x15) (x8) #A22620 #A21660 #A22610 #A23030 cam lock wood dowel cam bolt confirmat screw (x2) (x10) (x28) #A17400 #A11080 #A21110 (x1) 8-32 X 7/8" bolt #6 X 7/16" flat nail #A50415 handle...
  • Page 9 STEP 1 (x9) ameriwoodhome.com...
  • Page 10 STEP 2 (x2) (x5) Proper cam orientation ameriwoodhome.com...
  • Page 11 STEP 3 (x4) (x4) (x2) Proper cam orientation Proper cam orientation ameriwoodhome.com...
  • Page 12 STEP 4 (x3) (x2) (x2) Proper cam orientation finished edge ameriwoodhome.com...
  • Page 13 STEP 5 (x2) (x3) (x2) finished edge Proper cam orientation ameriwoodhome.com...
  • Page 14 STEP 6 (x2) finished edge finished edge UNLOCK LOCK ameriwoodhome.com...
  • Page 15 STEP 7 UNLOCK LOCK finished edge finished edge ameriwoodhome.com...
  • Page 16 STEP 8 UNLOCK LOCK Note: All back edges will be flush with each other. ameriwoodhome.com...
  • Page 17 STEP 9 UNLOCK LOCK ameriwoodhome.com...
  • Page 18 STEP 10 (x6) unfinished edge ameriwoodhome.com...
  • Page 19 STEP 11 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. Place the unit onto its front. Attached the back panel as shown nailing straight (x28) into the raw edges. Assure that the unit is square. Distance from corner to corner must be equal.
  • Page 20 STEP 12 (x14) (x2) ameriwoodhome.com...
  • Page 21 STEP 13 (x2) ameriwoodhome.com...
  • Page 22 STEP 14 (x10) (x2) (x2) Do not overtighten these screws. Snug fit only. finished edge  (top) unfinished edge (bottom) 22  ameriwoodhome.com...
  • Page 23 STEP 15 Be sure the guide stem is in the lower position before starting installation process.  If not, press in with your thumb and slide down to the lower position as shown. Guide stem in  Guide stem in  the upper position Fig. 1 the lower position Fig. 2 This part of the roller  inserts into the track The white roller will roll on  the top part of the track. If needed, loosen screws, insert screwdriver here, and rotate roller. Use this handle to raise or  Turn clockwise will lower the door lower door. and counter clockwise to raise the door. Then retighten screws This part will insert Do not overtighten these  into the track. screws. Snug fit only. 23  ameriwoodhome.com...
  • Page 24 STEP 16 Lower the guide stem in the upper door guide (11) as shown in Fig. 1. With the door slightly angled, position the door as shown. Insert door rollers (10) into the door track (Fig. 2) in the bottom (F). Lean the door inward until positioned over the shelf (G) groove.
  • Page 25 STEP 17 (x1) (x2) ameriwoodhome.com...

  • Page 26: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Apply the WARNING LABEL (14) to the top. You should be able to read the label when the TV is removed from the unit.
  • Page 27 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
