Antlion Audio ModMic USB 2 Installation Manual

ModMic USB 2 Installation
Parts List
One
ModMic USB 2
Surface Selection
Find a flat spot on the headphones for the 0.5 inch/12.7mm circle of adhesive. The adhesive will stick to smooth and
mesh surfaces but does not stick well to porous, lacquered, or rubberized surfaces.
1. Put the headphones on to ensure the ModMic will reach the corner of your mouth from the desired mounting point.
2. Thoroughly clean and dry the surface with the included alcohol pad.
Attaching & Orientation
1. Attach a to the
2. Remove the protective backing from the adhesive.
3. While holding the
it points towards where your mouth will be when using your
headphones. (This will reduce the need for additional bends
in the boom after installation—see Figure A).
4. Press the whole mic/clasp down onto the cleaned spot and
hold firmly for 60 seconds
for 1 hour .
In-line A to C
mute switch adapter
that holds the ModMic's boom.
orient the mic boom angle down so
. Allow the adhesive to cure
Carrying case & Two base clasps, one
instruction manual
top clasp with cap &
extra 3M adhesives
A
5x
One alcohol One foam
wipe pop filter
