Antlion Audio ModMic Business Tips

ModMic Business

Surface Choice

Find a flat spot on the headphones for the 0.5" circle of adhesive. The adhesive will stick to smooth and
mesh surfaces but does not stick well to rubberized surfaces.
1. Put the headphones on to ensure the ModMic will reach the corner of your mouth from the desired
mounting point.
2. Thoroughly clean and dry the surface with the included alcohol pad.
Attaching & Orientation
1. Attach a base clasp to the top clasp that holds the
ModMic's boom.
2. Remove the protective backing from the adhesive.
3. While holding the top clasp, orient the mic boom
angle down so it points towards where your mouth
will be when using your headphones. (This will
reduce the need for additional bends in the boom
after installation (see figure A).
4. Press the whole mic/clasp down onto the cleaned
spot and hold firmly for 30 seconds. (For best
results on irregular surfaces, allow the adhesive to
cure for 1 hour)
5. To reverse the orientation of the boom from right to
left, do not remove the boom from the clasp but
simply re-bend the cable end of the boom
downward in the opposite shape (see figure B).
www.AntlionAudio.com
For more information/extra clasps/questions/feedback visit www.AntlionAudio.com Designed in Portland, Oregon.
Manufactured in China. ModMic and Antlion logo are trademarks of GTDevice LLC. U.S. and International patents
A
B
Facebook: AntlionAudio
L
Twitter: @AntlionAudio
R
