Antlion Audio ModMic Uni Installation

ModMic Uni Installation

Surface Selection

Find a ﬂat spot on the headphones for the 0.5" circle of adhesive. The adhesive will stick to smooth and mesh surfaces

but does not stick well to rubberized surfaces.

1. Put the headphones on to ensure the ModMic will reach the corner of your mouth from the desired mounting point.

2. Thoroughly clean and dry the surface with the included alcohol pad.

Attaching & Orientation

1. Attach a base clasp to the top clasp

that holds the ModMic's boom.

2. Remove the protective backing

from the adhesive.

3. While holding the top clasp, orient the mic boom

angle down so it points towards where your mouth will

be when using your headphones. (This will reduce the

need for additional bends in the boom after

installation—see Figure A).

4. Press the whole mic/clasp down onto the cleaned spot

and hold ﬁrmly for 60 seconds. Allow the adhesive to

cure for 1 hour.

5. To reverse the orientation of the boom from left earcup

to right, do not remove the boom from the clasp but

simply re-bend the cable end of the boom downward

in the opposite shape (see Figure B). Always ensure

the cable is pointing down to prevent cable breaks.

www.AntlionAudio.com

For more information/extra clasps/questions/feedback visit www.AntlionAudio.com. Designed in Portland, Oregon.

Manufactured in China. ModMic and Antlion logo are registered trademarks of GTDevice LLC. U.S. and International patents.

Base Clasp

Facebook: AntlionAudio

Twitter: @AntlionAudio

Table of Contents

Do you have a question about the ModMic Uni and is the answer not in the manual?

Page 1 ModMic Uni Installation Surface Selection Find a ﬂat spot on the headphones for the 0.5” circle of adhesive. The adhesive will stick to smooth and mesh surfaces but does not stick well to rubberized surfaces. 1. Put the headphones on to ensure the ModMic will reach the corner of your mouth from the desired mounting point.
Page 2 Getting the most from your ModMic Uni 1. The mic is sensitive to plosive blast/wind from your mouth, especially P’s (see Figure C). Microphone Icon 2. To lessen unwanted cable torque on the clasp, fold the cable end of the boom so that it is close to the clasp (see Figure D).
