  • Page 1 Home Appliances KD-HD8S-W Tumble Dryer User Manual...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Caption Description...
  • Page 3 CONTENTS 1. SAFETY INSTRUCTIONS ................. 5 1.1. Electrical Safety ....................5 1.2. Children's Safety ..................... 6 1.3. Product Safety ....................7 1.4. Correct Use ..................... 8 1.5. Installing On Top Of a Washing Machine............9 2. INSTALLATION ....................11 2.1. Connection to Water Outlet (with optional drain hose) ........11 2.1.1.
  • Page 4 9. AUTOMATIC FAULT WARNINGS AND WHAT TO DO ........27 10. ENVIRONMENTAL PROTECTION AND PACKAGING INFORMATION ..28 10.1. Packaging Information ................. 28 11. DESCRIBING THE ENERGY LABEL AND SAVING ENERGY..... 28 11.1. Energy Labelling ..................28 11.2. Energy Efficiency ..................29 EN - IV...
  • Page 5 PRIMARY CONSIDERATIONS • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 • Assembly / disassembly for under-counter installation if neccessary must be done by an authorised service agent. • Before installation, check the product for visible damage. Never install or operate a damaged product. • Keep pets away from the dryer. •...
  • Page 7 • The clearance between the dryer and the floor should not be reduced with objects such as carpets, wood or tape. • Do not block the ventilation grills found on the plinth of the tumble dryer. • The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side of the tumble dryer, in such a way that blocks the full opening of the tumble dryer...
  • Page 8 Disposing the Old Product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This symbol, which is found on the product or information label, indicates that this product must not be disposed together with other household waste at the end of its service life.
  • Page 9 1. SAFETY INSTRUCTIONS This section contains safety instructions that will help protect you from risk of personal injury or property damage. Failure to follow these instructions will void any warranty. 1.1. Electrical Safety • The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
  • Page 10 1.2. Children's Safety • This appliance is not intended for use by people (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 11 1.3. Product Safety Due to risk of fire, the following laundry items and products should NEVER be dried in the dryer: • Do not dry unwashed items in the tumble dryer. • Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an...
  • Page 12 FIRE:R290 Risk of fire and damage! This product contains enviromental friendly but flammable R290 gas. Keep open flame and fire sources away from the product. 1.4. Correct Use ATTENTION: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
  • Page 13 The dryer may tip over. • To maintain a temperature that will not harm the laundry (e.g. to prevent the laundry from catching fire), a cooling process starts after the heating process. After this, the programme ends. At the end of the programme, always remove the laundry promptly.
  • Page 14 • To use the dryer on the washing machine, a fixing part must be used between the two products. The fixing part must be attached by an Authorised Service Provider. • When the dryer is placed on the washing machine, the total weight of these products may reach almost 150 kilograms (when loaded).
  • Page 15 2. INSTALLATION IMPORTANT: The water discharge hose must not be bent between the outlet and the product, folded or stepped over. 2.1. Connection to Water Outlet (drain hose is delivered in the packaging together with the product. ) 2.2. Adjusting the Feet In products with a heat pump unit, water •...
  • Page 16 3. OVERVIEW 1. Top plate 2. Control panel 3. Loading door 4. Plinth 5. Plinth opening slot 6. Ventilation grills 7. Adjustable feet 8. Plinth cover 9. Type plate 10. Lint filter 11. Drawer Cover EN - 12...
  • Page 17 4. PREPARING THE LAUNDRY 4.1. Sorting the Laundry to be Dried Follow the instructions on the labels of the laundry to be dried. Only dry items that have a statement/symbol that indicates "they can be dried in a dryer". • Do not operate the product with load amounts and laundry types other than those given in 4.3.
  • Page 18 4.3. Load Capacity IMPORTANT: Delicate fabrics, embroided fabrics, silk fabrics, clothes Follow the instructions in the "Programme made of delicate and expensive fabrics, selection and consumption table". (See: 5.2 airtight clothes and tulle curtains are not Programme selection and consumption suitable for drying in the dryer.
  • Page 19 5. USING THE TUMBLE DRYER 5.1.2. Electronic Indicator and Additional Functions 5.1. Control Panel 1. Programme Selection Knob Display symbols: 2. Electronic indicator and additional functions Water tank warning indicator 5.1.1. Programme Selection Knob Use the programme selection knob to select Lint filter cleaning warning indicator the desired drying programme Heat exchanger cleaning warning...
  • Page 20 Anti-crease 120‘ Delicate Buzzer Cancel Start and pause Drying Step Display: Drying Iron dry Cupboard dry The electronic display shows the drying steps throughout the program. Every time a program step starts, the relevant drying step light turns on. Once the drying step is complete, the relevant drying step light turns off.
  • Page 21 5.2. Programme Selection and Consumption Table Press the Start/Pause button to start the programme. The Start/Pause LED that indicates that the programme has started and the remaining the of the program is seen on the display. Approximate Washing amount of Duration Programme Load (kg)
  • Page 22 5.2.1. Auxiliary Functions The table that summarises the options that can be selected in programmes is given below. Option Description Select the drying target suitable for your laundry to be dried. Select Extra Dry for thick and multilayer laundry that takes time to dry. Select Drying Target Closet Dry for regular, single-layer laundry.
  • Page 23 Starting the Programme The Start/Pause LED will flash during programme selection.Press the Start/Pause button to start the programme. The Start/Pause LED that indicates that the programme has started and the drying LED will come on. Programme Description This programme dries cotton laundry including bedsheets, pillowcases, pyjamas, Cottons underwear, tablecloths etc.
  • Page 24 5.2.2. Selection Stand By 5.3. Drum Light Information After 15 minutes without user action in • This product includes LED Drum Light. selection mode, machine goes to energy- • The light works automatically when you saving mode due to decrease energy open the door.
  • Page 25 OPTIONS PROGRAMMES Drying Delay Buzzer Time Drying Anti- Child Lock Delicate Spin Target Start Cancel Drying Level crease Cottons Synthetics Delicate (default) Towels Hygiene Time drying Baby Care Duvet Sport Outdoor Wool Refresh Refresh Express 34' Shirt 20' Not selectable Selectable EN - 21...
  • Page 26 6. CLEANING AND CARE 7. Close the filters and fit the hooks 8. Place inner filter inside of outer filter IMPORTANT: Do not use industrial chemicals to clean your dryer. Do not use a 9. Refit the Lint filter dryer that has been cleaned with industrial After the dryer has been used for a certain chemicals.
  • Page 27 IMPORTANT: Clean the heat exchanger WITH BARE HANDS SINCE when you see the warning “Heat Exchanger THE EXCHANGER FINS ARE cleaning”. SHARP. THEY MAY HURT IMPORTANT: EVEN IF THE “HEAT YOUR HANDS EXCHANGER CLEANING WARNING LED” IS NOT ON: CLEAN THE HEAT EXCHANGER AFTER EVERY 30 DRYING 6.4.
  • Page 28 WARNING: Due to the risk or fire and explosion, do not use solution agents, cleaning agents or similar products when cleaning the sensors. 6.5. Cleaning the Inner Surface of the Loading Door IMPORTANT: DO NOT FORGET TO CLEAN THE INNER SURFACE OF THE LOADING DOOR AFTER EACH DRYING PROCESS.
  • Page 29 7. MACHINE SOUND SOURCE OF SOUND DEFINITION Pump Sound Pump is activated when the machine starts to work and during the operation at certain intervals. It is normal to hear pump and water sound during this process. Compressor Sound It is normal to hear a metallic sound from the compressor from time to time while the machine is running.
  • Page 30 8. TECHNICAL SPECIFICATIONS Brand SHARP Model name KD-HD8S-W Height Min: 845 mm / Max: 855 mm* Width 596 mm Depth 563 mm Capacity (max.) 8 kg** Net weight (with plastic door) 47,1 kg Net weight (with glass door) 48,6 kg...
  • Page 31 9. TROUBLESHOOTING Your dryer is fitted with systems that continuously perform checks during the drying process to take the necessary measures and warn you in case of any malfunction. WARNING: If the problem persists even if you have applied the steps in this section, please contact the your dealer or an Authorised Service Provider.
  • Page 32 PROBLEM REASON SOLUTION There might be lint accumulated on Clean the inner surfaces of the the inner surfaces of the loading Water leaking from the loading door. loading door and the surfaces of the door and on the surfaces of the gasket of the loading door.
  • Page 33 10. AUTOMATIC FAULT WARNINGS AND WHAT TO DO Your tumble dryer is equipped with a built-in fault detection system, indicated by a combination of flashing operation lights. The most common failure codes are shown below. ERROR CODE SOLUTION Contact the nearest authorised service agent. Empty the water tank, if problem does not solved, E03/ contact the nearest authorised service agent.
  • Page 34 11. ENVIRONMENTAL 12. DESCRIBING THE ENERGY PROTECTION AND PACKAGING LABEL AND SAVING ENERGY INFORMATION 12.1. Energy Labelling 11.1. Packaging Information The packaging of this product is made of recyclable materials. Do not dispose of the packaging, waste together with household or other waste. Instead, take it to a packaging collection point defined by your local authority.
  • Page 35 12.2. Energy Efficiency • You should operate the dryer to full capacity, but make sure that it is not overloaded. • When the laundry is being washed, the spin speed should be at the highest level possible. This will shorten the drying time and reduce energy consumption.
  • Page 36 PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 392/2012 Supplier name or trademark SHARP Model name KD-HD8S-W Rated capacity (kg) Type of Tumble Dryer Heat Pump Energy efficiency class Annual Energy Consumption (kWh) Automatic of Non-automatic Automatic Energy Consumption of the standard cotton programme at full load (kWh)
  • Page 37 Service & Support Visit Our Website www.sharphome.eu 52520556-240621-00...
