VITODENS 100-W HE AT ONLY

Commissioning Quickstart Guide

This guide highlights the new and unique process for commissioning. For installation,

please refer to the detailed steps in the Installation & Service Instructions.

User interface

Getting started

On the following pages you will find a step by step guide to commission the product by using

the control panel. The default parameters are highlighted for each step. Please refer to the last

page of this document to receive more information.

Heating circuit

DHW temperature

System pressure

DHW ECO function

Reduced temperature level

Wifi connection

Service menu

Fault display

Burner status

OK > confirm settings

Menu > opens the main menu

Up & down > change parameter

Need help?

Do you have a question about the VITODENS 100-W HEAT ONLY and is the answer not in the manual?

Page 1 VITODENS 100-W HE AT ONLY Commissioning Quickstart Guide This guide highlights the new and unique process for commissioning. For installation, please refer to the detailed steps in the Installation & Service Instructions. User interface Heating circuit DHW temperature System pressure DHW ECO function Reduced temperature level Wifi connection...
Page 2 Commissioning steps: Access Point AP Indicates the boiler is ready to be set up press 4 seconds to start commissioning from the panel Basic Advanced C.4 Operating Mode C.7 Gas Type 4 > weather comp., 13 - default > constant operation (switch live) with optional 2 - default >...
Page 3 & services The application can be downloaded from the Google Play Store or Apple App Store. For Once your Viessmann Account is set up, further information scan the QR code: you can access the Partner Portal via the QR code: Viessmann Account Further Information &...
