Senix PDHX2-M2-EU Instruction Manual page 9

To remove:
Turn the chuck counterclockwise to open the
jaw and pull the bit out of the jaw.
NOTE:
Make sure the bit is fixed firmly and will never
come out before use.
BATTERY PACK
NOTE:
Prior to installation, lock the switch trigger by
moving the direction selector to the center
lock position to avoid unintentional start.
To install:
Align and slide the battery pack to the battery
foot until it is locked in place.
SENIX.COM.AU
Fig. 2
Fig. 3
To remove:
Press the release button on battery pack and
slide the battery pack out.
OPERATION
OPERATION
WARNING:
Always wear eye, hearing, hand protection to
reduce the risk of injury when operating the
tool. Keep all parts of your body away from the
rotating bit.
RUNNING DIRECTION
The motor runs forward or backward for
driving the bit in or out. It is controlled by the
direction selector.
WARNING:
Do not change direction of rotation while
chuck is rotating.
Forward
Fig. 4
Reverse
Fig. 5
9 - EN
