J5create JCD353 Quick Installation Manual page 2

Dansk
Funktioner
■
● Understøtter HDMI™ opløsninger op til 4K
● To USB™ 3.2 Gen 1-porte med overførselshastigheder op til 5
Gbps
● Strømforsyning (PD) 3.0 forsyner strøm op til 100 W opladning
● Bagudkompatibel med USB 3.0 værter og enheder
● Stik til hukommelseskortlæser/skriver, der giver mulighed for
tilslutning til en ekstern hukommelsesenhed på op til 2 TB.
Understøtter SD™ 3.0 UHS-I med dataoverførselshastigheder op
til 104 MB/s
● Plug-and-Play. Der skal ikke installeres nogen drivere.
Systemkrav
■
● Tilgængelig DisplayPort™ Alt-funktion via USB-C®-port
● Tilgængelig USB™-strømforsyning via USB-C® til
upstream-opladning
Særlige bemærkninger
■
● Du skal bruge en 4K-kompatibel skærm for, at få en opløsning
på 3840 x 2160
Magyar
Jellemzők
■
● Támogatja a HDMI™-felbontásokat akár 4K-ig
● Kettő USB™ 3.2 Gen 1 aljzat akár 5 Gb/s átviteli sebességet
biztosít
● A Power Delivery 3.0 akár 100 W-os átmenő töltési lehetőséget
kínál
● Visszamenőleges kompatibilitás USB 3.0 gazdagépekkel és
eszközökkel
● A memóriakártya-olvasó/író nyílások lehetővé teszik a külső
memória elérését akár 2 TB-ig, támogatva az SD™ 3.0 UHS-I
kártyákat, akár 104 MB/s adatátviteli sebességgel
● Plug-and-Play, ezért nincs szükség illesztőprogram telepítésére
Rendszerkövetelmények
■
● Elérhető DisplayPort™ Alt mód az USB-C®-aljzaton
● Elérhető USB™ Power Delivery USB-C®-n az upstream töltés
támogatásához
Különleges megjegyzések
■
● A 3840 x 2160 felbontás eléréséhez 4K-képes megjelenítő
szükséges
繁中
功能特色
■
支援HDMI™顯示輸出最高可達4K解析度
●
提供2個USB™ 3.2 Gen 1 5Gbps連接埠
●
支援最高PD 100W Pass-Through 充電
●
向下相容USB™ 3.0裝置
●
支援讀寫最大容量2TB之記憶卡 ， 支援 SD™/microSD™ 3.0 UHS-I 傳
●
輸速度可達104MB/s
隨插即用 ， 無須安裝驅動程式
●
系統需求
■
具備可支援視訊輸出功能的USB-C®接口
●
具備可支援USB™ Power Delivery充電功能的USB-C®接口
●
附註
■
需要支援4K顯示功能的螢幕才可以顯示3840 x 2160 解析度
●
한국어
특징
■
HDMI™ 해상도를 최대 4K까지 지원합니다.
●
두 개의 USB™ 3.2 Gen 1 포트는 최대 5Gbps의 전송 속도를 제공합니다.
●
전원 공급 3.0은 최대 100W의 우회 충전을 지원합니다.
●
USB™ 3.0 호스트 및 장치와의 하위 호환성이 있습니다.
●
메모리 카드 리더/라이터 슬롯을 통해 최대 2TB까지의 외부 메모리 액세스가
●
가능하며, SD™/microSD™ 3.0 UHS-I을 지원하며 최대 104MB/s의 데이터
전송 속도를 제공합니다.
플러그 앤 플레이, 드라이버 설치가 필요하지 않습니다.
●
시스템 요구 사항
■
●
USB-C® 포트를 통한 DisplayPort™ Alt
Mode 사용 가능
●
업스트림 충전을 지원하기 위한 USB™ 전원
공급 가능
특별한 참고 사항
■
●
3840 x 2160 해상도를 얻기 위해서는 4K
지원 디스플레이가 필요합니다.
Funksjoner
■
● Støtter HDMI™-oppløsninger på opptil 4K
● To USB™ 3.2 gen. 1-porter gir opptil 5 Gbps overføringshas-
tighet
● Power Delivery 3.0 gir opptil 100 W ladegjennomgang
● Bakoverkompatibilitet med USB 3.0-verter og -enheter
● Minnekortleser-/skriverspor gjør det mulig med eksternt
minne på opptil 2 TB, støtter SD™ 3.0 UHS-I med dataover-
føringshastigheter på opptil 104 MB/s
● Plug-and-play – ikke nødvendig å installere driver
Systemkrav
■
● Tilgjengelig DisplayPort™ Alt-modus over USB-C®-port
● Tilgjengelig USB™ Power Delivery over USB-C for å støtte
oppstrømslading
Spesielle merknader
■
● En 4K-kompatibel skjerm kreves for å oppnå 3840 x 2160
oppløsning
USB-C® Мульти-xаб с 4K HDMI™ (JCD353)
Технические особенности
■
● Поддержка 4K HDMI™
● 2 USB™ 3.2 Gen 1 с поддержкой скорости передачи данных
до 5 Гбит/с
● Power Delivery 3.0 с поддержкой зарядки мощностью до 100
Вт
● Обратная совместимость с USB™ 3.0
● SD™ и microSD™ картридер SD™ 3.0 UHS-I с поддержкой
скорости передачи данных до 104 Мбит/с
● Plug-and-play, установка драйвера не требуется
Системные требования
■
● Доступный USB-C® порт с поддержкой DisplayPort™ Alt
Mode
● USB™ с поддержкой Power Delivery для зарядки ноутбука
или др. устройства
Примечания
■
● Для получения разрешения 3840 x 2160 требуется монитор с
поддержкой 4K
功能特色
■
支援HDMI™显示输出最高可达4K分辨率
●
提供2个USB™ 3.2 Gen 1 5Gbps接口
●
支援最高PD 100W Pass-Through 充电
●
向下相容USB™ 3.0装置
●
支持读写最大容量2TB之记忆卡 ， 支持SD™/microSD™ 3.0 UHS-I 传
●
输速度可达104MB/s
随插即用 ， 无须安装驱动程式
●
系统需求
■
具备可支援视讯输出功能的USB-C®接口
●
具备可支援USB™ Power Delivery充电功能的USB-C®接口
●
附注
■
需要支援4K显示功能的显示屏才可以显示3840 x 2160 分辨率
●
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
자세한 상품정보
■
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this device.
Norsk
Русский
简中
202402-V2
Suomi
Ominaisuudet
■
● Tuki enintään 4K:n HDMI™-resoluutioille
● Kaksi USB™ 3.2 Gen 1 -porttia tarjoavat enintään 5 Gbps
-siirtonopeuden
● Virransyöttö 3.0 tarjoaa enintään 100 W:n läpimenolataamisen
● Taaksepäin yhteensopiva USB 3.0 -isäntien ja laitteiden kanssa
● Muistikortin lukija/kirjoitinpaikat sallivat ulkoisen muistin
käytön enintään 2 Tt:n saakka, tuki SD™ 3.0 UHS-I:lle enintään
104 Mt/s -datansiirtonopeudella
● Plug-and-play, ohjaimien asennusta ei tarvita
Järjestelmävaatimukset
■
● Käytettävissä DisplayPort™ Alt -tila USB-C®-porttiliitännällä.
● Käytettävissä oleva USB™ Power Delivery over USB-C®
tukemaan ylävirtalataamista
Erityishuomautukset
■
● Vaaditaan 4K:n näyttö 3840 x 2160 -resoluution saavutta-
miseksi
日本語
特徴
■
最大4K30Hzの解像度に対応しています。
●
ホスト （USB-C®3.0） は後方互換性があります。
●
拡張ポート ：
●
USB™ Type-A 5Gbpsｘ2
○
USB-C® PD100Wｘ1
○
HDMI™ 4Kｘ1
○
UHS-I SD™/microSD™スロッ ト (最大容量2TBに対応しています)
○
プラグ＆プレイ
●
最小システム要件
■
USB-C®ポートがDisplayPort™ 1.2 Alt modeに対応している必要があり
●
ます 。
USB-C®ポートがPower Delivery機能に対応している必要があります 。
●
備考
■
4K解像度を出力するには 、 接続するディスプレイにも4Kに対応している
●
必要があります 。
LIMITED WARRANTY
j5create offers a limited 2-year warranty. User's wear & tear damage is not included. The user shall call or email
j5create customer service with the defect information of the product and obtain a return authorization number.
Users are responsible for one-way return freight cost and we will take care of one-way freight back. In order to
obtain a return authorization number, users should have the following information handy when calling or
emailing the service team:
(i) a copy of the original purchase invoice to verify your warranty
(ii) a product serial number
(iii) a description of the problem
(iv) customer's name, address, and telephone number
j5create does not warrant that the operation of the product will be uninterrupted or error-free. j5create is not
responsible for damage arising from failure to follow instructions relating to the product's use. This warranty
does not apply to: (a) consumable parts, unless damage has occurred due to a defect in materials or
workmanship; (b) cosmetic damage, including but not limited to scratches, dents, and broken plastic on ports; (c)
damage caused by use with non-j5create products; (d) damage caused by natural disasters; (e) damage caused
by human misuse (lost, accident, abuse, misuse or other external causes); (f) damage caused by operating the
product outside the permitted or intended uses described by j5create; (g) damage caused by service (including
upgrades and expansions) performed by anyone who is not a representative of j5create or a j5create Authorized
Service Provider; (h) a product or part that has been modified to alter functionality or capability without the
written permission of j5create; or (i) if any j5create serial number on the product has been removed or defaced. If
such a situation occurs, j5create will calculate the cost of materials and repair for your reference. This warranty is
given by j5create in lieu of any other warranties expressed or implied.
LIMITATION OF WARRANTY
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE (OR BY
COUNTRY OR PROVINCE). OTHER THAN AS PERMITTED BY LAW, J5CREATE DOES NOT EXCLUDE, LIMIT OR SUSPEND OTHER RIGHTS YOU
MAY HAVE, INCLUDING THOSE THAT MAY ARISE FROM THE NONCONFORMITY OF A SALES CONTRACT. FOR A FULL UNDERSTANDING OF
YOUR RIGHTS YOU SHOULD CONSULT THE LAWS OF YOUR COUNTRY, PROVINCE OR STATE. TO THE EXTENT NOT PROHIBITED BY LAW IN
YOUR STATE, PROVINCE, JURISDICTION OR COUNTRY, THIS WARRANTY AND THE REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL
OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED.
J5CREATE'S RESPONSIBILITY FOR MALFUNCTIONS AND DEFECTS IN HARDWARE AND/OR SOFTWARE IS LIMITED TO REPAIR OR
REPLACEMENT AS SET FORTH IN THIS WARRANTY. J5CREATE'S LIABILITY DOES NOT EXTEND BEYOND THE REMEDIES PROVIDED FOR IN
THIS LIMITED WARRANTY, AND J5CREATE DOES NOT ACCEPT LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, FOR THIRD-PARTY
CLAIMS AGAINST YOU FOR DAMAGES, FOR PRODUCTS NOT BEING AVAILABLE FOR USE, OR FOR LOST OR DAMAGED DATA OR SOFTWARE.
J5CREATE DOES NOT WARRANT THAT THE OPERATION OF ANY J5CREATE PRODUCT WILL BE UNINTERRUPTED OR ERROR FREE.
J5CREATE'S LIABILITY IN ANY SITUATION WILL BE NO MORE THAN THE AMOUNT YOU PAID FOR THE SPECIFIC PRODUCT THAT IS THE
SUBJECT OF A CLAIM. THIS IS THE MAXIMUM AMOUNT FOR WHICH WE ARE RESPONSIBLE.
EXCEPT FOR THE EXPRESS WARRANTIES CONTAINED IN THIS WARRANTY AND TO THE EXTENT NOT PROHIBITED BY LAW, J5CREATE
DISCLAIMS ALL OTHER WARRANTIES AND CONDITIONS, EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, WARRANTIES OF MERCHANTABILITY, MERCHANTABLE QUALITY AND FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES
AND CONDITIONS AGAINST HIDDEN OR LATENT DEFECTS. SOME STATES, PROVINCES, JURISDICTIONS OR COUNTRIES DO NOT ALLOW
DISCLAIMERS OF IMPLIED WARRANTIES AND CONDITIONS, SO THIS DISCLAIMER MAY NOT APPLY TO YOU.
TO THE EXTENT SUCH WARRANTIES AND CONDITIONS CANNOT BE DISCLAIMED UNDER THE LAWS OF THE UNITED STATES, CANADA (AND
ITS PROVINCES) OR OTHERWISE, J5CREATE LIMITS THE DURATION AND REMEDIES OF SUCH WARRANTIES AND CONDITIONS TO THE
DURATION OF THIS EXPRESS LIMITED WARRANTY AND, AT J5CREATE'S OPTION, REPAIR OR REPLACEMENT SERVICES. SOME STATES,
PROVINCES, JURISDICTIONS OR COUNTRIES MAY NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION MAY
LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT APPLY TO YOU.
NO WARRANTIES OR CONDITIONS, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE LIMITED WARRANTY PERIOD HAS EXPIRED.
SOME STATES, PROVINCES, JURISDICTIONS OR COUNTRIES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR
CONDITION LASTS, SO THIS LIMITATION MAY NOT APPLY TO YOU.
WARRANTY SUPPORT ONLY APPLIES WHEN THE COVERED PRODUCT IS LOCATED WITHIN THE COUNTRY IN WHICH J5CREATE ORIGINALLY
SOLD THE SYSTEM, AS REFLECTED IN J5CREATE'S RECORDS. IF YOU NEED SUPPORT FOR THE PRODUCT OUTSIDE OF THE COUNTRY OF
ORIGIN (FOR EXAMPLE, WHILE TRAVELING, OR IF THE SYSTEM HAS BEEN RELOCATED TO A NEW COUNTRY), THEN J5CREATE MAY OFFER
YOU OTHER SUPPORT OPTIONS FOR AN ADDITIONAL CHARGE.
For more information please visit our website at http://www.j5create.com
Copyright© 2024 j5create. All rights reserved. All trade names are registered trademarks of their respective owners. Features and
specifications are subject to change without notice. Product may not be exactly as shown in the diagrams.
