- Page 1 Wormhole KM Switch User Manual En.Ver 1.1...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION .................. 3 Highlighted Features ..............3 Required Environments ..............4 Physical Specifications ..............4 Package Contents ................ 4 GETTING STARTED ................5 SOFTWARE INSTRUCTIONS ..............7 Keyboard & Mouse Control Switching Settings ...... 10 Clipboard Share Option ............. 12 Event Notification ................ -
Page 3: Introduction
WORMHOLE KM SWITCH USER MANUAL INTRODUCTION Thank you for purchasing the j5 create Wormhole KM Switch (JUC100)! This amazing device allows you one click “Drag & Drop” and “Copy/Paste” capabilities to quickly transfer/share Data/Graphic/Music/video or other files between two computers. The Wormhole also lets you share the keyboard and mouse with another computer. -
Page 4: Required Environments
Required Environments Microsoft Windows 7, Vista, XP, 2000 SP3 (32-bit or 64-bit) Compatible CPU: Intel Pentium II Processor or later RAM: 512MB RAM or higher Hard disk: Space requirement of at least 100MB Available USB port (USB 2.0 is recommended) ... -
Page 5: Getting Started
WORMHOLE KM SWITCH USER MANUAL GETTING STARTED Follow the below steps to configure the j5 Wormhole KM Switch 1. Connect one end of the Wormhole KM Switch to a standard USB port on one of the two computers 2. Connect the other end of the Wormhole KM Switch to a USB port on the second computer. - Page 6 5. If the “User Account Control” window appears on the screen, Click “Yes” to continue. 6. When you see the pop-up message appear at the bottom right of the screen then you are ready to operate the Wormhole KM Switch application.
-
Page 7: Software Instructions
WORMHOLE KM SWITCH USER MANUAL Troubleshooting: If auto-run is not launched, please follow the step below to start the j5 Wormhole KM Switch application: 1. Check each connector on the USB cable that it is correctly inserted on your two computers. 2. - Page 8 o Disable (Enable) Keyboard and Mouse Control Temporarily: You can quickly Disable or Enable the Keyboard & Mouse Switch function temporarily and back to regular Keyboard & Mouse usage. If disabling this function temporarily, the icon ( ) will be shown. o Disable (Enable) Clipboard Share Temporarily: You can quickly Disable or Enable the copy and paste Clipboard sharing option.
- Page 9 WORMHOLE KM SWITCH USER MANUAL Checking and updating the latest software version, which we published from this option Note: Please make sure the network is available and don’t unplug during the driver update. o About j5 Wormhole KM Switch: All information of j5 Wormhole KM Switch will be shown here o Exit: To remove this device...
-
Page 10: Keyboard & Mouse Control Switching Settings
THE PREFERENCES SETUP: Keyboard & Mouse Control Switching Settings This option allows you to switch the control of keyboard and mouse from one computer to another. Select one of the following options: o Turn Off: Disable keyboard and mouse switch. o Use Mouse Middle Button: Click the middle button of the mouse to switch the keyboard and mouse from one computer to another. - Page 11 WORMHOLE KM SWITCH USER MANUAL options as shown below. ** You also can quickly change this setting on the pop-up menu that appears on the screen when you click the j5 Wormhole KM Switch icon ( ). Select “The Position of Other PC”, and then select one of the options.
-
Page 12: Clipboard Share Option
You can find the small orange window frame on your desktop. You can drag it to set up “Size” and “Location “. When you finish setting up the size and location, Click “OK”. The function will be set. * This function is also designed for touch panel computers. Simply touch the “hot area”... -
Page 13: Event Notification
WORMHOLE KM SWITCH USER MANUAL Event Notification This option helps you to set the type of notification when Clipboard Data is arriving / sending or switch keyboard and mouse control to another computer. You can choose to play sound or to display a pop- up balloon tip. -
Page 14: Explore The Outstanding Features
KM control functions simply by double-clicking the j5 Wormhole KM Switch icon ( ) at the right bottom on taskbar. o Send Ctrl-Alt-Del to another computer By Pressing: Alternative keys option for the [Ctrl-Alt-Del] command for another computer. EXPLORE THE OUTSTANDING FEATURES NOW! Get ready to explore the outstanding features! After configuring the settings on the previous section, you can start using your Wormhole KM Switch and enjoying the convenience it brings... -
Page 15: Clipboard Sharing
WORMHOLE KM SWITCH USER MANUAL Move the mouse cursor to the second computer and open any Editing applications such as word, excel, and power point, etc. and use the keyboard of the first computer to type the text on the file of the second computer. -
Page 16: File Transferring
Content (text/ pictures), and right-click and select “Paste * When receiving clipboard data from another computer, the ( icon appears at the bottom right of the screen. File Transferring It is an easy and fast way to transfer files between 2 computers. Just drag and drop the file or folder to the other computers. - Page 17 WORMHOLE KM SWITCH USER MANUAL 3. Move the cursor to the location that you would like to place the files, and press the (Ctrl+V) Keys to paste the copied files to another computer.
-
Page 18: Technical Support
2. Online Support Please visit j5 create website (www.j5create.com) to find the latest software for your device. If you still experience the same issue, you can submit a trouble description via email service@j5create.com... -
Page 19: Regulatory Compliance
REGULATORY COMPLIANCE This equipment has been tested and found to comply with FCC Part 15 Subpart B § 15.109/15.107 Class B. Operation is subject to the following two conditions: • This device may not cause harmful interference • This device must accept any interference, including interference that may cause undesired operation of the device. -
Page 20: Warranty Of J5 Create
WARRANTY OF j5 create j5 create offers a limited 2-year warranty. User’s wear & tear damage are not included. The user shall call or email j5 create customer service with defect information of the product and obtain a return authorization number. Users are responsible for one way return freight cost and we will take care of one way freight back. -
Page 21: J5 Create Products
SD, Memory Stick. Great for file sharing, fast storage, and KM switching. Wormhole KM Switch JUC100 The j5 Wormhole KM Switch (JUC100) allows you to connect and work/share on two PC/Laptops or Tablets with one USB cable. While connected you can Drag/drop and Copy/Paste files/photos/music/ or other documents from one computer to the other instantly.
