SERVICE MANUAL
Ver 1.0 2001.02
US and foreign patents licensed from Dolby
Laboratories.
System
Disc
Laser
Laser output
1)
This output is the value measured at a distance of
200 mm from the objective lens surface on the
Optical Pick-up Block with 7 mm aperture.
Laser diode
Revolutions (CLV)
Error correction
Sampling frequency
Coding
Modulation system
Number of channels
Frequency response
Signal-to-noise ratio
Wow and flutter
Inputs
ANALOG IN
DIGITAL IN
Sony Corporation
9-929-257-11
2001B0500-1
Audio Entertainment Group
C 2001.2
General Engineering Dept.
Photo: Gray model
SPECIFICATIONS
Outputs
MiniDisc digital audio
system
PHONES
MiniDisc
Semiconductor laser ( =
780 nm) Emission
ANALOG OUT
duration: continuous
1)
MAX 44.6 W
General
Material: GaAlAs
400 rpm to 900 rpm
Power requirements
ACIRC (Advanced Cross
US and Canadian models: 120 V AC, 60Hz
Interleave Reed Solomon
AEP, UK models:
Code)
Australian models:
44.1 kHz
Hong Kong models:
ATRAC (Adaptive
Other models:
TRansform Acoustic
Coding)/ATRAC 3
EFM (Eight-to-Fourteen
Modulation)
Power consumption
2 stereo channels
Dimensions (approx.)
5 to 20,000 Hz 0.3 dB
Over 96 dB during play
Below measurable limit
Mass (approx.)
Supplied accessories
Jack type: phono
Audio connecting cords (2)
Impedance: 47 kilohms
Optical cable (1)
Rated input: 500 mVrms
Remote commander (remote) (1)
Minimum input:
R6 (size-AA) batteries (2)
125 mVrms
Connector type: square
Design and specifications are subject to change
optical
without notice.
Impedance: 660 nm
(optical wave length)
MDS-S50
Canadian Model
Australian Model
Model Name Using Similar Mechanism
MD Mechanism Type
Optical Pick-up Name
Jack type: stereo phone
Rated output: 10 mW
Load impedance: 32 ohms
Jack type: phono
Rated output: 2 Vrms (at
50 kilohms)
Load impedance: over 10
kilohms
230 V AC, 50/60Hz
240 V AC, 50/60Hz
220-240 V AC, 50/60Hz
110-120/220-240 V AC,
50/60Hz
Adjustable with voltage
selector
15 W
280
84.5
290 mm (w/
h/d) incl. projecting parts
and controls
2.4 kg
MINIDISC DECK
US Model
AEP Model
UK Model
E Model
NEW
MDM-7A
KMS-260B
