- Page 1 Installation Instructions H-Series Splice Through Cassette for 4RU Housing Series...
- Page 2 Never look into the end of a ber or connector which may have a laser coupled to it. Should accidental eye exposure to laser light be suspected, arrange for an eye examination immediately. © AFL. All rights reserved Series...
-
Page 3: Component Overview
Protector Holder Holder 4RU Housing Ribbon Fiber Splice Protector Holder Single Fiber Splice Protector (05) Ribbon Fiber (04) Single Fiber Splice Protector Splice Protector Ribbon Fiber Splice Protector What You Will Need Cross-Head Scissors Screwdriver © AFL. All rights reserved Series... - Page 4 Loosen the screws and remove the clear lid. diagram. Af x the splice protector holders to the inner Af x the single splice protector holders as base (see 3A for single splice, 3B for ribbon per the above diagram. splice). © AFL. All rights reserved Series...
- Page 5 Step 5A shows how to secure cable to the cassette. Step 5B shows how to secure braided sleeve to the cassette. Note: The cassette can accommodate up to 1.5 metres of incoming ber and 1.5 metres of outgoing ber. © AFL. All rights reserved Series...
- Page 6 Splice the bers as per splicing equipment Splice the bers as per splicing equipment supplier’s instructions. Insert splice protectors supplier’s instructions. Insert splice protectors into the holder (single ber splicing). into the holder (ribbon ber splicing). © AFL. All rights reserved Series...
- Page 7 H-Series Splice Through Cassette for 4RU Housing Coil the bers according to the diagram Coil the bers according to the diagram (single ber splicing). (ribbon ber splicing). Re-attach the lid and tighten the screws. Load the cassettes into the housing. © AFL. All rights reserved Series...
- Page 8 Thank you for choosing AFL AFL reserves the right to make changes to this Installation Instruction at any time without notice AFLHSERIESSTCAS4RU231123...
