- Page 1 Installation Guide Three-Way Transfer Valve Trim K-T9474 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page“ Français-1” Español, página“ Español-1” 1012607-2-B...
-
Page 2: Tools And Materials
Before You Begin Observe all local plumbing and building codes. Shut off the main water supply. Kohler Co. reserves the right to make revisions in the design of products without notice, as specified in the Price Book. 1012607-2-B Kohler Co. - Page 3 Trim away any excess gasket material so the escutcheon drain opening is not blocked. Carefully slip the escutcheon over the collar and against the finished wall. Position the escutcheon so the ″Kohler″ logo is to the bottom. Kohler Co. 1012607-2-B...
-
Page 4: Install The Handle
flows from only one accessory. Turn off the water at the mixing valve. Fit the handle assembly over the valve stem so the lever handle points to one of the large detents on the escutcheon. 1012607-2-B Kohler Co. - Page 5 Press the cap firmly onto the handle assembly so the cap detent points to the lever. If needed, apply a small amount of silicone lubricant to the inside wall of cap to aid in assembly (a silicone capsule is included with the hardware kit). Kohler Co. 1012607-2-B...
-
Page 6: Valve Operation
Water will flow from a single accessory when the control knob detent lines up with any of the large detents on the escutcheon. Water will flow from two accessories at the same time when the control knob detent lines up with a small escutcheon detent. 1012607-2-B Kohler Co.
