• It is recommended that these products be repaired by trained service technicians. For customers electing to repair their own Lenovo products, please follow all instructions carefully. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1.
• Explosive hazards, such as a damaged cathode ray tube (CRT) face or a bulging capacitor • Mechanical hazards, such as loose or missing hardware IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.
Chapter 3. Identifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. Figure 1. System exploded view Table 1. FRU (CRU) categories...
Page 30
Heat sink Touchpad cable Touchpad mylar ac power adapter Power cord Screw kit * for selected models IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product.
Figure 3. Areas on the heat sink where thermal interface materials should be applied (for Intel models) Figure 4. Areas on the heat sink where thermal interface materials should be applied (for AMD models) Areas on the system board where thermal interface materials are applied The following figure shows the areas on the system board where thermal interface materials are applied.
Place the computer upside down on a flat surface. Step 2. Remove five screws, pry up the latches, and then remove the lower case. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
M2.0 1.8 ± 0.3 M2.0 1.8 ± 0.3 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Lower case Remove the lower case (for 16–inch models) Make sure the computer has been shut down before servicing the computer.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Torque (kgf.cm) Quantity Thread M2.0 1.8 ± 0.3 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Battery pack Remove the solid-state drive Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 30 Step 1.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Thread M2.0 1.8 ± 0.3 Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: Wi-Fi card Remove the memory shield or memory absorbing mylar Make sure the following FRUs (CRUs) have been removed. “Remove the lower case” on page 30...
Open the latches and remove the memory module. Figure 16. Open the latches and remove the memory module Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: Memory module Remove the heat sink Remove the heat sink (with memory shield) Make sure the following FRUs (or CRUs) have been removed.
Torque (kgf.cm) Quantity Thread M2.0 1.8 ± 0.3 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Heat sink Remove the fan Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 30 Step 1.
Page 46
1.8 ± 0.3 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Step 2. Disconnect the speakers’ cable from the system board and I/O board and remove the speakers. Figure 22. Disconnect and remove the speakers Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Chapter 4...
Disconnect the I/O board cable and left speaker cable from the I/O board, remove three screws, and open the left hinge. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Quantity Thread M2.0 1.8 ± 0.3 Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: I/O board Remove the touchpad cable Make sure the following FRUs (CRUs) have been removed. Chapter 4 Removing a FRU or CRU...
Disconnect the I/O board cable from the I/O board. Then, disconnect the keyboard cable, keyboard backlight cable, touchpad cable, speakers’ cable, and EDP cable from the system board. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Page 51
Figure 27. Disconnect all the cables Step 2. Remove three screws and open the right hinge. Then, remove five screws and remove the system board. Figure 28. Remove eight screws and the system board Table 14. Screws used to secure the LCD module and system board Length (mm) Torque (kgf.cm) Quantity...
Disconnect the I/O board cable from the I/O board. Then, disconnect the keyboard backlight cable, keyboard cable, touchpad cable, EDP cable, and speakers’ cable from the system board. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Page 53
Figure 30. Disconnect all the cables Step 2. Remove three screws and open the right hinge. Then, remove six screws and remove the system board. Figure 31. Remove eight screws and the system board Table 15. Screws used to secure the LCD module and system board Length (mm) Torque (kgf.cm) Quantity...
Figure 33. Remove the HDMI foil Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: HDMI foil Remove the PMIC board (for OLED panel models) Make sure the following FRUs (or CRUs) have been removed.
“Remove the Wi-Fi card” on page 34 “Remove the memory shield or memory absorbing mylar” on page 35 IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Page 57
Figure 36. Peel back the cables Step 2. Remove the touchpad mylar. Figure 37. Remove the touchpad mylar Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Touchpad mylar Chapter 4 Removing a FRU or CRU...
Rotate the OLED/LCD module to an angle of more than 120 degrees and remove the OLED/LCD module. Figure 40. Rotate the OLED/LCD module and remove the OLED/LCD module Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: OLED/LCD module Remove the OLED/LCD module (for 16-inch models) Make sure the following FRUs (CRUs) have been removed.
Page 60
Rotate the OLED/LCD module to an angle of more than 120 degrees and remove the OLED/LCD module. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Figure 43. Rotate the OLED/LCD module and remove the OLED/LCD module Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: OLED/LCD module Remove the upper case (with keyboard) Make sure the following FRUs (CRUs) have been removed.
Figure 45. Remove the OLED/LCD bezel Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: OLED/LCD bezel Remove the ToF rubber (for models with IR camera) Make sure the following FRUs (or CRUs) have been removed.
Figure 48. Remove the camera shutter Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: Camera shutter Remove the hinges Remove the hinges (for 14-inch models) Make sure the following FRUs (CRUs) have been removed.
Page 66
“Remove the OLED/LCD bezel” on page 56 Step 1. Remove seven screws and remove the hinges. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Torque (kgf.cm) Quantity Thread M2.0 1.8 ± 0.3 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement part: Hinges Remove the strip cover Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 30 “Remove the OLED/LCD module”...
Peel back the mylar, disconnect the EDP cable, and remove the LCD panel. Figure 53. Disconnect the EDP cable and remove the LCD panel Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: LCD panel...
Page 70
3. Go to C:\Program files (x86)\X-Rite Color Assistant and locate the ProfileUpdaterForDisplayReplacement.exe file. Double-click the EXE file. Follow the on-screen IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
OLED part. When the new color profiles are installed successfully, a prompted window will be displayed. Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts:...
“Remove the OLED bracket (for OLED panel models)” on page 65 Step 1. Disconnect the EDP cable from the camera board and remove the camera board. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Figure 58. Disconnect the EDP cable and remove the camera board Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: Camera board Remove the EDP cable Remove the EDP cable (for models without IR camera) Make sure the following FRUs (CRUs) have been removed.
Page 74
Disconnect the EDP cable from the camera board and ToF board. Then, remove the EDP cable. IdeaPad Slim 5 (14″, 10), IdeaPad Slim 5i (14″, 10), IdeaPad Slim 5 (16″, 10), and IdeaPad Slim 5i (16″, 10) Hardware Maintenance Manual...
Figure 60. Disconnect and remove the EDP cable Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement part: EDP cable Remove the OLED/LCD cover Make sure the following FRUs (CRUs) have been removed. “Remove the lower case” on page 30 “Remove the OLED/LCD module”...
