IdeaPad Pro 5 (14", 10) and IdeaPad Pro 5i
(14", 10)
Hardware Maintenance Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IdeaPad Pro 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Lenovo IdeaPad Pro 5

Summary of Contents for Lenovo IdeaPad Pro 5

  • Page 1 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 2 First Edition (January 2025) © Copyright Lenovo 2025.

  • Page 3: Table Of Contents

    Remove the battery pack ... Remove the solid-state drive (SSD) ..Trademarks ....lix © Copyright Lenovo 2025...
  • Page 4 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 5: About This Manual

    • It is recommended that these products be repaired by trained service technicians. For customers electing to repair their own Lenovo products, please follow all instructions carefully. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1.
  • Page 6 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Do not work alone under hazardous conditions or near equipment that has hazardous voltages. • Disconnect all power before: – Performing a mechanical inspection – Working near power supplies – Removing or installing main units © Copyright Lenovo 2025...

  • Page 8: Safety Inspection Guide

    This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-Lenovo features or options not covered by this inspection guide.

  • Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    • English • Arabic • Brazilian Portuguese • French • German • Hebrew • Japanese • Korean • Spanish • Traditional Chinese DANGER DANGER DANGER DANGER IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 11 DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO DANGER DANGER DANGER IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER DANGER VORSICHT Chapter 1 Safety information...
  • Page 16 VORSICHT VORSICHT VORSICHT VORSICHT VORSICHT IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 25: Chapter 2. General Checkout

    The following are not covered under warranty: • LCD panel cracked from the application of excessive force or from being dropped • Scratched (cosmetic) parts • Distortion, deformation, or discoloration of the cosmetic parts © Copyright Lenovo 2025...

  • Page 26: Cru List

    • Check for obvious damage to a hard disk drive. If the spindle of a hard disk drive becomes noisy, the hard disk drive might have been dropped or subject to excessive force. CRU list Table 1. Model: All Type ac power adapter self-service power cord self-service IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 27: Chapter 3. Identifying Frus (Crus)

    Chapter 3. Identifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. © Copyright Lenovo 2025...
  • Page 28 Figure 1. Exploded view IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 29 Table 2. FRU (CRU) categories FRU (CRU) category LCD module Note: The LCD module as a whole is not a FRU. It contains FRUs as its components. Upper case Touchpad with cable System board (Intel models) System board (AMD models) I/O board I/O board cable Solid-state drive (SSD)
  • Page 30 Figure 2. LCD module exploded view Table 3. FRU (CRU) categories for LCD module FRU (CRU) category Hinge cover LCD bezel Strip cover IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 31 Table 3. FRU (CRU) categories for LCD module (continued) FRU (CRU) category LCD panel Camera bracket Camera shutter Microphone rubbers IR rubber Camera Sensor board ToF cable Camera cable Hinges LCD cover EDP cable Chapter 3 Identifying FRUs (CRUs)
  • Page 32 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 33: Chapter 4. Removing A Fru Or Cru

    Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product.

  • Page 34: Handling Thermal Interface Materials

    Area Type Quantity PTM7958 0.2 g, 25.1 mm × 12.3 mm × 0.2 mm IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 35: Areas On The System Board Where Thermal Interface Materials Are Applied

    Figure 3. Areas on the heat sink where thermal interface materials should be applied (Intel models) Figure 4. Areas on the heat sink where thermal interface materials should be applied (AMD models) Areas on the system board where thermal interface materials are applied The following figure shows the areas on the system board where thermal interface materials are applied.

  • Page 36: Remove The Battery Pack

    Make sure the following FRU (or CRU) has been removed. “Remove the lower case” on page 29 Step 1. Disconnect the battery pack cable from the system board. IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 37 Figure 9. Remove the battery pack cable Step 4. Remove the battery bracket. Figure 10. Remove the battery bracket Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Battery pack Battery pack cable Chapter 4...

  • Page 38: Remove The Solid-State Drive (Ssd)

    • Install 2242 SSD: 1. Remove the screw in the 2280 SSD standoff. Table 8. Screw used to secure the SSD Length (mm) Torque (kgf.cm) Quantity Thread 1.85±0.15 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 39 2. Use this screw to install the 2242 SSD in the reverse order of the removal steps mentioned above. • Install 2280 SSD: 1. Remove the screw in the 2280 SSD standoff and then remove the 2242 SSD pad. Table 9. Screw used to secure the SSD Length (mm) Torque (kgf.cm) Quantity...

  • Page 40: Remove The Wi-Fi Card

    Table 11. Screw used to secure the Wi-Fi card Length (mm) Torque (kgf.cm) Quantity Thread 1.85±0.15 Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 41: Remove The Oled Board

    Length (mm) Torque (kgf.cm) Quantity Thread 1.85±0.15 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: OLED board Remove the speakers Make sure the following FRU (or CRU) have been removed. “Remove the lower case” on page 29 Step 1.

  • Page 42: Remove The Touchpad With Cable

    “Remove the lower case” on page 29 “Remove the battery pack ” on page 30 Step 1. Peel off the tape and then disconnect the touchpad cable from the system board. IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 43 Quantity Thread M1.6 1.2±0.15 Step 3. Remove the touchpad with cable. Figure 19. Remove the touchpad with cable Refer to to look up the Lenovo part number of the following https://support.lenovo.com/partslookup replacement part: Chapter 4 Removing a FRU or CRU...

  • Page 44: Remove The Thermal Module

    Peel off the tape and then disconnect two cables from the system board. Figure 20. Disconnect two cables Step 3. Remove seven screws and then remove the thermal module. Figure 21. Remove the thermal module (AMD models) IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 45: Remove The I/O Board

    Thread 1.85±0.15 1.85±0.15 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Thermal module Remove the I/O board Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 29 “Remove the thermal module”...

  • Page 46: Remove The System Board

    “Remove the Wi-Fi card” on page 34 “Remove the OLED board” on page 35 “Remove the thermal module” on page 38 Step 1. Remove three screws and then flip the hinge. IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...
  • Page 47 Figure 25. Remove three screws and flip the hinge Table 17. Screws used to secure the hinge Length (mm) Torque (kgf.cm) Quantity Thread M2.5 3±0.3 Step 2. Disconnect all cables connected to the system board. Chapter 4 Removing a FRU or CRU...
  • Page 48 Figure 26. Disconnect cables connected to the system board Step 3. Remove four screws and then remove the system board. Figure 27. Remove the system board IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 49: Use A Golden Key U1 Tool To Flash-Write Key Id Information

    Step 4. Remove the I/O board cable from the system board. Figure 28. Remove the I/O board cable Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: System board I/O board cable Related topics “Handling thermal interface materials ”...

  • Page 50: Remove The Upper Case

    Torque (kgf.cm) Quantity Thread M2.5 3±0.3 Remove the upper case Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 29 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 51: Disassemble The Lcd Module

    “Remove the system board” on page 40 “Remove the LCD module” on page 43 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Upper case Disassemble the LCD module The LCD module as a whole is not a FRU. Instead, it contains FRUs as its components. Before disassembling the LCD module, make sure it has been detached from the upper case.

  • Page 52: Remove The Lcd Bezel

    Step 1. Remove the LCD bezel. Note: The LCD bezel, removable tape, and Lenovo limit rubbers are packaged as a FRU kit. Figure 32. Remove the LCD bezel Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup...

  • Page 53: Remove The Hinges

    Torque (kgf.cm) Quantity Thread 1.85±0.15 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Hinges Remove the LCD panel Make sure the following FRUs (CRUs) have been removed. “Remove the LCD module” on page 43 “Remove the hinge cover”...
  • Page 54 Figure 35. Remove the removable tape and remove the LCD panel Step 2. Remove the EDP cable from the LCD panel. Figure 36. Remove the EDP cable IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 55: Remove The Camera Cable

    When installing: 1. Attach six Lenovo limit rubbers to the six positions in the figure below. 2. Attach the removable tape and then remove the release liner. 3. Align the LCD panel with the surrounding limit rubbers and gently press the LCD panel with your hands.

  • Page 56: Remove The Sensor Board

    “Remove the strip cover” on page 46 “Remove the LCD panel” on page 47 Step 1. Disconnect all cables connected to the sensor board and then remove the sensor board. IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 57: Remove The Camera Bracket

    Figure 38. Remove the sensor board Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Sensor board Removable tape Remove the camera bracket Make sure the following FRUs (CRUs) have been removed. “Remove the LCD module” on page 43 “Remove the hinge cover”...

  • Page 58: Remove The Tof Rubber

    “Remove the strip cover” on page 46 “Remove the LCD panel” on page 47 “Remove the camera bracket” on page 51 Step 1. Remove the ToF rubber. IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 59: Remove The Camera Shutter

    Figure 41. Remove the ToF rubber Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: ToF rubber Removable tape Remove the camera shutter Make sure the following FRUs (CRUs) have been removed. “Remove the LCD module” on page 43 “Remove the hinge cover”...

  • Page 60: Remove The Tof Cable

    “Remove the ToF rubber” on page 52 “Remove the camera shutter” on page 53 Step 1. Disconnect the camera cable from the camera board and then remove the camera. IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 61: Remove The Lcd Cover

    “Remove the ToF rubber” on page 52 “Remove the camera shutter” on page 53 “Remove the ToF cable” on page 54 “Remove the camera” on page 54 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: LCD cover Chapter 4...
  • Page 62 IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 63: Appendix A. Label Locations

    22 mm x 30 mm India BIS Label TW Caution Label 70 mm x 10 mm VietNam energy label 10 mm x 9 mm Belarus Label 40 mm x 8 mm 30 mm x 30 mm CECP Label © Copyright Lenovo 2025...
  • Page 64 Table 22. All base cover labels (continued) Applied country/region Label Label name Label dimensions USA warning Label (Canada) 120 mm x 20 mm Indonesia SDPPI label 40 mm x 10 mm IdeaPad Pro 5 (14″, 10) and IdeaPad Pro 5i (14″, 10) Hardware Maintenance Manual...

  • Page 65: Trademarks

    Trademarks LENOVO and the LENOVO logo are trademarks of Lenovo. All other trademarks are the property of their respective owners. © 2025 Lenovo.
