- Page 1 Glamox MIR G2 User manual...
- Page 2 English / Cable Deutsch / Kabel Nederlands / Kabel If the external flexible cable or cord of Um eine Gefährdung zu vermeiden, darf Als de externe flexibele kabel of het snoer this luminaire is damaged, it shall be die externe flexible Leitung der Leuchte van dit armatuur beschadigd is, mag exclusively replaced by the manufacturer bei einer Beschädigung, ausschließlich...
- Page 3 ELEKTRISK STØD Svenska Ljuskällan i denna armatur får endast Eesti Polski bytas ut i Glamox fabriker, av Glamox Selle valgusti valgusallikat võib Źródło światła w tej oprawie może zostać servicetekniker eller motsvarande asendada ainult tootja, tema wymienione wyłącznie przez producenta, kvalificerad personal.
- Page 4 Glamox MIR G2 MIR G2 Types MIR-600 G2 MIR-1200 G2 1334 1314 1296 MIR-1500 G2 1634 1614 1596 MIR G2 EM Types MIR-600 G2 MIR-1200 G2 1468 1448 1419 MIR-1500 G2 1768 1748 1718...
- Page 5 Glamox MIR G2 MIR G2 HOOD NUT Types CC = Hood nuts M8 distance MIR-600 G2 MIR-1200 G2 1296 MIR-1500 G2 1596 1100 MIR G2 EM HOOD NUT Types CC = Hood nuts M8 distance MIR-600 G2 MIR-1200 G2 1419...
- Page 6 Glamox MIR G2 400 C-C 396 M8 C-C 186...
- Page 7 Glamox MIR G2 5.0 Nm 5.0 Nm Torque, cable Polyamide 7-14 mm 9-18 mm Cable diameter 20.0 Nm 25.0 Nm Torque, cable, sealing ring S1+S2+S3 18.0 Nm 20.0 Nm Torque, cable, sealing ring S1+S2 NiPl Brass 15.0 Nm 18.0 Nm...
- Page 8 Glamox MIR G2...
- Page 9 Glamox MIR G2 0.8 Nm...
- Page 10 Glamox MIR G2 400 0.8 Nm...
- Page 11 Glamox MIR G2 NB! Use correct torque on terminal block NB! Ensure to make a drip loop on the power cable to avoid water ingress into the fitting 0.8 Nm For external bonding (M6) in luminaires with M8 hood nut...
- Page 12 Glamox MIR G2 suspension (options) Universal bracket M8 Bolt Shock absorbing bracket (M8 Bolt to be ordered in addition)
- Page 13 Emergency – Battery change external Spare part number on existing battery label. Use only original spare parts from Glamox. General inspections and main function control to be carried out regularly. Full emergency duration test by switching off power supply should be performed at least once a year.
- Page 14 Emergency – Battery change internal OLD BATTERY NEW BATTERY...
- Page 15 Glamox MIR G2 external connection Glamox MIR G2 external connection DALI DALI+ DALI- 24VDC 24VDC 24VDC 230V + 24VDC 24VDC 24VDC 24VDC 24VDC...
- Page 16 Glamox MIR G2 external connection EM Emergency DALI with on/off switch ON/OFF DALI+ DALI- Emergency S/ST With 1 pole on/off switch 2 pole on/off switch not to TEST ON/OFF be used for Emergency S SWITCH Emergency S/ST without on/off switch...
- Page 17 - Shut down mains/power before opening the luminaire. Dry out with a dry cloth and close the luminaire - If there is accumulated water inside an investigation of the cause should be performed. Check Cable glands towards cable and housing Manufacturer: Glamox AS Birger Hatlebakksveg 15 NO-6415 Molde, Norway...
- Page 18 “Installation and maintenance manual” manual” meie koduleheküljelt. w dokumencie „Instrukcja instalacji på vår hemsida. i konserwacji” na naszej stronie internetowej. Please refer to our website Please visit our web site for contact for information about information our 5-year warranty. www.glamox.com...
