Phone open
XT2323-4
XT2323-7
Camera
SIM Card
Screen
(see "Take
care of
phone")
Microphone
read me
ja
1
Protect your screen: Please do not remove the attached screen
protector or use third party screen protectors. Doing so will void the
device warranty.
Earpiece/Speaker
Microphone
Front
Microphone
Tray
Volume
Buttons
Power
Button
Fingerprint
Sensor
Main
1
your
Speaker
Phone back
Ultra-wide/
Main Camera
Macro
Camera
Flash
Proximity
Sensor
/
NFC Felica
Touchpoint
USB-C®/Charger/Digital Headset Jack
Wireless Charging: Charge your phone using a Qi-certified wireless charger
2
(sold separately).
3
Use a digital headset: To use a digital headset, you'll need one with a
USB-C connector. If using a 3.5mm headset, you'll need a 3.5mm to USB-C
digital headset adapter to connect it. Headset and adapter may be sold
separately.
External
Display
Wireless
Charging
Area
PART NUMBER
motorola.com
[VDR]
Printed in [Country]
[LOC]
MMM/YY
