WALL/WINDOW TYPE ROOM AIR CONDITIONER

Warning notices: Before using this product, please read this manual carefully and keep it for future reference.

The design and speciﬁcations are subject to change without prior notice for product improvement.

Consult with your dealer or manufacturer for details.

The diagram above is just for reference. Please take the appearance of the actual product as the standard.

OWNER'S MANUAL

MAT08R1ZWT

MAT10R1ZWT

MAT10R2ZWT

MODEL NUMBER

MAT12R1ZWT

MAT12R2ZWT

MAT14R2ZWT

Table of Contents

Need help?

Do you have a question about the MAT08R1ZWT and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea MAT08R1ZWT

Page 1 WALL/WINDOW TYPE ROOM AIR CONDITIONER OWNER’S MANUAL MODEL NUMBER MAT08R1ZWT MAT12R1ZWT MAT10R1ZWT MAT12R2ZWT MAT10R2ZWT MAT14R2ZWT Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and speciﬁcations are subject to change without prior notice for product improvement.
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS WHAT IS IN THE BOX BEFORE YOU GET START INSTALL YOUR PRODUCT. GET TO KNOW YOUR AC. GET TO KNOW THE FEATURES. CLEANING & MAINTENANCE TROUBLESHOOTING...
Page 3: Safety Precautions
SAFETY PRECAUTIONS It is really important you read Safety Precautions Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION. Explanation of Symbols WARNING This symbol indicates the possibility of personal injury or loss of...
Page 4 Keep ﬁrearms away. It may cause ﬁre. Do not use the power cord close to heating ● appliances.It may cause ﬁre and electric shock. Do not use the power cord near ﬂammable gas or combustibles, such as gasoline, benzene, thinner, etc. It may cause an explosion or ﬁre.
Page 5 Installation must be performed in accordance with the requirement of NEC and ● CEC by authorized personnel only. Do not operate your air conditioner in a wet room such as a bathroom or laundry ● room. The appliance with electric heater shall have at least 1 meter space to the ●...
Page 6 Grounding type wall receptacle Do not, under any circumstances, cut, remove, or bypass the grounding prongs. Power supply cord with 3-prong grounding plug and current detection device. WARNING Electrical Information The complete electical rating of your new room air conditioner is stated on the serial plate.
Page 7: Main Control
Electronic Work WARNING: BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE MAIN POWER TO THE SYSTEM. Electronic Type Display Compressor L/AC L/L1/L-IN Power Supply N/AC N/L2/N-IN Fan Motor Main Control Other NOTICE: Please strictly follow the wiring label attached to the machine for all wiring connections. The wiring diagram may vary for di erent unit.
Page 8 CAUTION: Risk of ﬁre ﬂammable materials Explanation of symbols displayed on the unit CAUTION This symbol shows that the operation manual should be read carefully. This symbol shows that a service personnel should be handling this equipment with reference to the CAUTION installation manual.
Page 9 1. Transport of equipment containing flammable refrigerants See transport regulations. 2. Marking of equipment using signs See local regulations. 3. Disposal of equipment using flammable refrigerants See national regulations. 4. Storage of equipment/appliances The storage of the appliance should be in accordance with the applicable regulations or instructions, whichever is more stringent.
Page 10 7)ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
Page 11 and the appropriate percentage of gas (25 % maximum) is conﬁrmed. Leak detection ﬂuids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. If a leak is suspected, all naked ﬂames shall be removed/ extinguished.
Page 12 Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant. It is essential that electrical power is available before the task is commenced. a) Become familiar with the equipment and its operation. b) Isolate system electrically.
Page 13: What Is In The Box
WHAT IS IN THE BOX. Package content Air Conditioner Unit Seal*2 (1"x1-1/2"x14") Trim Frame (top & bottom legs)*2 Seal*2 (1"x3/4"x14") Trim Frame (side legs)*2 Seal*2 (1"x3/8"x14") Wall Sleeve (purchase separately) Seal*2 (1"x3/8"x25") Aluminum Grille Seal*3 (1"x1-1/2"x25") Plastic Grille (1/8"x4-1/2"x14-1/2") Plastic Divider*2 (1/8"x4-1/2"x14-1/2") Centering/Support Blocks(Blue)*4 Screw*4 and Screw Washer*4 (4-1/2"x3-1/2"x1-1/2")
Page 14: Before You Get Start
BEFORE YOU GET START. Preparations before installation NOTE The installation must be carried out n u a in strict accordance with the instructions Save Carton and these Installation in this manual. Instructions for future reference. The carton is the best way to store unit during winter, or when We recommend doing this with a helper.
Page 15 Complete the installation of Wall Sleeve. Preparations before unit installation Install the wall sleeve and make grounding connection Remove old Air Conditioner from wall sleeve and prepare wall sleeve(if any). Clean interior (do not disturb seals). Under the front of the wall cover, there are two 1/8" holes for ground operation. Use the Ground Wire and Ground Screw(No.
Page 16 Installation of Aluminum Grille. Installation of new grille provided with unit NOTE We have a new design for the rear grille (two rear air intakes) to improve the performance of the product. Please be sure to use the aluminum grille we provide for installation to achieve the best performance of the product.
Page 17: Install Your Product
INSTALL YOUR PRODUCT. Installation overview #9 White Westinghouse or Frigidaire for example NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly di erent. The actual shape shall prevail. IMPORTANT Save these instructions for local inspectors use. Observe all governing codes and ordianaces. Proper installation is the responsibility of the installer.
Page 18 #1 Emerson(15" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the back, and attach it to the top of the sleeve where it meets the aluminum Cut the...
Page 19 #2 Fedders(19-3/4" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the back, and attach it to the top of the Cut the Seal(NO.12) sleeve where it meets the aluminum...
Page 20 #3 Fedders or Friedrich(16-3/4" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the back, and attach it to the top of the Cut the Seal(NO.12)
Page 21 #4 General Electra/Hotpoint(16-7/8" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the Cut the Seal(NO.12) back, and attach it to the top of the to a 14"...
Page 22 #5 Sears or Carrier 51S Series(18-5/8" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the Cut the Seal(NO.12) back, and attach it to the top of the...
Page 23 #6 Whirlpool(17-1/8" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the Cut the Seal(NO.12) back, and attach it to the top of the to a 15"...
Page 24 #7 Whirlpool(23" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall For the sleeve with too Tear the Seal(NO.13) paper The blocks much depth, we need to...
Page 25 #8 White Westinghouse/Frigidaire/Carrier 52F Series(16/17-1/2" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall Tear the Seal(NO.13) paper from the back, and attach it to the top of the sleeve where it meets the aluminum...
Page 26 #9 White Westinghouse or Frigidaire(22" Deep) installation guide NOTE Complete the ﬁrst installation step according to the wall cover installation guide (page 8) and aluminum grid installation guide (page 9) . Guide to installation before embedding the product into the wall For the sleeve with too Tear the Seal(NO.13) paper The blocks...
Page 27 You can installing aluminum grille at first. installation guide NOTE The previous directions are the preferable way to mount the new Aluminum Grill. The units performance is slightly better and the possibility of draughts is reduced. As a last resort, direct mounting of the grille to the unit can be considered (the installation tutorial follows).
Page 28 Finally, do some cosmetic work on your product. installation guide Step 2 Step 1 Step 3 Do some cosmetic work. The installation is complete. Step 1: Assemble the Trim Frame(NO.2) by inserting Congratulations on the installation, but top and bottom pieces into side pieces(NO.3), and you're not done yet.
Page 29: Get To Know Your Ac
GET TO KNOW YOUR AC. AC unit overview Components of the product Air Direction Levers Status display and Display Filter handshandle Front Intake Grille front panel Rear Condenser Vents Adjust the Air Direction Center handles Air directional louvers control air ﬂow direction. Your air conditioner has the 4-way directional system described below.The louvers will allow you to direct the air ﬂow Up or Horizontal, and Left or Right throughout the room as needed.Use the center handles to adjust the air directional louvers side-to-side until the desired Left or Right direction is obtained.Pivot horizontal louvers with your ﬁngertips until the...
Page 30: Get To Know The Features
GET TO KNOW THE FEATURES. ELECTRONIC CONTROL OPERATING INSTRUCTIONS NOTE Before you begin, thoroughly familiarize yourself with the control panel as shown below and all its functions, then follow the symbol for the functions you desire. The unit can be controlled by the unit control alone or with the remote.
Page 31: To Select The Operating Mode
ELECTRONIC CONTROL OPERATING INSTRUCTIONS Description Press Energy saver button to initiate this function. This function is available on COOL, DRY, AUTO (only AUTO-COOLING and AUTO-FAN) modes.The fan will ENERGY SAVER continue to run for 3 minutes after the compressor shuts o . The fan then FEATURE: cycles on for 2 minutes at 10 minutes intervals until the room temperature is above the set temperature, at which time the compressor turns back on and...
Page 32 ELECTRONIC CONTROL OPERATING INSTRUCTIONS Description When the unit is on or o , ﬁrst press Timer button, the TIMER ON indicator light illuminates. It indicates the Auto Start program is initiated. When the time of TIMER ON is displayed, press the Timer button again, the TIMER OFF indicator light illuminates.
Page 33 One more thing Additional Notes Your AC may look a little different. All the illustrations in this manual are for explanation purpose only. Your air conditioner may be slightly di erent. The actual shape shall prevail. Additional things you should know. Now that you have mastered the operating procedure, here are more features in your control that you should become familiar with.
Page 34: Remote Controller Specifications
Remote Controller Specifications RG51G(1)/CEFU1,RG51G(1)/EFU1,RG51G1(1)/EFU1, Model RG51G4(1)/EU1,RG51G5(1)/EU1, RG51G4(1)/CEU1 Rated Voltage 3.0V( Dry batteries R03/LR03×2) Signal Receiving Range Environment 23°F~140°F (-5°C~60°C) Quick Start Guide SELECT MODE FIT BATTERIES SELECT TEMPERATURE AUTO COOL HEAT PRESS POWER BUTTON POINT REMOTE TOWARD UNIT SELECT FAN SPEED AUTO HIGH NOT SURE WHAT A FUNCTION DOES?
Page 35: Handling The Remote Controller
Handling the Remote Controller Inserting and Replacing Batteries NOTES FOR USING REMOTE CONTROL Your air conditioning unit may come with two The device could comply with the local national batteries(some units). Put the batteries in the regulations. remote control before use. In Canada, it should comply with •...
Page 36: Buttons And Functions
Buttons and Functions Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air conditioner, refer to the How to Use Basic Functions section of this manual. Description TEMP Decreases temperate in1°F (1°C) increments.
Page 37 Buttons and Functions Description TEMP Decreases temperate in 1°F (1°C) increments. No.1 Min. temperature is 62°F(17°C). ON/OFF No.2 Turns the unit on or off. MODE Scrolls through operation modes as follows:     AUTO COOL HEAT No.3 NOTE: Please do not select HEAT mode if the machine you purchased is cooling only type.
Page 38 Buttons and Functions Description TEMP Decreases temperate in 1°F (1°C) increments. No.1 Min. temperature is 62°F(17°C). ON/OFF No.2 Turns the unit on or off. MODE Scrolls through operation modes as follows:     AUTO COOL HEAT No.3 NOTE: Please do notselect HEAT mode if the machine you purchased is cooling only type.
Page 39: Fan Speed
Buttons and Functions Description TEMP Decreases temperate in 1°F (1°C) increments. No.1 Min. temperature is 62°F(17°C). ON/OFF No.2 Turns the unit on or off. MODE Scrolls through operation modes as follows: No.3   COOL HEAT LED DISPLAY No.4 Turns indoor unit’s LED displayon and off. SLEEP No.5 Saves energy during sleeping hours.
Page 40 Remote Screen Indicators Information are displayed when the remote controller is power up. AUTO Mode display COOL HIGH COOL AUTO HEAT HEAT Displayed when data transmitted. Displayed when remote controller is ON. Displayed when TIMER ON time is set. Displayed when TIMER OFF time is set. Shows set temperature or room temperature, or time under TIMER setting.
Page 41: How To Use Basic Functions
How to Use Basic Functions Basic operation AUTO Mode ATTENTION! Before operation, please ensure the unit is plugged in and power is available. COOL Mode In AUTO mode, the unit will automatically select the COOL, FAN, or HEAT operation based on the set temperature.
Page 42 How to Use Basic Functions FAN Mode 1. Press the MODE button to select DRY. 2. Set your desired temperature using the TEMP or TEMP   button. 3. Press the ON/OFF button to start the unit. NOTE: FAN SPEED cannot be changed in ...
Page 43 How to Use Basic Functions Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER ON button Press Temp. up or down button for Point remote to unit and wait to initiate the ON time for multiple times to set the desired 1sec, the TIMER ON will be...
Page 44 How to Use Advanced Functions I SENSE (some models) °C/°F (some models) Press I SENSE button Press this button will alternate the temperature When the I SENSE function is activated, the display between the °C & °F. remote display is actual temperature at its location.
Page 45 How to Use Advanced Functions SHORTCUT function(some models) SHORT CUT Used to restore the current settings or resume previous settings.(For some models) Push this button when remote controller is on, the system will automatically revert back to the previous settings including operating mode, setting temperature, fan speed level and sleep feature(if activated).
Page 46: Cleaning & Maintenance
CLEANING & MAINTENANCE How to clean & change your filter. Check the air filter at least once a month to see if cleaning is necessary. Air Filter Cleaning Energy Saving Note The air ﬁlter should be checked at In order to reach the maximum energy least once a month to see if cleaning saving and comfort, it is recommended is necessary.
Page 47: Troubleshooting
TROUBLESHOOTING Problem Solving Before calling for service, review this list. It may save your time and expense. This list includes common occurrences that are not the result of defective workman-ship or materials in this appliance. Problem Solution Wall plug disconnected. Push plug ﬁrmly into wall outlet. House fuse blown or circuit breaker tripped.
Page 48 300 Kimball Dr Parsippany NJ 07054 Telephone number or internet contact information: Midea.com/us FCC Compliance Statement ( products subject to Part 15) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 49: Warranty
Operating Instructions. 2) Damages caused by services performed by persons other than authorized Midea costumer service; or external causes such as abuse, misuse, inadequate power supply or acts of God.
Page 52 2024 CW021IU-B(TTW)N8X(XD)NY(NEW)A 16120300A34354...
