- Page 1 5150 Getting Started Guide Software & Documentation To download software, the 5150 User Manual, and other supporting documentation scan the QR code here or on the tester to visit downloads.cirris.com. downloads.cirris.com...
-
Page 2: Getting Started
Getting Started The 5150 is an extremely flexible unit designed for use in testing and automated manufacturing applications. The Base includes an integrated PC running the Windows operating system with a 10-inch, capacitive touchscreen as the user interface, but it can also support a larger, external display, keyboard, mouse, and other common peripherals. -
Page 3: High Voltage Interlock
Protecting workers begins with training. Operators should understand: ● Basic electricity including the fact that electric current will take any avail- able path to ground, including through a person. ● How to use the test equipment and how to recognize when high voltage testing is being performed. -
Page 4: Intended Use
Medical Safety Warning An individual using a cardiac pacemaker, an insulin pump, or any electronically- controlled medical device should NOT perform high voltage testing. Intended Use The 5150 is designed for electrical testing and is intended to be used indoors, in a dry environment, at a temperature of 50-104 degrees Fahrenheit (10-40 degrees Celsius). -
Page 5: Assembling The System
Assembling the System The 5150 has rubber feet for placement on a level surface. Optional “L-shaped” brackets that attach to threaded inserts on each side of the enclosure allow the unit to be secured to vertical rails in racks or in a standard 19” (48.26 cm) electronics cabinet. - Page 6 Expansion Expansion The 5150 can support one Expansion unit to provide capacity for up to 384 additional test points The Expansion can be stacked CONTROLLER 64 PT SCANNER 64 PT SCANNER 64 PT SCANNER 64 PT SCANNER 64 PT SCANNER 64 PT SCANNER Status on top of the Base or located separately.
-
Page 7: Software Environment
High Voltage Interlock Override CONTROLLER Status The high voltage safety interlock must be engaged before the tester will perform high voltage testing. If not using external safety interlock hardware, plug the High Voltage Override supplied with the tester onto the IN connector on the Base Controller module to override the interlock and allow high voltage testing. - Page 8 Easy Test Interface (ETI) The Easy Test Interface is designed for use on the 5150 integrated touchscreen. On the ETI Main Menu, select any listed test program and tap Start to begin a test session. Typing the beginning characters of the test program name in the Search box or selecting a category from the Filter drop-down list can help narrow the search.
- Page 9 Tapping the Menu icon in the upper left corner opens a list of actions. Tapping anywhere outside the menu list closes the Menu. Import Test allows the user to import test programs created for the 5150 or CH2. The ETI Import function does not import associated connector graphics files as does the Easy-Wire Import function.
- Page 10 Easy-Wire with ETI The Main Menu is the launching point for subsequent Easy-Wire functions, all of which are described in the 5150 Easy-Wire User Manual and in the Easy-Wire contextual Help system. For quick reference, the User, Easy- Wire version, tester Status, tester type, and number of installed test points are all displayed.
-
Page 11: Accessing The Windows Desktop
Accessing the Windows Desktop Occasionally, it may be necessary to access Windows functions to add peripherals, change settings, attach the 5150 to a network database, install software, etc. When using ETI, exiting to Windows is available to all users. When using Easy-Wire as the default interface, only certain users are given the ability to access the Windows Desktop. -
Page 12: Database Backup
Database Backup The Easy-Wire software stores all test programs, connector profiles, and test results in a database. By Default, this database is located on the hard drive of the integrated PC. To protect the contents of the database against loss, the database should be backed up regularly. - Page 13 Changing the Easy-Wire Interface Language The language used in the Easy-Wire interface can be changed to one of the available options. From the Main Menu > Utilities > Setup System Options. Under the Software Settings tab, select Change. Select a language from the list of options and click OK.
- Page 14 Cirris Server Software The Cirris Server Software allows multiple Easy-Wire test stations to share a single database located on a network server. In this configuration, all the sta- tions load test programs from the network database and write test results to the same database.
- Page 15 Accessing the Easy-Wire Help The Easy-Wire software includes a contextual Help system accessible by clicking on the Help button available on each Easy-Wire window. The Help can be browsed using the Table of Contents or searched by keywords. Documentation In addition to this Getting Started Guide, there are several resources that pro- vide important information about the test system and its operation.
-
Page 16: Help & Support
Help / Support For assistance with your Cirris test system: ● Visit www.cirris.com/learning-center to read articles about Cirris products and other testing subjects. ● Visit the Cirris YouTube channel to find instructive videos. ● In the United States, contact our technical support team at techsupport@ cirris.com or by phone at 801-973-4600, ext.
