  • Page 1 English 4 C H P o w e r C o n t r o l l e r USER'S MANUAL Hold Dimmer SPEED MASTER AUDIO Midi Hold Sound Power Prog Sound Prog Speed Auto/Sound Auto/Speed DOWN Memory Flash Flash Flash Flash Mode...

  • Page 3: Table Of Contents

    Contents Features 1 General Instructions 2 1. Overview 3 1.1 Front View 3 1.2 Rear View 6 2. Operation Guide 7 2.1 Chase Modes 7 2.1.1 Hold Dimmer 7 2.1.2 Hold Sound 7 2.1.3 Prog. Sound 8 2.1.4 Prog. Speed 9 2.1.5 Auto Sound 10 2.1.6 Auto Speed 11 2.1.7 Memory 11...

  • Page 4: Features

    Features Thank you for your purchase. This product features include: 4 channels DMX /MIDI pack 4 individual faders and 1 master fader 4 Flash buttons, Full On & Standby(priority) 43 preset chases with adjustable chase rate 7 programmable chases, each holds up to 16 steps Fade Time(from instant to 10 seconds) enable/disable MIDI channel setting allows MIDI control capable Auto/Audio/Speed/Tap Sync/Memory chase can be selectable...

  • Page 5: General Instructions

    General Instructions Read the instruction in this manual carefully and thoroughly, as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to read about its operation and re lative instructions.

  • Page 6: Overview

    1. Overview 1.1 Front View...
  • Page 7 1. Overview 1.1 Front View 1. Channel Faders(1-4) These faders are used to control the intensity of channel 1-4. 2. Flash Buttons(1-4) These faders are used to control the intensity of channel 1-4. 3. Channel LEDs(1-4) These LEDs indicate the intensity of channel 1-4. 4.
  • Page 8 1. Overview 1.1 Front View 14. Audio Level Slider & its LED This slider controls the sensitivity of the audio for best effect, its LED flashes indicating the beat it detected. 15. Tap Sync Button Repeatedly tapping this button establish the chase speed. 16.

  • Page 9: Rear View

    1. Overview 1.2 Rear View Line input 0.1V-1Vp-p Midi Thru Midi In AC Input DMX out 1. Power Cord Plug this cord into a matching power outlet. 2. DMX Output This connector sends DMX data to the DMX fixture or DMX pack. 3.

  • Page 10: Operation Guide

    2. Operation Guide 2.1 Chase Modes 2.1.1 Hold Dimmer Every time you power up the unit, it always resume last chase mode before power off and Stand-by function is active(its LED flashes briefly). Be careful not to power on this unit twice within one second. 1.

  • Page 11: Prog. Sound

    2. Operation Guide 2.1.2 Hold Sound 2. The overall four channels will be controlled by the audio beat detected by the built-in microphone or line in audio signal. The audio sensitivity can be controlled by the Audio level slider. 2.1.3 Prog. Sound 1.

  • Page 12: Prog. Speed

    2. Operation Guide 2.1.3 Prog. Sound 3. Adjust channel faders and Master slider for desired dimming effect. 2.1.4 Prog. Speed 1. Tap Mode Select button until LED under Prog. Prog. Speed Speed is lit and the LED display reads "RP01", this unit is in Program Speed mode.

  • Page 13: Auto Sound

    2. Operation Guide 2.1.4 Prog. Speed 3. Adjust Speed slider(or Tap Sync) for desired chase effect. Adjust channel faders and Master slider for desired dimming effect. 2.1.5 Auto Sound 1. Tap Mode Select button until LED under Auto Auto Sound/ Sound/ Auto Speed is lit and the LED display reads Auto Speed "AS01", this unit is in Auto Sound mode.

  • Page 14: Auto Speed

    2. Operation Guide 2.1.6 Auto Speed 1. Tap Mode Select button until LED under Auto Auto Sound/ Auto Speed Sound/ Auto Speed flashes and the LED display reads "AP01", this unit is in Auto Speed mode. Mode Select 2. All 43 programs will sequence uninterruptedly. Adjust Speed slider(or Tap Sync) for desired chase effect.

  • Page 15: Programming Mode

    2. Operation Guide 2.1.7 Memory 2. Tap Up button to change between MP, MS and MP--: Uninterrupted chase of any of 7 programs MS--: Sequential chase of all 7 programs subject to audio beat MA--: Uninterruptedly sequential chase of all 7 programs 3.
  • Page 16 2. Operation Guide 2.2 Programming Mode 2. Adjust channel faders and Master slider to desired position. 3. Tap Prog. Select button, you can store the current setting this program and the step will be increased by one. Prog. Select 4. Continue steps 2-3 until you have finished your programming of up to 16 steps.

  • Page 17: Midi Mode

    2. Operation Guide 2.3 MIDI Mode 2.3.1 MIDI Channel Setting 1. Pressing Fade Time button three seconds activates MIDI channel setting, the LED display shows "MI" followed by two numbers. Fade Time 2. Use Up/Down buttons to select desired MIDI channel from 01-16. Be sure your MIDI channel matches with that of MIDI sequencer.

  • Page 18: Midi Implementation

    2. Operation Guide 2.3.2 MIDI Implementation When MIDI LED flashes, this unit will receives Note Number according to the following table: Note Number Function 22-25 Flash buttons(1-4) 26-29 Faders(1-4) Mode button Up button Down button Fade time button Full on button Stand-by button 2.4 Fade Time 1.

  • Page 19: Full On

    2. Operation Guide 2.4 Fade Time Speed 2. Fade time can be controlled by Speed slider. When Speed slider is at the top position, fade time is 0, when Speed slider is at the bottom position, fade time is 10 seconds. 2.5 Full On 1.

  • Page 20: Stand-By

    2. Operation Guide 2.6 Stand-by 1. Tap Stand-by button causing its LED to flash, which indicates stand-by is active. Stand-by allows you to interrupt the overall output instantly, and has higher priority than Full on or Flash buttons. Stand-by 2. Tap Stand-by button again causing its LED to go out, which means stand-by is discontinued.

  • Page 21: Technical Specifications

    Technical Specifications Power Input ..........AC 220-240V~50-60Hz Channel Output ........5A per channel, total 16A Channel Fuse ..........F6.3A 250V 5x20mm Internal Fuse ..........F0.5A 250V 5x20mm DMX Output ..........3-pin female XLR socket MIDI In/Thrul ........... 5 pin DIN socket x2PCS Audio Input ........
  • Page 24 All Rights Reserved Printed in PR China Rev 1.0 March 2005 24-004-1655...
