- Page 1 EPSBAE20 2.0 Outdoor Sound Bar USER MANUAL FOR SUPPORT, VISIT ELEMENTELECTRONICS.COM/SUPPORT...
-
Page 2: What's Included
WHAT’S INCLUDED Your new sound bar! Remote control Power adapter HDMI cable 3.5 to RCA 2 Iron pendants 2 mounting screws 2 short screws and 2 expansion tubes USER MANUAL... -
Page 3: For Your Attention
FOR YOUR ATTENTION • Please read through this manual before making connections and operating your new sound bar. Retain this manual for future reference. • Do not open the cabinet of this unit; there are no user-serviceable parts inside. Refer servicing to qualified personnel only. •... - Page 4 MOUNTING YOUR SOUND BAR IMPORTANT: Choose a location for your sound bar where it will not be in direct sunlight and is partially shaded (i.e. near trees, under structures, patio cover, etc.). Re- member that the position of the sun changes throughout the day, so choose a location and position based on the time of day you would use it most often.
- Page 5 MOUNTING YOUR SOUND BAR (continued) The center distance is 29.56 inches. Mark the location of the screws on the wall. Drill two holes in the wall with a powerful drill. Fasten the screw expansion tube to the hole in the wall. Fasten the iron bracket to the expansion tube of the wall with screws.
- Page 6 SOUND BAR PANELS Function Volume ON/OFF Switching Indicator light INDICATOR LIGHT DISPLAY: Red light: Standby mode Blue light: BT mode Green light: ARC mode White light: AUX mode USER MANUAL...
- Page 7 SOUND BAR PANELS (continued) Back ARC input port: Connect to a TV with HDMI ARC function. AUX input port: Connect the AUX one-to-two audio cable, connect Power interface AUX input port ARC input port with the red/white output port of the audio source device. Power interface: Connect the power adapter.
-
Page 8: Connect To Your Tv
CONNECT TO YOUR TV There are 2 ways to connect your sound bar to the TV: AUX Good Quality (cable not included) ARC input port: Best Quality (cable included) ARC (AUDIO RETURN CHANNEL) If you choose the ARC connection, please make sure your TV or device supports the HDMI ARC feature. - Page 9 CONNECTIONS This sound bar has an extra group of audio input terminals. Connect your sound bar to your TV or other external devices such as a CD, VCR, DVD player, etc. by connecting an AUX input cable (cable not included) to your sound bar and the AUX output of your external device.
-
Page 10: Remote Control Operation
REMOTE CONTROL Remote control operation Insert the batteries into the remote control. Point the remote control at the remote sensor on the front panel. The remote control works within a distance of about 8 meters from the sensor and within an angle of about 30 degrees from the left and right side. - Page 11 REMOTE CONTROL POWER (continued) POWER MUTE Remote control or host button to switch the signal source to BT state, the blue indicator will flash, the phone will turn on the Blue- tooth, search for the device, and the connec- tion and pairing are successful. MUTE SOUND EFFECTS SOUND EFFECTS...
-
Page 12: Troubleshooting
TROUBLESHOOTING Use the chart below to troubleshoot any issues you may be having. If you do not see your issue listed below, or the troubleshooting guide does not solve your issue, please contact Element customer support. SYMPTOM CAUSE REMEDY No Power •... - Page 13 SOUND BAR SPECIFICATIONS WORKING ENVIRONMENT SOUND BAR POWER SUPPLY AC ~100-240V, 50/60Hz RELATIVE TEMPERATURE HUMIDITY -4°F - 104°F 5% ~ 90% FREQUENCY RESPONSE 60Hz~20kHz MAX POWER OUTPUT 25W X 2 FOR SUPPORT, VISIT ELEMENTELECTRONICS.COM/SUPPORT...
- Page 14 REFERENCES Element TV Company, LP. bears no responsibility for data and/or information that is compromised during a wireless transmission. Frequency band • This system uses the 2.4 GHz frequency band. Certification • This system conforms to the frequency restrictions and has received certification based on frequency laws.
- Page 15 LICENSE FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2.
-
Page 16: Warranty
Element. and notifications. product registration.* *1-year manufacturer’s limited warranty with purchase, or 2-year limited warranty with product registration within 90 days of purchase. See warranty card for details. USER MANUAL... -
Page 17: We're Here To Help
We’re available 24 hours a day, 7 days a week elementelectronics.com 1.888.842.3577 customerservice@elementelectronics.com Element offers environmentally responsible options to recycle your unwanted consumer electronics device. More information can be found by visiting: www.elementelectronics.com/sustainability FOR SUPPORT, VISIT ELEMENTELECTRONICS.COM/SUPPORT... - Page 18 ® Element, the Element Logo, and Bring it home are trademarks of Element Brand Holding, LLC. All other trademarks are the property of the respective owner who has not sponsored, endorsed, or approved this product. ©2024, Element Brand Holding, LLC, All Rights Reserved.
