Description
The NEVE PRO RF is a wireless digital on/off chronothermostat composed of two units, a receiver
powered by 220V current and a transmitter (chronothermostat) powered by batteries or via a mi-
croUSB cable. With a clean contact in exchange normally open or closed, it is therefore possible to
manage and program the interventions of boilers, zone valves, heat pumps, air conditioners or
other types of compatible systems, in order to guarantee the most comfortable temperature inside
an environment and optimize energy consumption. Both the receiver and the transmitter are desi-
gned to be mounted on the wall or on the cover of a 503 box, communicating with each other re-
motely via radio frequencies. The wireless system allows, for example, to transport the mobile unit
to the environment where the temperature detection is most consistent with that of the rest of the
house. Through the "PrOG OFF" mode, the NEVE PRO RF can also be used as a simple on/off
room thermostat, therefore without the need to set a program. Although simple to connect, it is al-
ways recommended to have the device installed by a qualified technician.
NOTE: Read the user manual carefully before installation. Strictly follow the instructions
and precautions described regarding the installation and use of the product.
4
Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma - info@plikc.com - www.plikc.com
Technical specifications of the transmitter (chronothermostat)
• Three modes for weekly program settings:
• 5+2 - Two groups of days with a single program (MON-FRI and SAT-SUN).
• 7 days - A single group of days with a unique program (MON-SUN).
• 24 Hours - Ability to program each day of the week separately.
• Selectable thermostat/programming modes.
• Temperature measurement range: 0°C ~ 40°C.
• Set temperature range: 5°C ~ 35°C with 0.1°C increments.
• Temperature measurement accuracy: ± 1°C (at 20°C).
• Power supply: 2x AA alkaline batteries (1.5V).
• Switchable current: 6A (inductive load 2A), 230Vac.
• Nominal load: 6 (2)A, 230Vac.
• Low battery indicator: Flashing.
• Standby current: 40uA, illumination current ≤ 10 mA.
• Buttons: touch (soft touch);
