Installation Manual
AIR-TO-WATER HEATPUMP OUTDOOR UNIT
WH-WXG09ME8, WH-WXG12ME8, WH-WXG16ME8
CAUTION
R290
REFRIGERANT
This AIR-TO-WATER HEATPUMP contains
and operates with refrigerant R290.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY
QUALIFIED PERSONNEL.
Refer to National, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before the
installation, maintenance and/or service of this product.
SAFETY PRECAUTIONS
•
Read the following "SAFETY PRECAUTIONS" carefully before installation.
•
Electrical works and water installation works must be done by licensed electrician and licensed water system installer respectively. Be sure to use the correct
rating and main circuit for the model to be installed.
•
The caution items stated here must be followed because these important contents are related to safety. The meaning of each indication used is as below.
Incorrect installation due to ignorance or negligence of the instructions will cause harm or damage, and the seriousness is classifi ed by the following indications.
•
Please keep the operation and installation manuals with the unit after installation.
WARNING
CAUTION
The items to be followed are classifi ed by the symbols:
•
Carry out test run to confi rm that no abnormality occurs after the installation.
Then, explain to user the operation, care and maintenance as stated in instructions.
•
This appliance is not designed to be accessible to the general public.
•
If there is any doubt about the installation procedure or operation, always contact the authorized dealer for advice and information.
Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
Any unfi t method or using incompatible material may cause product damage, burst and serious injury.
Do not install outdoor unit near balcony railings. If the outdoor unit is installed on the balcony of a high-rise building, small children may climb onto the outdoor
unit and climb over the railing, which may lead to an accident.
Do not use unspecifi ed cable or joint cable for power supply cable.
Do not share the single outlet with other electrical appliances. Poor contact, poor insulation or over current will cause electrical shock or fi re.
Do not tie up the power supply cable into a bundle by band. Abnormal temperature rise on power supply cable may happen.
WEB-ACXF60-55040-EN
This indication shows the possibility of causing death or serious injury.
This indication shows the possibility of causing injury or damage to properties only.
Symbols with white background indicate prohibited items.
Symbols with dark background must be executed.
Required tools for Installation Works
1
Phillips screw driver
2
Level gauge
3
Electric drill,
hole core drill
4
Hexagonal wrench
(4 mm)
5
Spanner
6
Pipe cutter
7
Reamer
8
Knife
9
Gas leak detector
10
Measuring tape
Explanation of symbols displayed on the indoor unit or outdoor unit.
WARNING
CAUTION
CAUTION
CAUTION
WARNING
ENGLISH
11
Thermometer
12
Megameter
13
Multimeter
14
Torque wrench
15
Hand gloves
for refrigerant circuit repair
16
Vacuum pump
17
Gauge manifold
18
Recovery machine
19
Recovery cylinder
This symbol shows that this equipment uses a
fl ammable refrigerant with safety A3 group per
ISO 817. If the refrigerant is leaked, together
with an external ignition source, there is a
possibility of fi re / explosion.
This symbol shows that the Installation Manual
should be read carefully.
This symbol shows that a service personnel
should be handling this equipment with
reference to the Installation Manual.
This symbol shows that there is information
included in the Operation Manual and/or
Installation Manual.
1
