Panasonic WH-SDC0316M9E8 Service Manual

Panasonic WH-SDC0316M9E8 Service Manual

Air-to-water hydromodule
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the products dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be
replaced with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission
of manufacturer.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL
Refer to National, State, Territory and local legislation, regulations, codes, installation & operation manuals,
WH-SDC0316M9E8
IMPORTANT SAFETY NOTICE
PRECAUTION OF LOW TEMPERATURE
REFRIGERANT
This AIR-TO-WATER HEATPUMP contains and operates with refrigerant R290.
before the installation, maintenance and/or service of this product.
Air-to-Water Hydromodule
Indoor Unit
WARNING
CAUTION
R290
Order No: PCZ2411004CE
Outdoor Unit
WH-WXG09ME8
WH-WXG12ME8
WH-WXG16ME8
Destination
Europe
in the Schematic
