- Page 1 INSTALLATION GUIDE AND USER MANUAL L3 SERIES LIMITLESS LITHIUM™ L3 HV-40kWh L3 HV-60kWh Copyright © 2024 Sol-Ark LLC | SK140-0017-002...
- Page 2 By using the product, users acknowledge their understanding of these disclaimers and agree to use the product at their own risk. Sol-Ark reserves the right to update or modify product information, specifications, and guidelines without prior notice.
-
Page 3: Table Of Contents
2.4 Seismic Installation Guidelines ........................................... 15 2.5 Battery Overview ..............................................16 2.5 Wiring ..................................................17 2.6 Battery Communications ............................................. 19 2.7 Powering-up the Sol-Ark L3 System ........................................20 2.8 Power Cycle Sequence ............................................20 3. User Interface ..............................21 3.1 HMI Screens ................................................21 3.2 System Setup ................................................ -
Page 4: Important Instructions
WARNING: Risk of electric shock. Risk of fire. Only use electrical supplying this equipment before working on or inside equipment. system components approved for dry locations. Always use a properly rated voltage sensing device to confirm Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... -
Page 5: Product Recycling
Due to the considerable size, the L3 HV series battery storage system requires special handling to be recycled properly. For more information on locating recycling resources in your area, please visit our website at sol-ark.com/recycling. Proper recycling is crucial for lithium storage batteries. It keeps hazardous waste out of landfills and allows reusable materials like lithium and other metals to be recovered and repurposed. -
Page 6: L3 Series: First Glance
1. L3 Series: First Glance INSPECT SHIPMENT The box should include all items shown in the component guide. If there are damaged or missing parts, immediately call Sol-Ark customers support at +1 (972) 575-8875 Ext. 2. COMPONENT GUIDE The L3 battery energy storage system includes the following components:... -
Page 7: General Description
BMS Communication Ports HMI Touchscreen External 12V Power Supply Input BMS Start Button 200A Dual Pole, BMS DC Disconnect Switch High Voltage Indicator Battery Module (+, -) Connections Alarm Indicator Module-to-Module Internal Communications Ports Copyright © 2024 Sol-Ark LLC | SK140-0017-002... -
Page 8: Specifications
L3 HV-60kWh model 500.0mm 19.7in 600.0mm 23.6in 530.0mm 20.9in ISOMETRIC VIEW REFERENCE ONLY 654.8mm 25.8in 2115.0mm 83.3in 2080.0mm 81.9in 2000.0mm 78.7in 12X 146.1mm 5.8in 4X 106.7mm 4.2in 600.0mm 23.6in 530.0mm 20.9in 450.0mm 17.7in Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... - Page 9 Do not use impact drivers to tighten any fasteners on the inverter Connection Torque [in-lb] Torque [Nm] BMU/Rack Grounding Screw 40 in-lb 4.5 Nm BMU Mounting Screws 10.6 in-lb 1.2 Nm Battery Module Mounting Screws 10.6 in-lb 1.2 Nm Copyright © 2024 Sol-Ark LLC | SK140-0017-002...
- Page 10 2. Output current is affected by battery temperature and SOC. 3. Temperature is based on the average cell temperature as measured by the BMS. Charging is disabled below 0°C (32ºF). Derating occurs above 45°C (113ºF). See Sol-Ark technical sales for outdoor sites.
-
Page 11: Installation
L3 HV Battery Module Positive Link - Amphenol Battery Cable Series Link - Amphenol Battery Cable Negative Link - Amphenol Battery Cable RJ45 Module-to-Module Communication Cables (140mm) RJ45 BMS-to-Module Communication Cable (110mm) Battery Rack Screws (M4x20) Copyright © 2024 Sol-Ark LLC | SK140-0017-002... -
Page 12: Assembly
Use 8x additional screws (P) to fully secure the right rack to the rest and bottom crossbeams, ensuring correct orientation. Align each of the assembly. Tighten all screws before moving to the next step hole and secure in place with 8x screws (P). Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... - Page 13 Carefully slide the BMS (I) into the top slot of the rack and secure in place seismic area fasten the 3x angle brackets (H) using the 3x using 4x screws (P). included screws (P) and attach to the wall surface using a suitable fastener for the material. Copyright © 2024 Sol-Ark LLC | SK140-0017-002...
- Page 14 2.5. WARNING: HEAVY OBJECTS Damage can occur to the building due to static overload of the floor. Consult with a licensed professional structural engineer when installing batteries above ground level. Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©...
-
Page 15: Equipment Clearance Guidelines
Specific installation methods will depend on the requirements of your local AHJ, but the following general guidelines apply: × Do not fasten the battery directly to drywall or using expanding anchors. The Sol-Ark supplied mounting brackets must be secured to wall studs or other structural building elements. -
Page 16: Battery Overview
BCOM IN BCOM OUT Name Description Negative (-) Amphenol battery module connector. Positive (-) Amphenol battery module connector. BCOM IN Communication port for previous battery module BCOM OUT Communication port to next battery module Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... -
Page 17: Wiring
To interconnect an inverter, use the included Amphenol connectors. Run the wires from the positive and negative Amphenol connector (P+) and (P-) to the inverter’s battery input terminals, as shown in Fig 3. Copyright © 2024 Sol-Ark LLC | SK140-0017-002... -
Page 18: Communications Wiring
Connect all remaining 110mm (4.3in) communication cables for the rest of the battery modules. BCOM IN BCOM OUT BCOM IN BCOM OUT Figure 5: Terminating Resistor NOTICE: The BCOM OUT port of the last battery module should be terminated with the included 120Ω terminating resistor plug. Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... -
Page 19: Battery Communications
BCOM Battery Module BCOM BCOM IN BCOM OUT BMU_CANL BMU_CANL BMU_CANL BMU_CANH BMU_CANH BMU_CANH BMU (BACK) HVBOUT HVB IN HV OUT HV IN BMS_CANL BMS_CANL 485B- BMS_CANH BMS_CANH 485A+ PCANH PCANL 485A+ 485B- Copyright © 2024 Sol-Ark LLC | SK140-0017-002... -
Page 20: Powering-Up The Sol-Ark L3 System
BCOM BCOM C. PRESS the START button of the BMU to the ON position. The Sol-Ark boot-up screen will appear. The high voltage “HV” indicator will light up. Wait a few seconds, then tap the screen once to access the home screen. -
Page 21: User Interface
2. Login Screen Delete Escape Keypad Enter 3. System Maintenance Screen Battery diagnostics Overcurrent Overvoltage Undervoltage Different Voltage Overtemperature Different Temperature Other Faults Under temperature Exit BMU Number Protocol ID Copyright © 2024 Sol-Ark LLC | SK140-0017-002... -
Page 22: System Setup
The "BMU Number," located at the bottom-left of the screen, serves to identify the quantity of battery modules within the L3 system. This number is automatically displayed when there is proper communication between the battery modules and the BMU. The "Protocol ID" defines the CANBus communication protocol utilized by the L3 system. ID 0 should be selected for Sol-Ark Inverters You can tap on each Fault icon positioned on the right and left sides of the screen to access additional information about faults, including detailed descriptions and common causes. -
Page 23: Operation And Maintenance
The L3 HV series features an integrated aerosol-based fire suppression system at the battery module level. In the rare event of a thermal runaway, the aerosol canister would rapidly deploy, filling the battery module interior with non-toxic agent to suppress any potential fire before spreading. This unique, industry-leading safety capability from Sol-Ark ensures maximum protection for commercial and industrial users. -
Page 24: Hmi Firmware Update Process
In the root directory of the USB drive create new folder called “upgrade”, all lowercase. Place the .bin file provided by Sol-Ark in the “upgrade” folder on the USB drive. Turn on the battery following the procedure outlined in Section 2.7. -
Page 25: Long Term Battery Storage
Power on and cycle the battery at least once every 6 months to maintain the SOC within 30-50%. • Minimize BMU self-discharge by disconnecting the negative Amphenol battery connector (B-) during this period. This interrupts the power supply to the BMU, preventing battery discharge. Copyright © 2024 Sol-Ark LLC | SK140-0017-002... -
Page 26: Wiring Diagrams
Installers should exercise caution, seek professional advice when necessary, and adhere to established electrical standards and regulations during all installations. HVBOUT HVBIN HVBOUT HVBIN HVBOUT HVBIN Figure 7: Multi-Stack Battery Wiring Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... - Page 27 HVBOUT HVBIN HVBOUT HVBIN Figure 8: Two Battery System Connections Copyright © 2024 Sol-Ark LLC | SK140-0017-002...
-
Page 28: Error Codes
Cell voltage acquisition fault Inter-battery communication failure Pre-charge failure Insulation level 2 alarm External total voltage acquisition fault Internal total voltage acquisition fault Current acquisition fault Limit protection EEPROM failure Insulation level 2 Copyright 2024 Sol-Ark LLC | SK140-0017-002 ©... -
Page 29: Common Causes
The minimum cell voltage is lower than the set value BMU lost BMU message not received for a long time Abnormal number of BMU The number of BMU addresses is different from the number of set parameters Copyright © 2024 Sol-Ark LLC | SK140-0017-002...
