ATESS EVD-40DU
DC EV charging station
User Manual
Advertisement
Table of Contents
Related Manuals for ATESS EVD-40DU
Summary of Contents for ATESS EVD-40DU
- Page 1 ATESS EVD-40DU SHENZHEN ATESS POWER TECHNOLOGY CO.,LTD DC EV charging station GROWATT-ATESS Industrial Park, No.23 Zhulongtian Road, Shuitian Community, User Manual Shiyan Street, Baoan District, Shenzhen Tel: +86 755 2998 8492 www.atesspower.com Web: Email: info@atesspower.com Revised date: 2024-08-01...
-
Page 2: Copyright Notice
Thank you for choosing ATESS This user manual is copyrighted by Shenzhen ATESS Power Technology Co., Ltd. ATESS EVD series intelligent DC EV Charging station is a device that provides high- (hereinafter referred to as “ATESS Power Technology”). No unit or individual may... - Page 3 Contents Specification Product description Packaging list Appendix 7.1 Electric diagram 7.2 Warranty 7.3 Contact Installation and wiring 3.1 lnstallation on the wall 3.2 Installation on a pole 3.3 Wiring Parameter configuration 4.1 System Parameters 4.2 Network parameters 4.3 Protection parameters Operation instruction and LCD introduction 5.1 Charging mode and operation...
-
Page 4: Product Description
Product Description Internal view and terminal definition 1. SPD 2. AC input terminal block. Terminal definition is (L1/L2/L3) 1. HMI. 3. PE terminal 2. Charging connector holder. 3. RFID reader. 4. LED indicators. 5. WIFI/4G antenna. 6. Emergency Stop button. 7. -
Page 5: Packaging List
Packaging List Installation and Wiring Items Remark 3.1 lnstallation on the wall DC EV Charging station 3.1.1 Firstly, according to the specific installation height requirement of the user, determine the installation height of the charging equipment and the installation height of the cable User manual holder. -
Page 6: Installation On A Pole
3.2 Installation on a pole 3.1.3 After the mounting bracket and cable holder is fixed, place the charging equipment onto the mounting bracket, with the outward bent part inserted to the slot on the rear side 3.2.1 Open the packaging of the pole, take out the pole and mounting accessories. of the charging equipment. - Page 7 3.2.3 Fix the pole onto the holes with expansion bolts. The input cables shall go into 3.2.5 Position the charger onto the bracket and secure it on the bracket with the 2 screws. the pole from the bottom middle area and come out of it from the area below the cable holder.
- Page 8 3.3 Wiring Note: 1.Only professional personnel can do the wiring, connect the AC input wires in correct Now prepare for wiring. Use 3 power cables and 1 PE cable, it is suggested to use a phase order according to the markings on the terminal block. 4-core cable(with PE included) for the convenience of using the water-proof cable gland.
-
Page 9: Parameter Configuration
Parameter configuration 4.1 System Parameters After installed and connected, the charging equipment must first be configured according to the actual needs of the user. The parametersare configured through the LCD touch screen. Save the change and exit then the charging equipment can be used normally. -
Page 10: Network Parameters
Function description Function description Parameters Parameters DC meter’s modbus address(already preset in Server address setting, used to set domain or IP Server URL1 Meter address address of back-office server. factory, it is not allowed to modify) Language setting. Currently support Thai-English Address of backup server. -
Page 11: Protection Parameters
Operation instruction and 4.3 Protection parameters LCD introduction The protection-related parameters, such as voltage, current, temperature, power, etc. 5.1 Charging mode and operation APP/RFID mode: Initiate or cease charging by scanning QR code using APP or by swiping RFID card. You can also use APP for reservation and payment provided that the back-office server supports such function. -
Page 12: Lcd Interface Introduction
Plug&Charge: Charging will start automatically after EV plugged in. If you want to stop the Management page, user can set charging, just press the stop icon on the screen. different kinds of parameters here. P a s s w o r d a u t h e n t i c a t i o n i s required when entering each parameter setting page. - Page 13 5.3 Appendix: Fault code Fault description Protection parameters page of DC output, used to set limit value of Emergency stop is pressed! v o l t a g e , c u r r e n t , p o w e r , temperature, etc.
-
Page 14: Specification
Specification Ingress protection NEMA 3R Operating temperature -13℉~122℉, derate since 122℉ Model EVD-40DU Relative humidity 5%~95％ Dimension(mm) 632*858*300(W*H*D) ≤2000m, derate for higher than 2000m Altitude Weight(kg) 90kg Cooling method Forced air cooling Display Remote monitoring Ethernet/WIFI/4G/485/232 Casing material Stainless steel&acrylic sheet Payment APP/RFID/Plug&Charge... -
Page 15: Electric Diagram
For warranty cases during the warranty period, the customer should present the invoice of the purchase of the product to the service personnel of ATESS. At the 208V/240V/480V/AC input same time, the nameplate on the product should be clearly visible, otherwise the warranty claim might not be accepted. - Page 16 7.3 Contact Company Name: Shenzhen ATESS Power Technology Co.,Ltd Address: GROWATT-ATESS Industrial Park,No.23 Zhulongtian Road,Shuitian Community,Shiyan Street,Baoan District,Shenzhen Website: www.atesspower.com Service line:+8675529988492 E-mail:info@atesspower.com...
