- Page 1 Lighting made better. User Manual LED Wall Pack SKU: WP_DD_60SW-BR-3050K WP_DD_120SW-BR-3050K WP_DD_45W-BR WP_DD_80W-BR WP_DD-BR WP_BR-3050K support@sunco.com (844) 334-9938...
- Page 2 What’s in the Box? LED Wall Pack Get Your Gear Light Fixture Drill Wire Strippers Ladder Leveler Screwdriver...
- Page 3 Before You Start Safety Information To reduce the risk of fire, electric shock, or physical injury: • Turn off the switch and circuit breaker before installing this • To ensure efficient light, regularly clean the light panel. Do LED light fixture. not clean with harsh solvents.
- Page 4 Installation Guide STEP 1 a. Turn off the circuit breaker for the location where the wall pack will be installed. Make sure the area is well-lit by sunlight if the dusk to dawn sensor is going to be used. b. Install a compatible junction box (optional, not included). STEP 2 a.
- Page 5 Installation Guide (Cont.) STEP 4 Non Junction box a. Before mounting the wall pack, unscrew a cable port. There is one above the junction box and one on either side. Junction box STEP 5 a. Thread light wires through cable ports, then connect light wires with supply wires;...
- Page 6 Installation Guide (Cont.) STEP 6 Junction Box: Secure the wall pack to the junction box. Non Junction Box: Secure the wall pack to the wall. We recommend using a conduit for wall packs to protect the cables with a water-resistant seal. STEP 7 a.
-
Page 7: Product Details
Product Details Recommended Dimmers Brand Model LUTRON NTSTV-DV-WH LUTRON NFTV-IV LUTRON DVTV-WH LEVITON IP710-LFZ LEVITON DS710-10Z LEGRAND RH4FBL3PW WP_DD_60SW-BR-3050K Specifications Voltage Average Lifetime 120V-277V 50000 Hours Moisture Rating 3000K/4000K/ 5000K Wet Rated Lumens 4600 lm / 6800 lm / 8600 lm Beam Angle 85°... - Page 8 Product Details WP_DD_45W-BR Specifications Voltage Average Lifetime 120V-277V 50000 Hours Moisture Rating 4000K, 5000K Wet Rated Lumens 7,000 lm Beam Angle 85° Usage Outdoor Housing Material Die Cast Aluminium IP Rating IP65 Dimmable 0-10V Warranty 7 Years WP_DD_80W-BR Specifications Voltage 120V-277V Average Lifetime 50000 Hours...
- Page 9 Product Details WP_DD-BR Specifications Voltage 120V-277V Average Lifetime 50000 Hours 4000K, 5000K Moisture Rating Wet Rated Lumens 16,200 lm Beam Angle Usage 100° Outdoor Housing Material IP Rating Die Cast Aluminum IP65 Dimmable Warranty 0-10V 7 Years WP_BR-3050K Specifications Voltage Average Lifetime 120V-277V 50000 Hours...
-
Page 10: Common Troubleshooting
Common Troubleshooting Feeling in the dark about an issue with your product? No If you still need some assistance, please feel free to worries! Our troubleshooting section is here to shed some light contact us with any questions. Our team of lighting experts and provide you with easy-to-follow solutions for any problem. - Page 11 Light Distribution Angle I I N N T T E E N N S S I I T T Y Y D D I I S S T T R R I I B B U U T T I I O O N N D D I I A A G G R R A A M M I I N N C C P P L L A A N N S S -/+180...
- Page 12 Lighting made better. support@sunco.com (844) 334-9938 REV1.0...
